12. Ring Documentation, Release 1.4.1
202 NewLine 5
203 PushP 007D37D8 0 207
204 AssignmentPointer
205 PushN 1.000000
206 BeforeEqual 0
207 Assignment 0 0
208 FreeStack
209 NewLine 6
210 Return
===================================================
60.5 CGI Support
Command:
ring test.ring -cgi
60.6 No Run
Command:
ring test.ring -norun
60.7 Printing Instruction Operation Code
Command:
ring test.ring -ins
Output:
===================================================
Operation : ReturnNull
PC : 1
Line Number : 1 , File test.ring
SP (After) : 0 - FuncSP : 0
LineNumber 1
===================================================
.....
.....
.....
Tip: Output removed from the previous example because it’s very large!
60.8 Performance
Command:
60.5. CGI Support 589
13. Ring Documentation, Release 1.4.1
ring test.ring -performance
Output:
===================================================
Date : 2015/09/15 Time : 15:56:17
Clock : 0
===================================================
Hello World
1
2
3
4
5
6
7
8
9
10
welcome
x: 10.000000
y: 20.000000
z: 30.000000
===================================================
Date : 2015/09/15 Time : 15:56:17
Clock : 0
===================================================
60.9 Generate Object File
You can generate object file (.ringo) from your source code file (.ring) using -go option
Tip: You will get one object file to use for distributing/running your application which may contains one or many
ring source files that you can keep or distribute based on the application (commercial or open source).
Command:
ring test.ring -go
To run the compiled object file
ring test.ringo
60.9. Generate Object File 590
14. CHAPTER
SIXTYONE
LOW LEVEL FUNCTIONS
In this chapter we will learn about the low level functions provided by Ring
• callgc()
• varptr()
• space()
• nullpointer()
• object2pointer()
• pointer2object()
• ptrcmp()
• ringvm_cfunctionslist()
• ringvm_functionslist()
• ringvm_classeslist()
• ringvm_packageslist()
• ringvm_memorylist()
• ringvm_calllist()
• ringvm_fileslist()
61.1 callgc() function
Use this function to force calling the garbage collector during function execution when you use a loop that create temp.
variables that you don’t free using the assignment operation.
It’s very rare to need this function but it’s useful when you create something like event-loop for your game engine and
start creating lists on the fly when you call functions.
Example
While True
# process events
# call functions using temp. lists like myfunc(["temp list"])
# call the garbage collector
callgc()
End
591
15. Ring Documentation, Release 1.4.1
Tip: In Ring the garbage collector works automatically in the end of function execution or when you use the assign-
ment statement.
61.2 varptr() function
Use the varptr() function when you need to pass a pointer to a C/C++ function.
Syntax:
varptr(cVariableName,cPointerType) —> Low Level Object (C Pointer)
example:
r = 10
z = 20
see r + nl
see varptr("r","int")
see varptr("z","int")
Output:
10
00E3C740
int
2
00E3BEC0
int
2
Note: the low level object is a list contains three items (The Pointer, The Type, The Status)
61.3 space() function
Use the space function to allocate a specific number of bytes in Memory.
Syntax:
Space(nBytesCount) ---> String
Example:
mystring = space(200)
See "String Size : " + len(mystring) + nl
See "String : " + mystring + nl
See "String Pointer : "
See varptr("mystring","char *")
Output:
String Size : 200
String :
String Pointer : 00FF8FE8
char *
2
61.2. varptr() function 592
16. Ring Documentation, Release 1.4.1
Note: You may need the space() and VarPtr() functions to pass buffers to C functions.
61.4 nullpointer() function
You may need to pass the NULL pointer to a C function that may expect a pointer as parameter and accept NULL
pointers for optional parameters.
Example:
The next example uses the SDL_BlitSurface() function from the LibSDL Library through RingSDL The function
accept SDL_Rect pointers in the second and the last parameter. Also the function accept NULL pointers, so we can
pass them using the NULLPointer() Function.
SDL_BlitSurface(text, nullpointer(), surface, nullpointer())
Note: The previous code doesn’t work alone, you need to learn how to use RingSDL first.
