Join us on Wednesday, October 19th, for our webinar, "What Comes After MBSE?" SPEC Innovations President and Founder, Dr. Steven Dam, will discuss the future of our industry. Since 2007, the focus has been moving from document-based systems engineering to model-based systems engineering (MBSE). With our ever-changing industry and the update to SysML V2, we believe there will be a massive move toward more data-driven systems engineering.
Dr. Dam will dive deeper into the past and present of Systems Engineering, and how this will take us into the future of Data-Driven Systems Engineering. He will share how SPEC Innovations is currently moving into this trend using Innoslate and its power of migration. There will be a time in the end for questions, so bring any you may have with you.
