Some stuff about C++ and development

some stuff about C++
and development

sequence points
5.1.2.3 Program execution. Clause 2
At certain speciﬁed points in the
execution sequence called
sequence points, all side effects of
previous evaluations shall be
complete and no side effects of
subsequent evaluation shall have
taken place.

sequence points
program state
side effects
time

sequence points
Most C and C++ programmers use an implicit
mental model made up of lots of sequence points,
progressing in a mostly left-to-right order.
i + v[++i] + v[++i]

sequence points
In reality C and C++ have
very few sequence points
(this is to give maximum
scope for optimization).

sequence points where?
• at the end of a full expression
• after the ﬁrst operand of these operators
&& || ?: ,
• after evaluation of all arguments and
the function call expression in a
function call

only
sequence points
govern the order of
evaluation

sequence points
i = v[++i] + v[++i];
question: where are the
sequence points
in this statement ?

sequence points
i = v[++i] + v[++i];
answer: here!

shall
If a "shall" or a "shall not" requirement
that appears outside of a constraint is
violated, the behavior is undefined.
4. Conformance. Clause 2
undefined behavior:
behavior ... for which this International
Standard imposes no requirements.
3.Terms, definitions, and symbols

sequence point: rule-one
Between the previous and next
sequence point an object shall have its
stored value modiﬁed at most once by
the evaluation of an expression.
n = n++;
6.5 Expressions. Clause 2.
undeﬁned behavior

sequence point: rule-two
Between the previous and next
sequence point the prior value shall be
read only to determine the value to be
stored.
n + n++;
6.5 Expressions. Clause 2.
undeﬁned behavior

example
#include <stdio.h>
int main(void)
{
int v[] = { 0,2,4,6,8 };
int i = 1;
int n = i + v[++i] + v[++i];
printf("%dn", n);
}
$ gcc foo.c && ./a.out
gcc
(Mac OS 10.8.2)
http://www.pvv.org/~oma/UnspeciﬁedAndUndeﬁned_ACCU_Apr2013.pdf

example
#include <stdio.h>
int main(void)
{
int v[] = { 0,2,4,6,8 };
int i = 1;
int n = i + v[++i] + v[++i];
printf("%dn", n);
}
gcc
(Mac OS 10.8.2)
12

example
#include <stdio.h>
int main(void)
{
int v[] = { 0,2,4,6,8 };
int i = 1;
int n = i + v[++i] + v[++i];
printf("%dn", n);
}
gcc
$ clang foo.c && ./a.out
clang
(Mac OS 10.8.2)
12

example
#include <stdio.h>
int main(void)
{
int v[] = { 0,2,4,6,8 };
int i = 1;
int n = i + v[++i] + v[++i];
printf("%dn", n);
}
gcc
clang
(Mac OS 10.8.2)
12
11

example
#include <stdio.h>
int main(void)
{
int v[] = { 0,2,4,6,8 };
int i = 1;
int n = i + v[++i] + v[++i];
printf("%dn", n);
}
gcc
clang
$ icc foo.c && ./a.out
icc
(Mac OS 10.8.2)
12
11

example
#include <stdio.h>
int main(void)
{
int v[] = { 0,2,4,6,8 };
int i = 1;
int n = i + v[++i] + v[++i];
printf("%dn", n);
}
gcc
clang
icc
(Mac OS 10.8.2)
12
11
13

a reference to
a[i]
can also be written as
*(a+i)
5.3 Pointers and Arrays

example
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
dst[i] = src[i++];
printf("%d %d %d %dn",
dst[0], dst[1],
dst[2], dst[3]);
}
$ gcc *.c && ./a.out
gcc 4.8.0 20130210

example
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
dst[i] = src[i++];
dst[0], dst[1],
dst[2], dst[3]);
}
$ gcc *.c && ./a.out$ gcc *.c && ./a.out
0 2 0 0
gcc 4.8.0 20130210

