Cassandra & puppet, scaling data at $15 per month

  1. 1. Cassandra & Puppet:<br />Scaling data at $15/month<br />Constant Contact<br />March 2011<br />Dave Connors – VP Operations<br />Jim Ancona – Systems Architect<br />Mark Schena – Manager Systems Automation<br />
  2. 2. Constant Contact<br />Constant Contact<br />2000 – 2010 <br />Market leader for Small Businesses<br /><ul><li>Email, Event & Survey
  3. 3. Over 400k paying customers
  4. 4. No. 134 on the Deloitte Technology Fast 500 listing</li></ul>Business model<br /><ul><li>Many customers pay as little as $15 a month
  5. 5. ~2 million database transactions per minute</li></li></ul><li>Constant Contact<br />The business problem<br />
  6. 6. Constant Contact <br />Small Businesses are looking to us for help with Social Media marketing<br /><ul><li>Social Media 10-100 times more data
  7. 7. Challenge with our business model</li></li></ul><li>The Key Challenge<br />The Key Challenge<br />Integrate social media data<br /><ul><li>Solution = NoSQL
  8. 8. Cost = Low
  9. 9. Time to market = ?</li></li></ul><li>Implementation<br />Implementing NoSQL<br />Ops and Dev both face issues<br /><ul><li>Data model
  10. 10. Monitoring
  11. 11. Authentication
  12. 12. Logging
  13. 13. Risk profile
  14. 14. Roles & Responsibilities</li></li></ul><li>Ops<br />Dev<br />
  15. 15. Apache Cassandra<br />Apache Cassandra<br /><ul><li>Developed at Facebook
  16. 16. Open sourced in 2008
  17. 17. Incubated at Apache
  18. 18. Became an Apache top-level project in 2010
  19. 19. http://cassandra.apache.org
  20. 20. In use at Digg, Facebook, Twitter, Reddit, Rackspace, Cloudkick, Cisco, …
  21. 21. Largest production cluster has over 100 TB of data in over 150 machines</li></li></ul><li>What is Cassandra?<br />What is Cassandra<br /><ul><li>Implemented in Java
  22. 22. Fault Tolerant
  23. 23. Elastic
  24. 24. Durable
  25. 25. Rich data model
  26. 26. Replicated data
  27. 27. Consistency options</li></li></ul><li>Replication<br />Replication<br />How many copies of each piece of data <br />do we want?<br />N=3<br />
  28. 28. Consistency LevelONE<br />Consistency Level One<br />Y<br />
  29. 29. Consistency Level Quorum<br />X<br />
  30. 30. Risks and Mitigation<br />Risks and Mitigation<br /><ul><li>Moving target
  31. 31. Developer unfamiliarity
  32. 32. Operational procedures
  33. 33. Reliability concerns
  34. 34. Deployment automation
  35. 35. Community involvement
  36. 36. Training/Consulting
  37. 37. Application selection
  38. 38. Lots of monitoring
  39. 39. Phased rollout</li></li></ul><li>Development Challenges<br />Development Challenges<br />Understanding the data model<br />Choosing a client<br />Clients available for Java, Python, .NET, Ruby, PHP<br />Don’t use Thrift<br />Moving target<br />
  40. 40. Open Source<br /><ul><li>Not “one neck to wring”
  41. 41. Paid support and training is available: http://datastax.com
  42. 42. Community</li></ul>Mailing lists<br />IRC #cassandra at freenode<br /><ul><li>Contribute</li></li></ul><li>Phased Rollout<br /><ul><li>Switchable modes
  43. 43. Mirroring
  44. 44. Dial-able traffic </li></li></ul><li>Collaboration<br /><ul><li>Big, complex project
  45. 45. Close collaboration
  46. 46. Flexible roles
  47. 47. Ability to iterate</li></li></ul><li>Ops<br />Dev<br />
  48. 48. “Are you sure you really want that?” <br />“Are you sure you really want that?”<br /><ul><li>3 500G disks
  49. 49. 1 250G disk
  50. 50. No SWAP
  51. 51. RAID Zero Root Partition and Data Storage
  52. 52. 32G Memory</li></li></ul><li>We will need how many servers?<br />We will need how many servers?<br />
  53. 53. How many nodes?<br /><ul><li>Quorum = 3
  54. 54. Multiple Datacenters = 2
  55. 55. Use only half the available disk = 2
  56. 56. 12 Servers = ~1 TB Of Data Storage
  57. 57. ~6 TB of Data Storage </li></ul>72<br />x 6 =<br />x 2 = 12<br />3<br />x 2 = 6<br />
  58. 58. Ran<br />Random Partitioner<br />
  59. 59. Tool Chain<br />Tool Chain<br />
  60. 60. with Puppet<br /><ul><li>Puppet is the shared framework between Operations and Development
  61. 61. Versioning of puppet code allows for adoption of development best practices
  62. 62. Leverage Domain specific knowledge and skill</li></ul>DevOps with Puppet<br />
  63. 63. Always Move Forward<br />Always Move Forward<br />
  64. 64. Operational Efficiencies<br /><ul><li>Remote logging is a requirement
  65. 65. Cassandra uses log4j natively
  66. 66. Resources not available for remote log4j development
  67. 67. Scribed with Puppet provides the solution</li></ul>Operational Efficiencies<br />
  68. 68. Development takes the Operational Lead<br /><ul><li>Munin
  69. 69. JMX trending
  70. 70. Identify critical data points
  71. 71. Rapid development of graphs
  72. 72. Puppet Definitions are used for rapid deployment</li></li></ul><li>Sample Munin Graph<br />
  73. 73. Puppet Code <br />Example: Munin Puppet Code<br />define munin::cassandracolumnfamily ( ) {<br /> include cassandravirtual<br /> File <| title == "jmxbin" |><br /> $confdir="/opt/cassandra-munin-plugins”<br /> $plugindir="/etc/munin/plugins"<br /> $target="/opt/cassandra-munin-plugins/jmx_"<br /> # Match 3 strings separated by periods<br /> $pattern = '^([^.]*)[.]([^.]*)[.]([^.]*)$'<br /> $keyspace = regsubst($name, $pattern, '')<br /> $columnfamily = regsubst($name, $pattern, '')<br /> $file = regsubst($name, $pattern, '')<br />file {"${keyspace}_${columnfamily}_${file}.conf":<br /> owner => 'root', ensure => 'file', group => 'root', type => 'file',<br /> path => "${confdir}/${keyspace}_${columnfamily}_${file}.conf",<br /> mode => '644',<br /> content => template("munin/attribute_${file}.conf.erb"),<br /> require => [ Package['munin-node'], File['/opt/cassandra-munin-plugins'], File['jmxquery'], ], <br /> }<br />file {"$plugindir/${keyspace}_${columnfamily}_${file}":<br /> ensure => 'link', owner => 'root', group => 'root', mode => '511', type => 'link',<br /> target => "$target",<br /> require => [ File['/opt/cassandra-munin-plugins'], File["${keyspace}_${columnfamily}_${file}.conf"], File['jmxquery'], Package['munin-node'], ], <br />
  74. 74. Conclusion<br />Conclusion<br /><ul><li>Cassandra as an appliance
  75. 75. Development Best Practices with Life Cycle Management
  76. 76. Traditional vs. Today
  77. 77. Infrastructure </li></ul> 4 weeks 4 hours to build 72 nodes<br /><ul><li>Development to Deployment</li></ul> 9 months 3 months<br /><ul><li>Cost</li></ul> Millions 150k<br />
  78. 78. Q&A<br />Thank You!<br />

