DockerCon 2017 - Cilium - Network and Application Security with BPF and XDP
- 1. CILIUM: NETWORK AND APPLICATION SECURITY WITH BPF AND XDP Thomas Graf Co-founder & CTO Covalent
- 2. Who is this guy?
- 3. Helped build the biggest monolith ever … Who is this guy?
- 4. Helped build the biggest monolith ever … Who is this guy?
- 5. Time to rethink the kernel
- 6. syscalls syscalls Net IOBlock IO Time to rethink the kernel
- 7. Time to rethink the kernel From monolith to “microkernel” with BPF syscalls syscalls BPF BPF BPF BPF Net IOBlock IO
- 8. Time to rethink the kernel From monolith to “microkernel” with BPF syscalls syscalls BPF BPF BPF BPF BPF BPF Security Networking Net IOBlock IO
- 9. BPF is revolutionizing… • Tracing / Profiling
- 10. BPF is revolutionizing… • Tracing / Profiling Container Performance Analysis Brendan Gregg Wed 1:30pm “Black Belt”
- 11. BPF is revolutionizing… • Tracing / Profiling • Networking Container Performance Analysis Brendan Gregg Wed 1:30pm “Black Belt”
- 12. BPF is revolutionizing… • Tracing / Profiling • Networking • Security Container Performance Analysis Brendan Gregg Wed 1:30pm “Black Belt”
- 13. Application Architectures Delivery Frequency Operational Complexity Single Server App Yearly Low Delivery Frequency
- 14. Application Architectures Delivery Frequency Operational Complexity Single Server App Yearly Low 3-Tier App Monthly Moderate Delivery Frequency
- 15. Application Architectures Delivery Frequency Operational Complexity Single Server App Yearly Low Distributed Microservices 10-100 x’s / day Extreme 3-Tier App Monthly Moderate Delivery Frequency
- 16. Network Security has not evolved $ iptables -A INPUT -p tcp -s 15.15.15.3 --dport 80 -m conntrack --ctstate NEW -j ACCEPT The world still runs on iptables matching IPs and ports:
- 17. Your HTTP ports be like …
- 18. Network Security for Microservices Example Gordon is looking for a job…
- 19. Gordon Job Postings Example: Security for Microservices
- 20. GET /healthz GET /jobs/{id} PUT /jobs/{id} POST /jobs API Gordon Job Postings Example: Security for Microservices
- 21. GET /healthz GET /jobs/{id} PUT /jobs/{id} POST /jobs API GET /jobs/331 Gordon Job Postings Example: Security for Microservices
- 22. L3/L4 GET /healthz GET /jobs/{id} PUT /jobs/{id} POST /jobs API iptables -s 10.1.1.1 -p tcp --dport 80 -j ACCEPT GET /jobs/331 Gordon Job Postings Example: Security for Microservices
- 23. L3/L4 GET /healthz GET /jobs/{id} PUT /jobs/{id} POST /jobs API exposed exposed exposed GET /jobs/331 Gordon Job Postings Example: Security for Microservices iptables -s 10.1.1.1 -p tcp --dport 80 -j ACCEPT
- 24. Not exactly least privilege Security team is not amused
- 25. GET /healthz GET /jobs/{id} PUT /jobs/{id} POST /jobs API GET /jobs/331 Gordon Job Postings Example: Security for Microservices
- 26. L3/L4 GET /healthz GET /jobs/{id} PUT /jobs/{id} POST /jobs API FROM Gordon ALLOW GET /jobs/.* GET /jobs/331 Gordon Job Postings Example: Security for Microservices
- 27. We demand a demo
- 28. BPF - The Superpowers inside Linux
- 29. SANDBOX BPF GET /foo BPF: Transparent redirection into proxy
- 30. SANDBOX BPF Proxy GET /foo redirect rules sk BPF: Transparent redirection into proxy
- 31. SANDBOX BPF Proxy GET /foo redirect rules sk Shared State • Orig Dest IP • Identity BPF: Transparent redirection into proxy
- 32. SANDBOX BPF Proxy GET /foo redirect reinject rules sk sk Shared State • Orig Dest IP • Identity BPF: Transparent redirection into proxy
- 33. SANDBOX BPF Proxy GET /foo rules BPF: Transparent redirection into proxy sk sk 403 Access Denied
- 34. So what is BPF exactly?
