Danny Bryant presented on how the City of Atlanta used SQL Developer to migrate historical data from a Microsoft SQL Server database to their Oracle E-Business Suite database. The migration involved creating a migration repository in SQL Developer, using the migration wizard to map objects between the databases, and populating the Oracle tables with the migrated data. Some compatibility issues arose due to differences in the database versions, which required additional steps. The presentation provided lessons learned and guidelines for performing database migrations with SQL Developer.

1. Danny Bryant
City of Atlanta
 

2. Danny Bryant
IT Manager, Sr.- City of Atlanta
@dbcapoeira
dbryant@atlantaga.gov
http://www.dbaOnTap.com
Danny Bryant
User Groups: ODTUG | OAUG | IOUG
Publications & Media
ODTUG (blog) –
How’d You First Get Involved with ODTUG?
RMOUG – SQL>SELECT
Regular Expressions: A Love/Hate Relationship
Oracle Podcast
SQL Dev 4.0 in Action at the
City of Atlanta

3.  The City of Atlanta
 “You want to do WHAT?”
 SQL Developer to the Rescue
o Setup
o Migration
o Populating Tables
o Reporting
 Lessons Learned
 Q&A

4.  Overview
o Includes the Mayor/Executive Offices (13 Departments), Judicial and Board Officers,
and City Council (16 Members)
o Metropolitan Statistical Area (MSA) is the 9th largest metropolitan area in the country
o Population of 443,775 citizens (2012 US Census estimate)
o Manages Hartsfield-Jackson International Airport, the world's busiest airport by
serving over 95MM passengers in 2012
o Approximately 7,500 active employees and 5,000 retirees
o $1.8B Operating Budget

5.  Oracle Footprint
o Enterprise Resource Planning (ERP) Applications (eBS 11.5.10.2)
● Financials
● Human Resources Management System
● Procurement
● Discoverer Reporting
o Siebel Customer Relationship Management (CRM) Applications
o Enterprise Performance Management (EPM) Applications (v11.1.2)
● Hyperion Public Sector Planning and Budgeting
● Hyperion Financial Management
o Oracle Business Intelligence Enterprise Edition (OBIEE v11.1.1.2)
● Human Resources Analytics
● Financial Analytics

6. Oracle EBS
Database (10g)
In the beginning there was ….
PeopleSoft
MS SQL Server
MARS-G
MS SQL Server
Beginning of time - 2005 2005 - 4712

8.  We need historical data prior to 2005
o Pension Reform
o Open Records Requests
o Retiree Information

9.  Gather Requirements
 Query PeopleSoft for < 2005 data
o Export to Excel
 Query EBS for > 2005 data
o Export to Excel
 Stitch data together
 Email results to requestor
 Cross your fingers

10.  How can we speed up this process?
 How can we empower the end users?
 How do we take advantage of our existing reporting
tools? – Discoverer – Soon to be OBIEE thanks to DDR
capabilities

12.  Why SQL Developer?
o Integrated UI
o Wizard Driven
o DDL Script Generation
o Online Data Mode
o Offline Data Move
o Repository Based (we will see this shortly)
o Log File

13.  Pre-Requisites
1. Install 3rd party driver for source DB connectivity
2. Admin access to the MSSQL database
3. SYS and SYSTEM Login for Target Database (Wait a minute)
4. Build repository in a new schema for the meta-data, the user
requires the following role and system privileges:
● RESOURCE
● DBA
● CREATE SESSION
● CREATE Any VIEW
● CREATE VIEW
● UNLIMITED TABLESPACE (If using 12c)

14.  Four Phases
1. Verify Source DB Access
2. Create Migration Repository
3. Set up SQL Developer
4. Perform the Migration and Wait

15.  For MSSQL, I needed
db_owner
permissions

16.  Create your Migration
Repository in your new
schema. In this
example:migrationdemo

17.  Launch the Migration
Wizard

19.  This will coincide
with the 3rd party
driver. In this case
SQLServer.

22.  This is your Migration
Repository schema

23. This account has system
privs

26. Local XE
Database
MSSQL Adventure Works
2012 Database
SQL Developer 4.0.2

32. 1. Compatibility issues with DDL when DB versions are different.
PCTFREE 10 PCTUSED 40 INITRANS 1 MAXTRANS 255 NOCOMPRESS
LOGGING STORAGE(INITIAL 131072 NEXT 131072 MINEXTENTS 1
MAXEXTENTS 2147483645 PCTINCREASE 0 FREELISTS 1 FREELIST GROUPS
1 BUFFER_POOL DEFAULT)
DB 10.2.0.4 doesn’t like this.

33. 2. Extra Step to Populate DB
Tables
3. Use Database Copy

37.  3rd Party Drivers
o IBM DB2: http://www-306.ibm.com/software/data/db2/express/additional-downloads.html
o Microsoft SQL Server and Sybase: jTDS driver available
from http://jtds.sourceforge.net/. Use version 1.2
o MySQL: http://dev.mysql.com/downloads/connector/j/5.0.html
o Teradata: http://www.teradata.com/downloadcenter/
 Oracle documentation on Database Migration
o http://www.oracle.com/technetwork/database/migration/omwb-getstarted-
093461.html
