This is a Python library and set of tools that lets you build Docker images using masterless SaltStack instead of (or in addition to) using Dockerfiles. FlyingCloud is easy to run from the commandline, and built to be run on a Continuous Integration server.

1. Copyright © MetaBrite, Inc. 2016
FlyingCloud
Building Docker Containers
with SaltStack
Adam Feuer and George V. Reilly

2. Copyright © MetaBrite, Inc. 2016
The Story of Lectern
• Lectern Web Service
• Receives uploaded images of receipts from CookBrite mobile app
• OCRs images using Tesseract + OpenCV
• Extracts data about purchases
• Deployed on AWS ElasticBeanstalk
• Could not get app to build on Amazon Linux

3. Copyright © MetaBrite, Inc. 2016
Lectern v1
• ElasticBeanstalk also supports Docker
• We built a Docker app on top of an Ubuntu image
• Solved the build problem. Sort of.
• Our build was a twisted, unmaintainable, monolithic mess of
shell scripts.
• Took an hour to build. Any failure reset the clock.

4. Copyright © MetaBrite, Inc. 2016
Lectern's old Docker image setup scripts

5. Copyright © MetaBrite, Inc. 2016
Lectern v2: with FlyingCloud

6. Copyright © MetaBrite, Inc. 2016
One Big Idea
• Use Configuration Management to build Docker images
• Configure rather than write code
• More understandable
• Reusable and repeatable

7. Copyright © MetaBrite, Inc. 2016
What is Docker?
• Lightweight Virtualization
• Run multiple containers on one host system
• Isolated process group for each container
• Shared kernel
• Run a different Linux OS in each container
• Image = filesystem snapshot
• Container = running image

8. Copyright © MetaBrite, Inc. 2016
What is SaltStack?
• Configuration management system
• "Automated system administration"
• Configuration, not scripts
• Declarative, not imperative
• Salt is implemented in Python
• Though you usually write Salt States in YAML
• We use Salt Masterless mode
• Configure system at build time; no runtime dependency on Salt

9. Copyright © MetaBrite, Inc. 2016
Two Ways to Build Docker Images
• Traditional
• Dockerfile: static list of commands
• Run commands inside container, then commit
• FlyingCloud
• Use SaltStack to update state of Docker image
• Easy to make layers
• Easy to run in Continuous Integration

10. Copyright © MetaBrite, Inc. 2016
Example App - layers overview

11. Copyright © MetaBrite, Inc. 2016
Example App - project and base layers

12. Copyright © MetaBrite, Inc. 2016
Example App - app layer

13. Copyright © MetaBrite, Inc. 2016
Example App - testrunner layer

14. Copyright © MetaBrite, Inc. 2016
FlyingCloud Demo
See https://github.com/cookbrite/flyingcloud/tree/master/examples/flask-web-app

15. FlyingCloud
● Use Configuration Management to build
layered Docker images
● An FC Layer can be made from any of these:
○ A Dockerfile, Salt states, or custom Python code
○ Do not confuse with Docker’s layer filesystem
● Layers are buildable and/or runnable
● Can be pushed to or pulled from a Docker repository

16. Copyright © MetaBrite, Inc. 2016
Kubernetes
• Google’s open source platform that automates
deployment, scaling, and operations of application
containers built on Docker images across clusters of hosts
• Our Kubernetes workflow for new services:
• Build Docker images with FlyingCloud
• Configure Kubernetes cluster
• Test cluster in Continuous Integration
• Deploy cluster to AWS

17. Copyright © MetaBrite, Inc. 2016
FlyingCloud is Open Source
• Source: https://github.com/cookbrite/flyingcloud
• Docs: http://flyingcloud.readthedocs.org
• PyPI: https://pypi.python.org/pypi/flyingcloud/
• Mail: https://groups.google.com/group/flyingcloud-users
• Apache License
Contributors welcome! Especially:
• SaltStack users
• Ansible users