Tip: We can pass NULL as parameter instead of using NULLPointer()
61.5 object2pointer() function
Use this function to get a C pointer for Ring lists and objects
Syntax:
object2pointer(List|Object) --> Low Level Object ( C Pointer )
61.6 pointer2object() function
Use this function to get the Ring list and/or object from the low level object (C Pointer)
Syntax:
pointer2object(Low Level Object) ---> List|Object
Example:
# Create the list
mylist = 1:5
# Create pointer to the list
x = object2pointer(mylist)
see x
see nl
# Add items to the list
mylist + "welcome"
# print the list items
61.4. nullpointer() function 593
17. Ring Documentation, Release 1.4.1
y = pointer2object(x)
see y
Output:
0069A5D8
OBJECTPOINTER
0
1
2
3
4
5
welcome
Note: In Ring the assignment operator copy lists and objects by value, to copy by reference Just use the ob-
ject2pointer() and pointer2object() functions.
Tip: The object2pointer() and pointer2object() are used in the stdlib - Tree Class implementation to create a reference
for the parent node (object) in the child node (another object).
61.7 ptrcmp() function
We can compare between two pointers (C Objects) using the ptrcmp() function.
Syntax:
ptrcmp(oObject1,oObject2) ---> value = 1 if oObject1 = oObject2
value = 0 if oObject1 != oObject2
Example:
fp = fopen("ptrcmp.ring","r")
fp2 = fp
fp3 = fopen("ptrcmp.ring","r")
see ptrcmp(fp,fp2) + nl
see ptrcmp(fp,fp3) + nl
fclose(fp)
fclose(fp3)
Output:
1
0
61.8 ringvm_cfunctionslist() function
The Function return a list of functions written in C.
Syntax:
61.7. ptrcmp() function 594
18. Ring Documentation, Release 1.4.1
RingVM_CFunctionsList() ---> List
Example:
See RingVM_CFunctionsList()
61.9 ringvm_functionslist() function
The Function return a list of functions written in Ring.
Each List Member is a list contains the next items
• Function Name
• Program Counter (PC) - Function Position in Byte Code.
• Source Code File Name
• Private Flag (For Private Methods in Classes)
Syntax:
RingVM_FunctionsList() ---> List
Example:
test()
func test
see ringvm_functionslist()
Output:
test
8
B:/ring/tests/scripts/functionslist.ring
0
61.10 ringvm_classeslist() function
The Function return a list of Classes.
Each List Member is a list contains the next items
• Class Name
• Program Counter (PC) - Class Position in Byte Code.
• Parent Class Name
• Methods List
• Flag (Is parent class information collected)
• Pointer to the package (or NULL if no package is used)
Syntax:
RingVM_ClassesList() ---> List
61.9. ringvm_functionslist() function 595
19. Ring Documentation, Release 1.4.1
Example:
see ringvm_classeslist()
class class1
func f1
class class2 from class1
class class3 from class1
Output:
class1
9
f1
13
B:/ring/tests/scripts/classeslist.ring
0
0
00000000
class2
16
class1
0
00000000
class3
20
class1
0
00000000
61.11 ringvm_packageslist() function
The Function return a list of Packages.
Each List Member is a list contains the next items
• Package Name
• Classes List
Syntax:
RingVM_PackagesList() ---> List
Example:
see ringvm_packageslist()
package package1
class class1
package package2
class class1
package package3
class class1
Output:
61.11. ringvm_packageslist() function 596
20. Ring Documentation, Release 1.4.1
package1
class1
11
0
00FEF838
package2
class1
17
0
00FEF978
package3
class1
23
0
00FEFF68
61.12 ringvm_memorylist() function
The Function return a list of Memory Scopes and Variables.
Each List Member is a list contains variables in a different scope.
Each Item in the scope list is a list contains the next items
• Variable Name
• Variable Type
• Variable Value
• Pointer Type (List/Item) if the value is a list
• Private Flag (if the variable is an attribute in a Class)
Syntax:
RingVM_MemoryList() ---> List
Example:
x = 10
test()
func test
y = 20
see ringvm_memorylist()
Output:
true
2
1
0
0
false
2
0
0
61.12. ringvm_memorylist() function 597
22. Ring Documentation, Release 1.4.1
sysargv
3
B:ringbin/ring
B:/ring/tests/scripts/memorylist.ring
0
0
x
2
10
0
0
y
2
20
0
0
61.13 ringvm_calllist() function
The Function return a list of the functions call list.
