Comparison of Word2vec and Doc2Vec model driven Sentiment Analysis using SVM, LR, Keras CNN, Bidirectional LSTM with and without pre-trained Word and Document Embeddings
- 1. Sofia Dutta Data 602 – Spring 2019 Semester Project Comparing Word2vec, Doc2Vec model driven Sentiment Analysis using SVM, LR vs Keras CNN and Bidirectional LSTM with and without pre-trained Word and Document Embeddings
- 3. WHAT IS A WORD VECTOR? • Assume a vocabulary has five words: King, Queen, Man, Woman, Child. • One-hot vector doesn’t allow meaningful comparisons, i.e. no semantics available • The solution is to use Word2Vec which uses distributed representation of word in vector space. One-hot encoded vector for ‘Queen’
- 4. WHAT IS A WORD VECTOR? • Distributed representations of word2vec can help encode various aspects of a word • Aspects are represented by elements of the vector and can help define a word • Aspects can represent things like royalty, gender or age in our “little language”
- 5. WHAT IS A WORD VECTOR? • It has been observed that we can perform simple algebraic operations on the word vectors. • We can remove the masculinity aspect from King by performing the vector operation: vector(“King”) – vector(“Man”) • Following that we can add vector(“Woman”) to the result from above and obtain a vector that will be closest to the vector representation of the word Queen.
- 7. Movie review dataset 50K reviews Amazon Laptop review dataset 40K+ reviews Cleanup and pre-processing Word and Document embeddings Logistic regression, XGBoost, SVM etc. Keras word embeddings Keras CNN, Keras Bidirectional LSTM
- 8. DATA OVERVIEW Data source Columns Dataset review count Max review Comments Total Positive Negativ e Positive Negativ e Amazon laptop reviews Review Rating 40K+ ~30K ~10K 20K 3K Distribution mass should be covered by 900 to 1000 characters IMDb movie reviews Review Rating 50K 25K 25K 14K 5K Distribution mass should be covered by 1400 to 1500 characters
- 9. DATA EXPLORATION: REVIEW LENGTH, LAPTOP REVIEWS Laptop dataset review lengths
- 10. DATA EXPLORATION: REVIEW LENGTH, MOVIE REVIEWS Movie dataset review lengths
- 11. DATA EXPLORATION: REVIEW LENGTH Movie dataset review lengths Laptop dataset review lengths
- 12. DATA EXPLORATION: REVIEW COUNT Movie dataset review countLaptop dataset review count
- 13. TEXT PRE-PROCESSING Input • Review string Remove • HTML tags, URLs Convert • To lowercase Split • Into words Remove • Punctuations, Empty Strings, Stop-words Return • Concatenated tokens as a sentence
- 14. EXPLORING DATASET Looking at high frequency words in each dataset using nltk.FreqDist()
- 16. WORD2VEC CBOW MODEL EVALUATION
- 17. WORD2VEC CBOW MODEL EVALUATION
- 18. WORD2VEC CBOW MODEL EVALUATION
- 19. POSITIVE AND NEGATIVE REVIEW WORD CLOUDS • Amazon dataset • IMDb movie review dataset Positive cloud is with white background and negative cloud is with black background
- 20. SENTIMENT ANALYSIS • Word2Vec Word Embedding Based Sentiment Analysis using LogisticRegression • Word2Vec Word Embedding Based Sentiment Analysis using SVC • Word2Vec Word Embedding Based Sentiment Analysis using XGBClassifier
- 21. KERAS CONVOLUTIONAL NEURAL NETWORK • Sentiment Analysis using Keras Convolutional Neural Networks(CNN) • Sentiment Analysis Using Pre- trained Word2Vec Word Embedding To Keras CNN Image credit
