Extending Alfresco Digital Workspace with Docusign
1. Where Do I Sign?
Right on the Line!
Extending Alfresco Digital
Workspace with DocuSign
Bindu Wavell – bindu@ziaconsulting.com
Vijay Prince – vprince@ziaconsulting.com
2.
3. Learn. Connect. Collaborate.
Alfresco
Workspace
Extensions
The Alfresco Workspace team pioneered a way to
dynamically configure key user interface elements
such as: navigation sidebar links and groups,
context menus, info drawers, toolbar elements,
viewer actions, and metadata views all through a
single JSON file. Think Aikau but simpler.
4. Learn. Connect. Collaborate.
The Workspace team recently added the ability to
use external Angular libraries to bring in custom
user interface elements.
Libraries can replace, add, or even remove
components. Can also set up routing and rules.
Alfresco
Workspace
Extensions
6. Learn. Connect. Collaborate.
Flow/SPA OAuth
User triggers
action to sign
document
Do we
have valid
DocuSign
token for
user?
Document sent
to DocuSign
and user
redirected to
signature page
User signs or
cancels
signing in
DocuSign
Redirected to
Alfresco Workspace.
If signed, document
is updated in
Alfresco
User
redirected to
DocuSign
sign-in page
Yes
No
Did user
sign in and
grant
access?
Redirected to
Alfresco
Workspace,
action is not
performed
No
Redirected to
Alfresco
Workspace,
action is
retried
Yes
7. Learn. Connect. Collaborate.
Flow/SPA OAuth
User triggers
action to sign
document
Do we
have valid
DocuSign
token for
user?
Document sent
to DocuSign
and user
redirected to
signature page
User signs or
cancels
signing in
DocuSign
Redirected to
Alfresco Workspace.
If signed, document
is updated in
Alfresco
Yes
8.
9. Learn. Connect. Collaborate.
Flow/SPA OAuth
User triggers
action to sign
document
Do we
have valid
DocuSign
token for
user?
Document sent
to DocuSign
and user
redirected to
signature page
User signs or
cancels
signing in
DocuSign
Redirected to
Alfresco Workspace.
If signed, document
is updated in
Alfresco
User
redirected to
DocuSign
sign-in page
Did user
sign in and
grant
access?
Redirected to
Alfresco
Workspace,
action is
retried
Yes
No
13. Learn. Connect. Collaborate.
NGRX
Store/Actions
/Effects
● ngrx - reactive state for Angular
● State is managed in single hierarchy
(store)
● Actions are dispatched to indicate
something happened
● (Side)Effects observe actions and
transform state in response
14. Learn. Connect. Collaborate.
NGRX
Store/Actions
/Effects
● Alfresco Workspace uses ngrx internally
○ Dispatch actions to navigate, display
messages, or open dialogs, etc…
● Extensions can create new actions,
respond to new and existing actions, and
dispatch new and existing actions
● We made an action/effect pair for signing
a document and configured it into the
document list and preview screens
15. Learn. Connect. Collaborate.
Packaging &
Installing
Extensions
● You can npm publish your extension and then
Alfresco Workspace projects can depend on
your extension.
● However, some config will be required
● Denys’ ngi command line tool can perform
most of this configuration for you
● Can install from npm or from a tar file
16. Learn. Connect. Collaborate.
Upgrading
Alfresco
Workspace
● We forked the Alfresco Workspace repository
● We created a development branch from
master
● When cloning our project
● origin points to our fork
● upstream points to original project from
Alfresco
● Feature branches off of our development
● Pull requests back to our development
● We can pull updates into master from
upstream and then rebase development on
the new master
● We never commit to our master
17. Learn. Connect. Collaborate.
Misc.
● Had issues with GETing document content
using Alfresco JS API from browser (worked
fine from node)
● Including third-party JavaScript libraries when
type definitions can’t be found
● Using browserify
BOTH
Vijay Prince – Solution Architect at Zia. Geek night?.
First ADF project.
4-5hrs/week for 2 months.
Great learning experience
BINDU
Story:
At Zia, we have created a couple of digital-signature integrations to Alfresco Share, one of these integrates DocuSign.
Alfresco invited us to participate in the launch of the extension mechanism for Alfresco Workspace (Alfresco Content App.) Right from the beginning Alfresco suggested that another DocuSign integration would make a great story.
We set out to create a basic integration where people could sign their own documents. We have grand plans to allow for other flows and configurability like requesting signatures from others (fixed lists and ad-hoc.)
