This document describes a process for infiltrating carbon nanotube templates with tungsten to create mechanically robust microstructures. Carbon nanotubes are grown vertically in a pattern and then infiltrated with tungsten using chemical vapor deposition of tungsten hexacarbonyl. Parameters like temperature, geometry, and precursor amount influence the infiltration. Near full infiltration and capping of the carbon nanotube structures is achieved at temperatures above 300°C in an inverted sample geometry close to the precursor source. This process allows creation of tungsten-carbon nanotube composites for applications requiring high temperature or corrosion resistance.