example
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
dst[i] = src[i++];
dst[0], dst[1],
dst[2], dst[3]);
}
$ gcc *.c && ./a.out$ gcc *.c && ./a.out
0 2 0 0
gcc 4.8.0 20130210
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
*(dst + i) = *(src + i++);
dst[0], dst[1],
dst[2], dst[3]);
}

example
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
dst[i] = src[i++];
dst[0], dst[1],
dst[2], dst[3]);
}
$ gcc *.c && ./a.out $ gcc *.c && ./a.out$ gcc *.c && ./a.out
0 2 0 0
gcc 4.8.0 20130210
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
*(dst + i) = *(src + i++);
dst[0], dst[1],
dst[2], dst[3]);
}

example
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
dst[i] = src[i++];
dst[0], dst[1],
dst[2], dst[3]);
}
$ gcc *.c && ./a.out $ gcc *.c && ./a.out$ gcc *.c && ./a.out
0 2 0 0
$ gcc *.c && ./a.out
0 0 2 0
gcc 4.8.0 20130210
#include <stdio.h>
int main(void)
{
int src[] = { 1,2,3,4 };
int dst[] = { 0,0,0,0 };
int i = 1;
*(dst + i) = *(src + i++);
dst[0], dst[1],
dst[2], dst[3]);
}

precedence is not the
same as order of
evaluation

order of evaluation is
mostly unspeciﬁed
and is a
run-time thing

precedence is
completely speciﬁed
and is a
compile-time thing

precedence determines
which operands
bind to
which operators

temp_a = a();
temp_b = b();
temp_c = c();
a * b + c

temp_c = c();
temp_b = b();
temp_a = a();
a * b + c

temp_b = b();
temp_c = c();
temp_a = a();
a * b + c

example
#include <iostream>
...
int main()
{
int sum = a() + b();
std::cout << sum;
}
#include <iostream>
...
int a()
{
std::cout << "a";
return 3;
}
#include <iostream>
...
int b()
{
std::cout << "b";
return 4;
}

example
#include <iostream>
...
int main()
{
std::cout << sum;
}
$ g++ *.c && ./a.out
#include <iostream>
...
int a()
{
std::cout << "a";
return 3;
}
#include <iostream>
...
int b()
{
std::cout << "b";
return 4;
}

example
#include <iostream>
...
int main()
{
std::cout << sum;
}
$ g++ *.c && ./a.out
#include <iostream>
...
int a()
{
std::cout << "a";
return 3;
}
#include <iostream>
...
int b()
{
std::cout << "b";
return 4;
}
$ g++ *.c && ./a.out
ab7

example
#include <iostream>
...
int main()
{
std::cout << sum;
}
$ g++ *.c && ./a.out $ g++ *.c && ./a.out
#include <iostream>
...
int a()
{
std::cout << "a";
return 3;
}
#include <iostream>
...
int b()
{
std::cout << "b";
return 4;
}
$ g++ *.c && ./a.out
ab7

example
#include <iostream>
...
int main()
{
std::cout << sum;
}
$ g++ *.c && ./a.out $ g++ *.c && ./a.out
#include <iostream>
...
int a()
{
std::cout << "a";
return 3;
}
#include <iostream>
...
int b()
{
std::cout << "b";
return 4;
}
$ g++ *.c && ./a.out
ab7
$ g++ *.c && ./a.out
ba7

indeterminate value
6.2.4 Storage duration of objects
The initial value of the object is
indeterminate.
J.2 Undeﬁned behavior
The value of an object with
automatic storage duration is
used while it is indeterminate.

example
#include <stdio.h>
#include <stdbool.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc
Without optimization...

