Continuous Integration with Docker on AWS
The document discusses continuous deployment with Docker. It begins with introductions of the presenter Andrew Aslinger and an overview of Docker. It then discusses using Docker for continuous deployment on AWS, including building and pushing Docker images, triggering EC2 instances to pull the latest images. It covers some advanced Docker techniques and OpenWhere's experiences using Docker. It recommends Docker for continuous deployment but notes some limitations for more complex scenarios.
More Related Content
Similar to Continuous Integration with Docker on AWS
Continuous Integration with Docker on AWS
- 1. Con$nuous Deployment with Docker Andrew Aslinger Oct 9. 2014
- 2. Who is Andrew #1 So#ware / Systems Architect for OpenWhere Passion for UX, Big Data, and Cloud/DevOps Previously Designed and Implemented automated DevOps processes for several organiza@ons Mul$ple environments, many user / developer groups, big data clusters, hundreds of machines A Recovering “Chef”
- 3. Who is Andrew #2 (Andy) Host of AWS DC Meet Up Started as a developer who could talk to opera@ons and infrastructure teams Lived the transi@on from data center, Co-‐Lo, internal cloud, to AWS To much fun to ever go back
- 4. 4 Agenda What is Docker ? Con$nuous Delivery with AWS and Docker Docker Advanced Prac$ces and Lessons Learned Demo & Discussion
- 5. What is Docker? “Docker is an open pla/orm for developers and sysadmins to build, ship, and run distributed applica:ons” Yet another DevOps tool light weight container Latest hype?
- 6. Docker Benefits •Portability Across Machines – Local Vagrant like deployment, Remote Deployment including Amazon EC2 – Independent of host OS – Lightweight vs VMs • Supports DevOps Best Prac@ces & Re-‐use – Infrastructure as Code – Container Extensibility • Fits into a Con@nuous Deployment Pipeline • Isola@on and Single Responsibility – Reduce dependency conflicts, security Virtual Machines Docker
- 7. 7 A Typical Docker Flow with six simple commands Docker Image docker build –t imagename . Dockerfile conf Docker Registry registryname: docker tag imagename registryname/ imagename https://registry.hub.docker.com/ Private registry Docker Image Docker Container or docker run –p 9000:9000 –d --name containername imagename Development Environment Host Environment docker stop/restart/start containername
- 8. OpenWhere DevOps Philosophy 1. Immutable Infrastructure – Focus on one process (build) vs. two (build & maintain) 2. Simplify the Tools – Minimize On-‐boarding & Training – Minimize Tools 3. Purpose Built Environments 4. DevOps code should co-‐exist with applica@on code – How to build infrastructure for project inline with project – Jenkins scripts – Docker 5. Auto-‐scale from start
- 9. Why Docker with EC2? • Build once, run many places – Dev Machines, different clouds, different VPCs, share and build – Not $ed to box size or guest OS • AMI’s are difficult to rebuild and more difficult to maintain – Snapshots retain baggage – There is no “git” version control for AMI – AMI’s are not cross region compa$ble – Other AMI tools like Amiator aren’t easy to use • Easier to achieve immutable infrastructure and one click deploys – Maintaining machines sucks • Treat your infrastructure as code with a Con@nuous Deployment Pipeline
- 10. Why Docker with EC2? • Separate your data and state from your image • Machine layers evolve at different velocity and have different reuse (Example Later) – Core OS – Organiza$on Level Requirements – Applica$on Level Requirements – Applica$on Code • Test and version control your deploy ar$facts and configura$on together – Same container for developers and EC2 – Java Example • Stop maintaining AMIs +
- 11. Docker Con@nuous Deployment Flow: Set up AWS infrastructure Create AWS Ec2 Instances and install Docker 1 yum install -y docker-io service docker start ….
