This document provides information on Parker's electromechanical products including planetary gearheads, multi-drive gearheads, bevel/spur gearheads, gearmotors, and related products and services. It describes key product series, specifications, configurations, and applications. Example applications discussed include using gearheads and motors for plastic bottle extrusion machinery and food/packaging automation equipment.
The document provides information about Parker Hannifin Corporation and its products. Parker is a leading global supplier of motion and control technologies with annual sales over $10 billion. It offers a wide range of precision gearheads, gearmotors, and integrated motion systems for industrial, mobile, and aerospace applications. Parker provides customized solutions and has manufacturing facilities worldwide to enable fast delivery and global support through its large distribution network.
This document is a catalog for Parker electromechanical products including planetary gearheads, multi-drive gearheads, bevel/spur gearheads, gearmotors, and related products. It provides an overview of the various product series, their specifications including frame size, torque, load capacity, backlash, and intended applications. Configuration options and available ratios are also discussed. The catalog aims to help customers select the optimal solution for their needs.
Rotating Precision Mechanisms, Inc. (RPM) has been providing precision positioning products for over 31 years. RPM assists customers in defining requirements and develops modular hardware using proven components to reduce costs. RPM's product line includes rotators, pedestals, gimbals and platforms in geared and direct-drive configurations for ground, airborne and shipboard applications. RPM uses computer-aided design tools and has over 250 years of engineering experience to precisely manufacture and test positioning systems.
Parker Hannifin is a Fortune 300 company and world's leading supplier of motion control components and systems. It offers customers electromechanical, hydraulic, pneumatic or computer-controlled motion solutions. Parker's team of engineers can integrate pneumatic, structural and electromechanical products into customized system solutions. It has factories globally to ensure fast delivery and the largest distribution network for quick support worldwide. Parker provides training and around-the-clock technical support for its motion control products and solutions.
Gear Testers , CNC Gear Measuring Machines , Automatic inspection system for ...Prime Technologies
Welcome To Prime Technologies
We are in the field of Gear Measuring machines and 100% Automated inspection and sorting Machines for Auto Parts. Prime Technologies was established in the year 1991 and we are devoted to Gear and Industrial Metrology
Gear Measuring Machines
CNC Gear Testers /CNC Gear Measuring center/ Computerised Gear Roll & Noise Tester
Prime Technologies offers complete range of CNC Gear measuring Machines from world leaders
In the field of Gear Metrology R&P Metrology , Carl Zeiss , Frenco , INPROQ , D&P etc
Rebuilt , PC Retrofitted Gear Testers
We also offer Rebuilt & PC Retrofit Gear Testers of various makes and models such
Maag pH60 /SP60 /PH100 , Hofler EFRS 401/631 ,ZP260 , Klingelnberg PFS600/PFSU640
Goulder Mikron IL 600 , David Brown18T ,Osaka Seimitsu , FrencoSH450 , etc
100% High Speed Automatic Inspection ,Sorting Machine for Auto parts
Don’t ship another bad part - Prime Tech can offer Zero Reject 100% Inspection Quality
At Prime Technologies, inspection goes way beyond simple machine vision. With a broad spectrum of tools in our arsenal, we can offer a variety of inspection equipment from World leaders in this field. From robot-integrated machine vision for high speed sorting and packaging, to ultra-high resolution measurement systems to verify dimensions and inspection of surface craks on precision machined components, Prime Tech can offer inspection machines to complete the most demanding inspections.
Some Precision parts for which we provide Inspection, Measuring & Sorting Machines are
1. Bearings 2.fasteners 3. Gaskets 4.Disc Springs 5. Brake Disc 6.Spool 7. Rotor 8.Cam Ring 9. Camshaft 10.Crankshaft 11.Camring 12. Casing and any mass produced precision part
Training Division :
Prime Technologies with more than 3 decades of experience has developed expertise in the field of Gear Metrology and Industrial Metrology .
We offer provide high quality training to Industry professionals, Engineering college Students
In 1. Gear Metrology 2. Surface and Form Metrology
3. Heat Treatment etc
Harmonic Drive precision gears are used in critical applications like robotics, manufacturing equipment, and spaceflight. They offer zero backlash transmission with high accuracy, repeatability, and torque density. The document discusses Harmonic Drive gear components, actuators, and servo drivers that are suitable for various precision motion control applications.
редукторы серий TQ/TQF/TQK/TR/MP/LC/LCK/SL/KR BonfiglioliArve
Bonfiglioli has been designing and developing innovative and reliable power transmission and control solutions for industry, mobile machinery and renewable energy applications since 1956. The document provides an overview of Bonfiglioli's product portfolio including precision planetary gearboxes for servo applications (TQ, TQF, TQK, TR, MP, LC, LCK, SL, KR series) and technical information on symbols, units, output speeds, torques, forces, and other specifications.
Northline Industrial provides repair and testing services for industrial automation equipment including robots, servo motors, PLCs, drives, and more. They have test fixtures for various equipment from manufacturers like ABB, Allen Bradley, Fanuc, and others. The document provides details on specific systems they can test and repair, such as ABB robot models and Allen Bradley motor controls.
The document provides information about Parker Hannifin Corporation and its products. Parker is a leading global supplier of motion and control technologies with annual sales over $10 billion. It offers a wide range of precision gearheads, gearmotors, and integrated motion systems for industrial, mobile, and aerospace applications. Parker provides customized solutions and has manufacturing facilities worldwide to enable fast delivery and global support through its large distribution network.
This document is a catalog for Parker electromechanical products including planetary gearheads, multi-drive gearheads, bevel/spur gearheads, gearmotors, and related products. It provides an overview of the various product series, their specifications including frame size, torque, load capacity, backlash, and intended applications. Configuration options and available ratios are also discussed. The catalog aims to help customers select the optimal solution for their needs.
Rotating Precision Mechanisms, Inc. (RPM) has been providing precision positioning products for over 31 years. RPM assists customers in defining requirements and develops modular hardware using proven components to reduce costs. RPM's product line includes rotators, pedestals, gimbals and platforms in geared and direct-drive configurations for ground, airborne and shipboard applications. RPM uses computer-aided design tools and has over 250 years of engineering experience to precisely manufacture and test positioning systems.
Parker Hannifin is a Fortune 300 company and world's leading supplier of motion control components and systems. It offers customers electromechanical, hydraulic, pneumatic or computer-controlled motion solutions. Parker's team of engineers can integrate pneumatic, structural and electromechanical products into customized system solutions. It has factories globally to ensure fast delivery and the largest distribution network for quick support worldwide. Parker provides training and around-the-clock technical support for its motion control products and solutions.
Gear Testers , CNC Gear Measuring Machines , Automatic inspection system for ...Prime Technologies
Welcome To Prime Technologies
We are in the field of Gear Measuring machines and 100% Automated inspection and sorting Machines for Auto Parts. Prime Technologies was established in the year 1991 and we are devoted to Gear and Industrial Metrology
Gear Measuring Machines
CNC Gear Testers /CNC Gear Measuring center/ Computerised Gear Roll & Noise Tester
Prime Technologies offers complete range of CNC Gear measuring Machines from world leaders
In the field of Gear Metrology R&P Metrology , Carl Zeiss , Frenco , INPROQ , D&P etc
Rebuilt , PC Retrofitted Gear Testers
We also offer Rebuilt & PC Retrofit Gear Testers of various makes and models such
Maag pH60 /SP60 /PH100 , Hofler EFRS 401/631 ,ZP260 , Klingelnberg PFS600/PFSU640
Goulder Mikron IL 600 , David Brown18T ,Osaka Seimitsu , FrencoSH450 , etc
100% High Speed Automatic Inspection ,Sorting Machine for Auto parts
Don’t ship another bad part - Prime Tech can offer Zero Reject 100% Inspection Quality
At Prime Technologies, inspection goes way beyond simple machine vision. With a broad spectrum of tools in our arsenal, we can offer a variety of inspection equipment from World leaders in this field. From robot-integrated machine vision for high speed sorting and packaging, to ultra-high resolution measurement systems to verify dimensions and inspection of surface craks on precision machined components, Prime Tech can offer inspection machines to complete the most demanding inspections.
Some Precision parts for which we provide Inspection, Measuring & Sorting Machines are
1. Bearings 2.fasteners 3. Gaskets 4.Disc Springs 5. Brake Disc 6.Spool 7. Rotor 8.Cam Ring 9. Camshaft 10.Crankshaft 11.Camring 12. Casing and any mass produced precision part
Training Division :
Prime Technologies with more than 3 decades of experience has developed expertise in the field of Gear Metrology and Industrial Metrology .
We offer provide high quality training to Industry professionals, Engineering college Students
In 1. Gear Metrology 2. Surface and Form Metrology
3. Heat Treatment etc
Harmonic Drive precision gears are used in critical applications like robotics, manufacturing equipment, and spaceflight. They offer zero backlash transmission with high accuracy, repeatability, and torque density. The document discusses Harmonic Drive gear components, actuators, and servo drivers that are suitable for various precision motion control applications.
редукторы серий TQ/TQF/TQK/TR/MP/LC/LCK/SL/KR BonfiglioliArve
Bonfiglioli has been designing and developing innovative and reliable power transmission and control solutions for industry, mobile machinery and renewable energy applications since 1956. The document provides an overview of Bonfiglioli's product portfolio including precision planetary gearboxes for servo applications (TQ, TQF, TQK, TR, MP, LC, LCK, SL, KR series) and technical information on symbols, units, output speeds, torques, forces, and other specifications.
Northline Industrial provides repair and testing services for industrial automation equipment including robots, servo motors, PLCs, drives, and more. They have test fixtures for various equipment from manufacturers like ABB, Allen Bradley, Fanuc, and others. The document provides details on specific systems they can test and repair, such as ABB robot models and Allen Bradley motor controls.
The SPH series from GAM features helical gears that provide higher torque and precision over other gear reducers. The SPH was designed with special attention to every aspect to deliver powerful and efficient performance for demanding servo applications. It uses helical gears, optimized bearings, and a rigid housing to smoothly and quietly deliver torque while accommodating high loads. The SPH comes in different configurations and customizable options to flexibly meet application needs.