Each List Member is a list contains the next items
• Function Type
• Function Name
• Program Counter (PC)
• Stack Pointer (SP)
• Temp. Memory List
• Method or Function Flag
• Caller PC
• FuncExec Flag
• ListStart Flag
• Nested Lists Pointer
• State List
Syntax:
RingVM_CallList() ---> List
Example:
hello()
func hello
test()
func test
mylist = ringvm_calllist()
for t in mylist see t[2] + nl next
Output:
61.13. ringvm_calllist() function 599
23. Ring Documentation, Release 1.4.1
function hello() in file B:/ring/tests/scripts/calllist.ring
called from line 1
function test() in file B:/ring/tests/scripts/calllist.ring
called from line 3
ringvm_calllist
61.14 ringvm_fileslist() function
Function return a list of the Ring Files.
Syntax:
RingVM_FilesList() ---> List
Example:
load "stdlib.ring"
see ringvm_fileslist()
Output:
B:/ring/tests/scripts/fileslist.ring
B:ringbinstdlib.ring
eval
stdlib.ring
stdlib.rh
stdclasses.ring
stdfunctions.ring
stdbase.ring
stdstring.ring
stdlist.ring
stdstack.ring
stdqueue.ring
stdmath.ring
stddatetime.ring
stdfile.ring
stdsystem.ring
stddebug.ring
stddatatype.ring
stdconversion.ring
stdodbc.ring
stdmysql.ring
stdsecurity.ring
stdinternet.ring
stdhashtable.ring
stdtree.ring
61.14. ringvm_fileslist() function 600
24. CHAPTER
SIXTYTWO
INTRODUCTION
In this chapter we will learn about embedding Ring in Ring programs and applications.
62.1 Embedding Ring in Ring without sharing the State
From Ring 1.0 we already have functions for embedding Ring in the C language. Also we can execute Ring code
inside Ring programs using the eval() function. In this release we provide functions for embedding Ring in Ring
programs without sharing the state.
Advantages:
1. Quick integration for Ring programs and applications together without conflicts.
2. Execute and run Ring code in safe environments that we can trace.
Example:
pState = ring_state_init()
ring_state_runcode(pState,"See 'Hello, World!'+nl")
ring_state_runcode(pState,"x = 10")
pState2 = ring_state_init()
ring_state_runcode(pState2,"See 'Hello, World!'+nl")
ring_state_runcode(pState2,"x = 20")
ring_state_runcode(pState,"see x +nl")
ring_state_runcode(pState2,"see x +nl")
v1 = ring_state_findvar(pState,"x")
v2 = ring_state_findvar(pState2,"x")
see v1[3] + nl
see V2[3] + nl
ring_state_delete(pState)
ring_state_delete(pState2)
Output:
Hello, World!
Hello, World!
10
20
10
20
601
25. Ring Documentation, Release 1.4.1
62.2 Serial Execution of Programs
We can execute application after another application using ring_state_main()
Example:
chdir(exefolder()+"/../applications/formdesigner")
ring_state_main('formdesigner.ring')
chdir(exefolder()+"/../applications/cards")
ring_state_main('cards.ring')
62.2. Serial Execution of Programs 602
26. CHAPTER
SIXTYTHREE
EXTENSION USING THE C/C++ LANGUAGES
We can extend the Ring Virtual Machine (RingVM) by adding new functions written in the C programming language
or C++. The RingVM comes with many functions written in C that we can call like any Ring function.
We can extend the language by writing new functions then rebuilding the RingVM again, or we can create shared
library (DLL/So) file to extend the RingVM without the need to rebuild it.
The Ring language source code comes with two files to add new modules to the RingVM, ring_ext.h and ring_ext.c
63.1 ring_ext.h
The file ring_ext.h contains constants that we can change to include/exclude modules during the build process.
