Apache spark? if only it worked
- 1. @mszymani#Devoxx #TantusData #spark Apache Spark - if only it worked Marcin Szymaniuk TantusData
- 3. @mszymani#Devoxx #TantusData #spark Agenda • Execution model • Sizing executors • Skewed data • Locality • Caching • Debugging tools • Local run/tests • Challenge and a draw!
- 4. @mszymani#Devoxx #TantusData #spark What is Spark? • Engine for distributed data processing • Java, Scala, R, Python API • SQL, Streaming, Machine Learning
- 5. @mszymani#Devoxx #TantusData #spark … … … … … … … Stage 1 Stage N … … … … … … … Stage 2 … Shuffle Shuffle RDD
- 6. @mszymani#Devoxx #TantusData #spark … … … … … … … Stage 1 Stage N … … … … … … … Stage 2 … Shuffle Shuffle
- 7. @mszymani#Devoxx #TantusData #spark … … … … … … … Stage 1 Stage N … … … … … … … Stage 2 … Shuffle Shuffle
- 8. @mszymani#Devoxx #TantusData #spark … … … … … … … Stage 1 Stage N … … … … … … … Stage 2 … Shuffle Shuffle
- 9. @mszymani#Devoxx #TantusData #spark .reduceByKey{case (x, y) => x + y} .saveAsTextFile(output) Block 1 Block 2 … Task 1 sc.textFile(“/input/text/“) .flatMap(line=>line.split(" ")) .map(word => (word, 1)) Stage 1 Stage 2 … … … … … … … … … … … Stage 2 … … Stage 1 ………
- 10. @mszymani#Devoxx #TantusData #spark .reduceByKey{case (x, y) => x + y} .saveAsTextFile(output) Block 1 Block 2 … Task 1 sc.textFile(“/input/text/“) .flatMap(line=>line.split(" ")) .map(word => (word, 1)) Stage 1 Stage 2 … … … … … … … … … … … Stage 2 … … Stage 1 ………
- 11. @mszymani#Devoxx #TantusData #spark Sizing executors Executor - JVM process able to run one or more tasks … Executor Example config: --executor-cores 3 --executor-memory 10g … Executor … … Executor … Pending Tasks Complete Tasks … … Executor Job resources
- 12. @mszymani#Devoxx #TantusData #spark Executor - JVM process able to run one or more tasks … Executor Example config: --executor-cores 3 --executor-memory 10g … Executor … … Executor … Pending Tasks Complete Tasks … … Executor Job resources Driver Sizing executors
- 13. @mszymani#Devoxx #TantusData #spark Sizing executors Executor - JVM process able to run one or more tasks … Executor Example config: --executor-cores 3 --executor-memory 10g Executor Executor Executor Executor Node … Executor Executor Node … Node … Executor Executor Executor Executor Node Executor … vs vs vs vs…
- 14. @mszymani#Devoxx #TantusData #spark Sizing executors • Spark can benefit from running multiple tasks in the same JVM • Many cores leads to problems: HDFS I/O, GC • 1-4 CPUs should be good for start
- 15. @mszymani#Devoxx #TantusData #spark Sizing executors Executor heap Container Memory overhead spark.executor.memory spark.yarn.executor.memoryOverhead spark.shuffle.memoryFraction spark.storage.memoryFraction Executor heap Cache Shuffle User program
- 16. @mszymani#Devoxx #TantusData #spark Sizing executors • Keep in mind memory overhead • Keep some resources for OS • Determining memory consumption - cache an RDD • Consider dynamic resource allocation
- 17. @mszymani#Devoxx #TantusData #spark Shuffle zoom-in Task 1 Task 2 Task 3 Stage 1 Stage 2
- 18. @mszymani#Devoxx #TantusData #spark Task 1 Task 2 Task 3 Stage 1 Stage 2 Shuffle zoom-in