The document is a test fixture bulletin from Northline Industrial that provides information on various industrial automation equipment repair and testing services. It lists over 70 different automation systems and components that Northline has the ability to repair, including robots, servo motors, drives, controllers and other industrial equipment from manufacturers like ABB, Fanuc, Mitsubishi, and others. For each system, it provides details on the specific repairs and components that can be tested and validated on Northline's test fixtures to ensure quality repairs.
This document provides information on GAM's line of high precision gear reducers, couplings, and linear mounting products. It includes an overview of the company, product selection guides, specifications for various inline and right angle gear reducer series, as well as couplings and linear mounting kits. The SPH series is highlighted as GAM's highest performing inline planetary gear reducer, featuring helical gears for smooth and precise torque transmission under demanding operating conditions.
MENAISCO is a MENA-based engineering services company with over 50 years of experience in Saudi Arabia and other regions. It has over 800 professionals working across multiple sectors including power, water, oil and gas, and petrochemicals. The company provides a wide range of engineering services including design, construction management, commissioning, and operations and maintenance. It has successfully completed many large projects for clients such as GE, KBR, Aramco, and Gas Natural Fenosa across the MENA region.
Portable Power provides 24/7 support and servicing for generators to ensure minimal downtime. Their technicians are available at all times to conduct repairs, scheduled maintenance, and respond to breakdowns. The company offers on-site repairs, planned servicing, spare parts, and backup generators during failures. Their goal is to keep generators functioning properly through preventative maintenance and rapid response.
Craig Technologies Aerospace and Defense Manufacturing Center OverviewCarol Craig
Craig Technologies is a full-service engineering, technology and manufacturing company specializing in aerospace and defense. They provide services including software development, systems integration, engineering, training development, modeling and simulation, logistics support, research and development, and program support. They have capabilities in precision machining, specialty manufacturing, avionics, testing and evaluation, and design.
Nidec asi capability overview for lng and oil&gas applicationsNidec Corporation
Nidec ASI has over 40 years of experience serving the oil and gas industry. They provide electric drive systems, motors, and generators for applications across the oil and gas supply chain from extraction to distribution. Nidec takes an integrated engineering approach to design customized solutions that optimize performance, reliability, efficiency and costs.
Craig Technologies Aerospace Solutions (CTAS) supports your projects from concept to real-world
application or at any scalable solution in-between. CTAS takes pride in responding to the everchanging
needs of our customers by placing an emphasis on evaluating our manufacturing
processes and making continual improvements. Our small business flexibility, lean management
team and industry-leading employee benefits help us deliver exceptional customer-driven solutions
and a quick and cost-effective solution to any priority need.
Craig Technologies Aerospace and Defense Manufacturing Center (ADMC) Spec SheetCarol Craig
This document provides information about Craig Technologies, an aerospace and defense manufacturing company. It summarizes that Craig Technologies offers a range of manufacturing and engineering services at its 161,000 square foot facility in Cape Canaveral, Florida, including precision machining, avionics, testing, and design. It also lists commercial customers and capabilities.
The SPH series features helical gearing from GAM that provides a new level of power and precision for demanding servo applications. It combines design and engineering to deliver GAM's best inline planetary gear reducer. The SPH is highly powerful and efficient yet smooth and quiet. It undergoes rigorous testing and manufacturing methods to ensure high quality and performance.
Ascent Energy provides recruitment, staffing, and project management services to the global energy sector, including oil and gas, power generation, and alternative energy. They have expertise recruiting specialists and executing large project staffing contracts internationally. Ascent Energy aims to be a leading global partner for recruitment and mobility services to energy companies. Their clients include major oil and gas corporations and utility firms operating worldwide.
geared motor manufacturers in india| geared electric motorsara patil
adept motors provide the wide variety of the gear motors great quality.adept geared motors are configured from a modular range of motors and gearboxes that are designed for a perfectly
Muhammad Kashif Rafiq is an electrical engineer with over 10 years of experience testing and commissioning substations in Saudi Arabia. He is currently a Testing & Commissioning Engineer at Hyundai Heavy Industries Co Limited in Al Shuqaiq, KSA, where his responsibilities include testing various switchgear equipment, transformers, generators, and more. Previously, he worked as a Testing & Commissioning Engineer and Site Electrical Engineer in Saudi Arabia, and held electrical supervisory and technician roles in Pakistan. He is seeking new opportunities that utilize his strong technical and management skills.
geared motor manufacturers in india| geared electric motorsara patil
adept motors provide the wide variety of the gear motors great quality.adept geared motors are configured from a modular range of motors and gearboxes that are designed for a perfectly
Electronic Power Design is an engineering company that designs and integrates electrical power systems worldwide. Founded in 1986, it has over 300 employees and facilities in the US, China, Singapore, and Brazil. EPD is considered a top provider of integrated electrical power systems for industries like oil and gas, marine, mining, and industrial plants. It offers services from design and engineering to manufacturing, installation, and commissioning of customized automated power solutions.
Galil presentation advanced motion control techniques for nanopositioning ap...Electromate
This document discusses advanced motion control techniques for nanopositioning applications. It provides an overview of Galil Motion Control, including their product lineup and technical support offerings. Key topics covered include Galil controllers and drives, the Galil control filter for precision motion control, and applications in medical and biotech industries.
Alan D. Tolbert has over 20 years of experience managing telecom and CTI environments globally. He is currently the Global Telecom/CTI Manager at Verint Systems, where he oversees telecom teams in multiple countries and manages several large call testing environments incorporating TDM and IP technologies. Previously, he held telecom and operations management roles at MCI Worldcom and worked as a voice and data specialist performing installations.
This document provides information on linear motor products from ElectroCraft, including stepper and DC linear actuators, drives, and accessories. It discusses typical applications for linear actuators. The document provides specifications, performance curves, and selection information for various linear actuator and drive models to help customers choose the appropriate product for their needs. It also offers customization and engineering support services from ElectroCraft.
This document provides information on brushless DC motors and drives from ElectroCraft, including their RapidPower, RapidPower Plus, EA-Series, SC-Series, ACS-Series, ACE-Series, PFC-Series and PRO Series product lines. It describes the purpose, features, and applications of each product line. The document is intended as a quick reference guide for ElectroCraft products and not as a replacement for technical documentation or proper standards.
This document provides information on ElectroCraft's line of permanent magnet DC motors, including their DirectPower and DirectPower Plus series of small to medium PMDC motors, as well as their DA-Series and SC-Series of brushless DC motor drives. It includes specifications, typical applications, product descriptions, and configuration options to help customers select the appropriate motor or drive for their application.
This document is a catalog for ElectroCraft motors and drives that provides:
1) An overview of ElectroCraft's TorquePower, TorquePower Plus, and TorquePower Enhanced stepper motor series for sizes from Nema 11 to 42.
2) Details on the SA-Series and PRO Series drives that are compatible with the motors.
3) Examples of applications that can benefit from ElectroCraft stepper motors like medical equipment, packaging machines, and 3D printers.
The SPH series from GAM features helical gears that provide higher torque and precision over other gear reducers. The SPH was designed with special attention to every aspect to deliver powerful and efficient performance for demanding servo applications. It uses helical gears, optimized bearings, and a rigid housing to smoothly and quietly deliver torque while accommodating high loads. The SPH comes in different configurations and customizable options to flexibly meet application needs.
The document is a test fixture bulletin from Northline Industrial that provides information on various industrial automation equipment repair and testing services. It lists over 70 different automation systems and components that Northline has the ability to repair, including robots, servo motors, drives, controllers and other industrial equipment from manufacturers like ABB, Fanuc, Mitsubishi, and others. For each system, it provides details on the specific repairs and components that can be tested and validated on Northline's test fixtures to ensure quality repairs.
This document provides information on GAM's line of high precision gear reducers, couplings, and linear mounting products. It includes an overview of the company, product selection guides, specifications for various inline and right angle gear reducer series, as well as couplings and linear mounting kits. The SPH series is highlighted as GAM's highest performing inline planetary gear reducer, featuring helical gears for smooth and precise torque transmission under demanding operating conditions.
MENAISCO is a MENA-based engineering services company with over 50 years of experience in Saudi Arabia and other regions. It has over 800 professionals working across multiple sectors including power, water, oil and gas, and petrochemicals. The company provides a wide range of engineering services including design, construction management, commissioning, and operations and maintenance. It has successfully completed many large projects for clients such as GE, KBR, Aramco, and Gas Natural Fenosa across the MENA region.
Portable Power provides 24/7 support and servicing for generators to ensure minimal downtime. Their technicians are available at all times to conduct repairs, scheduled maintenance, and respond to breakdowns. The company offers on-site repairs, planned servicing, spare parts, and backup generators during failures. Their goal is to keep generators functioning properly through preventative maintenance and rapid response.
Craig Technologies Aerospace and Defense Manufacturing Center OverviewCarol Craig
Craig Technologies is a full-service engineering, technology and manufacturing company specializing in aerospace and defense. They provide services including software development, systems integration, engineering, training development, modeling and simulation, logistics support, research and development, and program support. They have capabilities in precision machining, specialty manufacturing, avionics, testing and evaluation, and design.
Nidec asi capability overview for lng and oil&gas applicationsNidec Corporation
Nidec ASI has over 40 years of experience serving the oil and gas industry. They provide electric drive systems, motors, and generators for applications across the oil and gas supply chain from extraction to distribution. Nidec takes an integrated engineering approach to design customized solutions that optimize performance, reliability, efficiency and costs.
Craig Technologies Aerospace Solutions (CTAS) supports your projects from concept to real-world
application or at any scalable solution in-between. CTAS takes pride in responding to the everchanging
needs of our customers by placing an emphasis on evaluating our manufacturing
processes and making continual improvements. Our small business flexibility, lean management
team and industry-leading employee benefits help us deliver exceptional customer-driven solutions
and a quick and cost-effective solution to any priority need.
