This document describes an electro-chemical activation system that uses salt water electrolysis to generate on-demand, non-toxic cleaners and sanitizers for various applications. The system uses dilute saltwater and electricity to produce both an anolyte solution with sanitizing properties and a catholyte solution for cleaning. The document provides details on the technology and its advantages over traditional chemical cleaners and sanitizers, including approvals for food contact surfaces and claims of superior pathogen reduction.

1. .
.
.
Generate Stable GRAS Cleaners And Sanitizers ON
DEMAND Using 0.05% Pure Salt, Pure Water And Clean
120V converted to DC Power – On-Site!
ELECTRO-CHEMICAL ACTIVATION
a div of JDP, Inc.
Thomas Johnson; CEO

2. ECA; Laws of Electrolysis, by
© your company name. All rights
reserved.
Title of your presentation
Michael Faraday; 1834
• Apprentice To Sir Humphrey Davy
• Tesla’s Mentor
• “Father” Of The Electric Motor
• Author Of Magnetic Field Theory
• Author Of Faraday’s Laws Of Electrolysis
• We Use The Most Advanced, State Of The Art
ECA Devices Featuring Modular Laminar Flow
Through Dielectric Membrane Cells
Simultaneously Generating Non-toxic
Cleaners And A Uniquely Powerful, Broad
Spectrum Non-toxic Sanitizer

3. WORLD CLASS AUTOMATED ECA SYSTEMS
Three models; UL-75a “mini”,
UL02, UL04.
Mini Ultra-Lyte produces 176 gpd
of 800-1000 ppm FAC, or 320GPD
of 200ppm FAC anolyte with pH
6.0
Anolyte remains stable for up to
120 days with <50% reduction in
FAC
Catholyte production is 50% of
anolyte production rate, with a
pH 12.0.
PLC network ready, float level
control or manual operation,
program “recipes”, auto deliming
feature
Cell guaranteed (prorated) for
6,000 hours, some have survived
triple that…
DILUTE BRINE ELECTROLYSIS

4. OUR KEY DIFFERENCES
We Do Not Sell Machines – We Coach Our Clients In their use of the latest State Of
The Art Technologies for generating on-site cleaners and sanitizer/disinfectants.
We develop new prerequisite programs With New Policies And Procedures based
our copyrighted protocols, each of which exceeds the Minimum International Or
National codified standards for Safety And Efficacy of cleaning and sanitizing
solutions.
We Are HACCP/Food Safety Technology And Infection disease transmission
prevention and remediation experts
We are Produce Safety experts too. See U.S. Patent 8282974, Oct 9, 2012.
We Work With Any And All Mfgrs Of On-site Devices.
We Select The Ideal Device, Devices And Protocols For Each Of Our Clients Needs.
The most stable ECA solutions with the lowest corrosivity and greatest operational
benefits currently known come from the most advanced form of dilute brine
electrolysis.
Only (2) companies in the world can produce the high character of solutions we
demand. Clarentis Technologies LLC is our spec ECA device.
We build our own ancillary and dosing systems, and provide all training and service

5. NOTHING - IS GREENER…
Table salt
Drinking water
Household power
(120V) HOCl is up to 300X more
effective than bleach, and its
non-toxic!

6. HOCl
Hypochlorus Acid
Hypochlorous acid has a number of uses, most of which take advantage of its strong
oxidizing properties which allow it to be used as a bleach and disinfectant among many
other things. Unlike covalently bonded acids, HOCl is an ionically bonded aqueous
solution and does not “burn” skin, eyes or mucosal membranes.
Hypochlorous acid is the most effective of all the chlorine forms, yet is similar in structure
to water. The germicidal efficiency of HOCl is due to the relative ease with which it can
penetrate cell walls (lyses) . This penetration is comparable to that of water and can be
attributed to both its modest size and to its electrical neutrality.
Anolyte, produced by ECA processes, possesses a physical character that transcends its
analytical chemistry. Tiny gas bubbles have extremely strong ionic activity along their
boundaries.
Most effective biofilm control, destroying mold, fungi and all micro-organisms including
virus. Destroy proteins with time and concentration by disassociating EPS.

