1. Android Wear
Douglas Drumond
douglas@cafelinear.com

6. Background

9. ≠

10. ⦸

11. Coding

12. Not Coding

13. Notifications

14. Notifications

15. Notifications

16. Notifications
Nada a ser feito

17. Enhanced notifications

18. Enhanced notifications
Nada a ser feito

19. Coding

20. Ação só p/ relógio
// Create an intent for the reply action
Intent actionIntent = new Intent(this, ActionActivity.class);
PendingIntent actionPendingIntent =
PendingIntent.getActivity(this, 0, actionIntent,
PendingIntent.FLAG_UPDATE_CURRENT);
// Create the action
NotificationCompat.Action action =
new NotificationCompat.Action.Builder(R.drawable.ic_action,
getString(R.string.label), actionPendingIntent)
.build();
// Build the notification and add the action via WearableExtender
Notification notification =
new NotificationCompat.Builder(mContext)
.setSmallIcon(R.drawable.ic_message)
.setContentTitle(getString(R.string.title))
.setContentText(getString(R.string.content))
.extend(new WearableExtender().addAction(action))
.build();

21. Ação só p/ relógio
// Create an intent for the reply action
Intent actionIntent = new Intent(this, ActionActivity.class);
PendingIntent actionPendingIntent =
PendingIntent.getActivity(this, 0, actionIntent,
PendingIntent.FLAG_UPDATE_CURRENT);
// Create the action
NotificationCompat.Action action =
new NotificationCompat.Action.Builder(R.drawable.ic_action,
getString(R.string.label), actionPendingIntent)
.build();
// Build the notification and add the action via WearableExtender
Notification notification =
new NotificationCompat.Builder(mContext)
.setSmallIcon(R.drawable.ic_message)
.setContentTitle(getString(R.string.title))
.setContentText(getString(R.string.content))
.extend(new WearableExtender().addAction(action))
.build();

22. Voz
// Key for the string that's delivered in the action's intent
private static final String EXTRA_VOICE_REPLY = "extra_voice_reply";
String replyLabel = getResources().getString(R.string.reply_label);
RemoteInput remoteInput = new RemoteInput.Builder(EXTRA_VOICE_REPLY)
.setLabel(replyLabel)
.build();

23. Voz com opções
public static final String EXTRA_VOICE_REPLY = "extra_voice_reply";
...
String replyLabel = getResources().getString(R.string.reply_label);
String[] replyChoices =
getResources().getStringArray(R.array.reply_choices);
RemoteInput remoteInput = new RemoteInput.Builder(EXTRA_VOICE_REPLY)
.setLabel(replyLabel)
.setChoices(replyChoices)
.build();

24. Voz// Create an intent for the reply action
Intent replyIntent = new Intent(this, ReplyActivity.class);
PendingIntent replyPendingIntent =
PendingIntent.getActivity(this, 0, replyIntent,
PendingIntent.FLAG_UPDATE_CURRENT);
// Create the reply action and add the remote input
NotificationCompat.Action action =
new NotificationCompat.Action.Builder(R.drawable.ic_reply_icon,
getString(R.string.label), replyPendingIntent)
.addRemoteInput(remoteInput)
.build();
// Build the notification and add the action via WearableExtender
Notification notification =
new NotificationCompat.Builder(mContext)
.setSmallIcon(R.drawable.ic_message)
.setContentTitle(getString(R.string.title))
.setContentText(getString(R.string.content))
.extend(new WearableExtender().addAction(action))
.build();