Craig Technologies Aerospace and Defense Manufacturing Center (ADMC) Spec SheetCarol Craig
This document provides information about Craig Technologies, an aerospace and defense manufacturing company. It summarizes that Craig Technologies offers a range of manufacturing and engineering services at its 161,000 square foot facility in Cape Canaveral, Florida, including precision machining, avionics, testing, and design. It also lists commercial customers and capabilities.
The SPH series features helical gearing from GAM that provides a new level of power and precision for demanding servo applications. It combines design and engineering to deliver GAM's best inline planetary gear reducer. The SPH is highly powerful and efficient yet smooth and quiet. It undergoes rigorous testing and manufacturing methods to ensure high quality and performance.
Ascent Energy provides recruitment, staffing, and project management services to the global energy sector, including oil and gas, power generation, and alternative energy. They have expertise recruiting specialists and executing large project staffing contracts internationally. Ascent Energy aims to be a leading global partner for recruitment and mobility services to energy companies. Their clients include major oil and gas corporations and utility firms operating worldwide.
geared motor manufacturers in india| geared electric motorsara patil
adept motors provide the wide variety of the gear motors great quality.adept geared motors are configured from a modular range of motors and gearboxes that are designed for a perfectly
Muhammad Kashif Rafiq is an electrical engineer with over 10 years of experience testing and commissioning substations in Saudi Arabia. He is currently a Testing & Commissioning Engineer at Hyundai Heavy Industries Co Limited in Al Shuqaiq, KSA, where his responsibilities include testing various switchgear equipment, transformers, generators, and more. Previously, he worked as a Testing & Commissioning Engineer and Site Electrical Engineer in Saudi Arabia, and held electrical supervisory and technician roles in Pakistan. He is seeking new opportunities that utilize his strong technical and management skills.
geared motor manufacturers in india| geared electric motorsara patil
adept motors provide the wide variety of the gear motors great quality.adept geared motors are configured from a modular range of motors and gearboxes that are designed for a perfectly
Electronic Power Design is an engineering company that designs and integrates electrical power systems worldwide. Founded in 1986, it has over 300 employees and facilities in the US, China, Singapore, and Brazil. EPD is considered a top provider of integrated electrical power systems for industries like oil and gas, marine, mining, and industrial plants. It offers services from design and engineering to manufacturing, installation, and commissioning of customized automated power solutions.
Galil presentation advanced motion control techniques for nanopositioning ap...Electromate
This document discusses advanced motion control techniques for nanopositioning applications. It provides an overview of Galil Motion Control, including their product lineup and technical support offerings. Key topics covered include Galil controllers and drives, the Galil control filter for precision motion control, and applications in medical and biotech industries.
Alan D. Tolbert has over 20 years of experience managing telecom and CTI environments globally. He is currently the Global Telecom/CTI Manager at Verint Systems, where he oversees telecom teams in multiple countries and manages several large call testing environments incorporating TDM and IP technologies. Previously, he held telecom and operations management roles at MCI Worldcom and worked as a voice and data specialist performing installations.
This document provides information on linear motor products from ElectroCraft, including stepper and DC linear actuators, drives, and accessories. It discusses typical applications for linear actuators. The document provides specifications, performance curves, and selection information for various linear actuator and drive models to help customers choose the appropriate product for their needs. It also offers customization and engineering support services from ElectroCraft.
This document provides information on brushless DC motors and drives from ElectroCraft, including their RapidPower, RapidPower Plus, EA-Series, SC-Series, ACS-Series, ACE-Series, PFC-Series and PRO Series product lines. It describes the purpose, features, and applications of each product line. The document is intended as a quick reference guide for ElectroCraft products and not as a replacement for technical documentation or proper standards.
This document provides information on ElectroCraft's line of permanent magnet DC motors, including their DirectPower and DirectPower Plus series of small to medium PMDC motors, as well as their DA-Series and SC-Series of brushless DC motor drives. It includes specifications, typical applications, product descriptions, and configuration options to help customers select the appropriate motor or drive for their application.
This document is a catalog for ElectroCraft motors and drives that provides:
1) An overview of ElectroCraft's TorquePower, TorquePower Plus, and TorquePower Enhanced stepper motor series for sizes from Nema 11 to 42.
2) Details on the SA-Series and PRO Series drives that are compatible with the motors.
3) Examples of applications that can benefit from ElectroCraft stepper motors like medical equipment, packaging machines, and 3D printers.
The document discusses Parker Hannifin Corporation, a manufacturer of motion control components and systems. It describes Parker as the world's leading supplier of electromechanical, hydraulic, pneumatic, and computer-controlled motion systems. Parker offers complete engineered motion control solutions and provides global support through manufacturing, distribution, training and emergency services.
Haydon Kerk Motion Solutions specializes in precision linear motion products including lead-screw assemblies, stepper motor linear actuators, and motorized and non-motorized linear rails and slides. Their catalog provides information on these product lines, which are used in applications requiring precision motion such as medical equipment, laboratory instrumentation, and automation. The document outlines the features and specifications of their lead-screw assemblies, including lead-screws, nuts, and accessories in Section 1, and stepper motor linear actuators in Section 2. Section 3 covers their linear rails and slides products.
This document provides an overview and table of contents for a precision linear motion products catalog and design guide. It summarizes Haydon Kerk Motion Solutions' portfolio of leadscrew assemblies, stepper motor linear actuators, and motorized/non-motorized linear rails and slides. It also provides brief descriptions of the company, its facilities, certifications, and parent company AMETEK.
Torque systems brushless_servomotor_product_guideElectromate
This document provides information about brushless servomotors from Torque Systems, including an overview of their standard and custom integration options, engineering design process, and product specifications. It details 17 motor platforms with 12 winding configurations each, offering configurable solutions to meet unique application needs. Dimensional specifications are provided for each motor platform.
The document is a catalog from Kollmorgen that describes their line of servo drives, motors, and motion control products. It includes:
- The AKD series of Ethernet-based servo drives that provide high performance and integrate easily into applications. They work seamlessly with Kollmorgen motors.
- A range of scalable programming options for the AKD drives from basic torque/velocity control to multi-axis synchronization with the Automation Suite.
- Other Kollmorgen products like linear motors, gearheads, and servomotors that pair well with the AKD drives for optimized motion control solutions.
Torque systems brush_servomotor_product_guideElectromate
This document provides information on torque systems and brush DC servomotors from ITT Torque Systems. It discusses the company's ability to customize solutions and lists standard integration options including brakes, encoders, windings, and gearheads. Tables show specifications for multiple motor platforms including torque, power, and inertia. The document also includes dimensional information and diagrams for motor sizing.
This document is the 2008 product catalog for Applied Motion Products. It introduces new products for 2008, including new ST drives, and highlights a new catalog format with quicklinks to individual product pages on their website. The catalog includes information on step motor and servo motor drives and controllers, motors, gearheads, and software for configuring and programming the devices. Applied Motion Products is celebrating 30 years in motion control and is focused on providing flexible, high-quality motion control solutions across various industries.
The document is a selection guide for Kollmorgen's VLM brushless servomotor line. It provides an overview of the VLM2x and VLM3x motor models, including their dimensional data, performance specifications, and curves. It also discusses bearing fatigue, connector options, and model nomenclature. The guide is intended to help users select the appropriate VLM motor for their application based on its torque, power, and physical requirements.
This document provides information on ElectroCraft's integrated motor drives catalog, including their PT, PR, and PS series integrated motor drive products. It describes the key features and specifications of the drives, such as their motor types, sizes, torque/force ratings, electrical specifications, integrated motion controller functionality, software, and accessories. The document is intended to be a quick reference guide for the integrated motor drives and their configuration.
The document provides information about various power transmission products from multiple manufacturers, including linear motion guides, ball screws, actuators and other motion control solutions from THK; motors, pumps, and air moving devices from AMETEK; custom motion control solutions from Promess; and linear actuators from Haydon Kerk. It also discusses trends in the power transmission industry such as the increasing demand for complete system solutions over individual components and the proliferation of mechanical motion components in applications.
Numatics, Inc. is a leading manufacturer of pneumatic products and motion control products. Their broad spectrum of standard, custom developed products and application components have made a significant impact on pneumatic innovation as well as pneumatic and motion control technology.
Numatics Express Shipping Program guarantees† product
shipment in two, three or five business days. Unlike most traditional quick ship programs, the Numatics Express Shipping Program includes the most comprehensive offering
in the industry. This program encompasses the range and options that you require!
RK Automation Solutions offers a wide range of flexible automation products and solutions. They provide both off-the-shelf and custom solutions for their customers' needs. Their in-house engineering and manufacturing capabilities allow them to offer complete system solutions from design to setup. They aim to be a flexible single-source partner for their customers' automation needs.
We take the pleasure of introducing ourselves as one of the leading organization involved in manufacturing and maintenance of various types and ratings of electrical motors and electro-mechanical jobs.
We take the pleasure of introducing ourselves as one of the leading organization involved in manufacturing and maintenance of various types and ratings of electrical motors and electro-mechanical jobs.
TPS provides rolling stock maintenance, repair, and overhaul (MRO) services for auxiliary power units and other electrical systems. It has over 40 years of experience in power electronics and electrical machines. TPS offers a range of MRO services including repairs, upgrades, component replacement, and long-term service agreements. It has infrastructure for manufacturing, testing, and MRO work and aims to provide faster turnaround times and obsolescence management.
Cast Craft Private Limited is an ISO 9001:2008 certified company located in Bangalore, India that provides precision machined components, sub-assemblies, and full assemblies. It has strengths in one-stop sourcing, quality delivery and cost control, contract manufacturing, metallurgy expertise, and experience with international standards. Specifically, Cast Craft has experience since 2006 manufacturing hydraulic and pneumatic actuators for valves used in gas and oil applications, producing over 9 types of actuators in 14 variants. It has a full machine shop, CNC machines, metrology equipment, painting facilities, and generates products like valve castings, internals, and machined components to tight tolerances.
Automated screw thread quality checking using SMAC LAR55 actuator new produc...Electromate
The document discusses an automated screw thread quality checking solution using SMAC LAR55 actuators. It allows 100% inspection of screw threads to check for issues like oversizing, cross-threading, depth, and pitch. This can help automakers meet higher quality standards by eliminating defective parts and providing immediate feedback. The LAR55's precision Z-theta motion makes it suitable for automatically checking screw threads.
