Baby Demuxed’s First Assembly
Language Function
Kieran Kunhya <kierank@obe.tv>

2. <Your Logo
Here>
Who am I?
• Company specialising in software-based
encoders and decoders for Sport, News
and Channel contribution (B2B)
• Build everything in house:
– Hardware, firmware, software
• Not to be confused with:
• Written assembly in FFmpeg and at work

3. <Your Logo
Here>
What is assembly language?
• A low-level (close to the hardware)
programming language
• Intel x86 assembly language is (somewhat)
backwards compatible to the 8008 CPU
from 1972!
• Languages like C are compiled into
Assembly Language
• Mnemonics are human readable versions
of machine code
• Jargon heavy, will try to keep to minimum

4. <Your Logo
Here>
Why does this matter?
• Single Instruction Multiple Data (SIMD) or
vector assembly functions are the backbone
of our industry.
• 10-20x speed improvements are a key
reason encoding/decoding is realtime
• This presentation will be followed by
Ronald’s more detailed dive into assembly
• FFmpeg/x264 assembly functions are some
of the most used functions in the cloud
• Fewer and fewer people writing assembly

5. <Your Logo
Here>

6. <Your Logo
Here>
Assembly Language Concepts
• CPUs don’t operate directly on memory,
data needs to be loaded from memory
into registers, operations performed and
then stored back
• Scalar registers (general purpose
registers) operate on one element at a
time, vector (SIMD) registers operate on
multiple elements with a single
instruction
• Vector instructions very suited towards
2D images. Operate on multiple pixels at
a time
a
Scalar addition
+
b
Vector (SIMD)
addition
+
b d
a c
+
= a + b
f
e
+
a + b c + d e + f
=

7. <Your Logo
Here>
Assembly Language Concepts (2)
pshufb a b c
=
• Shuffles (permutes) are the most important instruction in multimedia
• Most assembly in multimedia is integer based
• X86 has myriad of instructions, many very specialist (e.g encryption)
• Not all CPUs capable of every instruction. New instruction sets added (and
even removed!). SSE2, SSSE3, AVX2 are names of some
d e f g h
c a f h a 0 d b
pshufb index chooses the element to output (or zero)

8. <Your Logo
Here>
Assembly Language Concepts (3)
Richardson, The H.264
Advanced Video Compression
Standard
• Famous Zigzag, used to convert a 2D
array to a 1D array, grouping larger
coefficients towards the beginning
• A 4x4 zigzag can be implemented with a
simple shuffle (16-bit coefficients)
Square brackets = “read
from memory” (*ptr in C)

9. <Your Logo
Here>
Assembly Language Concepts (4)
• Intrinsics, an abstraction of assembly also commonly used
– (controversial) Around 15% slower than assembly itself
– Some instructions not representable in intrinsics
• How do you implement functions?
• Calling convention (aka. Application Binary Interface):
do_something(arg1, arg2, arg3);
RDI = arg1, RSI = arg2, RDX = arg3.
• Agreed location of function arguments
• But could define own for performance improvements

10. <Your Logo
Here>
Let’s write an assembly function
• A decoder needs to predict the next block when intra (de)coding
• Match prediction of encoder
Richardson, The H.264 Advanced
Video Compression Standard
Definitely not to scale

11. <Your Logo
Here>
Let’s write an assembly function (2)
• Replicate the left hand pixel across all
pixels in a row A A A A A A A A
B B B B B B B B
A
B
C C C C C C C C
D D D D D D D D
C
D
E E E E E E E E
F F F F F F F F
E
F
G G G G G G G G
H H H H H H H H
G
H
8x8 horizontal prediction
Loop counter
decrement
Jump if greater
than zero
2 arguments, 3
GPRs in use

12. <Your Logo
Here>
Let’s write an assembly function (3)
-
- - - A - - -
Load from 8 bytes (4 words) to register
movq = move quadword
-
A A A A - - -
Shuffle low words and replicate
pshuflw = packed shuffle low words
A
A A A A A A A
punpcklqdq = unpack and interleave
low quadword (with itself)
Write register data back to memory
Increment memory location by two lines
xmm registers (16-byte)
sse2 instruction set

13. <Your Logo
Here>
Let’s write an assembly function (4)
Author has decided to do the operations twice per loop,
Known as loop unrolling
RET = exits the function and goes back to the calling code

14. <Your Logo
Here>
Benchmarks
• Test suite (checkasm) to verify correctness and run benchmarks
• Benchmarks (decicycles):
pred8x8_horizontal_10_c: 35.5
pred8x8_horizontal_10_sse2: 17.5
2x faster than C!

15. <Your Logo
Here>
Other Benchmarks
• Pixel packing function for custom hardware (10-bit bitpacked):
uyvy_to_sdi_c: 3672.0
uyvy_to_sdi_ssse3: 368.0
uyvy_to_sdi_avx: 181.0
uyvy_to_sdi_avx2: 129.0
uyvy_to_sdi_avx512icl: 59.0
62x faster than C!

16. <Your Logo
Here>
Conclusion
• Assembly functions are an important part of making encoding
and decoding realtime or cost-effective
• High-schoolers have written many of these functions
• Ability to get very large speed gains
• If this expertise goes away, it goes away forever
• Only talked about x86, but there are new platforms like ARM and
RISC-V with their own assembly language
