Introducing the last features in Azure Sql Database service

1. #sqlsat589February 25th, 2017
What’s new with Azure SQL Database?
Marco Parenzan
@marco_parenzan

2. #sqlsat589February 25th, 2017
Sponsors

3. #sqlsat589February 25th, 2017
Organizers

4. #sqlsat589February 25th, 2017
Marco Parenzan | @marco_parenzan
•
•
•
•

5. #sqlsat589February 25th, 2017
PAAS EVOLUTION
The building block

6. #sqlsat589February 25th, 2017
PaaS
 You decide the size of the resources
 you always overprovision, you can scale elastic
 You don’t handle the resources’ infrastructure
 CPU+Memory+I/O(=tier) Unit of Measure

7. #sqlsat589February 25th, 2017
Cortana
Management Suite
Media ServicesStorage
Traffic
Manager
Visual Studio
Services
OMS
Management SuitMachine LearningCDNDocument DB
Search
SchedulerActive Directory Key Vault App Insights Cognitive Services Embedded Power BI
Hockey AppStream AnalyticsNotification HubIoT Hub Service Bus
Logic App
Where you decide the CPU on these?
Function

8. #sqlsat589February 25th, 2017
Serverless Architectures
Serverless architectures refer to applications that significantly
depend on third-party services (knows as Backend as a Service
or "BaaS") or on custom code that's run in ephemeral
containers (Function as a Service or "FaaS"), the best known
vendor host of which currently is AWS Lambda. By using these
ideas, and by moving much behavior to the front end, such
architectures remove the need for the traditional 'always on'
server system sitting behind an application. Depending on the
circumstances, such systems can significantly reduce operational
cost and complexity at a cost of vendor dependencies and (at
the moment) immaturity of supporting services.
From Martin Fowler
[https://martinfowler.com/articles/serverless.html]

9. #sqlsat589February 25th, 2017
Serverless vs. PaaS
 PaaS
 You decide the size of the resources
 you always overprovision, you can scale elastic
 You don’t handle the resources’ infrastructure
 CPU+Memory+I/O(=tier) Unit of Measure
 Serverless
 You consume
 «blended» Unit of Measure

10. #sqlsat589February 25th, 2017
Database Transaction Unit (DTU)
 DTUs provide a way to describe the relative
capacity of a performance level based on a
blended measure of CPU, memory, and read
and write rates offered by each performance
level.
 Documented here:
https://azure.microsoft.com/en-
us/documentation/articles/sql-database-
benchmark-overview

11. #sqlsat589February 25th, 2017
Azure SQL Database
 Fully managed SQL database service that lets you focus
on your business
 Database provisioning on-demand
 Predictable performance for enterprise workloads
 Elastic database pools for unpredictable SaaS
workloads
 99.99% availability SLA
 Geo-replication and restore services for data protection
 Secure and compliant to protect sensitive data
 Compatible with SQL Server 2016 databases

12. #sqlsat589February 25th, 2017
Predictable performance
 Isolated databases are allocated isolated resources
 Basic, Standard, and Premium tiers provide increasing performance
levels
 Scale up/down in response to actual or predicted change in
workload
 Databases remain online while scaling
 Hourly billing at highest rate that hour
S0 S1 S2 S3 P1 P2 P4 P6/P3 P11
Maximum Database Size 2GB 1TB
DTUs 5 10 20 50 100 125 250 500 1,000 1,750
Point-in-time restore Any point within 7 days
Disaster Recovery
Geo-Restore to any
Azure region
Max In-Memory OLTP Storage N/A N/A N/A N/A N/A 1GB 2GB 3GB 8GB 10GB
Max concurrent requests 30 60 90 120 200 200 400 800 1,600 2,400
Max concurrent logins 30 60 90 120 200 200 400 800 1,600 2,400
Max sessions 300 600 900 1,200 2,400 2,400 4,800 9,600 19,200 32,000
Standard Geo-Replication, offline
secondary
Active Geo-Replication, up to 4 online
(readable) secondary backups
Basic Standard Premium
250GB 500GB
Any point within 14 days Any point within 35 days
S0 S1 S2 S3 P1 P2 P4 P5 P11 P15
Maximum Database Size 2GB
DTUs 5 10 20 50 100 125 250 500 1,000 1,750 4,000
Point-in-time restore Any point within 7 days
Disaster Recovery
Max In-Memory OLTP Storage N/A N/A N/A N/A N/A 1GB 2GB 4GB 8GB 14GB 32GB
Max concurrent requests 30 60 90 120 200 200 400 800 1,600 2,400 6,400
Max concurrent logins 30 60 90 120 200 200 400 800 1,600 2,400 6,400
Max sessions 300 600 900 1,200 2,400 30,000 30,000 30,000 30,000 30,000 30,000
Premium
Active Geo-Replication, up to 4 online (readable) secondary backups
1TB
Any point last within 35 days
Basic Standard
250GB 500GB

13. #sqlsat589February 25th, 2017
Azure SQL Database Virtual Logical Server
 Logic container
 «Database», «Elastic Pool» and «Data Warehouse»
 Context
 «Endpoint» for connection (es.
dbdemo.database.windows.net)
 Users that can access to these databases
 «Policy» (es. «Audit», «Threat detection»)
 You loose ALL the typical functionalities at
server level

14. #sqlsat589February 25th, 2017
JSON SUPPORT

15. #sqlsat589February 25th, 2017
Built-in functions for JSON
 ISJSON - valid JSON ?
 JSON_VALUE extracts scalar value
 JSON_QUERY extracts an object or array

16. #sqlsat589February 25th, 2017
OPENJSON

17. #sqlsat589February 25th, 2017
FOR JSON
 In PATH mode dot syntax - 'Item.Price' – formats
nested output.