An overview of the various kinematic models in both parallel and serial robot...Electromate
This document provides an overview of kinematic models for parallel and serial robotic mechanisms and their suitability for precision applications. It introduces Ilian Bonev, a professor at École de technologie supérieure who is an expert in parallel robots and precision robotics. It then describes some parallel robots that have been developed at the Control and Robotics Laboratory including ones for medical, manufacturing, and research applications. The document concludes with sections on robot calibration methods and the differences between serial and parallel mechanisms.
Galil motion control robotic symposium presentation-linear motion from non-li...Electromate
The document discusses non-linear robotic motion control solutions. It describes how Galil Motion Control provides controllers for various types of non-linear robots like SCARA and delta robots. It covers topics like selecting the robot topology, designing each joint, motor selection, forward and inverse kinematics equations, vibration reduction techniques, and examples of implementing motion control for SCARA robots.
Advanced motion controls robotics symposium presentation-open standard tools ...Electromate
This document discusses the development of control software for a linear delta robot used in 3D printing. It describes using PLCopen function blocks and XML files to create reusable software components for robot kinematics and handling G-code from slicing programs. Function block diagrams are created to process G-code, set coordinate systems, and represent the overall project logic. The solution involves creating user-defined function blocks to handle the robot's inverse kinematics and translate G-code commands into motions.
Maxon motor ag robotic symposium presentation-impedance control overview and ...Electromate
The document discusses impedance control, an approach to robot control that models mechanical systems as electrical circuits using impedance. It defines electrical and mechanical impedance analogously and describes how components like resistors, inductors, and capacitors correspond to dampers, masses, and springs physically. The document outlines applications of impedance control and emphasizes the importance of selecting low-inertia motors, high-efficiency gears, and fast, accurate sensors and controllers. Overall, the document argues that impedance control requires creative engineering of mechanical designs and electrical components.
Kollmorgen robotic symposium presentation-motor design impacts on the optimiz...Electromate
The document discusses how motor design impacts the optimization of robotic systems. It explains that frameless motors can enable smaller, lighter and faster robots through their direct drive capabilities and high torque density. The document also covers various motor topologies and important concepts like torque constant, motor size constant, and how they relate to continuous torque capacity, efficiency and losses. Application examples discussed include collaborative robots, surgical robots, and mobile robots.
Harmonic drive llc robotics symposium presentation-designing from the inside ...Electromate
The document discusses defining robot performance requirements and how customized solutions from Harmonic Drive can help meet those requirements. It provides an overview of Harmonic Drive's product line and gear technologies, then discusses how mechanical modifications and performance customizations can be made to their gear components and systems to optimize robots for specific design requirements and applications. Customizations like increased accuracy, stiffness, torque properties and materials can be made, with varying levels of difficulty and cost implications discussed.
Thomson Linear Dual Shaft Rail 2DA Modular SpecsElectromate
This document provides specifications and dimensional drawings for Thomson Industries' Dual Shaft Rail linear guides with modular carriages. It includes part numbers, dimensions, load ratings and descriptions of the components. Linear guides use dual linear race shaft rails and modular carriages with open type Super Smart Ball Bushings. They are used in continuously supported applications requiring rigidity and are adaptable to any drive system.
Thomson Linear 2DA QuickSlide System with BrakeElectromate
This document provides specifications for Thomson Industries' 2DA QuickSlide system with brake, including:
- It offers manual locking with infinite positioning, no carriage surface deflection when locked, and immediate availability in common sizes.
- The locking mechanism does not increase load on the bearing and allows zero axial movement during locking.
- It provides a fully supported dual shaft assembly for maximum rigidity and unlimited travel.
Thomson Linear RoundRail 2CA Web Universal Carriage SpecsElectromate
This document contains specifications for Thomson Industries' Twin Shaft Web Linear Guide system. It includes dimensions, part numbers, load ratings and descriptions of the components. The linear guides use a double shaft and welded web design for improved torque strength and deflection characteristics. They are designed to move medium loads with low friction and are commonly used when bridging gaps.
Thomson Linear RoundRail 1VC Double End Supported SpecsElectromate
The document provides specifications for various FluoroNyliner linear guide components including:
- Pillow blocks, twin pillow blocks, shaft end support blocks, and mounting table tops for different size linear guides ranging from 0.375 to 1.5 inches in diameter.
- It lists the part numbers, dimensions, materials, weights, and other specifications for each component.
- It also includes an illustration of a double end supported linear guide system with pillow blocks, shafts, end supports, and a size B mounting table top.
Thomson Linear RoundRail 2CA Web Flanged Carriage SpecsElectromate
This document provides specifications for Thomson Industries' Twin Shaft Web Linear Guide system. It includes dimensions, load capacity information, and part numbers for various components of the 2CA linear guide, which features a flanged carriage design and double linear race shaft for improved torque and deflection characteristics. Configuration and installation details are also listed.
Thomson Linear RoundRail Twin Shaft Web 2CAElectromate
The document provides specifications for Thomson RoundRail linear guides and components. It includes dimensions, features, and part numbering for twin shaft web linear guides in both vertical and horizontal configurations ranging from 0.5 to 1 inch in diameter. Load capacity charts are provided for different guide sizes and configurations that can support loads between 165 to 3000 pounds depending on the model. Maximum guide lengths are listed as 72 inches and engineering calculations for shaft deflection are also noted.
Thomson Linear RoundRail 1VC Double Unsupported SpecsElectromate
The document contains specifications for various FluoroNyliner linear guide parts, including dimensions, part numbers, materials, load ratings, and performance notes. It lists 14 different linear guide parts with nominal diameters ranging from 0.375 to 1.5 inches. For each part, it provides dimensions for components like bearing blocks, carriages, and table tops. It also includes general information on specifying linear guides and product notes on materials and lubrication.
The Thomson WhisperTrak electric linear actuator offers a compact, quiet, and durable solution for applications requiring linear motion. It is particularly well-suited for personal mobility, medical, and rehabilitation equipment due to its small size and silent operation. The actuator provides reliable, maintenance-free movement and has an IP67 rating, making it protected against water and dust. Its flexibility and high performance in a small package make it suitable for a wide range of industries.
The document provides information on the T-Series Ball Profile Rail from Thomson, including:
- It is lightweight, highly flexible, and forgiving, making it suitable for applications with poor misalignment.
- It has a low cost of installation as it can be mounted directly to non-machined bases without special tools.
- It offers industry standard dimensions and dimensions interchangeable with other rail brands, allowing for easy replacement.
Thomson Linear RoundRail Accessories Collapsable Bellows SpecsElectromate
This document provides specifications for various bellows that can be used to protect slides and shafts. It lists different part numbers for bellows with a range of nominal shaft diameters from 1/4 to 1 1/2 inches. The bellows are made of polyester cover and PVC stiffeners. Dimensions such as length, width, and height are provided for each part number. Some bellows are single shaft while others are dual shaft or for horizontal vs vertical systems. Each bellows comes with attachment pieces like Velcro or mounting brackets.
Thomson Linear Roundrail Dual Shaft Rail 2DA SpecsElectromate
The document provides specifications for Danaher Motion's dual shaft rail linear guides with integrated carriages. It includes dimensions, load ratings, dynamic capacities, and part numbering for the 2DA series linear guides available in nominal diameters of 0.5, 0.75, and 1.0 inches. Both full and short length carriage options are detailed along with components, material specifications, and the supplier contact information.
Thomson Linear RoundRail Continuous Support 1PC SpecsElectromate
This document provides specifications for various linear guide assemblies with table tops from Thomson Industries. It includes dimensions, part numbers, load ratings and limit data for single rail linear guides with sizes ranging from M12 to M40 diameter in configurations with 4 pillow blocks, 2 twin pillow blocks or no pillow blocks and size E or F table tops. Mounting details and specifications are provided for the various components including rails, pillow blocks and table tops.
Thomson Linear RoundRail Continuous Support 1PB SpecsElectromate
The document contains specifications for various continuously supported linear guide assemblies and their components. It lists part numbers, dimensions, load ratings, and other technical specifications for linear guides, support rails, pillow blocks, and bearings. Materials include aluminum alloys and bearings include ball bushings. Linear guides are specified by part number plus length and provide continuous support for applications requiring rigidity.
Dr. Sean Tan, Head of Data Science, Changi Airport Group
Discover how Changi Airport Group (CAG) leverages graph technologies and generative AI to revolutionize their search capabilities. This session delves into the unique search needs of CAG’s diverse passengers and customers, showcasing how graph data structures enhance the accuracy and relevance of AI-generated search results, mitigating the risk of “hallucinations” and improving the overall customer journey.
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...Neo4j
Leonard Jayamohan, Partner & Generative AI Lead, Deloitte
This keynote will reveal how Deloitte leverages Neo4j’s graph power for groundbreaking digital twin solutions, achieving a staggering 100x performance boost. Discover the essential role knowledge graphs play in successful generative AI implementations. Plus, get an exclusive look at an innovative Neo4j + Generative AI solution Deloitte is developing in-house.
Removing Uninteresting Bytes in Software FuzzingAftab Hussain
Imagine a world where software fuzzing, the process of mutating bytes in test seeds to uncover hidden and erroneous program behaviors, becomes faster and more effective. A lot depends on the initial seeds, which can significantly dictate the trajectory of a fuzzing campaign, particularly in terms of how long it takes to uncover interesting behaviour in your code. We introduce DIAR, a technique designed to speedup fuzzing campaigns by pinpointing and eliminating those uninteresting bytes in the seeds. Picture this: instead of wasting valuable resources on meaningless mutations in large, bloated seeds, DIAR removes the unnecessary bytes, streamlining the entire process.
In this work, we equipped AFL, a popular fuzzer, with DIAR and examined two critical Linux libraries -- Libxml's xmllint, a tool for parsing xml documents, and Binutil's readelf, an essential debugging and security analysis command-line tool used to display detailed information about ELF (Executable and Linkable Format). Our preliminary results show that AFL+DIAR does not only discover new paths more quickly but also achieves higher coverage overall. This work thus showcases how starting with lean and optimized seeds can lead to faster, more comprehensive fuzzing campaigns -- and DIAR helps you find such seeds.
