DETAILED INFORMATION ABOUT TIME COMPLEXITIES

1. Time Complexity
UC Berkeley
Fall 2004, E77
http://jagger.me.berkeley.edu/~pack/e77
Copyright 2005, Andy Packard. This work is licensed under the Creative Commons Attribution-ShareAlike
License. To view a copy of this license, visit http://creativecommons.org/licenses/by-sa/2.0/ or send a letter to
Creative Commons, 559 Nathan Abbott Way, Stanford, California 94305, USA.

2. Time complexity of algorithms
Dependency of
– the time it takes to solve a problem
– as a function of the problem dimension/size
Examples:
– Sorting a list of length n
– Searching a list of length n
– Multiplying a n×n matrix by an n×1 vector
Time to solve problem might depend on data
– Average-case time
– Best-case time
• data is well suited for algorithm (can’t be counted on)
– Worst-case time
• data is such that algorithm performs poorly (time-wise)
Worst-Case gives an upper bound as to how much time
will be needed to solve any instance of the problem.

3. Example: N-by-N matrix, N-by-1 vector, multiply
Total = c1N+c2N+N(c3+c2N+N(c4+c5)+c5)
= (c2+c4+c5)N2 + (c1+c2+c3+c5)N
= c6N2 + c7N
N times
Y = zeros(N,1);
initialize space, c1N
initialize “for” loop, c2N
for i=1:N
Scalar assignment, c3
Y(i) = 0.0;
initialize “for” loop, c2N
for j=1:N
c4
Y(i) = Y(i) + A(i,j)*x(j);
End of loop, return/exit, c5
end
End of loop, return/exit, c5
end
N times
(3 accesses, 1 add, 1 multiply)

4. Asymptotic Time complexity of algorithms
Dependency of
– the time it takes to solve a problem
– as a function of the problem dimension/size
but
– formula may only be valid for “large” problems
So, we keep track of “growth rates” of the computational
workload as a function of problem dimension

5. Order, called “big O” notation
Given two functions, f and g, say that “f is of order g” if
– there is a constant c, and
– a value x0
such that
f ( x ) ≤ c ⋅ g ( x ) for all x > x0
So, apart from a fixed multiplicative constant, the function
g is an
– upper bound on the function f
– valid for large values of its argument.
Notation: write f = O( g ) to mean “f is of order g”.
Sometimes write f ( x )
arguments are labled.
= O( g ( x ) ) to remind us what the

6. Not equality,but “belongs to a class”
Recall that f ( n ) = O( g ( n ) ) means that
– there is a constant c, and
– a value n0
such that f ( n ) ≤ c ⋅ g ( n ) for all n > n0
The = sign does not mean equality!
It means that f is an element of the set of functions which
are eventually bounded by (different) constant multiples of
g.
Therefore, it is correct/ok to write
3n = O( n ) ,
( )
3n = O n 2 ,
(
3n = O n 3 ⋅ log n
)

7. Big O: Examples
Example:
Note:
f ( n ) = 31
g ( n) = 1
for all n > 0, 31 ≤ 31
f ( n ) 31⋅ g (n)
For all n, f is bounded above by 31g
Write
or
f ( n ) = O( g ( n ) )
31 = O(1)

8. Big O: Examples
Example:
f ( n ) = 4n 2 + 7 n + 12
g ( n) = n 2
for n > 8, 4n 2 + 7 n + 12 < 5n 2
Note:
f ( n)
For large enough n
f is bounded above by 5g
Write f ( n ) = O( g ( n ) )
f = O( g )
or
4n 2 + 7n + 12 = O n 2
or
( )
5 g ( n)
1200
1000
800
600
400
200
0
0
5
10
15

9. Big O: Relationships
Suppose f1 and f2 satisfy: There is a value n0
f1 ( n ) ≤ f 2 ( n ) for all n > n0
Then f1 ( n ) + f 2 ( n ) ≤ 2 f 2 ( n ) for all n > n0
Hence
f1 + f 2 = O( f 2 )
Example 3:
27 log( n ) + 19 + n = O( n )
f1 ( n )
f 2 ( n)
Generalization: f1 = O( f 2 ) ⇒
f1 + f 2 = O( f 2 )

10. Big O: Relationships
Suppose positive functions f1, f2, g1, g2, satisfy
f1 = O( g1 ) and
Then f1 ⋅ f 2 = O( g1 ⋅ g 2 )
f 2 = O( g 2 )
Why? There exist c1, c2, n1, n2 such that
f i ( n ) ≤ ci ⋅ g i ( n ) for all n > ni
Take c0=c1c2, n0=max(n1,n2). Multiply to give
f1 ( n ) f ( n ) 2 ≤ c0 ⋅ g1 ( n ) g 2 ( n ) for all n > n0
Example:
(12n
2
)
( )
+ 2 log n ( 27 log( n ) + 19 + n ) = O n 3
f 2 ( n)
f1 ( n )

11. Asymptotic: Relationships
Obviously, for any positive function g
g = O( g )
Let β be a positive constant. Then β ⋅ g = O( g ) as well.
( )
Example 4: 13n = O n
3
3
Message: Bounding of growth rate. If n doubles, then the
bound grows by 8.
Example 5:
log n
= O( log n )
512

12. N times
Y = zeros(N,1); initialize space, c1N
initialize “for” loop, c2N
for i=1:N
Scalar assignment, c3
Y(i) = 0.0;
initialize “for” loop, c2N
for j=1:N
c4
Y(i) = Y(i) + A(i,j)*x(j);
End of loop, return/exit, c5
end
End of loop, return/exit, c5
end
N times
Example: N-by-N matrix, N-by-1 vector, multiply
Total = c6N2 + c7N
•Problem size affects (is, in fact) N
•Processor speed, processor and language
architecture, ie., technology, affect c6 and c7
Hence, “this algorithm of matrix-vector multiply has O(N2)
complexity.”

13. Time complexity familiar tasks
Task
Matrix/vector multiply
Getting a specific element from a list
Dividing a list in half, dividing one halve in half, etc
Binary Search
Scanning (brute force search) a list
Nested for loops (k levels)
MergeSort
BubbleSort
Generate all subsets of a set of data
Generate all permutations of a set of data
Growth rate
O(N2)
O(1)
O(log2N)
O(log2N)
O(N)
O(Nk)
O(N log2N)
O(N2)
O(2N)
O(N!)
