Analysing performance
test results with ELK
Anoop Vijayan Maniankara
Tuxera Inc.
@maniankara
22008–2017 © Tuxera Inc. All Rights Reserved.

2. 2008–2017 © Tuxera Inc. All Rights Reserved.

3. 2008–2017 © Tuxera Inc. All Rights Reserved.
Elk (Elastic) stack 5.x
• Elastic search – Logs storing (~NoSQL database)
• Log stash – Log processor
• Kibana – Graphs and charts over JSON
Data shippers
• Filebeat
• Metricbeat
• Packet beat
• …

4. 2008–2017 © Tuxera Inc. All Rights Reserved.
Anoop Vijayan
12+ years experience in designing,
developing, testing Continuous
Integration systems in bigger enterprises
to small companies
DevOps lead at Tuxera Inc.
@maniankara
Github, stackoverflow, etc.

5. 2008–2017 © Tuxera Inc. All Rights Reserved.
Agenda
• All about logs
–Purpose of log handling, tools available
–With elkstack
• Live log monitoring or processing
• Static log/data analysis
–Demo

6. 2008–2017 © Tuxera Inc. All Rights Reserved.
Purpose - Log handling
Time
Activities
Longer Time
• Search – Trace events from past
• Analyze – Tracking trends over time
Event
• Monitor – Detect events
• Compare – Two or more instances

7. 2008–2017 © Tuxera Inc. All Rights Reserved.
Tools in the market
• Free and opensource:
– ELK stack/Elastic stack - More manual configurations
• Commercial (popular ones, not all)
– Splunk – 1GB/day $4.5k (Perpetual)/$1.8k (Annual)
– Loggly – Saas not available in-house $1.18k (1GB/day)/$2.38k (4GB/day)
– …

8. 2008–2017 © Tuxera Inc. All Rights Reserved.
Architecture – ELK stack
Souce: http://blog.arungupta.me/getting-started-elk-stack-wildfly/
L E K

9. 2008–2017 © Tuxera Inc. All Rights Reserved.
ELK stack (Kibana) look and feel
Monitoring system logs Analyzing http request resources

10. 2008–2017 © Tuxera Inc. All Rights Reserved.
ELK stack (Kibana) look and feel contd.
Analyzing event fields Comparing tools

11. 2008–2017 © Tuxera Inc. All Rights Reserved.
Scope
• Live log handling
• Static data comparison

12. 2008–2017 © Tuxera Inc. All Rights Reserved.
Live log parsing (nginx log)
…
192.168.75.130 - - [23/Apr/2017:10:03:34 +0300] "GET /elasticsearch/_site/vendor.js HTTP/1.1" 304 0 "http://sandbox.srv.tuxera.com:3005/elasticsearch/"
"Mozilla/5.0 (Macintosh; Intel Mac OS X 10_12_3) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/57.0.2987.133 Safari/537.36"
…
…
{"@timestamp":"2017-04-
23T07:55:37.886Z","beat":{"hostname":"sandbox.srv.tuxera.com","name":"sandbox.srv.tuxera.com","version":"5.2.2"},"input_type":"log","message":"192.168.75.
130 - - [23/Apr/2017:10:03:34 +0300] "GET /elasticsearch/_site/vendor.js HTTP/1.1" 304 0 "http://sandbox.srv.tuxera.com:3005/elasticsearch/" "Mozilla/5.0
(Macintosh; Intel Mac OS X 10_12_3) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/57.0.2987.133
Safari/537.36"","offset":1595,"source":"/var/log/nginx/access.log","type":"log"}
…
FilebeatLog collection
LogstashLog processing
elasticsearchLog storing
KibanaLog visualization
access.log
ELK stack
…
{”client”:” 192.168.75.130 ”,”time”:”23/Apr/2017:10:03:34 +0300”, ”request”:”GET”,”path”:” /elasticsearch/_site/vendor.js”,”response”:”304”,”host”:”
sandbox.srv.tuxera.com”,”client”:”"Mozilla/5.0 (Macintosh; Intel Mac OS X 10_12_3) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/57.0.2987.133
Safari/537.36"”, ”beat”:{"hostname" : " sandbox.srv.tuxera.com","name" : " sandbox.srv.tuxera.com ","version" : "5.2.2”,
"offset":1595,"source":"/var/log/nginx/access.log","type":"log"}}
…
…
{ "_index" : ”logstash-2017-04-23", "_type" : ”log", "_id" : "AVmDwg6kHxnroGLuXlMG", "_version" : 1, "found": true, "_source" : {”client”:” 192.168.75.130
”,”time”:”23/Apr/2017:10:03:34 +0300”, ”request”:”GET”,”path”:” /elasticsearch/_site/vendor.js”,”response”:”304”,”host”:”
sandbox.srv.tuxera.com”,”client”:”"Mozilla/5.0 (Macintosh; Intel Mac OS X 10_12_3) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/57.0.2987.133
Safari/537.36"”, ”beat”:{"hostname" : " sandbox.srv.tuxera.com","name" : " sandbox.srv.tuxera.com ","version" : "5.2.2”,
"offset":1595,"source":"/var/log/nginx/access.log","type":"log"}}}