- 22. BIDIRECTIONAL LONG SHORT TERM MEMORY • Sentiment Analysis Using Pre- trained Word2Vec Word Embedding To Keras CNN And Bidirectional LSTM • Sentiment Analysis Using Pre- trained Word2Vec Word Embedding To Keras Bidirectional LSTM Image credit
- 23. DOC2VEC: DISTRIBUTED BAG-OF-WORDS • Doc2Vec DBOW Based Sentiment Analysis using LogisticRegression • Doc2Vec DBOW Based Sentiment Analysis using SVC • Doc2Vec DBOW Based Sentiment Analysis using XGBClassifier
- 24. DOC2VEC: DISTRIBUTED MEMORY • DM (Concatenated) • Doc2Vec DMC Based Sentiment Analysis using LogisticRegression • Doc2Vec DMC Based Sentiment Analysis using SVC • Doc2Vec DMC Based Sentiment Analysis using XGBClassifier • DM (Mean) • Doc2Vec DMM Based Sentiment Analysis using LogisticRegression • Doc2Vec DMM Based Sentiment Analysis using SVC • Doc2Vec DMM Based Sentiment Analysis using XGBClassifier
- 25. DOC2VEC: DBOW + DMC AND DBOW + DMM • DBOW + DMC • Doc2Vec DBOW + DMC Based Sentiment Analysis using LogisticRegression • Doc2Vec DBOW + DMC Based Sentiment Analysis using SVC • Doc2Vec DBOW + DMC Based Sentiment Analysis using XGBClassifier • Doc2Vec DBOW + DMC Based Sentiment Analysis using Keras Neural Network • DBOW + DMM • Doc2Vec DBOW + DMM Based Sentiment Analysis using LogisticRegression • Doc2Vec DBOW + DMM Based Sentiment Analysis using SVC • Doc2Vec DBOW + DMM Based Sentiment Analysis using XGBClassifier • Doc2Vec DBOW + DMC Based Sentiment Analysis using Keras Neural Network
- 26. RESULTS: WORD2VEC Model IMDB Movie Reviews Accuracy Amazon Laptop Reviews Train Validation Test Train Validation Test Word2Vec LogisticRegression .8753 .8692 .8706 .9046 .9060 .9009 SVC with linear kernel .8755 .8714 .8690 .9050 .9089 .9001 XGBClassifier .8695 .8540 .8506 .9058 .9057 .8967 Keras Convolutional Neural Networks (CNN) .9994 .8770 .8788 .9992 .9239 .9146 Using Pre-trained Word2Vec Word Embedding Keras CNN .9593 .8444 .8268 .9690 .8969 .8891 Using Pre-trained Word2Vec Word Embedding Keras CNN And Bidirectional LSTM .9356 .8854 .8902 .9567 .9212 .9144 Using Pre-trained Word2Vec Word Embedding Keras Bidirectional LSTM .9011 .8800 .8786 .9418 .9205 .9229
- 27. RESULTS: DOC2VEC SIMPLE MODELS Model IMDB Movie Reviews Accuracy Amazon Laptop Reviews Accuracy Train Validation Test Train Validation Test Doc2Vec DBOW LogisticRegression .8732 .8738 .8778 .8982 .9094 .8955 SVC with linear kernel .8738 .8742 .8766 .8985 .9072 .8969 XGBClassifier .8682 .8500 .8556 .9008 .8964 .8849 Doc2Vec DMC LogisticRegression .5939 .5862 .5986 .8088 .8137 .7961 SVC with linear kernel .5933 .5864 .5936 .8086 .8130 .7956 XGBClassifier .6214 .5952 .5958 .8137 .8193 .7980 Doc2Vec DMM LogisticRegression .8187 .8196 .8174 .8472 .8571 .8307 SVC with linear kernel .8193 .8184 .8190 .8428 .8554 .8280 XGBClassifier .8115 .7858 .7920 .8494 .8525 .8282
- 28. RESULTS: DOC2VEC MODEL COMBOS Model IMDB Movie Reviews Accuracy Amazon Laptop Reviews Accuracy Train Validation Test Train Validation Test DBOW + DMC LogisticRegression .8741 .8738 .8778 .8982 .9099 .8940 SVC with linear kernel .8751 .8744 .8790 .8990 .9072 .8977 XGBClassifier .8692 .8510 .8574 .9000 .8969 .8849 DBOW + DMM LogisticRegression .8813 .8742 .8804 .9024 .9092 .8994 SVC with linear kernel .8809 .8756 .8786 .9033 .9092 .9001 XGBClassifier .8736 .8548 .8590 .9016 .8986 .8854 Combination of Doc2Vec DBOW And Document Embedding and Keras Neural Network .9088 .8742 .8746 .9312 .9040 .9033 Combination of Doc2Vec DBOW And Document Embedding and Keras Neural Network .9295 .8722 .8720 .9475 .9156 .8984