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc
true

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang
true

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang
true false

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang icc
true false

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang icc
true false true
false

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang icc
With optimization...
true false true
false

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang icc
true false true
false
false

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang icc
true false true
false
false false

example
#include <stdio.h>
void bar(void)
{
bool b;
if (b)
printf("truen");
if (!b)
printf("falsen");
}
void foo(void);
void bar(void);
int main(void)
{
foo();
bar();
}
void foo(void)
{
char c = 2;
...
}
gcc clang icc
true false true
false
false false false

what do you mean
by the word
unit ?

A
tests
C
B
F
G
D
E
external boundary

A
tests
C
B
F
G
D
database
external boundary

A
tests
C
B
F
registry
D
database
external boundary

A
tests
C
B
F
registry
D
ﬁle system
external boundary

A
tests
C
B
F
socket
D
ﬁle system
external boundary

A
tests
C
B
F
socket
D
ﬁle system
external boundary
unit tests should pass or fail based
solely on the correctness of our tests
and our code

A
tests
C
B
F
socket
D
ﬁle system
external boundary
not based on the correctness of
external code and its environment

this means we have
to design "seams"
into our
architecture

A
tests
C
B
F
socket
D
ﬁle system
substitute
ﬁle system
substitute
socket
seam
seam

so fast, your basic
development
activity can change
from...

this is not a mere
quantitative
change

some more about tests being...

void example_of_use()
{
q = snafu::instance().query(...)
...
snafu::instance().modifier(...);
...
}
spot the anti-pattern

class snafu
{
public: // singleton
static snafu & instance();
public: // api
int query(...) const;
void modifier(...);
private: // inappropriate
snafu(const snafu &);
snafu & operator=(const snafu &);
private: // 'tors
snafu();
~snafu();
};
singleton

this is the only good singleton

A
tests
C
B
F
socket
D
ﬁle system
substitute
ﬁle system
substitute
socket
seam
seam
1
singleton

A
unit
test
C
B
F
D
1
another
unit
test
danger

you should be
able to run your
unit tests in
any order

you should be
able to run your
unit tests in
parallel

unit tests
integration
system
no external
dependencies
some external
dependencies
all external
dependencies

waterfall
analysis
design
implement
test

waterfall
analysis
design
implement
debug

Debugging is twice as hard as
writing the code in the first
place. Therefore, if you write
the code as cleverly as possible,
you are, by definition, not smart
enough to debug it.

"agile"
...
...
...
test
...
...
...
test
...
...
...
test

virtual destructor?
class dice_roller
{
public:
virtual ~dice_roller();
...
virtual int roll_dice() const = 0;
};
question:
what does a virtual destructor mean?

virtual destructor
class random_dice_roller
: public
dice_roller
{
public:
...
};
answer:
any code can delete a derived object
through a base class pointers*
void contrived_example()
{
dice_roller * ptr =
new random_dice_roller();
...
delete ptr;
}
* and it will work!

virtual destructor?
class random_dice_roller
: public
dice_roller
{
public:
...
};
question:
should any code be able to write
delete expressions?
{
dice_roller * ptr =
...
delete ptr;
}
class dice_roller
{
public:
virtual ~dice_roller();
...
};

virtual destructor
suppose you don't want arbitrary code to
be able to write delete expressions?
{
dice_roller * ptr =
...
delete ptr;
}
class dice_roller
{
public:
...
protected:
~dice_roller();
};

bad inheritance
alpha
beta
gamma
delta
new alpha()
new beta()
new gamma()
new delta()

good inheritance
alpha beta gamma
abstraction
delta
client

factory pattern
abstract
factory
abstract
product
concrete
product
concrete
factory
<<creates>>
<<creates>>
client

#include header
#include "wibble.hpp"
class fubar
{
};

inheritance
class fubar : public wibble // 1
{
};

member function parameters
{
void value_parameter(wibble ); // 2
void ref_parameter(wibble &); // 3
void ptr_parameter(wibble *); // 4
};

member function return types
{
wibble value_result(); // 5
wibble & ref_result(); // 6
wibble * ptr_result(); // 7
};

data members
{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
};

static data member
{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
static wibble shared_value; // 11
static wibble & shared_ref; // 12
static wibble * shared_ptr; // 13
};

forward declaration
class wibble;
{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
};

which of 1..13 require #include ?
{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
};

my assistant will
now collect up the
answers

the answer is...
class wibble;
{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
static wibble & shared_ptr; // 12
};

we'll see how you all
did shortly!