25. Voz// Create an intent for the reply action
Intent replyIntent = new Intent(this, ReplyActivity.class);
PendingIntent replyPendingIntent =
PendingIntent.getActivity(this, 0, replyIntent,
PendingIntent.FLAG_UPDATE_CURRENT);
// Create the reply action and add the remote input
NotificationCompat.Action action =
new NotificationCompat.Action.Builder(R.drawable.ic_reply_icon,
getString(R.string.label), replyPendingIntent)
.addRemoteInput(remoteInput)
.build();
// Build the notification and add the action via WearableExtender
Notification notification =
new NotificationCompat.Builder(mContext)
.setSmallIcon(R.drawable.ic_message)
.setContentTitle(getString(R.string.title))
.setContentText(getString(R.string.content))
.extend(new WearableExtender().addAction(action))
.build();

26. Voz
private CharSequence getMessageText(Intent intent) {
Bundle remoteInput = RemoteInput.getResultsFromIntent(intent);
if (remoteInput != null) {
return remoteInput.getCharSequence(EXTRA_VOICE_REPLY);
}
return null;
}

27. Paginação

28. Paginação
NotificationCompat.Builder notificationBuilder =
new NotificationCompat.Builder(this)
.setSmallIcon(R.drawable.new_message)
.setContentTitle("Page 1")
.setContentText("Short message")
.setContentIntent(viewPendingIntent);

29. Paginação
BigTextStyle secondPageStyle = new NotificationCompat.BigTextStyle();
secondPageStyle.setBigContentTitle("Page 2")
.bigText("A lot of text...");
// Create second page notification
Notification secondPageNotification =
new NotificationCompat.Builder(this)
.setStyle(secondPageStyle)
.build();

30. Paginação
// Extend the notification builder with the second page
Notification notification = notificationBuilder
.extend(new NotificationCompat.WearableExtender()
.addPage(secondPageNotification))
.build();

31. Paginação
// Extend the notification builder with the second page
Notification notification = notificationBuilder
.extend(new NotificationCompat.WearableExtender()
.addPage(secondPageNotification))
.build();

32. Pilha

33. Pilha
setGroup com mesmo ID

34. Pilha
Notification notif = new NotificationCompat.Builder(mContext)
.setContentTitle("New mail from " + sender1)
.setContentText(subject1)
.setSmallIcon(R.drawable.new_mail)
.setGroup(GROUP_KEY_EMAILS)
.build();
…
Notification notif2 = new NotificationCompat.Builder(mContext)
.setContentTitle("New mail from " + sender2)
.setContentText(subject2)
.setSmallIcon(R.drawable.new_mail)
.setGroup(GROUP_KEY_EMAILS)
.build();

35. Pilha
Notification notif = new NotificationCompat.Builder(mContext)
.setContentTitle("New mail from " + sender1)
.setContentText(subject1)
.setSmallIcon(R.drawable.new_mail)
.setGroup(GROUP_KEY_EMAILS)
.build();
…
Notification notif2 = new NotificationCompat.Builder(mContext)
.setContentTitle("New mail from " + sender2)
.setContentText(subject2)
.setSmallIcon(R.drawable.new_mail)
.setGroup(GROUP_KEY_EMAILS)
.build();

36. Wearable Apps

37. O que não tem
• android.webkit
• android.print
• android.app.backup
• android.appwidget
• android.hardware.usb

38. Requisitos
• SDK tools versão 23.0.0 ou superior
• SDK Android 4.4W (API 20)

39. Custom notification
public void onCreate(Bundle bundle){
...
setContentView(R.layout.notification_activity);
}
<activity android:name="com.example.NotificationActivity"
android:exported="true"
android:allowEmbedded="true"
android:theme="@android:style/Theme.DeviceDefault.Light" />
Intent notificationIntent = new Intent(this,
NotificationActivity.class);
PendingIntent notificationPendingIntent =
PendingIntent.getActivity(this, 0, notificationIntent,
PendingIntent.FLAG_UPDATE_CURRENT);

40. Layouts
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/
android"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:orientation="vertical">
<TextView
android:id="@+id/text"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="@string/hello_square" />
</LinearLayout>