- 29. CONFUSION MATRIX: WORD2VEC Model IMDB Movie Reviews Confusion Matrix with Accuracy Amazon Laptop Reviews Confusion Matrix with Accuracy TN FP FN TP Accura cy TN FP FN TP Accura cy Word2Vec LR 2185 344 303 2168 0.87 554 279 125 3117 0.90 SVC 2182 347 308 2163 0.87 557 276 131 3111 0.90 XGBClassifier 2127 402 345 2126 0.85 535 298 123 3119 0.90 Keras Convolutional Neural Networks(CNN) 2302 227 379 2092 0.88 591 242 106 3136 0.91 Pre-trained Word2Vec Word Embedding To Keras CNN 2110 419 447 2024 0.83 571 262 190 3052 0.89 Pre-trained Word2Vec Word Embedding To Keras CNN And Bidirectional LSTM 2208 321 228 2243 0.89 615 218 131 3111 0.91 Pre-trained Word2Vec Word Embedding To Keras Bidirectional LSTM 2176 353 254 2217 0.88 652 181 133 3109 0.92
- 30. CONFUSION MATRIX: DOC2VEC SIMPLE MODELS Model IMDB Movie Reviews Confusion Matrix with Accuracy Amazon Laptop Reviews Confusion Matrix with Accuracy TN FP FN TP Accura cy TN FP FN TP Accura cy DBOW LogisticRegression 2205 324 287 2184 0.88 530 303 123 3119 0.90 SVC 2204 325 292 2179 0.88 533 300 120 3122 0.90 XGBClassifier 2152 377 345 2126 0.86 467 366 103 3139 0.88 DMC LogisticRegression 1586 943 1064 1407 0.60 2 831 0 3242 0.80 SVC 1654 875 1157 1314 0.59 0 833 0 3242 0.80 XGBClassifier 1452 1077 944 1527 0.60 28 805 18 3224 0.80 DMM LogisticRegression 2064 465 448 2023 0.82 246 587 103 3139 0.83 SVC 2062 467 438 2033 0.82 201 632 69 3173 0.83 XGBClassifier 1981 548 492 1979 0.79 193 640 60 3182 0.83
- 31. CONFUSION MATRIX: DOC2VEC MODEL COMBOS Model IMDB Movie Reviews Confusion Matrix with Accuracy Amazon Laptop Reviews Confusion Matrix with Accuracy TN FP FN TP Accura cy TN FP FN TP Accura cy DBOW + DMC LR 2204 325 286 2185 0.88 524 309 123 3119 0.89 SVC 2210 319 286 2185 0.88 529 304 113 3129 0.90 XGBClassifier 2164 365 348 2123 0.86 472 361 108 3134 0.88 DBOW + DMM LR 2206 323 275 2196 0.88 538 295 115 3127 0.90 SVC 2209 320 287 2184 0.88 538 295 112 3130 0.90 XGBClassifier 2166 363 342 2129 0.86 465 368 99 3143 0.89 DBOW + DMC And Keras Neural Network 2187 342 285 2186 0.87 564 269 125 3117 0.90 DBOW + DMM And Keras Neural Network 2142 387 253 2218 0.87 572 261 153 3089 0.90
- 32. CONCLUSION Keras Bidirectional LSTM and Keras CNN + Bidirectional LSTM • with Pre-trained Word2Vec Word Embedding Keras CNN • With Tokenizer Word2Vec • LogisticRegression > SVC > XGBClassifier Keras CNN • with Pre-trained Word2Vec Word Embedding Word2Vec > Doc2Vec • DBOW > DMM > DMC and DOW + DMC > DMC Also DOW + DMM > DMM • DBOW + DMM > DBOW + DMC
- 33. CONCLUSION Bidirectional LSTM is a Recurrent Neural Network (RNN). RNNs have the advantage of being able to persist information. The network considers current inputs as well as, previously received inputs. Hence, it works really well with sequence data like text, time series, videos, DNA sequences, etc
Editor's Notes
- Good evening folks, today I am going to present my semester project for Data 602 – Introduction to Data Analysis and Machine Learning In this project I am going to carry out Sentiment analysis using both the machine learning library Keras and common classification algorithms like SVM that use Word2Vec embeddings as their features. I will compare the results of these two and present the results in my final report.