- 35. .insns = { BPF_MOV64_REG(BPF_REG_2, BPF_REG_10), BPF_ALU64_IMM(BPF_ADD, BPF_REG_2, -8), BPF_ST_MEM(BPF_DW, BPF_REG_2, 0, 0), BPF_LD_MAP_FD(BPF_REG_1, 0), BPF_EMIT_CALL(BPF_FUNC_map_lookup_elem), BPF_MOV64_REG(BPF_REG_1, BPF_REG_10), BPF_ALU64_IMM(BPF_ADD, BPF_REG_1, -152), BPF_STX_MEM(BPF_DW, BPF_REG_1, BPF_REG_0, 0), BPF_JMP_IMM(BPF_JEQ, BPF_REG_0, 0, 2), BPF_LDX_MEM(BPF_DW, BPF_REG_3, BPF_REG_1, 0), BPF_ST_MEM(BPF_DW, BPF_REG_3, 0, 42), BPF_EXIT_INSN(), } What is BPF? Learn more about BPF: docs.cilium.io
- 36. BPF: Toolchain – from user to kernel USER SPACE SOURCE CODE [C] </>
- 37. BPF: LLVM compiles program code to bytecode USER SPACE SOURCE CODE [C] </> BYTE CODE [BPF] </>
- 38. BPF: Bytecode is loaded and verified into kernel USER SPACE KERNELVERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </>
- 39. BPF: Bytecode runs inside safe kernel sandbox USER SPACE KERNELVERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </> SANDBOX BPF
- 40. BPF: Program is attached to event (packet-in) USER SPACE KERNELVERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </> SANDBOX BPF
- 41. BPF: Program can redirect to netns & sockets USER SPACE KERNELVERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </> SANDBOX BPF
- 42. BPF – An opportunity to rethink security policy enforcement
- 43. Status Quo: Policy Enforcement connect()
- 44. Status Quo: Policy Enforcement connect() TCP
- 45. Status Quo: Policy Enforcement connect() TCP Network packets
- 46. Status Quo: Policy Enforcement connect() TCP Network packets veth veth namespace boundary
- 47. Status Quo: Policy Enforcement connect() TCP Network packets iptables veth veth namespace boundary
- 48. Status Quo: Policy Enforcement connect() drop TCP Network packets iptables veth veth namespace boundary
- 49. Status Quo: Policy Enforcement connect() drop TCP Network packets ETIMEDOUT iptables veth veth namespace boundary
- 50. Status Quo: Policy Enforcement connect() drop TCP Network packets ETIMEDOUT/ ECONNREFUSED iptables RST veth veth namespace boundary
- 51. Can we do better? connect()
- 52. BPF: Leverage user space tool chain USER SPACE KERNEL connect() VERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </>
- 53. BPF: Attach program to connect() syscall (LSM) USER SPACE KERNEL connect() VERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </> BPF LSM Hook
- 54. BPF: Return EACCESS – No packets created at all USER SPACE KERNEL connect() EACCESS VERIFIER + JIT SOURCE CODE [C] </> BYTE CODE [BPF] </> BPF LSM Hook
- 55. XDP/BPF – The software loadbalancer of the future
- 56. WHAT IF I TOLD YOU XDP allows for 10x IPVS performance
- 57. Source: https://www.netdevconf.org/2.1/slides/apr6/zhou-netdev-xdp-2017.pdf FB moves from IPVS to BPF/XDP for L3/L4 LB XDP throughput IPVS throughput Source:
- 58. Regular BPF mode BPF Driver Software Stack
- 59. XDP [Express Data Path] mode BPF Driver Run BPF Program inside network driver with access to DMA buffer Software Stack
- 60. XDP [Express Data Path] mode BPF Driver Can drop millions of packets per Second while under DDoS Software Stack drop
- 61. XDP [Express Data Path] mode BPF Driver Can pass packets to network stack Software Stack drop Stack
- 62. XDP [Express Data Path] mode BPF Driver Can perform loadbalancing and transmit out the wire again Software Stack drop LB & TX Stack
- 63. How can I use BPF with Docker?
- 72. Cilium Architecture BPF BPF BPF Cilium Agent CLI Monitor Policy Plugins
- 73. Project Status • Initial release two weeks ago • Docker & Kubernetes integration • Looking for feedback and contributions
- 74. Getting Started • Play with our vagrant box: $ git clone https://github.com/cilium/cilium $ cd cilium/examples/getting-started $ vagrant up
- 75. Summary
- 78. Summary • BPF/XDP will drive the future of software based networking on Linux. • Never underestimate the Jedi • Traditional L3/L4 network policies are insufficient for microservices. Least privilege requires HTTP / API / Function awareness.
- 79. Summary • Never underestimate the Jedi • Traditional L3/L4 network policies are insufficient for microservices. Least privilege requires HTTP / API / Function awareness. • BPF/XDP will drive the future of software based networking on Linux. • Cilium brings BPF/XDP and L7 policies to containers and microservices.
- 80. Thank You! github.com/cilium/cilium http://cilium.io/ @ciliumproject Want to chat? DM me! @tgraf__ Don’t forget to vote and grab a shirt on the way out!
- 81. 75 140 205 240 325 365 370 365 410 412 425 445 450 460 460 490 495 505 515 525 545 565 0 100 200 300 400 500 600 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 BPF redirect() performance [GBit per core] Intel Xeon 3.5Ghz Sandy Bridge, 24 Cores, (1 TCP GSO flow per core, netperf -t TCP_SENDFILE, 10K policies)
