Error is defined as the numerical difference between a measured value and the absolute or true value of an analytical determination.

1. Shafna Jose
Assistant professor
Department of Chemistry
St. Mary’s College, Thrissur
ERRORS

2. Error is defined as the numerical difference between a
measured value and the absolute or true value of an analytical
determination.
The absolute or true value of a quantity is, however, never
unknown. All that we can use is only an accepted value.
The error in a measured quantity may be represented either as
absolute error or relative error .
Errors

3. Absolute error :The absolute error E, in a measurement is expressed
as
E = xi – xt
where xi is the measured value and xt is the true (accepted) value
for the given measurement.
Relative error : The relative error in a measurement is expressed as
Er = xi - xt
xt
Absolute error and Relative Error

4. Error
Determinate errors or
Systematic errors
Indeterminate errors or
Random errors
• Instrument errors
• Method errors
• Personal errors
Classification of errors

5. Determinate Errors
• Have a definite source
• Determinate error is generally unidirectional with respect to true
value and thus makes the measured value either low or higher
than the true value.
• Reproducible
• Predicted by an expert analyst
• These errors can be either avoided or corrected

6. Determinate errors are of three types : instrument errors, method errors and
personal errors.
Instrument Errors
• These errors arise from imperfections in measuring devices.
• For instance, measuring devices such as pipettes, burettes, measuring
cylinders, measuring flasks etc. contain volumes that are different from
those indicated by their graduations

7. The reasons for these differences are :
1. The use of glassware at a temperature which is significantly
different from the temperature at which the glassware was
calibrated.
2. Distortions in the walls of the container due to heating while
drying the glassware
3. Errors in the original calibration
4. Contamination of the inner surfaces of the containers

8. Instruments powered by electricity are very much prone to
determinate errors because of the following reasons :
• Fall in voltage of battery operated instruments.
• Increased resistance in circuits due to unclean electrical contacts.
• Effect of temperature on resistors and standard cells.
• Currents induced from 220V power lines.
These errors can be easily detected and corrected.

9. Method Errors
These errors arise from the non ideal behavior of reagents and
reactions involved in a given analysis.
The non ideality originates from :
• The slowness of the reactions
• Incompleteness of reactions.
• Instability of reactants
• Non-specificity of reagents .
• Occurrence of side reactions which interfere with the main
process of measurement.
Since theses errors are inherent in the method, they cannot be
easily detected and corrected.

10. Personal Errors
• These errors arise from erratic personal judgement, as also from
prejudice or bias.
• Many experimental measurements such as the estimation of the
position of the pointer between two scale divisions , judgement of
the color of the solution at the end point of a titration, judgement of
the level of a liquid with respect to a graduation on a burette or a
pipette, are sources of personal errors.
• These errors would vary from person to person and can be reduced
to a minimum by experience and careful physical manipulation

11. Determinate errors are further classified into constant errors
and proportional errors
Determinate Errors
Constant Errors Proportional Errors

12. Constant Errors
• The magnitude of a constant error is independent of the size of the
sample or the size of the quantity that is being measured.
• It is also independent of the concentration of the substance being
analyzed.
• For e.g. in volumetric analysis, the excess of the titrant that has to be
added to bring about a change in color at the end point remains the
same whether we titrate 10 ml or 20 ml or 25 ml of the solution.
• Constant errors would become more serious as we decrease the size of
the quantity being measured.
• The effect of a constant error can be reduced to a minimum by
increasing the size of the sample to a maximum within permissible
limits

13. Proportional Errors
• It arises due to the presence of interfering impurities in the
sample.
• The magnitude of such an error depends upon the fraction of the
impurity and is independent of the size of the sample.
Graphical representation of constant and proportional errors

14. Correction of Determinate
Errors
• The determinate instrument errors are detected and corrected by
periodic calibration of the instruments.
• The determinate personal errors can be reduced to a minimum by
care and self-discipline. The most essential requisite of avoiding
personal errors is to fight against bias.
• The determinate method errors are rather difficult to detect. The
following procedures are suggested for the identification and
compensation of method errors.

15. 1. Analysis of standard samples : Method errors can be detected by
carrying out the analysis of a standard sample prepared in such a way
that its composition is exactly the same as that of the material under
test.
2. Independent Analysis : A dependable procedure for detecting
method errors consists in carrying out parallel analysis of the sample
by another independent method of established reliability.
3. Blank determination : Blank determination in which all the steps
involved in the analysis are carried out in the absence of the sample in
exactly the same fashion is quite useful for exposing method errors
which are due to contaminations of the reagents and glass vessels
employed for the analysis.

16. Indeterminate errors
• These errors arise from uncertainties which are inevitably
associated with every physical or chemical measurement.
• These are random or accidental errors whose sources, though
many cannot be positively identified.
• As a result of these errors, the data from replicate
measurements fluctuate randomly around the mean of the set.

17. Fluctuation of data from the mean in replicate measurements
• It is evident from these curves that most frequently the deviation
from the mean is very small.
• It is also clear that there is almost equal probability of positive and
negative errors with the result that overall magnitude of the
indeterminate errors become almost insignificant.

18. References :
Principles of Inorganic Chemistry – B.R Puri, L.R Sharma, K.C Kalia
Inorganic Chemistry – Shriver & Atkins