Editor's Notes

  • “… a highly scalable second-generation distributed database, bringing together Dynamo&apos;s fully distributed design and Bigtable&apos;sColumnFamily-based data model.”
  • Operational attributesFault TolerantData is automatically replicated to multiple nodes for fault-tolerance. Replication across multiple data centers is supported. Failed nodes can be replaced with no downtime.DecentralizedEvery node in the cluster is identical. There are no network bottlenecks. There are no single points of failure.ElasticRead and write throughput both increase linearly as new machines are added, with no downtime or interruption to applications.DurableCassandra is suitable for applications that can&apos;t afford to lose data, even when an entire data center goes down.Not just key-value. Replication and Consistency are configurable and datacenter aware
  • Can also be configured cross-datacenter.
  • Consistency Level is tunableONEQUORUMALLAt level ONE, one copy makes it to disk synchronously, before caller returns success.Same with reads. One node is read, so can get old data
  • At QUORUM, two of three (QUORUM) written before returningQUORUM Read: Quorum must AGREEFirst two don’t, so wait for the third node to resolve the tie
  • RISKS0.7.x in beta when we started, multiple betas and RCsRDBMS best practices are understood, if they exist for Cassandra how to discover them?Complicated system, lots of knobs, how to tune themMITIGATIONSWe deployed 0.7.2 across 72 servers in 90 minutes two days before we went live. 0.7.3 any day nowMailing lists, read code, file bugsA little about DatastaxStarted with a small app, higher risk ones come later, Mark will talk about monitoring—we have hundreds of graphs
  • Data model: no joins, referential integrity or fixed schema. If you want those things, you have to code them.Rows with millions of columnsThrift: driver-level interface, doesn’t do things an application-level client should do, e.g. failover, retry
  • Contributed bug reports and patches to Cassandra and HectorIncorporated in follow-on releasesNo need to maintain our own fork
  • Mirror modeShort timeoutsLog errors DB2 is still database of record
  • Necessary for success
  • Authentication and Authorization; test basic functionaiity; rapidly deploy new changes
  • ×