#include in .hpp .cpp
#ifndef FUBAR_INCLUDED
#define FUBAR_INCLUDED
#include "snafu.hpp"
#include "widget.hpp"
class fubar
{
...
};
#endif
#include "fubar.hpp"
...
fubar.hpp client.cpp

class snafu;
class widget;
class fubar
{
...
};
#endif
#include "snafu.hpp"
#include "widget.hpp"
...
fubar.hpp client.cpp
• compile times down
• physical coupling down
• happiness up
#include in .hpp .cpp

how much does a #include cost?
#include <string>
includer.cpp
$ g++ -H includer.cpp &> lines
$ wc -l lines

#include <string>
includer.cpp
$ wc -l lines
. /usr/include/c++/4.2.1/string
.. /usr/include/c++/4.2.1/bits/c++config.h
... /usr/include/c++/4.2.1/bits/os_defines.h
.... /usr/include/unistd.h
..... /usr/include/_types.h
...... /usr/include/sys/_types.h
....... /usr/include/sys/cdefs.h
........ /usr/include/sys/_symbol_aliasing.h
........ /usr/include/sys/_posix_availability.h
....... /usr/include/machine/_types.h
........ /usr/include/i386/_types.h
..... /usr/include/sys/unistd.h
...... /usr/include/sys/cdefs.h
...
...
...
... /usr/include/c++/4.2.1/bits/stl_uninitialized.h
... /usr/include/c++/4.2.1/bits/stl_algo.h
.... /usr/include/c++/4.2.1/bits/stl_heap.h
..... /usr/include/c++/4.2.1/debug/debug.h
.... /usr/include/c++/4.2.1/bits/stl_tempbuf.h
..... /usr/include/c++/4.2.1/memory
.... /usr/include/c++/4.2.1/debug/debug.h
.. /usr/include/c++/4.2.1/bits/basic_string.tcc

#include <string>
includer.cpp
$ wc -l lines
. /usr/include/c++/4.2.1/string
.. /usr/include/c++/4.2.1/bits/c++config.h
... /usr/include/c++/4.2.1/bits/os_defines.h
.... /usr/include/unistd.h
..... /usr/include/_types.h
...... /usr/include/sys/_types.h
....... /usr/include/sys/cdefs.h
........ /usr/include/sys/_symbol_aliasing.h
........ /usr/include/sys/_posix_availability.h
....... /usr/include/machine/_types.h
........ /usr/include/i386/_types.h
..... /usr/include/sys/unistd.h
...... /usr/include/sys/cdefs.h
...
...
...
... /usr/include/c++/4.2.1/bits/stl_uninitialized.h
... /usr/include/c++/4.2.1/bits/stl_algo.h
.... /usr/include/c++/4.2.1/bits/stl_heap.h
..... /usr/include/c++/4.2.1/debug/debug.h
.... /usr/include/c++/4.2.1/bits/stl_tempbuf.h
..... /usr/include/c++/4.2.1/memory
.... /usr/include/c++/4.2.1/debug/debug.h
.. /usr/include/c++/4.2.1/bits/basic_string.tcc
$ wc -l lines
244 lines

you must not tell lies!
class snafu;
class widget;
class fubar
{
...
};
#endif
namespace fishing
{
class snafu
{
...
};
}
fubar.hpp
ﬁshing/snafu.hpp
namespace fishing
{
class widget
{
...
};
}
ﬁshing/widget.hpp

namespace fishing
{
class snafu;
class widget;
}
class fubar
{
...
};
#endif
fubar.hpp
namespace fishing
{
class snafu
{
...
};
}
ﬁshing/snafu.hpp
namespace fishing
{
class widget
{
...
};
}
ﬁshing/widget.hpp

namespace std
{
class string;
}
class fubar
{
...
};
#endif
namespace std
{
class string
{
...
};
}
fubar.hpp <string>
it's not like this!

