The Giraffa File System   Konstantin V. Shvachko   Alto Storage Technologies        Storage    September 19, 2012         ...
AltoStor                                     Giraffa      Giraffa is a distributed,      highly available file system     ...
AltoStor                                        Apache Hadoop      A reliable, scalable, high performance distributed     ...
AltoStor                                     The Design Principles      Linear scalability        More nodes can do more w...
AltoStor                                                       Hadoop Cluster      HDFS – a distributed file system       ...
AltoStor                  Hadoop Distributed File System      The namespace is a hierarchy of files and directories       ...
AltoStor                                           Scalability Limits      Single-master architecture: a constraining reso...
AltoStor                                                            Node Count Visualization                              ...
AltoStor                      Horizontal to Vertical Scaling      Horizontal scaling is limited by single-master architect...
AltoStor                                 Scalability for Hadoop 2.0      HDFS Federation        Independent NameNodes shar...
AltoStor                                  Namespace Partitioning       Static: Federation         Directory sub-trees are ...
AltoStor                                         Giraffa File System      HDFS + HBase = Giraffa        Goal: build from e...
AltoStor                                     Giraffa Requirements      Availability – the primary goal        Load balanci...
AltoStor                                             HBase Overview      Table: big, sparse, loosely structured        Col...
AltoStor           HBase Architecture 15
AltoStor                                                      HBase API      HBaseAdmin: administrative functions        C...
AltoStor                                         Building Blocks      Giraffa clients        Fetch file & block metadata f...
AltoStor                                                      Giraffa Architecture                                    Name...
AltoStor                                                                               Giraffa Client      GiraffaFileSyst...
AltoStor                                               Namespace Table      Single Table called “Namespace” stores        ...
AltoStor                                                                  Namespace Service           HBase Namespace Serv...
AltoStor                                                  Block Manager      Maintains flat namespace of Giraffa block met...
AltoStor                                  Data Management      DataNodes Store and Report data blocks;      Blocks are fil...
AltoStor                                        Row Key Design      Row keys        Identify files and directories as rows...
AltoStor                                    Locality of Reference      Files in the same directory – adjacent in the table...
AltoStor                                    Partitioning: Random      Straightforward partitioning based on random hashing...
AltoStor                                       Partitioning: Full Subtrees      Partitioning based on lexicographic full-p...
AltoStor              Partitioning: Fixed Neighborhood      Partitioning based on fixed depth neighborhoods               ...
AltoStor                                              Atomic Rename      Giraffa will implement atomic in-place rename    ...
AltoStor                           3-Step Recovery Procedure      Move of a file from srcDir to trgDir failed  1. If only ...
AltoStor                                 New Giraffa Functionality      Custom file attributes: user defined file metadata...
AltoStor                                                            Status      We are on Apache Extra      One node clust...
AltoStor           Thank You! 33
AltoStor                                                 Related Work      Ceph        Metadata stored on OSD        MDS c...
AltoStor                                                                 History      (2008) Idea. Study of distributed sy...
AltoStor                                                Etymology      Giraffe. Latin: Giraffa camelopardalis      Family ...