#ifndef ringext_h
#define ringext_h
/* Constants */
#define RING_VM_LISTFUNCS 1
#define RING_VM_REFMETA 1
#define RING_VM_MATH 1
#define RING_VM_FILE 1
#define RING_VM_OS 1
#define RING_VM_MYSQL 1
#define RING_VM_ODBC 1
#define RING_VM_OPENSSL 1
#define RING_VM_CURL 1
#define RING_VM_DLL 1
#endif
63.2 ring_ext.c
The file ring_ext.c check constants defined in ring_ext.h before calling the start-up function in each module.
Each module contains a function that register the module functions in the RingVM.
#include "ring.h"
void ring_vm_extension ( RingState *pRingState )
{
/* Reflection and Meta-programming */
#if RING_VM_REFMETA
ring_vm_refmeta_loadfunctions(pRingState);
#endif
603
27. Ring Documentation, Release 1.4.1
/* List Functions */
#if RING_VM_LISTFUNCS
ring_vm_listfuncs_loadfunctions(pRingState);
#endif
/* Math */
#if RING_VM_MATH
ring_vm_math_loadfunctions(pRingState);
#endif
/* File */
#if RING_VM_FILE
ring_vm_file_loadfunctions(pRingState);
#endif
/* OS */
#if RING_VM_OS
ring_vm_os_loadfunctions(pRingState);
#endif
/* MySQL */
#if RING_VM_MYSQL
ring_vm_mysql_loadfunctions(pRingState);
#endif
/* ODBC */
#if RING_VM_ODBC
ring_vm_odbc_loadfunctions(pRingState);
#endif
/* OPENSSL */
#if RING_VM_OPENSSL
ring_vm_openssl_loadfunctions(pRingState);
#endif
/* CURL */
#if RING_VM_CURL
ring_vm_curl_loadfunctions(pRingState);
#endif
/* DLL */
#if RING_VM_DLL
ring_vm_dll_loadfunctions(pRingState);
#endif
}
63.3 Module Organization
Each module starts by include the ring header file (ring.h). This files contains the Ring API that we can use to extend
the RingVM.
Each module comes with a function to register the module functions in the RingVM The registration is done by using
ring_vm_funcregister() function.
The ring_vm_funcregister() function takes two parameters, the first is the function name that will be used by Ring
programs to call the function. The second parameter is the function pointer in the C program.
for example, the ring_vmmath.c module contains the next code to register the module functions
#include "ring.h"
void ring_vm_math_loadfunctions ( RingState *pRingState )
{
ring_vm_funcregister("sin",ring_vm_math_sin);
ring_vm_funcregister("cos",ring_vm_math_cos);
63.3. Module Organization 604
28. Ring Documentation, Release 1.4.1
ring_vm_funcregister("tan",ring_vm_math_tan);
ring_vm_funcregister("asin",ring_vm_math_asin);
ring_vm_funcregister("acos",ring_vm_math_acos);
ring_vm_funcregister("atan",ring_vm_math_atan);
ring_vm_funcregister("atan2",ring_vm_math_atan2);
ring_vm_funcregister("sinh",ring_vm_math_sinh);
ring_vm_funcregister("cosh",ring_vm_math_cosh);
ring_vm_funcregister("tanh",ring_vm_math_tanh);
ring_vm_funcregister("exp",ring_vm_math_exp);
ring_vm_funcregister("log",ring_vm_math_log);
ring_vm_funcregister("log10",ring_vm_math_log10);
ring_vm_funcregister("ceil",ring_vm_math_ceil);
ring_vm_funcregister("floor",ring_vm_math_floor);
ring_vm_funcregister("fabs",ring_vm_math_fabs);
ring_vm_funcregister("pow",ring_vm_math_pow);
ring_vm_funcregister("sqrt",ring_vm_math_sqrt);
ring_vm_funcregister("unsigned",ring_vm_math_unsigned);
ring_vm_funcregister("decimals",ring_vm_math_decimals);
ring_vm_funcregister("murmur3hash",ring_vm_math_murmur3hash);
}
Tip: Remember that the function ring_vm_math_loadfunctions() will be called by the ring_vm_extension() function
(in the ring_ext.c file).
63.4 Function Structure
Each module function may contains the next steps
1 - Check Parameters Count
2 - Check Parameters Type
3 - Get Parameters Values
4 - Execute Code/Call Functions
5 - Return Value
The structure is very similar to any function (Input - Process - Output) But here we will use the Ring API for the steps
1,2,3 and 5.