BINDU
Denys Vuika will be presenting Extensibility for ADF Applications next in this room.
https://devcon.alfresco.com/speaker/denys-vuika/
https://alfresco.github.io/alfresco-content-app/#/extending/
https://angular.io/guide/libraries
Configure via JSON files.. It can dynamically reference components / features/ routes that are in the main application or in a library
BINDU
Denys Vuika will be presenting Extensibility for ADF Applications next in this room.
https://devcon.alfresco.com/speaker/denys-vuika/
https://alfresco.github.io/alfresco-content-app/#/extending/
https://angular.io/guide/libraries
Configure via JSON files.. It can dynamically reference components / features/ routes that are in the main application or in a library
BINDU
Denys Vuika will be presenting Extensibility for ADF Applications next in this room.
https://devcon.alfresco.com/speaker/denys-vuika/
https://alfresco.github.io/alfresco-content-app/#/extending/
https://angular.io/guide/libraries
Configure via JSON files.. It can dynamically reference components / features/ routes that are in the main application or in a library
VIJAY
As Bindu mentioned, there are 2 main workflows. The first workflow will show the signing process with a DocuSign Authenticated session. The second workflow will show the signing process where there is no DocuSign Authenticated session.
https://oauth.net/2/grant-types/implicit/
https://auth0.com/docs/flows/concepts/single-page-login-flow
https://developer.okta.com/blog/2018/05/24/what-is-the-oauth2-implicit-grant-type
VIJAY
We want to sign the document that is shown in the preview screen. Lets look at the process..
What just happened? Let us walk through the steps. We have configured the preview page to show the ‘Sign Document’ action. Since we have an authenticated DocuSign session, we are sending the document to DocuSign for signature as shown in the SnackBar. The document is opened in the embedded signing flow in DocuSign. The user signs the document. DocuSign makes a callback to Alfresco Workspace. Workspace now fetches the signed document from DocuSign and updates in Alfresco.
VIJAY
In this workflow, the user has to Authenticate with DocuSign before they can sign a document. The interesting part of this workflow is that..Workspace remembers the action that the user wanted to do before authentication..In this case, ‘Sign Document’ action is called after authentication. Docusign Auth -> redirect to workspace -> call ‘Sign Document’ action -> Upload the doc to docusign and sign -> Make a callback to Workspace -> Fetch signed doc from docusign -> update in Alfresco
https://oauth.net/2/grant-types/implicit/
https://auth0.com/docs/flows/concepts/single-page-login-flow
https://developer.okta.com/blog/2018/05/24/what-is-the-oauth2-implicit-grant-type
VIJAY
In this workflow, we have configured the Document List view to show the ‘Sign Document’ action. This workflow will show that the user has to Authenticate with DocuSign before they can sign a document. we authenticate in DocuSign and redirects back to workspace. workspace remembers the action that was performed and it uploads the document to DocuSign...then it redirects to the embedded signing flow. DocuSign redirects back to the document list. Workspace fetches the signed document from DocuSign and updates the document in Alfresco. We are going back to preview just to show the signature is there
BINDU
Alfresco uses Hashbased routing by default. Docusign returns hash based routes and we had to use webscripts to handle routing from Docusign
CORS issue - simplest way is to serve the angular app to proxy the services
VIJAY
to integrate with DocuSign, we need a client id (integrator key). each installation will have a different id. we dont want to bake this into the code. We want to use a central configuration file. Workspace uses app.config.json for its extensions.. We just added our custom configuration into this app config file to be used in the code. The screenshot at the left shows us retrieving the clientId from the config file.
BINDU
https://ngrx.io/
NGRX is a framework inspired by Redux. Alfresco uses ngrx for state information. It is used to dispatch actions. The effect gets the action and a piece of the state, performs business logic and then updates the state
BINDU
https://ngrx.io/
Alfresco uses ngrx for state information. It is used to dispatch actions. The effects gets th action and a piece of the state, performs business logic and then updates the state
VIJAY
ngi.json - we want to package our extension so that it is easy to deliver . There are 2 ways to package. 1) publish to npm or 2) create a local tar ball
1) OOTB npm install works but requires us to manually updates a few files. Like add import statements in app.module.ts and updating ‘angular.json’ with references to the assets of the extensions.
2) use ngi tool created by Denys. The ngi command line tool automates a bunch of changes we had to manually do in npm install. All you need is to install ngi tool and create a ngi.json as shown in the screenshot. The tool can take the extension as a local tar ball or from NPM and install to the project..for example, if we had a npm library, we can just say ‘ngi zia-extension’. If we had a tarball, we can use ‘ngi zia-extension-0.0.1.tgz zia-extension’. ngi updates angular.json.
there are links in our slides and you can take a look at it
https://medium.com/@DenysVuika/announcing-ngi-installer-for-angular-libraries-f29c003d4fcd
https://www.npmjs.com/package/@ngstack/install
BINDU
BINDU
File uploading/posting issue should be fixed in new TypeScript based Alfresco JS API.
https://github.com/Alfresco/alfresco-js-api/issues/377
