This document discusses how Cassandra can help optimize key performance indicators like velocity, security, availability, and performance. It explains Cassandra's peer-to-peer architecture with no single point of failure, how it scales horizontally by adding nodes, and its log-structured storage format that makes writes fast with no overhead for read-before-write. It also covers Cassandra's replication across multiple nodes for high availability and data distribution across regions.

1. 1

2. 2

3. We specialize in addressing 5 major KPIS
Velocity - achieve goals faster
Security
Availability
Performance
Cost
And help in strategies to optimize those KPIs
3

4. • Explosion in data volumes
–More types of data tracked
–Higher detail levels
–Retention over time
•Need to manage with existing staff
•Globally-distributed data
•Rise of public clouds for real business use
•Limited budgets and resources
4

5. 5

6. • Peer-to-peer architecture
• No single master or directory node
• Data divided into partitions with primary keys
• Allocated to a node using a hash function
• Clients can connect to any node
6

7. • Additional nodes bring extra storage and processing capacity
• Vertical scaling too
• No built-in size limits
• Data distributed by hash function - no central directory required
7

8. 8

9. • Log-structured data format appends all changes
• Particularly fast for writes
• No read-before-write
• High concurrency through load distribution
• Smart routing to nearest replica
9

10. Log-structured data is a new concept for people coming from relational databases
For speed, we never look at the current data
That means that inserts and updates are the same
In this example, Billy has his first name updated to William
The last line is a deletion, or “tombstone” as referred to in Cassandra, and tracks that
a deletion has taken place
10

11. • Data is replicated across multiple nodes
• Administrator can control how many
• All nodes can serve data
• Peer-to-peer “gossip” of state information
• Automatic retry and routing around failed nodes
11

12. • Supports multiple geographic regions
• Simultaneously active in all
• Automatic replication
• Can run across both your own datacenter and the cloud
• Can be used for workload isolation too
12

13. Easiest way to show is as an example
Assuming replication factor of 3: all data is on all nodes
Insert on A
Data will be replicated everywhere
Buy do you wait until all nodes respond?
What if node C is down?
OK, write one
What if C comes back up?
You read old data
Fix: force read on a majority of nodes (quorum) for strong consistency model
But you trade off overhead doing reads twice, and waiting for two writes
13

14. What if node C is down?
A will hang.
OK, write one
What if C comes back up?
You read old data
Fix: force read on a majority of nodes (quorum) for strong consistency model
But you trade off overhead doing reads twice, and waiting for two writes
14

15. What if C comes back up?
You read old data
(Cassandra has mechanisms to help catch up quickly though)
Fix: force read on a majority of nodes (quorum) for strong consistency model
But you trade off overhead doing reads twice, and waiting for two writes
You can set this at the statement level
15

16. 16

17. 17

18. This afternoon you’ll hear a lot about data modeling in Cassandra
A common theme: don’t treat it like an Excel spreadsheet
Cassandra doesn’t do joins between tables
Instead, data nesting can store similar data together
18

19. • Selects ideally on primary key
• Duplicate data for frequently-used queries
• But ad-hoc queries could have hundreds of combinations
• Not efficient to duplicate at this level
• Need to run aggregate functions: SUM(), GROUP BY, etc
19

20. 20

21. 21

22. DataStax OpsCenter: dashboarding and monitoring tool
One-click management operations like rebalancing
See the status of your entire cluster in one place
22

23. DataStax DevCenter: integrated development for environment
Visual view of database structure
Interactive query execution
23

24. 24

25. 25

26. 26

27. If you’re not quite so skilled on Cassandra, Azure, or both, Pythian can help
(pass onto Jeff?)
34

28. The result is competitive advantage by addressing most companies top KPIs—
velocity, efficiency, security, performance, and availability—through continuous
business transformation and operational excellence.