- These are slides of the talk given at IEEE International Conference on Software Testing Verification and Validation Workshop, ICSTW 2022.
UiPath Test Automation using UiPath Test Suite series, part 5DianaGray10
Welcome to UiPath Test Automation using UiPath Test Suite series part 5. In this session, we will cover CI/CD with devops.
Topics covered:
CI/CD with in UiPath
End-to-end overview of CI/CD pipeline with Azure devops
Speaker:
Lyndsey Byblow, Test Suite Sales Engineer @ UiPath, Inc.
Introducing Milvus Lite: Easy-to-Install, Easy-to-Use vector database for you...Zilliz
Join us to introduce Milvus Lite, a vector database that can run on notebooks and laptops, share the same API with Milvus, and integrate with every popular GenAI framework. This webinar is perfect for developers seeking easy-to-use, well-integrated vector databases for their GenAI apps.
Pushing the limits of ePRTC: 100ns holdover for 100 daysAdtran
At WSTS 2024, Alon Stern explored the topic of parametric holdover and explained how recent research findings can be implemented in real-world PNT networks to achieve 100 nanoseconds of accuracy for up to 100 days.
TrustArc Webinar - 2024 Global Privacy SurveyTrustArc
How does your privacy program stack up against your peers? What challenges are privacy teams tackling and prioritizing in 2024?
In the fifth annual Global Privacy Benchmarks Survey, we asked over 1,800 global privacy professionals and business executives to share their perspectives on the current state of privacy inside and outside of their organizations. This year’s report focused on emerging areas of importance for privacy and compliance professionals, including considerations and implications of Artificial Intelligence (AI) technologies, building brand trust, and different approaches for achieving higher privacy competence scores.
See how organizational priorities and strategic approaches to data security and privacy are evolving around the globe.
This webinar will review:
- The top 10 privacy insights from the fifth annual Global Privacy Benchmarks Survey
- The top challenges for privacy leaders, practitioners, and organizations in 2024
- Key themes to consider in developing and maintaining your privacy program
Maruthi Prithivirajan, Head of ASEAN & IN Solution Architecture, Neo4j
Get an inside look at the latest Neo4j innovations that enable relationship-driven intelligence at scale. Learn more about the newest cloud integrations and product enhancements that make Neo4j an essential choice for developers building apps with interconnected data and generative AI.
20 Comprehensive Checklist of Designing and Developing a WebsitePixlogix Infotech
Dive into the world of Website Designing and Developing with Pixlogix! Looking to create a stunning online presence? Look no further! Our comprehensive checklist covers everything you need to know to craft a website that stands out. From user-friendly design to seamless functionality, we've got you covered. Don't miss out on this invaluable resource! Check out our checklist now at Pixlogix and start your journey towards a captivating online presence today.
Why You Should Replace Windows 11 with Nitrux Linux 3.5.0 for enhanced perfor...SOFTTECHHUB
The choice of an operating system plays a pivotal role in shaping our computing experience. For decades, Microsoft's Windows has dominated the market, offering a familiar and widely adopted platform for personal and professional use. However, as technological advancements continue to push the boundaries of innovation, alternative operating systems have emerged, challenging the status quo and offering users a fresh perspective on computing.
One such alternative that has garnered significant attention and acclaim is Nitrux Linux 3.5.0, a sleek, powerful, and user-friendly Linux distribution that promises to redefine the way we interact with our devices. With its focus on performance, security, and customization, Nitrux Linux presents a compelling case for those seeking to break free from the constraints of proprietary software and embrace the freedom and flexibility of open-source computing.
Let's Integrate MuleSoft RPA, COMPOSER, APM with AWS IDP along with Slackshyamraj55
Discover the seamless integration of RPA (Robotic Process Automation), COMPOSER, and APM with AWS IDP enhanced with Slack notifications. Explore how these technologies converge to streamline workflows, optimize performance, and ensure secure access, all while leveraging the power of AWS IDP and real-time communication via Slack notifications.
How to Get CNIC Information System with Paksim Ga.pptxdanishmna97
Pakdata Cf is a groundbreaking system designed to streamline and facilitate access to CNIC information. This innovative platform leverages advanced technology to provide users with efficient and secure access to their CNIC details.
Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdfPaige Cruz
Monitoring and observability aren’t traditionally found in software curriculums and many of us cobble this knowledge together from whatever vendor or ecosystem we were first introduced to and whatever is a part of your current company’s observability stack.
While the dev and ops silo continues to crumble….many organizations still relegate monitoring & observability as the purview of ops, infra and SRE teams. This is a mistake - achieving a highly observable system requires collaboration up and down the stack.
I, a former op, would like to extend an invitation to all application developers to join the observability party will share these foundational concepts to build on:
In his public lecture, Christian Timmerer provides insights into the fascinating history of video streaming, starting from its humble beginnings before YouTube to the groundbreaking technologies that now dominate platforms like Netflix and ORF ON. Timmerer also presents provocative contributions of his own that have significantly influenced the industry. He concludes by looking at future challenges and invites the audience to join in a discussion.
Alt. GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using ...James Anderson
Effective Application Security in Software Delivery lifecycle using Deployment Firewall and DBOM
The modern software delivery process (or the CI/CD process) includes many tools, distributed teams, open-source code, and cloud platforms. Constant focus on speed to release software to market, along with the traditional slow and manual security checks has caused gaps in continuous security as an important piece in the software supply chain. Today organizations feel more susceptible to external and internal cyber threats due to the vast attack surface in their applications supply chain and the lack of end-to-end governance and risk management.
The software team must secure its software delivery process to avoid vulnerability and security breaches. This needs to be achieved with existing tool chains and without extensive rework of the delivery processes. This talk will present strategies and techniques for providing visibility into the true risk of the existing vulnerabilities, preventing the introduction of security issues in the software, resolving vulnerabilities in production environments quickly, and capturing the deployment bill of materials (DBOM).
Speakers:
Bob Boule
Robert Boule is a technology enthusiast with PASSION for technology and making things work along with a knack for helping others understand how things work. He comes with around 20 years of solution engineering experience in application security, software continuous delivery, and SaaS platforms. He is known for his dynamic presentations in CI/CD and application security integrated in software delivery lifecycle.
Gopinath Rebala
Gopinath Rebala is the CTO of OpsMx, where he has overall responsibility for the machine learning and data processing architectures for Secure Software Delivery. Gopi also has a strong connection with our customers, leading design and architecture for strategic implementations. Gopi is a frequent speaker and well-known leader in continuous delivery and integrating security into software delivery.
2. Hannifin
Corporation
Parker offers complete
engineered systems.
Parker world headquarters in Cleveland
Training
Parker’s best-in-class
technology training
includes hands-on
classes, Web-based
instruction, and
comprehensive texts for
employees, distributors,
and customers. Parker also provides computer-based
training, PowerPoint presentations, exams,
drafting and simulation software, and trainer
stands.
parkermotion.com
Our award-winning
Web site is your single
source for:
• Product
information
• Downloadable
catalogs
• Motion-sizing software
• 3D design files
• Training materials
• Product-configuration software
• RFQ capabilities
• Videos and application stories
24/7 Emergency Breakdown Support
!e Parker product information center is available
any time of the day or night at 1-800-C-Parker.
Our operators will connect you with a live, on-call
representative who will identify replacement parts
or services for all motion technologies.
Parker
A Fortune 300 company with annual sales exceeding
$10 billion and more than 400,000 customers
in 43 countries, Parker Hannin is the world’s
leading supplier of innovative motion control
components and system solutions serving the
industrial, mobile, and aerospace markets. We are
the only manufacturer o#ering customers a choice
of electromechanical, hydraulic, pneumatic, or
computer-controlled motion systems.
Total System Solutions
Parker’s team of highly qualied application engineers,
product development engineers, and system specialists
can turn pneumatic, structural, and electromechanical
products into an integrated system solution.
Moreover, our Selectable Levels of Integration™ allows
you to choose the appropriate system, subsystem, or
component to meet your specic need.
First in Delivery, Distribution, and Support
In today’s competitive, fast-moving economy, what
good is an application that isn’t ready on time? !is
is especially true when compressed design cycles
make the quick delivery of critical components
essential. With factories strategically located on
ve continents, Parker o#ers an unrivaled delivery
record, getting solutions out our door and onto your
oor faster than ever.
Parker also has the industry’s largest global
distribution network, with more than 8,600
distributors worldwide. Each of these locations
maintains ample product inventory to keep your
downtime to a minimum. And many distributors
have in-house design capabilities to support your
system and subsystem requirements.
!roughout the design process, Parker’s factory-trained
electromechanical engineers work hand in
hand with you and day or night at 1-800-C-Parker.
Our operators will connect you with a live, on-call
representative who will identify replacement parts
or services for all motion technologies.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
3. Welcome!
!ank you for your interest in the products
o#ered by the Parker Hannin Electromechanical
Automation Division. !is catalog presents Parker’s
electromechanical solutions for high-precision and
high-speed automation. Our gearheads, motors,
and integrated products are recognized around
the world for their functionality, performance, and
reliability.
Bayside pioneered the market for precision servo
gearheads many years ago. Parker continues this
tradition in quality and design with innovations
like our Stealth Generation II Helical Planetary
Gearhead, enhanced to provide superior
performance for the most demanding applications.
Our PV Series planetary gearhead combines power
and versatility in an economical package. Our
line of Frameless Motors, Servo Wheels, and other
integrated products provide an ideal solution for
machine designs that require high performance in
small spaces.
As you read through this catalog, you will
discover that Parker o#ers the widest variety of
electromechanical solutions that are delivered in
the shortest amount of time. Still, many customers
require special solutions to satisfy unique or
special requirements. Parker has been providing
custom engineered solutions for over 30 years to
satisfy those requirements. If your application
cannot be fullled by the complement of products
found in this catalog, please contact an authorized
Parker Automation Technology Center or a factory
applications engineer.
