Presented at DockerCon 2018 EU, I go through using Docker and the Swarm Orchestrator (a simpler Kuberentes) to stack different tools up from the base OS to a full-featured production server cluster. Also, Sci-Fi. The Video to this deck will be at https://www.bretfisher.com/docker once they are posted.

1. BRET FISHER
Docker Captain, DevOps Dude,
Author of Docker Mastery
Building Your Swarm Tech Stack
bretfisher.com/dockercon18
@bretfisher

2. People ask "Where's my LAMP for container clusters?"
Your solutions will be a "stack" of infrastructure tools
Cloud-native container tools are new
We need patterns and examples of full cluster stacks
Problem: No Server Tool Lives In Isolation

3. Build examples of full-ish stacks on different tools
Options for solo to medium-sized DevOps/Ops teams
Use Docker Swarm latest stable as orchestrator
Limit cloud vendor lock-in*
4 Goals for Today
* Lock-in: A service I can't swap out in my server stack

4. The Duality of Container Infrastructure
“It was the best of times,
it was the worst of times,
it was the age of wisdom,
it was the age of foolishness,
it was the epoch of belief,
it was the epoch of incredulity...”
Charles Dickens
A Tale of Two Cities, 1859

5. Clusters are Complex
Start small and simple, grow them as you grow

6. EE Platform Architecture
PhysicalVirtualizationPublic Cloud
Platform
Security
Developer
Services
Registry
Services
Access
Policies
App Lifecycle
Management
Automation &
Extensibility
Networking Orchestration Storage
Container Engine
ENTERPRISE EDITION PLATFORM

7. CE Platform Architecture
Public Cloud
Overlay Swarm
Container Engine
COMMUNITY EDITION PLATFORM
PhysicalVirtualization
Platform
Security

9. Sci-Fi!
Am I Right!

10. Sci-Fi!
Am I Right!

11. Epic Battle Royale, on Swarm
dogvs.cat

12. Epic Battle Royale, on Swarm
dogvs.cat
VS

13. Epic Battle Royale, on Swarm
dogvs.cat
Sci-Fi Sounds Edition

14. dogvs.cat App Services
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

15. dogvs.cat App Services
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat
(Stack Files)

16. dogvs.cat
Swarm CE,
(Han) Solo Sysadmin

17. Cloud agnostic, minimal infra
Apps auto-recover on node fail
Incoming TLS
Centralized logging
Centralized monitoring
Healthcheck all containers
Infra Requirements of dogvs.cat
Performance auto-scaling
Self-healing nodes
Support serverless functions
Services highly available
Han Solo Requirements Optional Requirements for Later

18. 3+ Droplets (Ubuntu 18.04)
Block Storage (Volumes)
Load Balancer (incoming HTTP)
Digital Ocean dogvs.cat
Services Needed for High Availability

19. App Services
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

20. App Services + L7 Proxy
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

21. App Services + L7 Proxy + Overlay
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

22. App Services + L7 Proxy + Ops
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

23. App Services + L7 Proxy + Ops
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

24. Cluster + External Load Balancer
www.dogvs.cat vote.dogvs.cat blog.dogvs.catresult.dogvs.cat

25. Open Source Stack
HW / OS Docker Machine + Digital Ocean
Runtime Docker CE
Orchestration Docker Swarm
Networking Docker Swarm Overlay
Storage REX-Ray + Digital Ocean Volumes
Layer 7 Proxy Traefik + Let's Encrypt
Central Logging Elastic ELK
Central Monitoring Prometheus + Grafana
Swarm GUI Portainer

26. Deploy Nodes: Docker Machine
./create-servers.sh
./enable-monitoring.sh
./create-swarm.sh

27. Deploy Storage: RexRay Plug-in
docker stack deploy -c stack-rexray.yml rexray

28. Deploy Proxy Stack: Traefik with Let's Encrypt
docker stack deploy -c stack-proxy.yml proxy
http://www.dogvs.cat:8080/dashboard/

