Vector Duty
USATENV09

2. TENV Vector Duty line
3
PH
ENCL
FRAME
5(3.7)
HP(kW)
TENV
1.0
SF
VOLTS
TYPE
INS CL
NEMA NOM EFF
89.5%
230/460
F
ET
PF
t 105
K
1760
0.77
CODE
87.5%
13.6/6.8
3/4 LOAD EFF
AMPS
CONT.
DUTY
184TC
RPM
SFA
MODEL 00518ET3FVD184TC
3.060
2.553
R1
R2
CONNECTION
Hz
0.06
60
90
HP (KW)
0
5(3.7)
5(3.7)
IP55
M
DES
A
MAX
AMB.
40°C
9.437
12.353
213.329
X1
X2
XM
TQ (FT-LB)
14.9
14.9
10
RPM
0
1760
2625
6307-ZZ-C3
6307-ZZ-C3
60
Hz
ALT 1000 m.a.s.l.
VOLTS
0
460
460
AMPS
6.8
6.8
6.6
90lb
ALSO ENERGY VERIFIED
CSA C390-98
CSA
Class I - Division 2
Groups B, C and D
CLASS I , DIV 2, GROUP F; TEMP CODE T3
E R
E104590
EEV 78282
MOD.1UTEIFGNXH00504E
LR 50962 AND LR 38324
RUN CONNECTION
T4
T5
T4
T6
T7 T8 T9
T1 T2 T3
L1 L2 L3
460 V
Applications
g Conveyors
g Crane and Hoists
g Extruders
g Metal Processing
g Any that would require
constant torque over a
wide speed range
CC029A
Severe Duty
OHMS/PHI
Special Features
g Different mounting configurations
g Thermistors
g Space heater
g IP56, 65, 66 ratings
g Tropicalized Internal Painting
g Special shaft seals
g Encoder
g Brake w/torque up to 105lb ft.
g AEGISTM SGR Bearing protection
ring (shaft grounding ring)
g Insulated Bearings
208-230 V
Standard Features
NEMA Premium Efficiency
g Constant torque operation from 0 to base
speed (1000:1) on PWM Vector Drive
g Constant Horsepower operation to 150% base
speed at 40oC ambient
g C-face mount with feet
g Spike Resistant Wire
g Ready for Encoder or Brake mount*
g W ith Thermostats (1 per phase)
g Totally Enclosed Non-Ventilated
g V-Ring Seals
g Standard NEMA frame sizes
g Special nameplate data for easy drive setup
g IP55
g A ll Cast Iron Construction
g
MADE IN MEXICO
This product line is designed specifically for Inverter
Operation, allowing its use in applications where
1000:1 constant torque turndown ratio is required.
T5
T6
T7 T8 T9
T1 T2 T3
L1 L2 L3
„
* NEMA 4.5 (AK) flange in NDE with 5/8 shaft allowing encoder or brake
assembly (Brake limited to 10lb. ft. torque)
NEMA PREMIUM
Design
NEMA 4.5
Flange
Cast Iron Frame
and Brackets
Spike Resistant
Wire
Stub Shaft
Thermally Protected
(Thermostats)
2
NEMA C Flange

3. TENV Vector Duty
Motor
MODEL
HP
RPM
VOLTS
FRAME
List
Price
Enclosure
FL AMPS
(460V)
APPROX.
WEIGHT
Inertia
Max Safe
RPM
00118ET3FVD143TC
00158ET3FVD145TC
00218ET3FVD145TC
00318ET3FVD182TC
00518ET3FVD184TC
00718ET3FVD213TC
01018ET3FVD215TC
01518ET3FVD254TC
1
1.5
2
3
5
7.5
10
15
1800
1800
1800
1800
1800
1800
1800
1800
230/460
230/460
230/460
230/460
230/460
230/460
230/460
230/460
143TC
145TC
145TC
182TC
184TC
213TC
215TC
254TC
697
705
928
1150
1373
1803
2157
2567
TENV
TENV
TENV
TENV
TENV
TENV
TENV
TENV
1.41
2.08
2.66
3.81
6.88
9.35
12.74
20.5
49
55
60
97
99
168
175
300
0.0930
0.1196
0.1329
0.3178
0.3813
1.0118
1.5638
2.6198
10400
10400
10400
6800
6800
6000
6000
5360
EQUIVALENT CIRCUIT (IN Ω AT 20°C)
MODEL
00118ET3FVD143TC
00158ET3FVD145TC
00218ET3FVD145TC
00318ET3FVD182TC
00518ET3FVD184TC
00718ET3FVD213TC
01018ET3FVD215TC
01518ET3FVD254TC
R1
R2
X1
X2
XM
8.985
7.220
5.625
2.611
3.060
0.814
0.471
0.299
4.585
3.576
6.604
1.578
2.553
0.555
0.327
0.240
13.438
9.694
8.187
5.917
9.438
1.783
1.014
0.782
17.810
12.710
10.249
8.740
12.354
3.451
1.984
1.710
360.765
271.252
227.337
184.704
213.329
65.554
32.462
28.562
CFW-11
Vector Motor and Drives
Innovative and simple
Technology - Patents
The CFW-11 presents many
innovations that are helpful and
beneficial to customers, mainly due
to the simplicity of its installation
and operation. The CFW-11 was
developed based on Plug-andPlay philosophy (connect and use)
allowing simple and fast installation of the VSD and its accessories. The
Keypad has a navigation and programming system similar to mobile
phones, with softkey buttons. It is possible to access the parameters
sequentially or through groups of parameters. The Keypad also makes
the Oriented Start-up function available, guiding the user through the
necessary programming.
Vectrue Technology®
F
ield oriented Vector Control: Sensorless
and closed loop with encoder
g ensorless vector control permits high
S
torque and quick response in open loop,
even at low speeds
g lose loop vector control allows zero
C
speed and full torque even for continuous
operation
g he self-tunning function automatically
T
matches the WEG motor and the vector
control modes.
g
Flexibility
The CFW-11 adapts itself to the customer’s needs through a broad range
of accessories, which are easily installed. Besides this, the standard
product comes with the SoftPLC function that attributes PLC functions
to the VSD, which allows the customer to create his/her own applications
(user programs) through the WLP software (programming in LADDER).
3