41. Layouts

42. Layouts
compile 'com.google.android.support:wearable:+'

43. Layouts
<android.support.wearable.view.WatchViewStub
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/watch_view_stub"
android:layout_width="match_parent"
android:layout_height="match_parent"
app:rectLayout="@layout/rect_activity_wear"
app:roundLayout="@layout/round_activity_wear">
</android.support.wearable.view.WatchViewStub>

44. Layouts
<android.support.wearable.view.WatchViewStub
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:id="@+id/watch_view_stub"
android:layout_width="match_parent"
android:layout_height="match_parent"
app:rectLayout="@layout/rect_activity_wear"
app:roundLayout="@layout/round_activity_wear">
</android.support.wearable.view.WatchViewStub>

45. Layouts
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_wear);
}

46. ⛔

47. Layouts
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_wear);
WatchViewStub stub = (WatchViewStub) findViewById(R.id.watch_view_stub);
stub.setOnLayoutInflatedListener(new WatchViewStub.OnLayoutInflatedListener() {
@Override public void onLayoutInflated(WatchViewStub stub) {
// Now you can access your views
TextView tv = (TextView) stub.findViewById(R.id.text);
...
}
});
}

48. Layouts
WatchViewStub stub = (WatchViewStub)
findViewById(R.id.watch_view_stub);
stub.setOnLayoutInflatedListener(new
WatchViewStub.OnLayoutInflatedListener() {
@Override
public void onLayoutInflated(WatchViewStub stub) {
// Now you can access your views
TextView tv = (TextView) stub.findViewById(R.id.text);
...
}
});

49. Layouts
<android.support.wearable.view.BoxInsetLayout
xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
android:layout_height="match_parent"
android:layout_width=“match_parent>
…
</android.support.wearable.view.BoxInsetLayout>

50. Layouts

51. Layouts
• android.support.wearable.view.BoxInsetLayout
• android.support.wearable.view.CardScrollView
• android.support.wearable.view.CardFrame
• android.support.wearable.view.WearableListView
• WearableListView.Adapter

52. Confirmação

53. Confirmation
• DelayedConfirmationView
// Two seconds to cancel the action
mDelayedView.setTotalTimeMs(2000);
// Start the timer
mDelayedView.start();
• DelayedConfirmationListener
public void onTimerFinished(View view); // Usuário
não cancelou, continue
public void onTimerSelected(View view); // Usuário
cancelou, abortar

54. Fechando
• Default: swipe da esquerda
• Pode ser desabilitado
• Long press

55. Fechando
<style name="AppTheme" parent="Theme.DeviceDefault">
<item name="android:windowSwipeToDismiss">false</item>
</style>

56. Fechando
<FrameLayout
xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_height="match_parent"
android:layout_width="match_parent">
<!-- resto do layout -->
<android.support.wearable.view.DismissOverlayView
android:id="@+id/dismiss_overlay"
android:layout_height="match_parent"
android:layout_width="match_parent"/>
<FrameLayout>

57. Fechando
mDismissOverlay =
(DismissOverlayView) findViewById(R.id.dismiss_overlay);
mDismissOverlay.setIntroText(R.string.long_press_intro);
mDismissOverlay.showIntroIfNecessary();
// Configure a gesture detector
mDetector = new GestureDetector(this,
new SimpleOnGestureListener() {
public void onLongPress(MotionEvent ev) {
mDismissOverlay.show();
}
});

58. O que mais?
• Transferência de dados entre wearable e device:
• Wearable Data Layer
• Watch Face:
• CanvasWatchFaceService,
CanvasWatchFaceService.Engine…

59. Próximos passos?
• http://developer.android.com/wear/

60. WatchFace
• https://github.com/ustwo/Clockwise
• http://wear.ustwo.com

61. Obrigado

62. Obrigado
+DouglasDrumond
@douglasdrumond
www.cafelinear.com
douglas@cafelinear.com
+GdgCampinasOrg
@gdgcampinas
www.gdg-campinas.org