13. 2008–2017 © Tuxera Inc. All Rights Reserved.
Static data comparison
FilebeatLog collection
LogstashLog processing
elasticsearchLog storing
KibanaLog visualization
Syslog
ELK stack
…
{”time”:” Apr 23 06:47:01”, ”host”:” sandbox”,
”application”:”CRON”, ”processid”:” 23259”, ”cmd”:”
(test -x /usr/sbin/anacron || ( cd / u0026u0026 run-
parts --report /etc/cron.weekly ))”,
”beat”:{"hostname" : "
sandbox.srv.tuxera.com","name" : "
sandbox.srv.tuxera.com ","version" : "5.2.2"}}
…
…
{ "_index" : ”logstash-2017-04-23", "_type" : ”log", "_id" : "AVmDwg6kHxnroGLuXlMG", "_version" : 1, "found": true, "_source" :
{”time”:” Apr 23 06:47:01”, ”host”:” sandbox”, ”application”:”CRON”, ”processid”:” 23259”, ”cmd”:” (test -x /usr/sbin/anacron || ( cd /
u0026u0026 run-parts --report /etc/cron.weekly ))”, ”beat”:{"hostname" : " sandbox.srv.tuxera.com","name" : "
sandbox.srv.tuxera.com ","version" : "5.2.2"}}}
…
{”time”:” Apr 23 06:47:01”, ”host”:” sandbox”,
”application”:”CRON”, ”processid”:” 23259”, ”cmd”:”
(test -x /usr/sbin/anacron || ( cd / u0026u0026 run-
parts --report /etc/cron.weekly ))”,
”beat”:{"hostname" : "
sandbox.srv.tuxera.com","name" : "
sandbox.srv.tuxera.com ","version" : "5.2.2"}}
…

14. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demos
• Github path: https://github.com/maniankara/elk5.x-perf-testing

15. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo – 1 – Live monitoring of nginx access.log
• Demo1
– Live events
– Filtering based on string
FilebeatLog collection
LogstashLog processing
elasticsearchLog storing
KibanaLog visualization
access.log
ELK stack
• Recap

16. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo1 – live events of nginx access logs

17. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo – 2 – Helsinki air quality stats
• Helsinki metropolitan air quality statistics (from HSY)

18. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo 2 – all pollution dashboard

19. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo2 – NO2 pollution dashboard

20. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo – 3 –Tuxera performance tests
• Terms to know
• Effective read/write
• Cache read/write
–Performance improvement/degradation over time
–commit comparison

21. 2008–2017 © Tuxera Inc. All Rights Reserved.
Demo4 - Alerts
• Elasticsearch aggregations

22. 2008–2017 © Tuxera Inc. All Rights Reserved.
Thank you !
Slides: https://goo.gl/ZZi5EL
Demo: https://goo.gl/4JYBE9
Anoop Vijayan
@maniankara