29. Deploy Ops Stacks:
Prometheus + ELK + Portainer
docker stack deploy -c stack-swarmprom.yml prom
docker stack deploy -c stack-elk.yml elk
docker stack deploy -c stack-portainer.yml portainer

30. Our Apps: Voting + Ghost + Static Site
docker stack deploy -c stack-ghost.yml ghost
docker stack deploy -c stack-voting.yml vote
docker stack deploy -c stack-menu.yml menu

31. Deploy Stacks: Maintenance Tasks
docker stack deploy -c stack-prune.yml prune
backups (in stack file with app)

32. Day Two Operations: Updates
stack deploy ∞
micromanage update_config and healthcheck
tune your limits and reservations

33. Swarm CE,
Trek Tag-Team DevOps
dogvs.cat

34. Create Swarm with Terraform
Moving beyond docker-machine for multi-admin

35. Docker for AWS/Azure
*for CE only

36. Remote Management Bonus
18.09 has SSH endpoints for docker CLI !!
DOCKER_HOST=ssh://user@server docker ps

37. Windows Server 2019 Workers
Swarm and overlay network feature parity!

38. Windows Server 2019 Workers
Swarm and overlay network feature parity!

39. Our Apps using Docker App
docker-app deploy dogvscat/ghost:0.1.0
docker-app deploy dogvscat/voting:0.1.0
docker-app deploy dogvscat/menu:0.1.0
* Go check it out at github.com/docker/app

40. Security?
host setup scanning: Docker Bench
image scanning: Aqua Microscanner
behavior monitoring: Sysdig Falco
user namespaces

41. Swarm Enterprise,
Amazonian DevOps
dogvscat.biz
or

42. Complex Infrastructure, Harder Deployment
"How can I deploy many multi-tier
app on a many servers, with all the
b e l l s a n d w h i s t l e s o f H A
orchestration, have load balancing
at all levels, with failover and
auto recovery?"
Amazonian
Team

43. CE Platform Architecture
PhysicalVirtualizationPublic Cloud
Platform
Security
Networking Orchestration
Container Engine
COMMUNITY EDITION PLATFORM

44. EE Platform Architecture
PhysicalVirtualizationPublic Cloud
Platform
Security
Developer
Services
Registry
Services
Access
Policies
App Lifecycle
Management
Automation &
Extensibility
Networking Orchestration Storage
Container Engine
ENTERPRISE EDITION PLATFORM

45. No More One Size Fits All
Docker for
AWS
Docker for
Azure
for CE only

46. Reference
Architecture
Automation
Tools
Ecosystem
Integration
Docker Certified Infrastructure

47. DCI AWS

48. DCI AWS

49. Docker EE on AWS Stack
HW / OS Terraform + Ansible + AWS
Runtime Docker EE
Orchestration Docker Swarm
Networking Docker Swarm Overlay
Storage Docker Cloudstor EBS/EFS
Layer 7 Proxy HTTP Routing Mesh (Interlock+Nginx)
Registry Docker EE DTR
Central Logging AWS Cloudwatch Logs
Central Monitoring AWS Cloudwatch + Telegraph
Swarm GUI Docker EE UCP

50. Summary
Infrastructure as code, make everything repeatable
No "special" nodes, use remote management
Grow as you go, assume you'll resize
Look for compose files of popular tools to make stacks
Don't throw out the good in search of the perfect

51. Where to Go From Here
Automating Docker Enterprise 5:25 this room
Mission-Critical Migration to Multi-Cluster Kubernetes
Wed 2pm room 113
Swarm Intro Workshop
Today 4pm room 133
Wed 1:30pm room 133
Swarm Hallway Track Wed 4pm

52. I'd like to
thank the
internet

53. Support
the open source
you use

54. PLEASE USE SESSION
SURVEY IN EVENTSPACE APP
Thanks! !
bretfisher.com/dockercon18
"Building Your Swarm Tech Stack"