18. #sqlsat589February 25th, 2017
TEMPORAL TABLES

19. #sqlsat589February 25th, 2017
Temporal Tables
 Automatically keeps track of changed data
 Available in SQL Azure
 Transparent to existing applications (if needed)

20. #sqlsat589February 25th, 2017
Temporal Queries
 AS OF <date_time>
 FROM <start_date_time> TO <end_date_time>
 BETWEEN <start_date_time> AND
<end_date_time>
 CONTAINED IN (<start_date_time> ,
<end_date_time>)
 ALL

21. #sqlsat589February 25th, 2017
Temporal Tables
 Some limitations compared to “classic” tables
 No TRUNCATE TABLE support
 INSTEAD OF triggers not supported
 Temporal tables *can* be ALTERed
 A few limitations:
 Cannot add a computed columns
 Cannot add an Identity column
 Versioning can be turned on/off as we wish
 There is *no* automatic cleanup of versioning
 Stretch Database offer “a sort of” automatic archival (but still
no cleaning!)
 Tips: https://msdn.microsoft.com/library/mt637341.aspx

22. #sqlsat589February 25th, 2017
ROW LEVEL SECURITY

23. #sqlsat589February 25th, 2017
Row-level security
 Protect data privacy by ensuring the right access
across rows
 Give users access only the rows
applicable to their role
 Simplify the design and coding of
security in your apps
 Administer with SQL Server Management Studio
or SQL Server Data Tools

24. #sqlsat589February 25th, 2017
DYNAMIC DATA MASKING

25. #sqlsat589February 25th, 2017
Dynamic data masking
 Limit the exposure of sensitive data by hiding it
from users
 Auto-discovery of potentially sensitive data to mask
 Configurable masking policy
from the Azure portal or via
DDL in the server
 On-the-fly obfuscation of data in query results
 Flexibility to define a set of privileged users for un-
masked data access

26. #sqlsat589February 25th, 2017
GEO REPLICATION

27. #sqlsat589February 25th, 2017
High-availability platform
Reads are completed at the primary
Writes are replicated to secondaries
Single logical database
Write
Write Ack
Ack
Read
value write
Ack
Critical capabilities:
 Create new replica
 Synchronize data
 Stay consistent
 Detect failures
 Failover
 99.99% availability

28. #sqlsat589February 25th, 2017
«Active Geo-Replication»
 Fino a 4 copie secondarie
 Accessibile in sola lettura
 Supportati scenari di aggiornamento e trasferimento
 «Failover» manuale
 «Estimated Recovery Time»: <30 secondi
 «Recovery Point Objective»:<5 secondi
 Disponibile per tutti i «Service Tier»!

29. #sqlsat589February 25th, 2017
SCALABILITY

30. #sqlsat589February 25th, 2017
Scalability patters [1]

31. #sqlsat589February 25th, 2017
«Scale up» e «Scale down»
 Change the service level
 «Service Tier/Performance Level»
 Copy by replica operation
 Interruption during switch
 Check compatibility with feature used (ex.
Database size)

32. #sqlsat589February 25th, 2017
Predictable performance
 Isolated databases are allocated isolated resources
 Basic, Standard, and Premium tiers provide increasing performance
levels
 Scale up/down in response to actual or predicted change in
workload
 Databases remain online while scaling
 Hourly billing at highest rate that hour
S0 S1 S2 S3 P1 P2 P4 P6/P3 P11
Maximum Database Size 2GB 1TB
DTUs 5 10 20 50 100 125 250 500 1,000 1,750
Point-in-time restore Any point within 7 days
Disaster Recovery
Geo-Restore to any
Azure region
Max In-Memory OLTP Storage N/A N/A N/A N/A N/A 1GB 2GB 3GB 8GB 10GB
Max concurrent requests 30 60 90 120 200 200 400 800 1,600 2,400
Max concurrent logins 30 60 90 120 200 200 400 800 1,600 2,400
Max sessions 300 600 900 1,200 2,400 2,400 4,800 9,600 19,200 32,000
Standard Geo-Replication, offline
secondary
Active Geo-Replication, up to 4 online
(readable) secondary backups
Basic Standard Premium
250GB 500GB
Any point within 14 days Any point within 35 days
S0 S1 S2 S3 P1 P2 P4 P5 P11 P15
Maximum Database Size 2GB
DTUs 5 10 20 50 100 125 250 500 1,000 1,750 4,000
Point-in-time restore Any point within 7 days
Disaster Recovery
Max In-Memory OLTP Storage N/A N/A N/A N/A N/A 1GB 2GB 4GB 8GB 14GB 32GB
Max concurrent requests 30 60 90 120 200 200 400 800 1,600 2,400 6,400
Max concurrent logins 30 60 90 120 200 200 400 800 1,600 2,400 6,400
Max sessions 300 600 900 1,200 2,400 30,000 30,000 30,000 30,000 30,000 30,000
Premium
Active Geo-Replication, up to 4 online (readable) secondary backups
1TB
Any point last within 35 days
Basic Standard
250GB 500GB

