These are the slides from my presentation on JavaFX and WidgetFX at the Silicon Valley Code Camp.

1. Getting Started with JavaFX and WidgetFX Stephen Chin Inovis, Inc. Keith Combs Inovis, Inc.

2. JavaFX Crash Course

3. 3 Start Here: JavaFX.com

4. 4 Hello Earthrise

5. 5 JavaFX API Docs

6. JavaFX Mobile Development

7. JavaFX Mobile Advantages Write Once, Run Anywhere Desktop, Mobile, Set-top Boxes (future) Large Embedded Base Built on top of Java ME platform Wide Range of Devices Runs on Feature Phones, Smart Phones Currently available for Windows Mobile devices

8. JavaFX Mobile Constraints Screen Size Your application has to be capable of running within a resolution of 320 by 240 or possibly even smaller. Common Profile Mobile applications are limited to the JavaFX APIs that are part of the Common Profile, which is a subset of the Desktop Profile. Performance Mobile applications run on much less powerful devices, so they have less CPU and memory resources available to work with.

9. Developing for the Common Profile

10. Mobile Demos Try out the HTC Touch Diamond

11. Java User Group Spinner Wheel 11 Web Service Integration

12. Calling a REST Service REST URL: http://api.meetup.com/rsvps.json/event_id={eventId}&rsvp=yes&key={apiKey} Output: { "results": [ {"zip":"94044","lon":"-122.48999786376953","photo_url":"http:photos1.meetupstatic.comphotosmember14bamember_5333306.jpeg","response":"no","name":"Andres Almiray","comment":"Can't make it :-("} ]} 12

13. JUG Spinner - JSONHandler in 3 Steps public class Member { public varplace:Integer; public varphotoUrl:String; public varname:String; public varcomment:String; } varmemberParser:JSONHandler= JSONHandler { rootClass: "org.jfxtras.jugspinner.data.MemberSearch “ onDone: function(obj, isSequence): Void { members = (obj as MemberSearch).results; }} req = HttpRequest { location: rsvpQuery onInput: function(is: java.io.InputStream) { memberParser.parse(is); }} 13 1 POJO 2 JSONHandler 3 HttpRequest

14. 14 rsvpQuery http://jfxtras.org/

15. Silicon Valley JavaFX Users Group Free membership Rockstar presenters First Event: Google Campus (Seville Room) Speaker: Richard Bair Member of the JavaFX Team JavaOne 2009 Rockstar Speaker December 9th (Tuesday) 15 http://svjugfx.org/

16. The JavaFX Desktop Widget Platform WidgetFX

17. WidgetFX Origins 17

18. 18 Why another desktop widget framework? Open-Source But widgets can be licensed commercially Write Widgets in Java & JavaFX HTML, CSS, and Javascript are great for websites, but not app development Cross-Platform Support Windows XP/Vista, Linux, and Mac OS X. One-Click Installation Plus automatic updates of the dock and widgets. Robust Security Secure sandbox + signed widgets

19. Built-in Widgets Clock Skinnable via CSS Slide Show Configurable Directory, Speed, & Filter Web Feed Supports Atom and all RSS flavors 19

20. Dock Features Drag to desktop Resize widgets (option for fixed aspect ratio) Per widget transparency Widget settings saved on restart Toggle dock always-on-top Launch on start-up Multi-monitor support Dock and widgets can be styled via CSS 20

21. Movie Widget Tutorial

22. Widget Properties 22

23. Widget Definition var widget: Widget; widget = Widget { width: 640 height: 352 aspectRatio: bind player.media.width / player.media.height content: bind player } 23

24. Load the Media var source = "http://projavafx.com/movies/ elephants-dream-640x352.flv"; var player = bind SimpleMoviePlayer { media: Media { source: source } width: bind widget.width height: bind widget.height } 24

25. Run in Widget Runner 25

26. Widget Configuration Properties 26

27. Widget Configuration widget = Widget { ... configuration: Configuration { properties: [ StringProperty { name: "source“ value: bind source with inverse } ] scene: Scene {…} // see next page } } 27

28. Widget Config Dialog Scene { content: Grid { rows: row([ Text { content: "Source URL:“ }, TextBox { columns: 30, value: bind source with inverse } ]) } } 28

29. Add an On-Replace Trigger var player = bind SimpleMoviePlayer { media: Media { source: source } width: bind widget.width height: bind widget.height } on replace =oldPlayer { oldPlayer.player.stop(); } 29

30. Widget Configuration (demo) 30

31. Widget Development Contest 31

32. Widget Contest Results 3rd Place Infix WeatherWidget Larry Dickson 2nd Place RadioFX Yannick Van Godtsenhoven 32

33. Widget Contest Results 1st Place ScreenshotFX Pär Dahlberg 33

34. Pro JavaFX Book Giveaway! 34

35. 35 Thank You Stephen Chin http://steveonjava.com/ Tweet: steveonjava Keith Combs
