This document provides instructions for Task 2 of the robotics competition. It explains that the task involves using image processing to interpret images and extract useful information. Teams must complete two sections - Section A involves answering questions about the task algorithm, while Section B involves modifying code snippets and test images to perform experiments. Teams are instructed to name and submit their solution files according to the provided format, compress them into a zip folder labeled with their team ID, and upload it to the competition portal by the deadline. Plagiarism is strictly prohibited.