7. HOCl PROPERTIES
• Addition of chlorine to water gives both hydrochloric acid (HCl) and
hypochlorous acid (HOCl, which is sometimes annotated as HClO):
• Cl2 + H2O « HClO + HCl
• In organic synthesis, HOCl converts alkenes to chlorohydrins.
• In ECA systems that electrolyze H2O and NaCl, there is no HCl.
• ECA is the mechanization of a biological system; bio-mimicry in its finest form.
In biology,
hypochlorous acid is
generated/activated in
neutrophils by
myeloperoxidase-
mediated peroxidation
of chloride ions
contributing to the
destruction of invading
microorganisms

8. Where physiological saline is 0.9%, we use <0.1% pure NaCl in pure
H2O to generate a neutral pH sanitizer (anolyte) and
simultaneously a high pH amphoteric surfactant (catholyte).
No human or animal can develop has ever deveoped a sensitivity
to anolyte exposures.
AN IMMUNE SYSTEMS MECHANICAL
ANALOG – IS NOW AUTOMATED
Water Electrolysis; Based On The Laws Of Electrolysis; Michael Faraday, 1834
Pathogens have no possible adaptive
resistance to properly prepared ECA
anolytes
ECA is a form of combustion physics;
its cold plasma electro-chemistry

9. UNIQUE DISINFECTION PROPERTIES
A combination of effects; chemical and physical
increasing biocidal affect 100-300 times over bleach!
The solution is in a temporary “meta-stabilized” state of
activation
Physical affects reduced in 96 hours
Clarentis patented design retains chemical character (FAC) for
up to 180 days.
Combustion cold-plasma physics of water and salts
Ions are highly reactive free radicals
Catholyte penetrates dirt and biofilms due to surface tension
alteration and water cluster reduction
Both solution exhibit high density of micro bubbles that
rapidly cavitate emitting intense energy similar to
ultrasonication treatments
The amount of physical damage done to microbes makes
repair or resistance extremely difficult and unlikely
9

10. HOW DOES IT WORK?
The Core Technology Is A Method Of
Transferring constant electrical energy to a moving thin film of water
containing a small amount of salt
Ensuring that the entire film of water is treated evenly
Using special catalytic coatings on titanium electrodes
Using an ion permeable membrane, separating the ion species into TWO
opposing polarized streams; one a cleaner/surfactant with a high pH and
reduced surface tension (catholyte), the other a powerful, broad spectrum
sanitizer/disinfectant (anolyte - HOCl)
Reverts to tiny desiccant mineral crystal (salts) when H2O evaporates –
there no toxic alkaline film residues typical of detergents and/or chemical
sanitizers such as quats, bleach, hydrogen peroxide, iodine & chloramines.
The ONLY additive is the PUREST form of SALT - dissolved in water

11. ECA cell in lower right is formed of a large diameter
tubular titanium anode with a smaller diameter
titanium cathode tube nested inside. The two
tubes are separated by a dielectric membrane that
allows electrons to pass thru, but no molecules.
STATE-OF-THE-ART ELECTRO-CHEMICAL
ACTIVATION SYSTEMS
11
Our Systems Simultaneously
Generate Non-toxic Anolyte
Sanitizers And Catholyte Cleaners
From A Dilute Brine.
Clarentis UL75a “Mini”
© Johnson Diversified Products,
Inc..Food Safety, Risk Management And The Evolution Of Commercial Kitchens
Rental Units Are Automatic,
Mobile “Plug-N-Play” complete
with water softener and every -
thing else needed for self-
contained operation

12. ELECTRO CHEMICALLY ACTIVATED SOLUTIONS
12
Physical and chemical changes occur:
• Molecular cluster sizes decrease
• Kinetic energy equivalent to 80oC water is
stored but water remains cool
•Cold liquid plasma micro bubbles are formed
with strong ionic activity
The effects of this are:
•Better penetration
•Even distribution of redox elements
•Better transport of redox elements
•Constant electron transition of redox
elements
•Bubble implosion like ultrasonication

13. Ice
Emulsion
Fog
Foam
Spray
Cold
plasma
Mist
Liquid
Gel
ECA SOLUTIONS
CAN BE USED IN ANY OF THESE FORMS, MAINTAINING ITS CHARACTERISTIC PROPERTIES

