Expansion Vessel
•Download as PPTX, PDF•
0 likes•442 views
The expansion vessel is a small tank used in closed heating systems to absorb excess pressure caused by thermal expansion as coolant is heated. It contains a rubber diaphragm dividing it into two sections - one connected to the pipe system, the other containing compressed air. As water pressure increases, the diaphragm compresses the air, cushioning pressure shocks that could otherwise damage plumbing. It is made of stainless steel and has an EPDM rubber membrane.
