Virtual Clustered Multiprocessing (vCMP) allows administrators to segment physical ADC resources into independent virtual ADCs. It provides true isolation between instances through a purpose-built hypervisor designed specifically for F5 hardware and software. This deep integration enables high performance virtual instances without sacrificing reliability. It allows organizations to independently operate and manage virtual instances while maintaining interoperability with existing equipment.
