- 1. Advanced Renewable Energy DistributedGeneration Consequences Dr Muhammad Arshad Shehzad Hassan
- 2. Technical Consequences of DistributedGeneration • Voltage Changes • Fault Levels • Power Quality • Protection (Later lecture) • Stability (Notes) • Network Operation (Notes)
- 3. Objectives • To understandthe concept of Power Quality • To understand the main power quality issues raised by and affecting DG
- 4. Power Quality • PowerQuality = Voltage Quality – Frequency – Amplitude – Purity • Power Quality Problem – Any power problem manifested in voltage, current, or frequency deviations that results in failure or mal-operation of customer equipment • Why increased emphasis ? – Sensitive loads – Power electronic loads/generator interfaces – Increased customer awareness
- 5. Source of PowerQuality from the Network
- 6. Source of PowerQuality from the Load/Generator
- 7. Power Quality • VoltageFlicker • Harmonics • Unbalance
- 8. Flicker • Impression ofvisual unsteadiness induced by light whose luminance fluctuates with time.
- 9. Harmonics • Distortion increasing; •Caused by non-linear characteristics of devices and loads; • Increases losses in machines; • Interferes with power electronic control systems.
- 10.
- 11. Unbalance • Caused primarilyby single phase loads or potentially by single phase micro- generators • The maximum deviation from the average of the three phase voltages or currents, divided by the average of the three phase voltages or currents.
- 12. Unbalance 0 10 20 30 40 50 60 70 80 90 100 00:00:00 03:00:00 06:00:0009:00:00 12:00:00 15:00:00 18:00:00 21:00:00 00:00:00 Power (kW) Time (hrs) Phase 1 Phase 2 Phase 3 238 240 242 244 246 248 250 00:00:00 03:00:00 06:00:00 09:00:00 12:00:00 15:00:00 18:00:00 21:00:00 00:00:00 Voltage (V) Time (hrs) Phase 1 Phase 2 Phase 3
- 13. Summary • The consequencesof DG; • Power quality; – Voltage Flicker; – Harmonics; – Unbalance;
- 14.
Editor's Notes
- #1 Introduce myself Introduce yourselves Introduce this course Really the course is all about how to integrate new and renewable energy into electrical networks such that the power can be exported and sold.
- #2 OK so this is a list of the most important technical issues raised by the growth of DG. We will try to deal with each of these issues in turn. We dealt with voltage changes and fault levels on Wednesday
- #4 What is power quality ? Power quality = Voltage quality because this is what we can control we have less or little control over the current that is drawn by a load. It is a customer driven issue
- #5 Some power quality issues are caused by EG and affect load customers Some power quality issues are caused by loads or by system events/characteristics and affect EG. They can cause nuisance tripping of EGs. Sag is a decrease between 0.1 and 0.9 pu voltage for durations of from 0.5 cycles to 1min Swell an increase to 1.1 to 1.8 pu in voltage for durations of 0.5 cycle to 1 minute Both usually associated with fault conditions
- #6 Some power quality issues are caused by EG and affect load customers Some power quality issues are caused by loads or by system events/characteristics and affect EG. They can cause nuisance tripping of EGs. Sag is a decrease between 0.1 and 0.9 pu voltage for durations of from 0.5 cycles to 1min Swell an increase to 1.1 to 1.8 pu in voltage for durations of 0.5 cycle to 1 minute Both usually associated with fault conditions
- #7 There are many disturbances that cause power quality to be deteriorated, some transient some steady state. The issues we are going to focus on are Flicker, Harmonics and Unbalance as they are closely related to embedded generation.
- #8 Can be caused by loads which exhibit continuous, rapid variations in load current magnitude. Arc Furnace typical load that can cause flicker Sensitive in the range 6-10Hz On graph 10 Hz would be 20 changes per second as sinusoidal which would be 1200 voltage changes per minute. This would be the point the human eye is the most sensitive. Graph shows the percentage change that would cause annoyance. Also can be caused by EG if the output power fluctuates rapidly such that it causes voltage fluctuations of sufficient size and at the sensitive frequency range. Also if connecting and disconnecting IG. Tower Shadow 60 rpm, 3 blades, 180 changes per minute Obviously the impedance at the point of connection determines the magnitude of the voltage changes for a given power fluctuation.