14. ECA SOLUTIONS REPLACE :
Quats, peracetic acid (PAA), hydrogen peroxide formulations such as
the brands Virox, Virkon, Oxiver Five 16 along with sodium
hypochlorite (bleach), sodium hydroxide (caustic soda), Cl, O3, ClO2
and more…
Detergents in dishwashers (automatic remote dosing), window
cleaners and all floor cleaners.
Carpet cleaning solution's and deodorizers (Zerorez - uses Clarentis)
All sanitizers and disinfectants
Floor and surface cleaners, both machine and manual.
Risks to employee’s and the public associated with exposures to toxic
chemical concentrates typically used to clean and disinfect hygiene
sensitive surfaces and spaces.
Chemical oxygen demand (COD) associated with toxic chemical
residues and discharges typical in the janitorial sanitation field.

15. JRS INTEGRATIONS
The ECAS device to the right automatically doses the
dish machine below it.
Johnson Risk Services provides and installs all
necessary components from custom reservoirs to
demand and boosted pumps, dosing systems and all
of the materials and supplies needed to easy
operations and continuous use
Nationwide ECAS Pioneers and Experts in
the U.S. Food industry ECAS
protagonists since 1999.

16. Clarentis UL-75a mini – a fully automatic device with
remote tank level control capability. Above includes
ancillary direct-connect dishwasher interface

17. HENNEPIN COUNTY ADULT CORRECTIONAL
FACILITY, MN
Designer; Terry Pellegrino, Robert Rippe Assoc.
Wall mounted automatic UL-75a
“mini” generates cleaning non-
toxic solutions for the dishwasher,
for general use and approved food
contact surface sanitizers (40 CFR
180.940; FDA 7-204.11; HOCl)
Secondary ancillary system from
JDP automatically doses their
86”Stero conveyor dish machine.
ECA system is “remote” in
another room, 10’ from dish
machine
“Inmates can’t hurt themselves or
others with these products”

18. 18
STATE OF THE ART SUSTAINABILITY
Surly (Destination) Brewery, Minneapolis
Direct Connected to FIVE Dish Machines!!
Designer:
Steve Carlson,
President
Robert Rippe Assoc.
1 conveyor, 1 door
and 3 glass washers
served by (2) mini’s
run in parallel tied to
common reservoirs.
Glass washers are on
level two. Nearest
dish machine is 30’
away; most remote
machine is 110’ away.

19. ECA machine is over 250
feet away from dish
washer!
Automatic ECA device
with ancillary float level
control reservoirs
elevated to fill floor
cleaning machines
North Education
Center, Plymouth
Nova controller doses
catholyte into high
temp dish washer tank
.
.
.

20. ULTRA-LYTE 75A “MINI’S”-AS
MOBILE PLUG-N-PLAY ECAS
MODULES; EXCLUSIVELY BY JDP, INC
Full Auto Generator module Mobile Concentrate module

21. MOBILE MINI’S ENROUTE TO
PURDUE UNIV. FOR MELON
RESEARCH STUDY

22. Solutions Applications
Anolyte
Broad spectrum sanitizers
Produce wash and fog dispersion
Beverage line sanitizing for biofilm
control
General purpose disinfectant
Norovirus control and a powerful
virucide
Mold remediation
Biological control for LM,
Legionella, water systems, pools,
laundry and more
Catholyte
Amphoteric surfactant for
cleaning with no film residue –
no biofilm matrix
No COD component to effluent
Dishwasher dosing
Carpet and floor cleaning
General decontamination
Coach, car and cart wash
Biofilm control

23. EVOLVED SANITARY
OPERATIONS PLATFORMS®
Prerequisite Programs are Customized For Each Client/Customers
Operation Using Environmental And Food HACCP – WITH ECA
Two-step Process Uses
Catholyte to decontaminate and VERIFY’s CLEAN
Anolyte is sprayed onto clean surface to SANITIZE

24. SEPTEMBER ‘13 INSTALL ON
THE GOLDEN PRINCESS CRUISE
SHIP
A new, Norovirus control strategy proven to provide statistically
significant improvement in reducing risk of transmission

25. ATP METERS PROVIDED BY JRS/JDP
ALONG WITH ESOP TRAINING
Because we measure “CLEAN”
quantitatively, using ATP, we ensure
clean surfaces prior to surface
sanitizing.
!