namespace std
{
class string;
}
class fubar
{
...
};
#endif
namespace std
{
template<typename T>
class basic_string
{
...
};
typedef basic_string<char> string;
...
}
fubar.hpp <string>
it's a bit like this!

namespace std
{
class basic_string;
typdef
basic_string<char>
string;
}
class fubar
{
...
};
#endif
namespace std
{
class basic_string
{
...
};
...
}
fubar.hpp <string>
?
?

namespace std
{
class basic_string;
typdef
basic_string<char>
string;
}
class fubar
{
...
};
#endif
namespace std
{
template<typename T1,
typename T2 = ...,
typename T3 = ...>
class basic_string
{
...
};
...
}
fubar.hpp <string>
default template types

don't forward declare
anything in std::

template
#ifndef SNAFU_INCLUDED
#define SNAFU_INCLUDED
#include <algorithm>
...
class snafu
{
public:
void reserve(int limit)
{
std::for_each(...)
}
...
};
#endif
snafu.hpp
templates can
increase
coupling

template
#ifndef SNAFU_INCLUDED
#define SNAFU_INCLUDED
...
class snafu
{
public:
void reserve(int limit);
...
};
#include "snafu-template.hpp"
#endif
#include <algorithm>
void snafu<T>::reserve(int limit)
{
std::for_each(...)
}
...
snafu.hpp snafu-template.hpp
templates can
increase
coupling

inline
#include <vector>
class fubar
{
public:
typedef std::vector<int>::iterator iterator;
void algo(iterator from, iterator to)
{
...
}
...
};
inlining usually increases coupling
fubar.hpp

template
...
class fubar
{
public:
template<typename iterator>
void algo(iterator from,
iterator to)
{
...
}
...
};
#endif
#include <vector>
void eg(std::vector<int> & v)
{
fubar f;
f.algo(v.begin(), v.end());
}
fubar.hpp
example.cpp
templates can
also decrease
coupling!

does this compile?
class fubar
{
public:
...
void fu();
...
private:
std::vector<wibble> wibbles;
};
#endif
#include <vector>
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp

does this compile?
class fubar
{
public:
...
void fu();
...
private:
};
#endif
#include <vector>
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp
yes

does this compile?
class fubar
{
public:
...
void fu();
...
private:
};
#endif
#include <vector>
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp

does this compile?
class fubar
{
public:
...
void fu();
...
private:
};
#endif
#include <vector>
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp
no

class fubar
{
public:
...
void fu();
...
private:
};
#endif
#include <vector>
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp

does this compile?
#include <vector>
class fubar
{
public:
...
void fu();
...
private:
};
#endif
...
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp

does this compile?
#include <vector>
class fubar
{
public:
...
void fu();
...
private:
};
#endif
...
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp
yes

include your own header 1st
#include <vector>
class fubar
{
public:
...
void fu();
...
private:
};
#endif
...
void fubar::fu()
{
...
}
fubar.hpp fubar.cpp

better still - make sure each
header compiles (on its own) as
part of the build!
#include <vector>
class fubar
{
public:
...
void fu();
...
private:
};
#endif
fubar.hpp

{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
};

the answer is...
{
wibble value; // 8
wibble & ref; // 9
wibble * ptr; // 10
};

the Satir change curve
old status quo
new status quo old status quo
foreign element
resistance
and
chaos integration
and
practicetime
competence

Some stuff about C++ and development

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to Some stuff about C++ and development

Similar to Some stuff about C++ and development (20)

More from Jon Jagger

More from Jon Jagger (13)

Recently uploaded

Recently uploaded (20)

Some stuff about C++ and development