4. TENV Vector Duty
Accessories
ENCODER
Catalog
Number
Description
Magnetic
or Optical
ECHSD38-D *
HSD38 Dynapar
1024
Optical
5-26V (7272)
5/8
10 Pin
1418
PARTS.I
4
ECHS25A-A
HS25A Avtron
1024
Optical
5-28V (7272)
5/8
10 Pin
1423
PARTS.I
2
PPR
Bore
(in)
Input Voltage
Connector
Mult.
Sym.
List Price
Approx.
Wt.(lbs)
ECHS35A-A
HS35A Avtron
1024
Optical
5-28V (7272)
5/8
10 Pin
1590
PARTS.I
3
ECHS35M-A
HS35M Avtron
1024
Magnetic
5-24V (7272)
5/8
10 Pin
2150
PARTS.I
2
* Provided with Encoder guard
feedback cable assembly with ms connector
Catalog Number
Cable Length
List Price
Mult. Sym.
Appr. Wt. (lbs)
ENCCBLMS-10
10 ft
232
PARTS.I
2
ENCCBLMS-20
20 ft
413
PARTS.I
3
ENCCBLMS-30
30 ft
454
PARTS.I
4
ENCCBLMS-50
50 ft
672
PARTS.I
6
P
Dimensions
AB
BF
T
UNC 3/8-16
900
900
Ø5.875
ØAK
J
ØA
ØBD
D
AH
AA
G
0.157
0.188
1.750
BC
BA
2F
s
N-W
HOLE H
J
d1
A4
C-1
K
s
BB
A-1
B
NEMA
FRAME
143T
145T
182T
184T
213T
215T
254T
NEMA
FRAME
143T
145T
182T
184T
213T
215T
254T
2E
5.500
7.500
8.500
10.000
S
0.187
2F
4.000
5.000
4.500
5.500
5.500
7.000
8.252
KEYWAY
R
0.765
H
0.344
BA
A
6.457
2.750
8.661
0.406
3.500
0.531
9.764
4.250
12.126
ES
N-W
1.575
2.250
DE SHAFT
U
0.517
A-1
ØU
FC
B
2.250
A
C
5.157
6.142
5.945
6.969
7.362
8.858
10.000
10.890
11.874
12.766
13.766
15.737
17.237
20.610
DRIVE END
D
G
J
K
O
P
T
AB
AA
3.500
0.547
1.496
1.654
7.000
7.047
---
5.905
NPT 3/4”
4.500
0.720
1.890
1.969
9.343
8.740
0.875
5.250
0.827
2.008
2.165
10.841
10.630
6.250
0.817
2.520
2.559
12.431
12.283
2.087
BC
AH
FBD
FC
AJ
AK
BD
DE FLANGE
BF
BB
4.500
6.500
UNC 3/8”-16
0.156
2.125
0.125
0.250
0.984
1.969
2.750
1.125
0.313
1.203
2.480
3.375
1.375
0.375
1.406
2.756
4.000
6.496
2.625
A4
7.250
8.500
1.625
7.086
1.772
5.875
d1
R
Ø0.625
NON DRIVE END
2E
C
8.875
UNC 1/2”-13
0.250
0.250
3.125
3.750
6.693
NPT 1”
8.149
13.693
14.678
15.569
16.569
18.541
20.041
23.414
10.079
NPT 1-1/2”
BEARINGS
D.E.
N.D.E
6205-ZZ
6205-ZZ
6307-ZZ
6307-ZZ
6308-ZZ
6308-ZZ
6309-C3
6309-C3