Parker is proud to present these high precision
products to you. We invite you to discover the
advantages that can be realized by relying on Parker
for products and systems which represent the very
best value in the electromechanical marketplace.
Sincerely,
3
Ken Sweet
General Manager
Table of Contents
Product Overview
4 – 7 Products and Technologies; Application Examples
Planetary Gearheads
8 – 49 Overview and Selection
Generation II Stealth® PS/PX/RS/RX Series:
• 60 – 115 mm / NEMA 23-42
• In-line and Right Angle
Generation I Stealth® PS/PX/RS/RX Series:
• 142 – 220 mm / NEMA 56
• In-line and Right Angle
PV Series:
• 40 – 115 mm / NEMA 17-42
• In-line
Multi-Drive Right-Angle Gearheads
50 – 57 Overview and Selection
• RT Hollow Shaft Series: 90 – 220 mm
• RD Double Shaft Series: 90 – 220 mm
• RB Low Ratio Series: 90 – 220 mm
Bevel/Spur Gearheads
58 – 61 Overview and Selection
• NE Series: NEMA 23 – 42 (In-line)
Gearmotors (integrated planetary gearhead and servo motor)
62 – 68 Overview and Selection
DX Series ServoWheel™:
• Gearmotor Drive Wheels for Electric Vehicles
Related Products and Services
69 – 71 Other Parker Products
72 – 73 Gearhead Sizing/Selection Design Reference
74 Offer of Sale
If you don’t find exactly what you are looking for in this
catalog, please contact us for information on other
suitable Parker products or to have an application
engineer discuss your requirements.
Visit our Website
Complete up-to-date technical
assistance can be found on our web
at www.parkermotion.com. !is
includes all the latest information
on current products, new product
introductions, local assistance and support, plus a
comprehensive “Engineering Reference Library”
including: complete product catalog data, product
selection Wizards, performance charts and graphs,
engineering data and calculations, CAD drawings,
local service and support directory, on-line
purchasing, application stories and videos.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
4. Product Overview
Product
Series
4
Gear
Geometry Performance Configuration
220 mm and NEMA 56 frame sizes. For standard
precision applications, the PV Series gearhead
combines power and versatility in an economical
package available in a wide range of options.
Frame
Size
Continuous
Torque
Nm (in-lb)
Radial Load
Backlash
N (lbs) arc-min Page
RT Helical High Precision
Right Angle
Hollow Shaft
90 – 220 mm
23 – 565
(204 – 5178)
2800 – 7500
(692 – 1685)
14 – 6 50
RD Helical High Precision
Right Angle
Double Shaft
90 – 220 mm
30 – 150
(266 – 1328
2800 – 7500
(692 – 1685)
14 – 6 50
RB Helical High Precision
Right Angle
Low Ratio
90 – 220 mm
35 – 190
(266 – 1682)
2800 – 7500
(692 – 1685)
14 – 6 50
Planetary Gearheads
Our new Generation II Stealth® Series provides
higher radial load, increased service life and
ease of mounting than comparably sized
planetary gearheads. !e Stealth Generation II
Helical Planetary Gearheads incorporate design
enhancements to provide superior performance
for the most demanding high performance
applications. For larger frame sizes, Parker oers
Generation I Stealth® Series gearheads in 142 to
Product
Series
Gear
Geometry Performance Configuration Frame Size
Nominal
Continuous
Torque
Nm (in-lb)
Radial
Load
Backlash
N (lbs) arc-min Page
Generation II
Stealth®
PS Helical Planetary
High
Precision
In-Line 60 – 115 mm
27 – 230
(240 – 2047)
1650 – 7500
(370 – 1683)
8 – 3 12
PX Helical Planetary
Mid
Precision
In-Line
60 – 115 mm
NEMA 23 – 42
20 – 160
(178 – 1424)
1550 – 6800
(348 – 1526)
10 – 6 16
RS
Helical Planetary/
Spiral Bevel
High
Precision
Right Angle 60 – 115 mm
13 – 220
(115 – 1958)
1650 – 7500
(370 – 1683)
14 – 6 20
RX
Helical Planetary/
Right Angle
Mid
Precision
Right Angle
60 – 115 mm
NEMA 23 – 42
10 – 136
(89 – 1210)
1550 – 6800
(348 – 1526)
20 – 12 24
Generation I
Stealth®
PS Helical Planetary
High
Precision
In-Line 180 – 220 mm
294 – 1808
(2616 – 16,091)
7900 – 58,000
(1775 – 13,020)
8 – 3 30
PX Helical Planetary
Mid
Precision
In-Line
142 mm
NEMA 56
220 – 278
(1958 – 2474)
6000
(1347)
10 – 8 34
RS
Helical Planetary/
Spiral Bevel
High
Precision
Right Angle 180 – 220 mm
141 – 1808
(1255 – 16,091)
7900 – 58,000
(1775 – 13,020)
10 – 4 36
PV Planetary Standard In-Line
40 – 115 mm
NEMA 17 – 42
3.5 – 148
(31 – 1317)
190 – 10,555
(43 – 2370)
15 – 12 40
MultiDrive Gearheads
Stealth® MultiDrive (MD) oers three dierent
output options for true #exibility. MultiDrive models
include low-ratio, dual-shaft and hollow-shaft
options in a compact, right angle package. With 5
frame sizes and multiple ratios to choose from,you
are guaranteed to $nd a Stealth® MultiDrive to $t
your servo motor application.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
5. 5
Product
Series
Gear
Geometry Performance Configuration
Frame
Size
Continuous
Torque
Nm (in-lb)
Radial Load
Backlash
N arc-min Page
NE Spur Gear Economy In-Line NEMA 23 – 42
6 – 40
(50 – 350)
90 – 890
(20 – 200)
10 – 30 58
Product
Series
Gear
Geometry Performance Configuration
Frame
Size
Continuous
Torque
Nm (in-lb) Feedback
Backlash
arc-min Page
GM Helical Planetary Mid-Precision In-Line
60 – 142 mm
NEMA 23 – 56
3 – 60 Encoder/
Resolver
10
Consult
Factory
DX Planetary Mid-Precision In-Line
6 and 8 inch dia.
Wheel Drive
26 – 48
Encoder — 62
NEMA Gearheads
NEMA gearheads feature a high-e)ciency spur gear
design, in a light, compact package, and are ideal for
applications requiring smooth operation and low
starting torque. Ratios from 3:1 to 100:1 are available.
Integral Solution Gearmotors
Stealth® Gearmotors represent the rst time a
brushless servo motor and a helical planetary
gearhead have been integrated into a single product.
Previously, engineers needing a gear drive with
servo motor were forced to purchase the gearhead
and motor separately. Parker Bayside manufactures
precision gearheads and gearmotors under one roof.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
6. Application Examples
Plastic Bottle Extrusion
!e manufacturer of
high-performance
plastic extrusion
equipment needed a
drop-in replacement
gearhead for an existing
worm gearbox used
with their motor
without having to
alter the design of their machine. !e gearhead/motor
combination is being used to drive the machine’s
rollers, controlling the speed at which the plastic
is extruded into high-quality plastic sheets. !e
smoothness of the rollers is critical to the quality of the
plastic sheets being produced.
Application Challenges:
High Transmission Error and Velocity Ripple
!e customer used worm gearheads to control the
rollers. Worm gears exhibit a sliding action of involute
gears instead of a rolling action, contributing to the lack
of smoothness of the machine rollers. Due to the high
transmission error and velocity ripple from the worm
drive, the rollers operated at di#ering speeds. !is
produced small lines and imperfections on the plastic
sheets, rendering it unusable.
Food/Packaging Automation
A manufacturer
of machines for
gluing, ll, sealing
and diverting food
containers for the
food-processing
industry had a
requirement for the motor and gearhead to
be mounted above the food plane. Certain
modications were also needed for the gearhead to
make it safe for the food environment, and capable
to withstand frequent washdowns.
Gearhead Design Considerations:
• Lubrication – must be USDA food grade
6
approved in case of incidental contact to food
• Sealing –must prevent any leaking as well as
prevent any ingress of the fluid during washdown
• Finish – special FDA-approved finish must
be used making it very durable and resistant
to chipping, oxidizing or rusting
High Wear and Low E!ciency
!e high level of rubbing (sliding action) between the
worm and wheel teeth in the worm gearhead caused a
high gear-tooth-wear rate and a lower e)ciency (70%)
than other major gear types.
Parker SOLUTION:
Stealth PS Gearhead and RT
MultiDrive (hollow shaft) Gearhead
were used in combination to provide
the required 120:1 ratio. !e result
was high-quality plastics sheets that
exceeded the customer’s specications.
!e Stealth’s all-helical planetary design (HeliCrown
Gear Tooth) features extremely high gear tooth
accuracy, minimizing transmission error and
velocity ripple. !e HeliCrown design features
extremely high e)ciency (95%) while minimizing
tooth wear by providing a pure rolling action.
Parker’s Plasma Nitriding heat-treating process
further heightens the gear tooth’s wear resistance.
!e MultiDrive gearhead features a space-saving
bore (hollow shaft) option, eliminating compliance
that occurs when coupling a gearhead shaft to the
rollers being driven. !is solution can be used for a
variety of applications, including packaging, food,
semiconductor, automotive and medical.
• Output Shaft – stainless steel prevents any
rust from developing and contaminating the
processing food.
Parker SOLUTION:
Stealth PS planetary gearhead with
standard F01 food grade special option
Stealth PS planetary gearhead with
standard food grade option provides
the gearhead with standard modications including
special lubrication, viton seals, special nish and a
stainless steel output shaft.
Since this food grade modication is a standard
option, delivery is only one week over the standard
gearhead lead time. (Note: Similar standard
modications exist for vacuum, clean room, high
temperature and radiation.)
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
7. 7
High-Speed Milling
High-speed milling
machines are
commonplace in
industries such
as aerospace and
automotive because
they allow large
structural components
to be machined from
one piece rather
than assembled from
many smaller subcomponents. For a customer
that manufactures high-speed milling machines,
spindle heads are operating at speeds ranging from
18,000 to 40,000 RPM, so that the cutting is above
the resonant frequency of the machine. Because
of this, many characteristics become more critical
than with their standard machines. !e extremely
large size of the spindle head also posed problems
for the manufacturer in trying to keep it accurately
positioned during the milling stage.
