6WIND Virtual Accelerator Performance Test Comparison
•
6 likes•6,970 views
The document describes performance tests of a 6WIND Virtual Accelerator for network packet forwarding. Test 1 used an Open vSwitch and Linux VM and achieved 14 Gbps. Test 2 used the Virtual Accelerator and a Linux VM and achieved 118 Gbps, an 8x increase. Test 3 used the Virtual Accelerator and a DPDK-enabled VM and achieved wire-speed performance of 240 Gbps. The Virtual Accelerator is designed to provide high-performance networking and virtual switching capabilities for virtual network applications.