- 12. Docker Con@nuous Deployment Flow: Build and push docker image with latest code Commit New Code w/ Docker file SCM Poll Trigger build Push Artifacts (optional) Push new Image to public or private repo 2 3 4 6 Build new Docker Image 5 from Docker File
- 13. Docker Con@nuous Deployment Flow: Trigger EC2 to pull latest Docker image Trigger Docker Pull on target machines 7 Docker Pull & start container 8
- 14. Advanced #1: Docker Image Layers using FROM and OnBuild commands in the Docker File Project Code Specific Image Organiza$on Applica$on Image (Example NodeJs Web App Image) Organiza$on Base OS Core OS Project SCM Application Dependencies & Config: NodeJS, express, supervisord etc. Common Dependencies & Config: Security, LDAP, Logging, etc. Base OS: CentOs, Ubuntu, etc. ONBUILD Docker Image Layers Jenkins Built Reusable Machine layers can evolve at different velocity and have different levels of reuse
- 15. Advanced #2: Linked Containers Run multiple containers on a machine. Each with a responsibility linked by ports / address https://docs.docker.com/userguide/dockerlinks/ --link name:alias docker run -d -P --name web --link db:db training/webapp python app.py Host OS Container 1 DB Container 2 Web $DB_PORT = 6379, etc. /etc/hosts db 172.0.0.2
- 16. Advanced #3: Data Containers A container which allows sharing of data across containers https://docs.docker.com/userguide/dockervolumes/ Benefits: Change image independent of data (maintainability) Enables Data sharing patterns (single responsibility) sudo docker run -d --volumes-from dbdata --name db2 training/postgres Host OS Data Container (non running) Container 2 Web /volume Limitations: Data is Tied to Host OS /volume -file1.txt -file2.txt Physical files docker managed Container 3 Web /volume
- 17. Advanced #4: Customize on Init You need to parameterize and modify items in a container based on the environment Examples: Set a IP address or DNS name, Set a DB password Pattern: 1. Load a script onto the box as part of an building the image 2. Run script at container launch 3. Script uses environment variables to customize settings files etc 4. Environment variables are passed to the docker run Command Data Container (non running) docker run -e sed DB=10.0.0.1 start.sh config.conf Discovery Service & is Registra$on an area emerging
- 18. OpenWhere Docker Wins 1. Full con@nuous deployment and write once, deploy many @mes realized 2. Developer Replacement for vagrant – Less complexity – Test with what you deploy! 3. Deployment build process co-‐exists with the so#ware! – Reduced Maintenance, developer buy-‐in, testability 4. Awesome Re-‐use with minimal code – 1 line Dockerfile(s) for new MEAN Stack apps 5. Simplicity (Streamlined DevOps)
- 19. OpenWhere Docker Burns • Learning Curve / Maturity – Learning a Docker way for each DevOps task (s$ll in progress) – Example: Need “tricks” to do things like have more than one process running in a container – Example: Learning layers are independent and don’t retain state between RUN commands • A Docker Container is not the same as a typical virtual machine – Basic stuff like syslog off and tar, wget not installed – Base Image: hmp://phusion.github.io/baseimage-‐docker/ • Containers not restar@ng on EC2 Restart – We hacked a cloud-‐init work around • Upda@ng to new images is dirty – Manually clean up images / containers or run out of disk! • Debugging more complex: You can only a`ach to a Docker container if the program you are running is a shell – Install SSH or we have a workaround trick
- 20. Recommenda$ons • Docker works great for a Con$nuous Deployment flow on EC2 – Especially for stateless applica$ons or a micro-‐service architecture • Complex cluster deployments, stateful applica$ons or databases, service discovery etc. not quite there yet – You may need to roll your own solu$on or integrate with another technology
- 21.
- 22. 22 Contact Informa$on Andrew Aslinger Senior Systems Architect OpenWhere aaslinger@openwhere.com @aaa572 hmp://owaaa.github.io/ Andrew Heifetz Chief Cloud Officer OpenWhere aheifetz@openwhere.com @andyheifetz hmp://www.linkedin.com/pub/andrew-‐heifetz Cell: 240-‐481-‐7442