26. THE CREW IS HAPPY TO BE DONE
WITH VIROX - WHICH RUINED THEIR
HANDS

27. © Johnson Diversified Products,
Inc..
Food Safety, Risk Management And The
Evolution Of Commercial Kitchens
CROWN, GOLDEN AND STAR PRINCESS CRUISE SHIPs INSTALLATION; IMPLEMENTED “ESOPs” FOR
EFFECTIVE, CLEANING, SANITIZING FOR DISEASE TRANSMISSION PREVENTION
Ready To Use
Sanitizer,
200ppm FAC
Concentrated
Sanitizer,
1,100ppm FAC
(2) ECA Systems
ClarentisTech, LLC
S
A
L
T
S
A
L
T
B
R
I
N
E
B
R
I
N
E
27s

28. COMPELLING DATA, LOW 150PPM FAC;
5 LOG REDUCTION IN ONLY 1 MINUTE!

29. ONE MACHINE REPLACES ALL VIROX SANITIZERS
AND DISINFECTANTS USED FOR NOV CONTROL

30. NYC INSTALLATION PHOTOS
ECA Device with
auto float control
in oversized
tanks
Proportioning
station for fruit
and produce
Proportioning
for best
practice hand
sanitizer
Old style DEMA
injection fitting for
catholyte replacing
dish machine
detergentWhole Foods,
Union Square
Manhattan, NY (sold and
serviced by our channel
partnerS, Ecologic
Solutions).

31. Mobile Ul-75A “mini”
Fully automatic,
110 or 220V
Produces stable
HOCl anolyte
selectable from
150-1100 PPM FAC
pH 5.8-7.2; pH 12.5
catholyte cleaner
(hydroxyl radical)
Plug and play
modules set up
quickly

32. COSTS AND OPTIONS
Mini base units start
at $23K, larger units
range from $40K to
$65K
Mobile modules with
ancillaries and water
softener add $12K
Add for other options
for connecting to dish
washers or remote
mixing/dosing, crates,
etc.
Lease programs and
rentals too.

33. 3 – 4X SHELF LIFE
EXTENSION FOR BERRIES!
400% increase in
profits!
100PPM FAC Ultra-
Lyte in unique
Ultrasonic fogger
with “Double Dome”
from Diligence Corp.
Fogging systems for
retail cases, cold
rooms, containers
and trailers

34. Anolyte destroys all known pathogens
Catholyte disrupts biofilm adhesion
No film residues from anolyte or catholyte
Harmless to humans and environment
Non-Toxic; a true “GREEN” technology
AFFORDABLE, SUSTAINABLE, EFFECTIVE

35. OTHER USES FOR ECA?
Floor cleaning and sanitizing; hard surface and carpets
Lavatories, shower and locker rooms, walk-off mats, gear and clothing
cleaning, disinfection and deodorization, commercial laundry
Remediation; mold, flood, fire, infectious disease
Biofilm control
Legionella, CIP, narrow bore water line (DUWl)
Cooling tower and all other evaporative uses
Listeria control; drain hygiene systems, animal husbandry vet medicine
Swimming pools, hot tubs/spa’s, no more bromine!
Potable water disinfection - no risk of chlorine tolerant strains of water
borne micro-organisms.
General cleaning and disinfection; excellent anti viral is non-toxic

36. APPROVALS AND USE
U.S. Patent 8,282,974, Oct 9th, 2012 http://tinyurl.com/aqtzf5c
EPA Label; when distributers package and sell in container:
http://clarentistechnologies.com/storage/Final%20EPA%20Label%20Clarentis-
2.pdf
Infection control eg., Norovirus (CDC VSP)
FDA Food Code 7-204.11 and 4-501.114
Grade A Pasteurized Milk Ordinance (PMO) per NCIMS
CFRs
40 CFR 180.940
4o CFR 152.500
40 CFR 156.10
21 CFR 173.315
On-Site generated pursuant to ESOP®; Generally Recognized As Safe (GRAS)

