In this session, speakers Giles Sirett and Philipp Reisner shared insights into CloudStack and LINBIT. Giles detailed Apache CloudStack’s scalability, multi-tenancy, and compatibility with various hypervisors. He also discusses CloudStack’s integrated, easy-to-use nature, rapid time-to-value, and its active community. Following this, Giles delves into different use cases, such as IaaS/Cloud Provisioning, Disaster recovery, Sovereign Clouds, and the list goes on. CloudStack’s features, including its support for Kubernetes clusters, its scalable architecture, high availability and other features were also discussed. Following this, Philipp highlighted the 4 key ways in which LINBIT can help an organisation: ‘Protecting data, Always Keeping Your Services On, Shaping Your Destiny and Exceeding with Best Performance”. Philipp also delved into the different reasons why LINBIT SDS is so fast, and what the next steps are for DRBD, LINSTOR and the LINSTOR Driver for CloudStack. ----------------------------------------- On October 10th 2023, ShapeBlue, Ampere Computing and LINBIT held a joint virtual event – Building Next-Generation IaaS. The event explored how the synergy between ARM, Apache CloudStack and LINBIT’s storage solutions can achieve a formidable price-to-performance ratio. There were a total of 3 sessions held by speakers from all 3 organisations.

1. www.linbit.com | www.shapeblue.com
1. Updates from CloudStack
& LINBIT SDS
+

2. www.amperecomputing.com | www.linbit.com | www.shapeblue.com
Speakers
Philipp Reisner
CEO
Giles Sirett
CEO

3. www.linbit.com | www.shapeblue.com
What is
CloudStack?
Apache CloudStack is a scalable, multi-tenant,
open-source, purpose-built, orchestration
platform for delivering turnkey Infrastructure-as-
a-Service environments.

4. www.linbit.com | www.shapeblue.com
compute Storage
Networking
Hypervisor
CMP - Orchestration layer
orchestration API
eCommerce Platform
Choice of Hypervisor (KVM, VMware,
Xen, OVM, XCP-ng)
Apache CloudStack
CloudStack API
Networking Compute Storage
eCommerce Platform
Developer
Tooling
Automation
Tooling
How to Build IaaS

5. www.linbit.com | www.shapeblue.com

6. www.linbit.com | www.shapeblue.com
Why
CloudStack?
● Integrated end-to-end IaaS product
● Narrow scope/easy integration
● Proven at scale, widespread adoption
● Rapid time to value
● Low implementation & operational
costs
● Truly multi-tenant
● User-led, development community,
governed by Apache
● Free and open-source

7. www.linbit.com | www.shapeblue.com
CloudStack
Use Cases
• IaaS/Cloud Provisioning
• Private Cloud Management
• Telecom Cloud Services Provisioning
• Test and Dev Environments
• Disaster Recovery
• High-Performance Computing
• Data Storage and Big Data Analysis
• Service Provider
• CI/CD Pipelines
• Hybrid Clouds
• Sovereign Clouds

8. www.linbit.com | www.shapeblue.com
Key CloudStack Features
• User self-service
• Web UI, command line, REST-based API
• Multi-tenant
• Hypervisor-agnostic
• XenServer, KVM, VMware, OracleVM, Hyper-V, XCP-
ng
• Support for Kubernetes clusters
• Enterprise-grade tenant Virtual Networking model
• Scalable architecture
• Support thousands of hosts and virtual machine
guest
• Largest known production cloud 35k+ physical hosts
• High availability
• Configurations that provide automatic failover for
virtual machines

9. www.linbit.com | www.shapeblue.com
CloudStack & Kubernetes
Kubernetes Cluster
Kubernetes Cluster
CloudStack API
Kubernetes Cluster API
CloudStack Kubernetes
Service
CloudStack CAPI provider
Other CAPI providers
Kubernetes Cluster
Kubernetes Cluster

10. www.linbit.com | www.shapeblue.com
Selected CloudStack Users
… and many more

11. www.linbit.com | www.shapeblue.com
Apache CloudStack – a True
Open-source Platform
● ASF: Proven record in building some of the
worlds most used software platforms
● No dependency on vendor roadmap
● No license IP restrictions
● No vendor “lock-in”
● Reduced cost-at-scale
● User-driven dev community

