This drawing shows dimensions for a 3" AF32P SER valve with an ANSI300 rating and NACE compliance. Key dimensions include a 371.5mm stem diameter, 480mm actuator height, and 168.3mm PCD. The drawing also specifies the material as C45SR, a scale of 1:5, and general tolerancing and title block information.