37. Specialized Validation
U.S. Patent 8,282,974, Tandem use of Catholyte and
Anolyte to Clean and sanitize Fruit and Vegetables (Dole),
Thomas Johnson, first named inventor, Oct 9th, 2012
Antiviral activity of Ecasol (anolyte) against feline
calicivirus a surrogate of human norovirus, Journal of
Infection of Public Health, December, 2012
Many others relating to diverse applications; eg., mold
remediation, sporocidal, fungicide, broad spectrum
antibacterial vs MRSA, C. diff., protozoa and oocysts;
blood pathogens. Can be aerosolized; fogged.
http://cfpub.epa.gov/si/si_public_record_Report.cfm?dirE
ntryId=238135

38. Used by the U.S. Army rangers
and other armies of the world
for biological, chemical and
nuclear decontamination and
remediation regimes.

39. Validated Antiviral
NoV
H3N2
H1N1

40. WHAT OTHER PROOF?
University of MN/ Journal
of Infection and Public
Health, Dec, 2012, NoV
control:
http://tinyurl.com/d6f5d
2p
MSDS
Food contact surface
sanitizer reports
Non-toxic(cytotoxicity)
documentation
ATS Labs NoV
reports
ATS Swine and
Avian Influenza
reports
Legionella papers
EPA Reports

41. A FEW JRS ECA CLIENTS
Princess Cruises 2013 - present
Surly Brewery, Minneapolis – 2014 to present
Adult Correctional Facility (Hennepin County; since 2007)
North Education Center, New Hope, MN; Speciall Intermediate School District 287
Dole Fresh Vegetables (Soledad, CA since 2008)
Viking Coke (St. Cloud, MN since July 2010 - for CIP systems)
*Whole Foods, Union square pls (27) other stores in the NE (see pictures next slide, since October
2010).
*Statue of Liberty Foundation, AmTrak (2012)
USDA ARS; BARC and Philadelphia.
Clean Response and Catastrophe Response (Remediation Experts, St. Paul, MN since March 2011)
Zerorez Carpet Cleaning, Richfield, MN, 2011
MN ISD 287 North Education Center, since 9/2012
U.S. Armed Forces; Homeland security ( EPA 600/R-11/124 | October 2011 | www.epa.gov/ord)
* Ecologic Solutions Inc. was our NYC Distributer/Partner and these were their customers.
http://www.ecologicsolutions.com

42. CLARENTIS CERTIFICATIONS
Listed by CSA to ANSI UL 979
Labeled with EPA Establishment number
Reservoirs are labeled with contents, MSDS
information and dilution instructions ; 40 CFR
152.10
Anolyte solution approval; 40 CFR 180.940, FDA 7-
204.11
Provided with owners manual, test strips and user
training

44. Thomas W. Johnson
Johnson Diversified Products, Inc.
Food Safety Technology; HACCP (HARPC) and PRP writer and
Implementer.
Food Equipment And Systems Expert; Consultant to
Manufacturers and Associations.
Infection Control Expert; Evolved Sanitary Operations
Platform® (ESOP)Original Author and Current IP Owner.
Protagonist, ECA And ‘On-Site Device’ Expert Since 1999
Deep, Decades Long Experience with National And Local
Regulatory Compliance As Well As Is Due Diligence Associated
With Claims And Intended Uses For ECA ‘Electrolytes’.
Codes and Standards Development Organization
Memberships; 26yrs
Over A Decade Of Integration/Implementation Experience
Installing, Servicing, along with ECA Systems Certification
Learning Programs For Crews in Hygiene Sensitive Facilities.
Broad, Extensive “Who’s - Who” List Of Local, Regional, National
And Global References, Principals, Clients and Customers
https://www.linkedin.com/profile/view?id=12998541&trk=nav_responsive_tab_profile

45. More info?
Contact: Thomas Johnson
Email: tomj@jdpinc.com
Direct: 651-203-2462
Cell: 651-587-0418
.
.
.
http://www.Jrsrisk.com http://www.jdpinc.com http://www.evolvedkitchens.com
