Unleashing your Kafka Streams Application Metrics!
- 1. Unleashing your Kafka Streams Application Metrics Neil Buesing Kinetic Edge Current 2023
- 3. So Many Metrics • Kafka Broker • Network • Machine / Pod • JVM • Kafka Client • Producer • Consumer • Admin • Kafka Streams
- 4. Stress Free Monitoring Katniss (best pair programmer)
- 5. Kafka Streams - GitHub Inquiry (path:**/pom.xml OR path://**/build.gradle) AND kafka-streams AND NOT (org:confluentinc OR org:apache) September 2023 = 8.9K (23K kafka-clients)
- 7. processor task thread JVM task allocation to threads - streams-consumer-group topic partition t1 p0 t1 p1 t2 p1 t3 p1 t2 p0 t3 p0 • Instance (JVM) • Client (Topology) • Thread (Worker) • Task • sub-topology • partition • Processor • State Stores Kafka Streams Architecture state store
- 8. Con fi guration • metrics.recording.level — INFO, DEBUG, TRACE • metrics.sample.window.ms — 30_000 • metrics.num.samples — 2
- 9. Exporting • JMX Reporter + Prometheus Agent • Dashboards Demonstrated with this configuration • No renaming of metrics in extraction rules • Micrometer • renames some metrics — makes dashboards incompatible. • does not export info metrics
- 10. Exporting • JMX Reporter + Prometheus Agent • Dashboards Demonstrated with this configuration • No renaming of metrics in extraction rules • Micrometer • renames some metrics — makes dashboards incompatible. • does not export info metrics private String meterName(MetricName metricName) { String name = METRIC_NAME_PREFIX + metricName.group() + "." + metricName.name(); return name.replaceAll("-metrics", "").replaceAll("-", "."); } currentMetrics.forEach((name, metric) -> { // Filter out non-numeric values // Filter out metrics from groups that include metadata if (!(metric.metricValue() instanceof Number) || APP_INFO.equals(name.group()) || METRICS_COUNT.equals(name.group())) return; 1.11.2
- 12. state store Client Metrics • version • state • num threads • application_id • job (application) • instance (JVM) • client (topology) • thread (worker) processor task thread JVM
- 13. state store Thread Metrics • operation • commit • poll • process • punctuate • ratio • metric • total • rate • latency-{avg|max} • job (application) • instance (JVM) • client (topology) • thread (worker) processor task thread JVM computing rate within grafana from a total metric rate(metric_total{}[$__rate_interval])
- 14. state store Task Metrics processor task thread JVM • operation • commit • process • punctuate • metric • total • rate • job (application) • instance (JVM) • client (topology) • thread (worker) • task • sub-topology • partition KAFKA-9441 (2.6)
- 15. state store Processor Metrics processor task thread JVM • operation • process • total/rate • suppression-emit • total/rate • record-e2e-latency • min/max/avg • job (application) • instance (JVM) • client (topology) • thread (worker) • task • sub-topology • partition • process node
- 16. state store Topic Metrics • operation • consumed • produced • metric • records total • bytes total • job (application) • instance (JVM) • client (topology) • thread (worker) • task • process node • topic processor task thread JVM consumed metrics produced metrics source & sink processors only topic=“topic_name” attribute included
- 17. state store Record Cache Metrics processor task thread JVM • metric • hit-ratio-min • hit-ratio-max • hit-ratio-avg • job (application) • instance (JVM) • thread (worker) • task • subtopology • partition • store name
- 18. state store State Store Metrics processor task thread JVM • operation • all • delete • fetch • get • pre fi x-scan * • put, put-all, put-if-absent • range • remove • restore • fl ush • computed • record-e2e ** • metric • rate • latency-avg (ns) • latency-max (ns) • job (application) • instance (JVM) • thread (worker) • task • subtopology • partition • store type • store name • other • suppression-bu ff er-size • suppression-bu ff er-count • metric • avg • max * KIP 614 / KAFKA-10648 - Pre fi x Scan support to State Stores - 2.8 ** KIP 613 / KAFKA-10054 - e2e latency metrics 2.7 TRACE