63.5 Check Parameters Count
We can check the parameters count using the RING_API_PARACOUNT macro.
We can compare RING_API_PARACOUNT with any numeric value using == or != operators.
Example:
if ( RING_API_PARACOUNT != 1 ) {
/* code */
}
Example:
63.4. Function Structure 605
29. Ring Documentation, Release 1.4.1
if ( RING_API_PARACOUNT == 1 ) {
/* code */
}
63.6 Display Error Message
We can display error messages using the RING_API_ERROR() function.
The function will display the error and end the execution of the program.
Note: the behaviour of this function can be changed by the Ring code using Try/Catch/Done statements, so in your C
code, use Return after this function.
Syntax:
RING_API_ERROR(const char *cErrorMsg);
The Ring API comes with some of predefined error messages that we can use
#define RING_API_MISS1PARA "Bad parameters count, the function expect one parameter"
#define RING_API_MISS2PARA "Bad parameters count, the function expect two parameters"
#define RING_API_MISS3PARA "Bad parameters count, the function expect three parameters"
#define RING_API_MISS4PARA "Bad parameters count, the function expect four parameters"
#define RING_API_BADPARATYPE "Bad parameter type!"
#define RING_API_BADPARACOUNT "Bad parameters count!"
#define RING_API_BADPARARANGE "Bad parameters value, error in range!"
#define RING_API_NOTPOINTER "Error in parameter, not pointer!"
#define RING_API_NULLPOINTER "Error in parameter, NULL pointer!"
#define RING_API_EMPTYLIST "Bad parameter, empty list!"
63.7 Check Parameters Type
We can check the parameter type using the next functions
int RING_API_ISNUMBER(int nParameterNumber);
int RING_API_ISSTRING(int nParameterNumber);
int RING_API_ISLIST(int nParameterNumber);
int RING_API_ISPOINTER(int nParameterNumber);
The output of these functions will be 1 (True) or 0 (False).
63.8 Get Parameters Values
We can get paramters values using the next functions
double RING_API_GETNUMBER(int nParameterNumber);
const char *RING_API_GETSTRING(int nParameterNumber);
int RING_API_GETSTRINGSIZE(int nParameterNumber);
List *RING_API_GETLIST(int nParameterNumber);
void *RING_API_GETCPOINTER(int nParameterNumber, const char *cPoinerType);
int RING_API_GETPOINTERTYPE(int nParameterNumber);
63.6. Display Error Message 606
30. Ring Documentation, Release 1.4.1
63.9 Return Value
We can return values from our function using the next functions.
RING_API_RETNUMBER(double nValue);
RING_API_RETSTRING(const char *cString);
RING_API_RETSTRING2(const char *cString,int nStringSize);
RING_API_RETLIST(List *pList);
RING_API_RETCPOINTER(void *pValue,const char *cPointerType);
63.10 Function Prototype
When we define new function to be used for RingVM extension, we use the next prototype
void my_function_name( void *pPointer );
or we can use the RING_FUNC() Macro
RING_FUNC(my_function_name);
63.11 Sin() Function Implementation
The next code represents the sin() function implementation using the Ring API and the sin() C function.
void ring_vm_math_sin ( void *pPointer )
{
if ( RING_API_PARACOUNT != 1 ) {
RING_API_ERROR(RING_API_MISS1PARA);
return ;
}
if ( RING_API_ISNUMBER(1) ) {
RING_API_RETNUMBER(sin(RING_API_GETNUMBER(1)));
} else {
RING_API_ERROR(RING_API_BADPARATYPE);
}
}
63.12 Fopen() and Fclose() Functions Implementation
The next code represents the fopen() function implementation using the Ring API and the fopen() C Function.
The function takes two parameters, the first parameter is the file name as string. The second parameter is the mode as
string.
In the file ring_vmfile.h we have some constants to use as the pointer type like
#define RING_VM_POINTER_FILE "file"
#define RING_VM_POINTER_FILEPOS "filepos"
The function implementation in ring_vmfile.c
63.9. Return Value 607