33. #sqlsat589February 25th, 2017
«Query Performance Insight»

34. #sqlsat589February 25th, 2017
SaaS issues
 Customers with different requirements
(performances)
 Customers in different regions
 Overprovisioning

35. #sqlsat589February 25th, 2017
Scalability patters [2]

36. #sqlsat589February 25th, 2017
Scenario
 IoT, device syncronization
 Multiple customers
 Monthly subscription
S0 S1 S2 S3 P1 P2 P4 P5 P11 P15
Maximum Database Size 2GB
DTUs 5 10 20 50 100 125 250 500 1,000 1,750 4,000
Point-in-time restore Any point within 7 days
Disaster Recovery
Max In-Memory OLTP Storage N/A N/A N/A N/A N/A 1GB 2GB 4GB 8GB 14GB 32GB
Max concurrent requests 30 60 90 120 200 200 400 800 1,600 2,400 6,400
Max concurrent logins 30 60 90 120 200 200 400 800 1,600 2,400 6,400
Max sessions 300 600 900 1,200 2,400 30,000 30,000 30,000 30,000 30,000 30,000
Premium
Active Geo-Replication, up to 4 online (readable) secondary backups
1TB
Any point last within 35 days
Basic Standard
250GB 500GB

37. #sqlsat589February 25th, 2017
Failure scenario
 Bad performance on a query (timeout)
 Need time to check
 No time to check immediatly
 Immediate reaction: scale up (BasicS0)
 Time: 5minutes
 Time to check: 2 weeks
 Costs of DB: 12€/2=6€
 Fixed query
 Scale down (S0Basic)

38. #sqlsat589February 25th, 2017
Scalability patters [4]

39. #sqlsat589February 25th, 2017
«Sharding»
 Molteplici database condivisi da più «tenant»?
 Tecnica «Scale out» distribuzione dati
 Strutturati in maniera identica
 In più database indipendenti
 In base a «Sharding Key»
 Mappature per intervallo di valori o lista

40. #sqlsat589February 25th, 2017
«Elastic Database client library»
 «Shard Map Management»
 Mappatura «Shard Keys» e database
 «Shard Keys» liste o intervalli di valori
 «Data Dependent Routing»
 Supporto apertura connessione in base a «Shard Key»
 «Multi-Shard Queries»
 Supporto Query che coinvolge più «Shard»
 Fusione unico «Result Set» con Semantica UNION ALL
Image source: https://docs.microsoft.com/en-us/azure/sql-database/sql-database-elastic-scale-shard-map-management

41. #sqlsat589February 25th, 2017
«Elastic Database Pools»
 DTU Pool (eDTUs) and Storage Pool (GBs)
shared
 Minimal guaranteed
 Maximum set
 «Auto-Scale»
 You can add/remove during lifetime
Image source: https://docs.microsoft.com/en-us/azure/sql-database/sql-database-what-is-a-dtu

42. #sqlsat589February 25th, 2017
BACKUP

43. #sqlsat589February 25th, 2017
Point-in-time restore
Programmatic “oops recovery” of data deletion
or alteration
Auto backups
 «Full» weekly
 «Differenziale» some hours
 «Log» every 5-10 minutes
Backups in Azure Storage and geo-replicated
Creates a side-by-side copy, non-disruptive
REST API, PowerShell or Azure Portal
Backups retention policy:
 Basic, up to 7 days
 Standard, up to 14 days
 Premium, up to 35 days (preview 10 years)
Automated export of logical backups for long-
term backup protection
Geo- replicated
Restore from
backup
SQL Database
Backups
sabcp01bl21
Azure
Storagesabcp01bl21

44. #sqlsat589February 25th, 2017
CONCLUSIONS

45. #sqlsat589February 25th, 2017
Conclusions
Almost complete alignment with IaaS/On Premise
SQL Server 20016
Think PaaS
Think about alternatives to Management System

46. #sqlsat589February 25th, 2017
Funzionalità rispetto versione «on-premise»
 Not everything on Azure SQL Database
 Es. CDC, CLR, FILESTREAM, PBM, Service Broker
 Different implementation
 Es. AwaysOn AG/Active Geo Replication, SSIS/Azure Data Factory
 Some in preview
 Es. Row-Level Security, Data Masking, Temporal Tables

47. #sqlsat589February 25th, 2017
Compliance
SOC 1 Type 2 and
SOC 2 Type 2
ISO/IEC 27001 FedRAMP/FISMA
HIPAA
business associate
agreement (BAA)
PCI DSS Level 1
EU Model Clauses

48. #sqlsat589February 25th, 2017
THANKS! Q&A
#sqlsat589
