1. Definition
Algorithm: Steps of problem solving
well defined
Analysis:
1. Study Performance Characteristics of
Algorithms: Time and Space
2. Know the existing ways of problem solving
3. Evaluate its suitability for a particular problem
1

2. Properties of Algorithm
Algorithm:
• Precision
• Determinism
• Finiteness
• Correctness
• Generality
2

3. Basics of Studying Algorithms
o Independent of Hardware
o Op. Systems, Compilers and Languages
o Independent of Data?
• Badly chosen Starting Point, Initial Condition
• Intelligent selection or well defined start
state
• Random Selection of an element
• Repeat algorithm several times
3

4. Analysis
Complexity: Goal is to classify algorithms
according to their performance characteristics:
Time and Space
This can be done in two ways:
Method 1: Absolute Value
Space required: Bytes?
Time required: Seconds?
4

5. Computational Complexity
Second Method:
Size of the problem represented by n
Independent of machine, operating system,
compiler and language used
5

6. Space Complexity
How much Space required to execute an
algorithm
Unit Cost Model for memory representation
Begin
Initialize n variable n
For i=0 to n variable i
Print i
Next
End
6

7. Space Complexity
Space no longer a problem
Many algorithms compromise space
requirements since memory is cheap
Search Space grows out of bound!
Swapping with secondary memory
7

8. Time Complexity
Time required: Unit Cost Model for time
Begin
Initialize n
For i=0 to n
Print i
End For
End
8

9. Time Complexity
Time required: Unit Cost Model for time
Begin labels do not cost anything
Initialize n 1
For i=0 to n n+2
Print i n+1
End For label
End label
Total T(n) = 2n+4
9

10. Complexity
Asymptotic Complexity
• Ignore machine-dependent constants ---
instead of the actual running time
• Look at the growth of the running time.
10

11. Asymptotic Complexity
Example:
T(n) = 2n3
T(n) = 1000n2
Which one is better?
For large values of n or
small values of n
11

12. Asymptotic Complexity
We study algorithms for large values of n but that
does not mean that we should forget that high
complexity algorithms can execute faster if size
of problem is small
We focus our analysis for large values of n
where n → ∞
12

13. Kinds of Analysis
Worst-case: (usually)
• Max. time of algorithm on any input of size n.
Average-case: (sometimes)
• expected time over all inputs of size n.
• Need assumption of statistical distribution of
inputs.
• Best-case: (bogus)
• Cheat with a slow algorithm that works fast on
some input.
13

14. Analysis of Algorithms
Worst Case, Best Case, Average Case
Example: Sorting
Which one to use?
For Real Time Applications
Data already sorted!
Is it really the best case?
14

15. Mathematical Notations
Big-O: O (f(N) ) is bounded from above
at most!
Big-Omega: Ω (f(N) ) is bounded from below
at least!
Little-o: o (f(N) ) is bounded from above
smaller than!
Little-omega: ω (f(N) ) is bounded from below
greater than!
Theta: Θ (f(N) ) bounded, above & below
equal to!
15

16. Big-O
• O-notation is an upper-bound notation.
• It makes no sense to say f(n) is at least
O(n2).
16

17. Complexity
Example: T(n) = 2n+4
Dominant Term: As n gets large enough, the
dominant term has a much larger effect on the
running time of an algorithm
Example 2:
T(n) = 2n3 + 1000n2 + 100000
17

18. Dominant Term
Example 1: T(n) = 2n+4
Example 2: T(n) = 2n3 + 1000n2 + 100000
Remove negligible terms
Example 1: n
Example 2: n3
18

19. Dominant Term & Big-O
Example 1: n
Example 2: n3
We say that the algorithm runs
Ex1: in the Order of n = O(n)
Ex2: in the Order of n3 = O(n3)
O(n) : The Time Complexity in the worst case,
grows with the size of the problem
19

20. Rules for using Big-O
• For a single statement whose execution does
not depend on n: O(1)
Example: i=0
• For a sequence of statement, S1,S2,…,Sk
T(S1)+T(S2)+…+T(Sk)
Example: i=0 O(1) +
print i O(1)
20

21. Rules for using Big-O
• Loop: For i=0 to n
S1
S2
End For
Dominent Term * No. of times loop executed
Example: For i=0 to n
j=j*8
j=j-1
End For 21

22. Rules for using Big-O
• Conditional Loop: While i<0
S1
S2
End While
No fixed rule, find a bound on the number of
iterations
22

23. Rules for using Big-O
• If condition C then
S1
else
S2
end if
T(C) + max (T(S1) , T(S2) )
23

24. Rules for using Big-O
• Nested Loop
S1
For i=0 to n
For j=0 to m
S2
End For
End For
As n → ∞, m → ∞
24

25. Time Complexity
Begin
Initialize n 1
For i=0 to n n+2
For j=0 to m (m+2)(n+2)
Print i (m+1)(n+1)
End For
End For
End
Total T(n) = 2mn + 3m + 4n + 8
O(n)=n^2
25

26. Constants?
Begin
Initialize n
For i=0 to n
Print i
End for
End
What are these?
T(n)= 2 n + 4
26

27. Slope Intercept Form
T(n)= 2n+4
18
n T(n) 16
14
1 6 12
2 8 10
8
3 10 6
4 12 4
5 14
2
0
6 16 1 2 3 4 5 6
27

28. Slope Intercept Form
T(n)= 2n+4 C1n + C2
if n = 0 ?
n T(n) if C2= 0?
1 6
2 8
18
3 10 16
14
4 12 12
10
5 14 8
6
6 16
4
2
0
1 2 3 4 5 6
28

29. Growth
29

30. Growth
30

31. Order notation –
some useful comparisons
• O(1) < log n < n < n log n < n2 < n3 <
2n < 3n < n! < nn
31

32. Order notation –
some useful comparisons
• Behavior of Growth for Log( number, base) is
the same; Log2 n = Log3 n = Log10 n
32

33. Practical and
Un-practical algorithms
• Algorithm is practical, if it’s time complexity is
T(n) = O(na) (polynomial)
• Algorithm is not practical otherwise
T(nn) usually is exponential)
33

34. Example
• Assume that we have a record of 1000
students. If we want to search a specific
record, what is the time complexity?
• If ordered?
Fastest Known Sorting Algorithm (n * log n)
Quick Sort / Merge Sort
Fastest Known Searching Algorithm (log n)
Binary Search
34