Application Challenge:
Low Stiness
!e spindle head was moved rotationally by 2 bull
gears, driving a large ring gear. Because of the
system characteristics, it was di)cult to keep the
spindle head absolutely sti# during the milling
process. !e problems associated with low sti#ness
are:
• Poor surface finish
• Accuracy errors
• Excessive tool chatter
• Reduced tool life
Parker SOLUTION:
Two Stealth® PS Helical Planetary
Gearheads were used in tandem
to create a sti# platform for the
spindle machine head. One
gearhead, acting as the master,
and the other as the slave, were
attached to the bull gears to
simultaneously turn the ring
gear that positioned the machine head. While the
master gearhead moved the ring, the slave was
taking up the backlash. In this way, the precision
gears allowed for the spindle to be moved accurately,
while the two gearhead combination maintained
maximum system sti#ness.
Parker’s Stealth PS gearhead features an all-helical
planetary gear design. Helical gears have a much
higher tooth-contact ratio and greater face width
than straight-spur gears, providing higher loads,
smoother tooth engagement and quieter operation.
!e Stealth’s HeliCrown Gear Tooth design
provides extremely high gear tooth accuracy, while
minimizing tooth wear. Parker Bayside’s Plasma
Nitriding heat-treating process further heightens the
gear tooth’s wear resistance.
!is solution can also be used in the aerospace and
automotive industries.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
8. High-, Mid- and Standard-Precision
Planetary Gearheads
Helical planetary technology is superb for low-backlash,
high-stiness and high-accuracy
requirements, making the Parker Generation II
Stealth® line of helical planetary gearheads ideal
for these high-and medium-level performance
applications. $e introduction of the PV Series
gearhead completes the Parker gear family by oering
a standard-grade gearhead with the highest radial
load capacity available today in a cost-eective
solution. Whether you need high-, medium- or
standard-grade performance, Parker can match the
need. All Parker gearheads are proudly manufactured
in the USA in our state-of-the-art facility which,
displays the best use of Lean manufacturing practices.
For more information go to parkermotion.com.
Generation II Stealth® PS/PX/RS/RX:
Our new Generation II Stealth® series provides
higher radial load, increased service life and ease of
mounting
!e Generation II Stealth® Helical Planetary
Gearheads incorporate design enhancements
to provide superior performance for the most
demanding high performance applications.
Stealth Generation II incorporates dual angular
contact bearings providing higher radial load
capacities while maintaining high input speeds.
Design enhancements also include full complement
needle bearings allowing for increased service life
and extended warranties. Internal design changes
and optimized gearing geometries allow for one oil
ll level for any orientation, resulting in shortened
part number designation and simplied order
placement.
Universal mounting kits provide common mounting
kits across multiple product lines to promote quicker
deliveries and ease of mounting to any servo motor.
Applications that require either high precision (PS/
RS Series Gearheads) or mid-range precision (PX/
8
RX Series Gearheads) utilize the same mounting kit
part numbers within the same frame size.
Mounting to any servo motor is as easy as A-B-C
(adapter, bushing, collet).
Features Benefits
• Higher radial load capacity: widely spaced
angular contact output bearings
• Increased service life: full complement of
planet needle bearings
• Universal mounting kits: quicker deliveries
and easier mounting
• High torque and low backlash: helical
planetary gearing
• High stiffness: Integral ring gear and rigid
sun gear
• Higher gear wear resistance: plasma
nitriding heat treating
• PX models are optionally
available with flange mounting
for easy installation. (Contact
factory for flange mount
availability for RX models.)
Other Planetary Gearheads:
Generation I Stealth® PS, PX and RS Gearheads
For larger frame sizes, Parker o#ers Generation
I Stealth® Series gearheads in 142 to 220 mm and
NEMA 56 frame sizes.
PV Series Precision Gearheads
!e PV Series gearhead combines power
and versatility in an economical package.
It comes in a wide range of options
including dimensional output face crossovers
to the Parker Bayside PX, Alpha LP, Neugart PLE,
Stober PE and Standard NEMA gearheads.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
9. 9
Standard Options for Planetary Gearheads
Planetary Gearhead Selection Overview
Product
Series
Gear
Geometry Performance Configuration Frame Size
Nominal
Continuous
Torque
Nm (in-lb)
Radial
Load
Backlash
N (lbs) arc-min Page
Generation II
Stealth®
PS Helical Planetary
High
Precision
In-Line 60 – 115 mm
27 – 230
(240 – 2047)
1650 – 7500
(370 – 1683)
8 – 3 12
PX Helical Planetary Mid Precision In-Line
60 – 115 mm
NEMA 23 – 42
20 – 160
(178 – 1424)
1550 – 6800
(348 – 1526)
10 – 6 16
RS
Helical Planetary/
Spiral Bevel
High
Precision
Right Angle 60 – 115 mm
13 – 220
(115 – 1958)
1650 – 7500
(370 – 1683)
14 – 6 20
RX
Helical Planetary/
Right Angle
Mid Precision Right Angle
60 – 115 mm
NEMA 23 – 42
10 – 136
(89 – 1210)
1550 – 6800
(348 – 1526)
20 – 12 24
Generation I
Stealth®
PS Helical Planetary
High
Precision
In-Line 180 – 220 mm
294 – 1808
(2616 – 16,091)
7900 – 58,000
(1775 – 13,020)
8 – 3 30
PX Helical Planetary Mid Precision In-Line
142 mm
NEMA 56
220 – 278
(1958 – 2474)
6000
(1347)
10 – 8 34
RS
Helical Planetary/
Spiral Bevel
High
Precision
Right Angle 180 – 220 mm
141 – 1808
(1255 – 16,091)
7900 – 58,000
(1775 – 13,020)
10 – 4 36
PV Planetary Standard In-Line
40 – 115 mm
NEMA 17 – 42
3.5 – 148
(31 – 1317)
190 – 10,555
(43 – 2370)
15 – 12 40
Gearheads Ready to Mount to
Linear Actuators
Most belt driven linear slides
need a gearhead to reduce inertia.
Parker has pre-engineered in-line and right-angle
gearheads to mount directly to most popular linear
slides, eliminating the need for couplings or adapters.
Input Shaft Speed Reducer/Speed Increaser for
Increased Design Flexibility
Parker gearheads are available
with an input-shaft option. !e
input-shaft option allows more
design exibility, as options like brakes, encoders, or
safety couplings can be used between the motor and
the gearhead. !is option also allows you to operate
the gearhead as a speed increaser.
Mil-Spec Gearheads
Parker has extensive experience
in military and aerospace
applications. !e Stealth Bomber,
M1 Tank and the Space Shuttle
all use Parker gearheads. Parker’s
quality system has been approved by NASA and the
US Government to MIL-I-45208A.
Special Environments
Put a Parker gearhead anywhere!
Parker can supply gearheads
to operate in the harshest
environments:
Vacuum - Available as a standard option to 10-6 Torr
vacuum ratings.
Clean Room - Special gearheads for Class 10,000
clean room applications.
High Temperature - Special lubricants and seals for
temperatures up to 250° C.
Radiation - Gearheads customized to operate within
radioactive environments.
Food Grade/Washdown - Gearheads customized
to operate within food-handling and washdown
environments.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
10. Helical Planetary Gearhead Features
Parker planetary gearheads incorporate the latest
technology enhancements...
Helical Planetary Design
Helical gears have more tooth
contact and greater face width
than spur gears. !is results in
higher loads, smoother tooth
engagement, quieter operation
and lower backlash.
HeliCrown®
Parker developed the
HeliCrown gear tooth to
further optimize Stealth’s®
performance. Since most
vibration occurs at the entry and exit points of a
gear tooth, HeliCrown eliminates metal only in
these areas, without sacricing gear strength,
producing a quieter and stronger gear.
Plasma Nitriding
Parker’s in-house Plasma
Nitriding process results in an
ideal gear tooth. !e surface is
very hard (65 Rc) and the core
is strong, but exible (36 Rc).
!e result is a wear-resistant
gear tooth that can withstand
heavy shock, ensuring high accuracy for the life of
the gearhead.
ServoMount®
Parker’s ServoMount design
features a balanced input
gear supported by a oating
bearing. !is unique design
compensates for motor shaft
runout and misalignment,
ensuring TRUE alignment of
the input sun gear with the planetary section and
allowing input speeds up to 6,000 RPM. ServoMount
ensures error-free installation to any motor, in a
matter of minutes.
10
“The Helical Advantage”
Parker planetary gearheads are a superior design
with construction integrity to deliver power, speed
and accuracy – quietly and e)ciently.
• Latest technology in seals to reduce heat
and wear
• Oil lubrication reduces friction and operating
temperature, increasing gear life
tage”
Power… 30% more torque than comparably
sized gearheads
Speed... up to 6,000 RPM input speeds
Accuracy… Less than 3 arc-minutes backlash
Quiet… Less than 68 dB noise
Efficiency... Over 97% e)ciency
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
11. 11
Parker Stealth® planetary gearhead features
Features unique to Generation II Stealth® gearheads
• Widely spaced angular contact bearings provide higher radial load capacity
• Full compliment of needle bearings for increased service life
• Universal mounting kits offer easier mounting and quick delivery
7
2
5
8
1
5
4
1
4
6
3
6
2
3
Space Tight? Turn Right
For space constrained applications, Parker’s RS
and RX right-angle gearheads o#er as much as a
2X space savings compared to in-line products.
Common features for all Generation I II
Stealth® gearheads
1 Helical Planetary – Provides smooth, quiet
operation, high torque and high accuracy.
2 ServoMount® – Motor-mounting design ensures
error-free installation and the balanced pinion
allows higher input speeds.
3 Precision Bearings – Provide high speed and
high radial and axial load capacity.
4 HeliCrown® – Parker’s proprietary gear tooth
geometry ensures quieter operation and higher
loads than conventional gears.
5 Sealed Unit – Vition seals and O-Rings provide
IP65 protection to prevent leaks and protect
against harsh environments.