- 19. @mszymani#Devoxx #TantusData #spark Task 1 Task 2 Task 3 Stage 1 Stage 2 BOOM!BOOM! Shuffle zoom-in
- 20. @mszymani#Devoxx #TantusData #spark We are up & running • 2G block limit • Timeouts • GC overhead limit exceeded • OOM • ExecutorLostFailure
- 21. @mszymani#Devoxx #TantusData #spark We are up & running What to watch out for: • Failing tasks • GC heavy tasks • Shuffle read/write sizes • Long running tasks
- 22. @mszymani#Devoxx #TantusData #spark We are up & running • Too much data per task? • Is parallelism level large enough? • More memory for executor? def groupByKey(numPartitions: Int) def repartition(numPartitions: Int)
- 23. @mszymani#Devoxx #TantusData #spark Skewed data … … … … … … … … … … … … … … … … … … … … … … You want: NOT: FOO V1 FOO V2 FOO V3 FOO_1 V1 FOO_1 OUT1 SALT EXEC FOO OUTMERGE V4BAR FOO_2 V2 FOO_1 V3 BAR_1 V4 FOO_2 OUT2 BAR_1 OUT3 BAR OUT
- 24. @mszymani#Devoxx #TantusData #spark Locality Executor Node 1 HDFS Block 1 Executor Node 2 HDFS Block 2 Executor Node 3 HDFS Block 3 Driver sparkContext.textFile(“hdfs://…”)
- 25. @mszymani#Devoxx #TantusData #spark Locality • Increase number of executors • For small jobs better to leave as is • spark.locality.wait parameter
- 26. @mszymani#Devoxx #TantusData #spark Caching val rdd1=calculate1() rdd1. … saveAsTextFile(…) rdd1. … saveAsTextFile(…) Executed twice!
- 27. @mszymani#Devoxx #TantusData #spark val rdd1=calculate1() rdd1. … saveAsTextFile(…) rdd1. … saveAsTextFile(…) Executed twice! Caching
- 28. @mszymani#Devoxx #TantusData #spark Caching • Branch in execution plan is a candidate for caching • Spark UI shows to see how much memory an RDD is taking • You cannot control priority - it's LRU • Don't cache to disk if computation is cheap • Caching with RF - only when recreation is extremely costly • Checkpointing vs caching • Shuffle data is automatically persisted
- 29. @mszymani#Devoxx #TantusData #spark Join zoom-in Task 1 Task 2 Stage 1 Task 1 Task 2 Stage 2 Stage 3
- 30. @mszymani#Devoxx #TantusData #spark Optimize shuffle Use the same number of partition Change map to mapValues
- 32. @mszymani#Devoxx #TantusData #spark Broadcast Variable Executor RDD1_0 RDD2 RDD2 Join Executor RDD1_1 RDD2 Join Executor RDD1_2 RDD2 Join Executor RDD1_3 RDD2 Join Broadcast
- 33. @mszymani#Devoxx #TantusData #spark Optimize shuffle - recap • Control number of partitions • Use mapValues instead of map if you can • Broadcast variables • Filter before shuffle • Avoid groupByKey, use reduceByKey
- 34. @mszymani#Devoxx #TantusData #spark Debugging tools • Spark UI • HDFS monitoring • Aggregate your logs • Extra Java options - observe your GC • Run and test locally
- 35. @mszymani#Devoxx #TantusData #spark Challenge time! goo.gl/7eTtvH
- 36. @mszymani#Devoxx #TantusData #spark Use case UUID UUID UUID UUID UUID UUID goo.gl/7eTtvH
- 37. @mszymani#Devoxx #TantusData #spark General notes • Tests vs no tests? - Test your code! • You are probably not the only user of the cluster • What are you optimizing for? • Share the knowledge • Spark actually works :) goo.gl/7eTtvH
- 39. @mszymani#Devoxx #TantusData #spark Thank you! @mszymani marcin@tantusdata.com