- Let’s assume a vocabulary has five words: King, Queen, Man, Woman, Child. A one-hot encoded vector of a word in this language will have 1 in a single position to represent a specific word. All other elements will be zero. Such an encoding can only allow comparisons in form of equality testing. Meaningful comparisons cannot be performed as each word is independent of each other. Word2Vec on the other hand represents words using a distributed representation. Each word represented by a vector is defined by the combination of its various aspects. Aspects are represented in the elements of the vector. As a result, we can have an aspect of royalty, gender, age etc. in our “little language”. Once such a representation is created, we can perform algebraic operations with language. We can remove the masculinity of a King by performing vector(“King”) – vector(“Man”). Then we can add femininity to the result vector by adding vector(“Woman”) to it to obtain a vector that is closest to the vector representation of the word Queen. See image below
- The source for movie review dataset is from Stanford https://ai.stanford.edu/~amaas/data/sentiment/aclImdb_v1.tar.gz And the source URL for the Amazon product review is from UIUC http://sifaka.cs.uiuc.edu/~wang296/Data/LARA/Amazon/AmazonReviews.zip There is no cost to accessing this data. Accessing this data does not require creation of an account. Accessing this data does not violate any laws. The Data Set I am using is amazon laptops review and movie review. IMDb shape: Before Shape of the Data Frame : (50000, 2) After Shape of the Data Frame : (50000, 2) Amazon shape: Before Shape of the Data Frame : (40762, 2) After Shape of the Data Frame : (40762, 2) Performing sentiment analysis. Using Word2Vec word embeddings Classification Algorithms: Logistic regression, XGBoost, SVM, Random Forest Compared results to Keras Convolutional Neural Network
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The term frequency distribution of words in the review is obtained using nltk.FreqDist(). This provides us a rough idea of the main topic in the review dataset.
- Word embedding is a language modeling technique that uses vectors with several dimensions to represent words from large amounts of unstructured text data. Word embeddings can be generated using various methods like neural networks, co-occurrence matrix, probabilistic models, etc. There are two models for generating word embeddings, i.e. CBOW and Skip-gram. CBOW (Continuous Bag of Words) model CBOW model predicts the current word given a context of words. The input layer contains context words and the output layer contains current predicted word. The hidden layer contains the number of dimensions in which to represent current word at output layer. The CBOW architecture is shown in Fig 1.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- The first dataset of laptop product reviews from Amazon’s website contained 40,744 reviews. The dataset contained over 30K positive reviews and close to 10K negative reviews. The longest positive review length contained over 20,000 characters and longest negative review contained close to 3,000 characters. The box plot of review length shows exponential properties. Looking at the graph shown in Fig 5 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 900 to 1,000 words. The review dataset contains just two columns, one with the rating and the other with the review text. The IMDb movie review dataset contains 50,000 reviews. The dataset contains equal number of reviews annotated as positive and negative. The longest positive review length contains about 14,000 characters and the longest negative review contains close to 5,000 characters. Similar to the first dataset, the box plot of review length shows exponential properties. Looking at the graph shown in Fig 6 it can be estimated that the mass of the distribution can probably be covered with a clipped length of 1,400 to 1,500 words. The review dataset contains just two columns, one with the rating and the other with the review text.
- CNN is a class of deep, feed-forward artificial neural networks ( where connections between nodes do not form a cycle) & use a variation of multilayer perceptrons designed to require minimal preprocessing. These are inspired by animal visual cortex. I have taken reference from Yoon Kim paper and this blog by Denny Britz. CNNs are generally used in computer vision, however they’ve recently been applied to various NLP tasks and the results were promising 🙌 .
- Recurrent Neural Network (RNN) is one of the most popular architectures used in Natural Language Processing (NLP) tasks because its recurrent structure is very suitable to process variable length text. RNN can utilize distributed representations of words by first converting the tokens comprising each text into vectors, which form a matrix. And this matrix includes two dimensions: the time-step dimension and the feature vector dimension. Then most existing models usually utilize one-dimensional (1D) max pooling operation or attention-based operation only on the time-step dimension to obtain a fixed-length vector. However, the features on the feature vector dimension are not mutually independent, and simply applying 1D pooling operation over the time-step dimension independently may destroy the structure of the feature representation. On the other hand, applying two-dimensional (2D) pooling operation over the two dimensions may sample more meaningful features for sequence modeling tasks. Compared with the state-of-the-art models, the proposed models achieve excellent performance on 4 out of 6 tasks. Specifically, one of the proposed models achieves highest accuracy on Stanford Sentiment Treebank binary classification and fine-grained classification tasks.
- Doc2Vec can be modeled using paragraph vector distributed bag of words (PV-DBOW or DBOW model) which is a model analogous to Skip-gram in Word2Vec. The document vectors are obtained by training a neural network on the task of predicting a probability distribution of words in a paragraph given a randomly-sampled word from the document.
- Often called paragraph vector distributed memory (PV-DM or DM model) is obtained by training a neural network on the task of inferring a center word based on context words and a context paragraph.
- Often called paragraph vector distributed memory (PV-DM or DM model) is obtained by training a neural network on the task of inferring a center word based on context words and a context paragraph.