12. www.linbit.com | www.shapeblue.com
CloudStack 4.18 – headline new
features
Edge Zones Allowing CloudStack orchestrated
environments to be deployed to the
edge
SDN Integration – Tungsten Fabric Use CloudStack to build complex
software-defined networks
CloudStack Autoscaling Allow users to scale-up and scale-down
according to demand
Managed User-Data Allow users to build libraries of host post-
deployment configurations
Two-Factor Authentication
Framework
Allow use of any 2FA provider
An Active Community
CloudStack 4.18, released March 2023

13. www.linbit.com | www.shapeblue.com
CloudStack 4.19- headline new
feature
VNF Appliances Deployment and management of virtual
network appliance
Hypervisor agnostic DRS Automatic workload placement and
balancing across any hypervisor type
Object Storage Framework Access to any S3-compliant Bucket
through a single API
DRaaS Easily offer DRaaS services based on
CloudStack
KVM Import Easily import KVM VM’s as CloudStack
Instances
An Active Community
CloudStack 4.18, released March 2023

14. www.linbit.com | www.shapeblue.com
●23-24 November
●Paris, France
●cloudstackcollab.org
An Active Community
CloudStack Collaboration Conference - 2023

15. www.linbit.com | www.shapeblue.com
compute Storage
Networking
Hypervisor
CMP - Orchestration layer
orchestration API
eCommerce Platform
Choice of Hypervisor (KVM, VMware,
Xen, OVM, XCP-ng)
Apache CloudStack
CloudStack API
Networking Compute Storage
eCommerce Platform
Developer
Tooling
Automation
Tooling

16. www.linbit.com | www.shapeblue.com
LINBIT helps you with
Shape Your Destiny
You must trust the software you select to
protect your data and services. Stay clear
of a vendor-lock-in-trap. Open Source is
the ultimate form of trust between
LINBIT and you.
Exceed with Best Performance
Whether you invest in server hardware or
cloud infrastructure, be assured that your
services get the best performance in
accessing your data under the constraints
of your precious investments
Protect Your Data
You will keep your data, no matter how
precarious the situation — hardware failures,
drives, servers, data centers, or even
ransomware.
Keep Your Services Always
On
The data might be worthless if your
services can not access them. Keep your
business running, no matter how bad the
universe treats you.

17. www.linbit.com | www.shapeblue.com
Protecting Data by replication

18. www.linbit.com | www.shapeblue.com
DRBD Roles: Primary & Secondary

19. www.linbit.com | www.shapeblue.com
DRBD – multiple Volumes
• consistency group

20. www.linbit.com | www.shapeblue.com
DRBD – up to 32 replicas
• each may be synchronous or
async

21. www.linbit.com | www.shapeblue.com
DRBD – Diskless nodes
• intentional diskless
• disks can fail

22. www.linbit.com | www.shapeblue.com
LINBIT helps you with
Shape Your Destiny
You must trust the software you select to
protect your data and services. Stay clear
of a vendor-lock-in-trap. Open Source is
the ultimate form of trust between
LINBIT and you.
Exceed with Best Performance
Whether you invest in server hardware or
cloud infrastructure, be assured that your
services get the best performance in
accessing your data under the constraints
of your precious investments
Protect Your Data
You will keep your data, no matter how
precarious the situation — hardware failures,
drives, servers, data centers, or even
ransomware.
Keep Your Services Always
On
The data might be worthless if your
services can not access them. Keep your
business running, no matter how bad the
universe treats you.

23. www.linbit.com | www.shapeblue.com
Keep Your Services Always On
Virtualization IaaS Clouds
Failover Cluster
● Corosync/Pacemaker
● drbd-reactor/promoter
Containers
…
… …

24. www.linbit.com | www.shapeblue.com
Types of applications
Transaction Processing
● Oracle DB
● PostgreSQL
● MariaDB
● Message queuing systems
Analytic Processing
● DB2 Warehouse
● And similar read intensive workloads
● Big Data, Map-reduce
● AI/ML training data

25. www.linbit.com | www.shapeblue.com
LINBIT helps you with
Shape Your Destiny
You must trust the software you select to
protect your data and services. Stay clear
of a vendor-lock-in-trap. Open Source is
the ultimate form of trust between
LINBIT and you.
Exceed with Best Performance
Whether you invest in server hardware or
cloud infrastructure, be assured that your
services get the best performance in
accessing your data under the constraints
of your precious investments
Protect Your Data
You will keep your data, no matter how
precarious the situation — hardware failures,
drives, servers, data centers, or even
ransomware.
Keep Your Services Always
On
The data might be worthless if your
services can not access them. Keep your
business running, no matter how bad the
universe treats you.

