The document outlines the flow of activities for installing a diesel generator, including: 1) Preparing the plant room with adequate clearances as specified in consultant drawings for the generator, fuel tank, piping, cabling, and crane access. 2) Completing civil works like casting the generator platform, locating the fuel storage tank, and installing plant room infrastructure power supply. 3) Constructing the fuel storage tank platform and connections as shown in the drawings, including a trench for fuel piping and cables and a road for refueling trucks.

1. Flow of Activities for
DG Installation

2. Plant room
•
Plant room with clear height of 5.5 Meter clearance and the width as per the
service consultant drawing.
•
The final location of HSD tank and the routing of fuel pipe as per the service
consultant drawings.
•
The Cable / Buss bar routing as per the service consultants.
•
A clear space for the Crain to enter the plant room to shift the DG sets from
trucks to the proper location.
•
The plant room to be fully equipped with the fire extinguishers as lot of
insulating material and fire hard material will be used during the installation of
complete system.
•
No water should stop in the Plant room and for that all the drainage system to
be ready before DG set arrive to the plant room

3. Civil works
DG Installation
DG Set plat form casting
HSD Tank location
Plant Room IPS
White wash to the entire plant room

5. DG set plat form
IPS @ plant room

6. HSD Tank Construction
•
As per the service consultants drawing the required height for the
HSD tank …… Meters need to be constructed
•
Plat form for HSD tank
•
The concrete trench for fuel pipe and LT Cables
•
Concrete road for the fuel truck to come for refueling
Concrete wall for HSD tank
Plat form for HSD
tank
HSD tank

8. Cooling
Tower
HSD tank
Fuel
Tank
for DG