6 Integral Ring Gear – Cutting the ring gear
directly into the housing allows for larger
bearing and planet gears, delivering maximum
power and sti#ness in a minimum package.
Features unique to Stealth®
right-angle gearheads
7 Spiral Bevel Gears – Deliver
high e)ciency and high torque
in a compact, right angle package.
8 Compact Design – Package size
is the same regardless of ratio.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
12. Generation II Stealth® Series
RS Generation II Performance Specifications
Parameter Units Ratio RS60 Gen II RS90 Gen II RS115 Gen II RS142 Gen II
Nominal Output Torque 1)
20
Tnom r
Nm (in-lb)
5 13 (115) 55 (487) 85 (752) 225 (1992)
10 24 (212) 80 (708) 160 (1415) 365 (3232)
15,20,25,50 35 (310) 88 (779) 220 (1947) 430 (3807)
30,40,100 30 (266) 86 (752) 195 (1726) 310 (2745)
Maximum Acceleration Output
Torque 2)
Tacc r
Nm (in-lb)
5 19 (168) 83 (743) 127 (1124) 337 (2984)
10 36 (320) 120 (743) 240 (2124) 547 (4843)
15,20,25,50 45 (400) 123 (867) 255 (2257) 645 (5711)
30,40,100 37 (327) 112 (797) 240 (2124) 465 (4717)
Emergency Stop Output Torque 3)
Tem r
Nm (in-lb)
5 40 (355) 150 (1327) 270 (2390) 625 (5534)
10 72 (637) 240 (2125) 480 (4248) 1000 (8854)
15,20,25,50 80 (708) 250 (2213) 510 (4514) 1100 (9739)
30,40,100 60 (531) 200 (1770) 430 (3806) 830 (7349)
Nominal Input Speed Nnom r RPM
5 to 10 3200 2800 2400 2000
15,20,25,30,40 3700 3300 2900 2500
50,100 4200 3800 3400 3000
Maximum Input Speed Nmax r
4) RPM 5 – 100 6000 5300 4500 3800
Maximum Radial Load Prmax 5, 7) N (lbs) 1650 (370) 4800 (1080) 7500 (1685) 10,000 (2247)
Maximum Axial Load Pamax 6) N (lbs) 2100 (475) 3600 (810) 6800 (1530) 8800 (1976)
Service Life h 20,000
Standard Backlash 8) arc-min
5 – 10 14 12 12 10
15 – 100 12 10 10 8
Low Backlash 8) arc-min
5 – 10 10 8 8 6
15 – 100 8 6 6 4
Efficiency at Nominal Torque % 5 – 100 94 94 94 94
Noise Level at 3000 RPM 9) db 5 – 100 65 68 68 70
Torsional Stiffness
Nm/arc-min (in-lb/
arc-min)
5 – 100 2.5 (22) 10 (90) 22 (195) 42 (372)
Maximum Allowable Case
Temperature
° C 5 – 100 -20 to 90
Lubrication 5 – 100 Per Maintenance Schedule
Mounting Position 5 – 100 Any
Degree of Protection IP65
Maximum Weight kg (lbs) 5 – 100 2.0 (4.4) 6.0 (13.2) 11.0 (24.2) 24 (52)
1) At nominal speed Nnom r.
2) Parker MotionSizer sizing software available for free download at parkermotion.com.
3) Maximum of 1000 stops.
4) For intermittent operation.
5) Max radial load applied to the center of the shaft at 100 rpm.
6) Max axial load at 100 rpm.
7) For combined radial and axial load consult factory.
8) Measured at 2% of rated torque.
9) Measure at 1m.
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
13. 21
RS Generation II Output Shaft Load Rating
Formulas below graphs are used to calculate radial load (Prx) at any distance X from the gearhead
mounting surface:
2200
2000
1800
1600
1400
1200
1000
800
4700
4300
3900
3500
3100
2700
2300
1900
* Radial load applied to center of the shaft.
Prx = Pr * 124 mm / (81 + X)
Prx = Pr * 4.88 in / (3.19 in + X)
Prx = Pr * 96 mm / (62 + X)
Prx = Pr * 3.78 in / (2.44 in + X)
RS142
Prx = Pr * 156 mm / (93 + X)
Prx = Pr * 6.14 in / (3.66 in + X)
Prx = Pr * 75 mm / (49 + X)
Prx = Pr * 2.95 in / (1.93 in + X)
Load, P (N)
RS60
600
0 100 200 300 400 500 600 700 800 900 1000
Speed, n (rpm)
Radial Pr*
Axial
Load, P (N)
RS115
7500
7000
6500
6000
5500
5000
4500
4000
3500
3000
0 100 200 300 400 500 600 700 800 900 1000
Speed, n (rpm)
Radial Pr*
Axial
Load, P (N)
RS90
1500
0 100 200 300 400 500 600 700 800 900 1000
Speed, n (rpm)
Radial Pr*
Axial
12000
10000
8000
6000
4000
2000
0 200 400 600 800 1000 1200
Speed, n (rpm)
Load, P (N)
Radial Pr*
Axial
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
14. Generation II Stealth® Series
RS Generation II Dimensions
U R D
Metric Frame Sizes
Frame
Size
22
L AD*
K
Ej6
h9
O
O
H
A B C D E F G H
Square Flange
Bolt
Hole
Bolt
Circle Pilot Diameter
Output Shaft
Diameter
Output Shaft
Length
Pilot
Thickness
Flange
Thickness
mm in mm in mm in mm in mm in mm in mm in mm in
RS60 62 2.441 5.5 0.217 70 2.756 50 1.969 16 0.630 40 1.575 11 0.433 8 0.315
RS90 90 3.543 6.5 0.256 100 3.937 80 3.150 22 0.866 52 2.047 15 0.591 10 0.394
RS115 115 4.528 8.5 0.335 130 5.118 110 4.331 32 1.260 68 2.677 16 0.630 14 0.551
RS142 142 5.591 11.0 0.433 165 6.496 130 5.118 40 1.575 102 4.016 20 0.787 15 0.591
Frame
Size
I J K L M N O P
Recess Length
Housing
Recess
Distance
to Output
Centerline
Housing
Length Housing Width
Distance
to Input
Centerline
Taper
Distance
Distance
from Shaft
End
mm in mm in mm in mm in mm in mm in mm in mm in
RS60 23.5 0.925 5.0 0.197 66.0 2.598 124.7 4.909 78.0 3.071 47.0 1.850 15 0.591 2 0.079
RS90 33.0 1.299 6.5 0.256 132.0 5.197 177.0 6.969 103.0 4.055 58.0 2.283 27 1.063 3 0.118
RS115 42.0 1.653 7.5 0.295 153.5 6.043 211.0 8.307 132.0 5.177 74.0 2.913 34 1.339 5 0.197
RS142 56.5 2.224 10.0 0.394 198.5 7.815 269.5 10.610 158.2 6.228 87.2 3.433 42 1.654 5 0.197
Frame
Size
Q R S T U V
Keyway Length Key Height Keyway Width
Shoulder
Height
Shoulder
Diameter
Tap Depth
mm in mm in mm in mm in mm in (end of shaft)
RS60 25 0.984 18.0 0.709 5 0.197 0.5 0.020 22 0.866 M5x8
RS90 32 1.260 24.5 0.965 6 0.236 0.5 0.020 35 1.378 M8x16
RS115 40 1.575 35.0 1.378 10 0.394 1 0.039 45 1.772 M12x25
RS142 63 2.480 43.0 1.693 12 0.472 2.5 0.098 78 3.071 M16x32
I
G
T F
N
Q
P
M
S
A g6
B C
V J
Free 3D Solid Models and drawings available at parkermotion.com
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
15. 23
RS Generation II Universal Mounting Kits*
Adapter Length “AD” Dimension
Frame
Size
RS Generation II Inertia
All moment of inertia values are as reected at the input of the gearhead
Ratio Units* RS60 RS90 RS115 RS142
5
kg-cm 0.2200 0.8100 2.5000 9.4000
in-lb-sec 0.000195 0.000717 0.002213 0.008319
10
kg-cm 0.1900 0.6100 1.9000 6.7000
in-lb-sec 0.000168 0.000540 0.001682 0.005929
15
kg-cm 0.1800 0.6000 1.7000 6.6000
in-lb-sec 0.150000 0.000531 0.001505 0.005841
20
kg-cm 0.1700 0.5100 1.4000 5.2000
in-lb-sec 0.000150 0.000451 0.001239 0.004602
25
kg-cm 0.1600 0.4200 1.3000 4.5000
in-lb-sec 0.000142 0.000372 0.001151 0.003983
30
kg-cm 0.1800 0.6000 1.7000 6.7000
in-lb-sec 0.000159 0.000531 0.001505 0.005929
40
kg-cm 0.1700 0.5100 1.4000 5.2000
in-lb-sec 0.000150 0.000451 0.001239 0.004602
50
kg-cm 0.1500 0.4000 1.1000 3.4000
in-lb-sec 0.000133 0.000354 0.000974 0.003009
100
kg-cm 0.1500 0.4000 1.1000 3.4000
in-lb-sec 0.000133 0.000354 0.000974 0.003009
* Note: 1 kg-cm² = 0.000885 in-lb-sec²
Motor Shaft Length Gearhead Adapter Length
mm in mm in
60
16 – 35
35.1 – 41
0.630 – 1.378
1.382 – 1.614
16.5
22.5
0.65
0.886
90
20 – 40
40.1 – 48
0.787 – 1.575
1.579 – 1.890
20
28.5
0.787
1.122
115
22 – 50
50.1 – 61
0.866 – 1.969
1.972 – 2.402
24
35
0.945
1.378
142
26 – 62
62.1 – 82
1.023 – 2.441
2.445 – 3.228
30
50
1.181
1.969
* Know your motor and need our mounting kit part number? See page 29 or use our Motor Mounting Search Tool on our website at:
www.parkermotion.com
Sold Serviced By:
ELECTROMATE
Toll Free Phone (877) SERVO98
Toll Free Fax (877) SERV099
www.electromate.com
sales@electromate.com