26. www.linbit.com | www.shapeblue.com
Leading Open Source OS based SDS
COMPANY OVERVIEW
REFERENCES
• Developer of DRBD and LINSTOR
• 100% founder owned
• Offices in Europe and US
• 40 experienced Linux experts
• Partner in Japan: SIOS
• Support Subscriptions
• YUM/APT package repositories
• three SLAs
• Open Source Software
• GPL, Apache
BUSINESS MODEL
SOLUTIONS
LINBIT SDS
Since 2016
Perfectly suited for SSD/NVMe high performance storage
LINBIT HA, LINBIT DR
Market leading solutions since 2001, over 600 customers
Ideally suited to power HA and DR in OEM appliances

27. www.linbit.com | www.shapeblue.com
LINBIT helps you with
Shape Your Destiny
You must trust the software you select to
protect your data and services. Stay clear
of a vendor-lock-in-trap. Open Source is
the ultimate form of trust between
LINBIT and you.
Exceed with Best Performance
Whether you invest in server hardware or
cloud infrastructure, be assured that your
services get the best performance in
accessing your data under the constraints
of your precious investments
Protect Your Data
You will keep your data, no matter how
precarious the situation — hardware failures,
drives, servers, data centers, or even
ransomware.
Keep Your Services Always
On
The data might be worthless if your
services can not access them. Keep your
business running, no matter how bad the
universe treats you.

28. www.linbit.com | www.shapeblue.com
Why is LINBIT SDS so fast?
Layout at volume allocation
• All participating machines have full replicas, which
machines participate determined when creating a
volume.
• Be faster at IO submission time
• Saving on CPU/memory
In Kernel data-path
• Reduce number of context switches
• Saving on CPU/memory resources
• Minimal latency for block-IO operations
• Optional load-balancing for READs
Hyper-Converged
Very well suitable for hyper-converged deployment
• Reduced network load for reads
• Reduces latency
• LINBIT SDS’ Low resource consumption leaves most
of CPU and memory for workload. About 0.5% of a
single core are consumed by DRBD under heavier IO
load (measured with an analytics DB)
Build on existing components
• DRBD, LVM, ZFS, LUKS, VDO, ...
• Help day2 operations by leveraging on the
opera tion teams prior knowledge
• Build on the shoulders of giants

29. www.linbit.com | www.shapeblue.com
Where are the IOPS numbers?
22 Million IOPS
• November 2019
• 12 nodes x86 (Intel)
• 25Gb network (Intel)
• Intel SSDs
• Blog post
25 Million IOPS
• March 2023
• 3 nodes ARM (Ampere)
• 100Gb network (Mellanox)
• Samsung SSDs
• Complete paper (21 pages)
Concrete results heavily depend...
• On the storage devices (NVMe-SSDs, PMEM)
• HCI , workload and storage device co-location
• Network switches and NICs
• CPU single core performance

30. www.linbit.com | www.shapeblue.com
Next Steps
DRBD
• TCP transport multi-pathing
• TLS encryption
• RDMA transport updates
• Improvements to handling I/O timeouts
LINSTOR
• Better handling of failing backing storage devices
• Prioritize LINSTOR control network traffic over bulk
DRBD traffic
• Improvements with clusters with many thousands of
storage resources
LINSTOR Driver for CloudStack
• Supported Hypervisors: KVM and XCP-ng
• VM snapshots (in addition to volume snapshots)
• Optional copying of snapshots to secondary storage
• Network switches and NICs
• Provisioning by copying in addition to provisioning by snapshots

31. www.amperecomputing.com | www.linbit.com | www.shapeblue.com

32. www.amperecomputing.com | www.linbit.com | www.shapeblue.com
Contact Us
sales@linbit.com
www.linbit.com
Linbit HA-Solutions GmbH
Stiegergasse 18
1150 Vienna, Austria
Linbit USA, LCC
8100 SW Nyberg St. Suite 200
Tualation, OR 97062
eursales@shapeblue.com
www.shapeblue.com
ShapeBlue
3 London Bridge Street
London SE1 9SG, UK
ShapeBlue USA
800 West El Camino Real, Suite 180
Mountain View, California, USA