- 19. RocksDB Metrics • ~40 Metrics • Property Metrics • INFO • Statistical Metrics • DEBUG* • KIPs • 471 (2.4) • 607 (2.7) • KAFKA-8941 (3.2) ** background-errors block-cache-capacity block-cache-data-hit-ratio block-cache-filter-hit-ratio block-cache-index-hit-ratio block-cache-pinned-usage block-cache-usage bytes-read bytes-read-compaction bytes-written bytes-written-compaction compaction-pending compaction-time ** cur-size-active-mem-table cur-size-all-mem-tables estimate-num-keys estimate-pending-compaction-bytes estimate-table-readers-mem live-sst-files-size memtable-bytes-flushed mem-table-flush-pending memtable-flush-time ** memtable-hit-ratio number-file-errors number-open-files num-deletes-active-mem-table num-deletes-imm-mem-tables num-entries-active-mem-table num-entries-imm-mem-tables num-immutable-mem-table num-live-versions num-running-compactions num-running-flushes size-all-mem-tables total-sst-files-size write-stall-duration * emit as 0 in INFO https://docs.con fl uent.io/platform/current/streams/monitoring.html#rocksdb-metrics https://github.com/facebook/rocksdb/blob/main/include/rocksdb/db.h - “struct Properties”
- 21. Application rekey (user) attach user price aggregate orders fl atmap (line- item) rekey (sku) pickup attach store rekey (order) pickup peek users ktable stores global ktable products ktable fi lter RocksDB sub-topology indicator
- 22. Analytic Applications (Tumbling Window) line-item product-stats aggregate toStream mapValue windowBy TimeWindows .ofSize(30sec) RocksDB
- 23. line-item product-stats aggregate toStream mapValue windowBy TimeWindows .ofSize(30sec) .advanceBy(15sec) RocksDB Analytic Applications (Hopping Window)
- 24. line-item product-stats aggregate toStream mapValue windowBy SlidingWindows .ofSize(30sec) suppress RocksDB InMemory Analytic Applications (Sliding Window)
- 25. line-item product-stats aggregate toStream mapValue windowBy SessionWindows .ofInactivityGap(30sec) RocksDB Analytic Applications (Session Window)
- 26. line-item product-stats aggregate toStream processor mapValue punctuate schedule(15s, wall-clock) Analytic Applications (No Window)
- 27. Dashboards
- 29. Sub-topology Listing name your processors
- 30. Sub-topology Listing prometheus — label_replace label_replace( kafka_streams_stream_processor_node_metrics_process_total{} * on (instance) group_left(application_id) kafka_streams_info{application_id=~"${application}"}, "subtopology", "$1", "task_id", "(.*)_.*" ) prometheus — on / group_left name your processors
- 31. Task Assignment
- 32. Task Assignment
- 37. Threads
- 39. End to End Latency
- 40. State Stores
- 41. Demo
- 42. Recommendations
- 43. • Thread ⬌ Task Assignment • Provide Topology and Task Assignment Dashboards • End-To-End Latency Metrics • Consumed and Produced Metrics • State Store Metrics • DSL could change implementation • ∴ always check metrics after upgrade • Don’t collected too frequently • these demo collections ⥇ what production collections • Verify Documentation Recommendations
- 44. Resources
- 45. • Kinetic Edge Blog https://www.kineticedge.io/insights • GitHub • https://github.com/kineticedge/kafka-streams-dashboards • Sample Applications, dashboards, kraft cluster, zk cluster, “load-balanced” cluster • docker - tra ffi c control, single image to run application (with libraries built in — fast!) • KIPs • KIP-444: Augment metrics for Kafka Streams - 2.4 (& 2.5, 2.6) • KIP-471: Expose RocksDB Metrics in Kafka Streams - 2.4 (& 3.2) • KIP-607: Add Metrics to Kafka Streams to Report Properties of RocksDB - 2.7 • KIP-613: Add end-to-end latency metrics to Streams - 2.6 (& 2.7) • KIP-846: Source/sink node metrics for Consumed/Produced throughput in Streams - 3.3 • KIP-869: Improve Streams State Restoration Visibility - 3.5 (They keep on coming!) • StateUpdated also needs to be enabled (experimental?) Resources restart < 3 seconds
