The Full Power of ASP.NET Web API

Browser Request
Index.html
MVC4
Traditional Request / Response for ALL rendered content and assets

Initial Request
Application.htm
MVC4
RequireJS Loader
Page1 Partial.htm
IndexViewModel.js
Application.js (bootstrap)
ViewModel (#index)
ViewModel (#login)
Model (LoginModel)
JSON Requests
HTML5 localstorage
Handling disconnection

Source: www.programmableweb.com – current APIs: 4,535

POST SimpleService.asmx/EchoString HTTP/1.1
Host: localhost:1489
User-Agent: Mozilla/5.0
Accept: text/html
Content-Type: application/json;
Content-Length: 27
...
XML, JSON, SOAP, AtomPub ...
Headers
Data
Verb URL

POST SimpleService.asmx/EchoString HTTP/1.1
Host: localhost:1489
User-Agent: Mozilla/5.0
Accept: text/html,application/xhtml+xml
Content-Type: application/json;
Content-Length: 27
...
{
"Age":37,
"FirstName":"Eyal",
"ID":"123",
"LastName":"Vardi“
}
Headers
Data
Verb URL
<Envelope>
<Header>
<!–- Headers -->

</Header>
<Body>
<!– XML Data -->
</Body>
</Envelope>

Dependency Injection
Filters
Content Negotiation
Testing

“An architectural style for
building distributed
hypermedia systems.”

WSDL description of a web services
types defined in <xsd:schema>
simple messages
parts of messages
interface specification
operations of an interface
input message
output message
binding of interface to protocols & encoding
description of the binding for each operation
service description
URI and binding to port
<definitions>
<types></types>
<message>
<part></part>
</message>
<portType>
<operation>
<input>
<output>
</operation>
</portType>
<binding>
<operation>
</binding>
<service>
<port>
</service>
</definitions>

ASP.NET MVC 4 and the Web API: Building a REST Service from Start to Finish book

<?xml version="1.0" encoding="utf-8"?>
<Tasks>
<TaskInfo Id="1234" Status="Active" >
<link rel="self" href="/api/tasks/1234" method="GET" />
<link rel="users" href="/api/tasks/1234/users" method="GET" />
<link rel="history" href="/api/tasks/1234/history" method="GET" />
<link rel="complete" href="/api/tasks/1234" method="DELETE" />
<link rel="update" href="/api/tasks/1234" method="PUT" />
</TaskInfo>
<TaskInfo Id="0987" Status="Completed" >
<link rel="self" href="/api/tasks/0987" method="GET" />
<link rel="users" href="/api/tasks/0987/users" method="GET" />
<link rel="history" href="/api/tasks/0987/history" method="GET" />
<link rel="reopen" href="/api/tasks/0987" method="PUT" />
</TaskInfo>
</Tasks>
/api/tasks

ASP.NET and Web Tools 2012.2 Update
Adding a simple Test
Client to ASP.NET
Web API Help Page

Serialization Validation
DeserializationResponse
Controller /
Action
Request
HTTP/1.1 200 OK
Content-Length: 95267
Content-Type: text/html | application/json
Accept: text/html, application/xhtml+xml, application/xml

GlobalConfiguration.Configuration.Formatters

var json = GlobalConfiguration.Configuration.Formatters.JsonFormatter;
json.UseDataContractJsonSerializer = true;

 "opt-out" approach
 "opt-in" approach
public class Product
{
public string Name { get; set; }
public decimal Price { get; set; }
[JsonIgnore]
public int ProductCode { get; set; }
}
[DataContract] public class Product
{
[DataMember] public string Name { get; set; }
[DataMember] public decimal Price { get; set; }
// omitted by default
public int ProductCode { get; set; }
}

public object Get()
{
return new {
Name = "Alice",
Age = 23,
Pets = new List<string> { "Fido", "Polly", "Spot" } };
}
public void Post(JObject person)
{
string name = person["Name"].ToString();
int age = person["Age"].ToObject<int>();
}

var xml = GlobalConfiguration.Configuration.Formatters.XmlFormatter;
xml.UseXmlSerializer = true;
The XmlSerializer class supports a narrower set of types
than DataContractSerializer, but gives more control over the resulting
XML. Consider using XmlSerializer if you need to match an existing XML
schema.

“the process of selecting the best
representation for a given response when
there are multiple representations
available.”

public HttpResponseMessage GetProduct(int id)
{
var product = new Product() { Id = id, Name = "Gizmo", Price = 1.99M };
IContentNegotiator negotiator = this.Configuration
.Services.GetContentNegotiator();
ContentNegotiationResult result = negotiator.Negotiate( typeof(Product),
this.Request, this.Configuration.Formatters);
if (result == null) {
var response = new HttpResponseMessage(HttpStatusCode.NotAcceptable);
throw new HttpResponseException(response));
}
return new HttpResponseMessage()
{
Content = new ObjectContent<Product>(
product, // What we are serializing
result.Formatter, // The media formatter
result.MediaType.MediaType // The MIME type
)
};
}

public class ProductMD
{
[StringLength(50), Required]
public string Name { get; set; }
[Range(0, 9999)]
public int Weight { get; set; }
}

 [Required]
 [Exclude]
 [DataType]
 [Range]
[MetadataTypeAttribute( typeof( Employee.EmployeeMetadata ) )]
public partial class Employee
internal sealed class EmployeeMetadata
[StringLength(60)]
[RoundtripOriginal]
public string AddressLine { get; set; }
}
}
 [StringLength(60)]
 [RegularExpression]
 [AllowHtml]
 [Compare]

public class ProductsController : ApiController
{
public HttpResponseMessage Post(Product product)
{
if ( ModelState.IsValid ) {
// Do something with the product (not shown).
return new HttpResponseMessage(HttpStatusCode.OK);
}
else {
return new HttpResponseMessage(HttpStatusCode.BadRequest);
}
}
}

public class ModelValidationFilterAttribute : ActionFilterAttribute
{
public override void OnActionExecuting(HttpActionContext actionContext)
{
if (actionContext.ModelState.IsValid == false)
{
// Return the validation errors in the response body.
var errors = new Dictionary<string, IEnumerable<string>>();
foreach ( var keyValue in actionContext.ModelState )
{
errors[keyValue.Key] =
keyValue.Value.Errors.Select(e => e.ErrorMessage);
}
actionContext.Response =
actionContext
.Request
.CreateResponse(HttpStatusCode.BadRequest, errors);
}
}
}

public class ModelValidationFilterAttribute : ActionFilterAttribute
{
public override void OnActionExecuting(HttpActionContext actionContext)
{
if (actionContext.ModelState.IsValid == false)
{
// Return the validation errors in the response body.
var errors = new Dictionary<string, IEnumerable<string>>();
foreach ( var keyValue in actionContext.ModelState )
{
errors[keyValue.Key] =
keyValue.Value.Errors.Select(e => e.ErrorMessage);
}
actionContext.Response =
actionContext
.Request
.CreateResponse(HttpStatusCode.BadRequest, errors);
}
}
}
protected void Application_Start() {
// ...
GlobalConfiguration
.Configuration
.Filters.Add(new ModelValidationFilterAttribute());
}

http://www.asp.net/web-api/
Why I’m giving REST a rest
Building Hypermedia Web APIs with ASP.NET Web API

The Full Power of ASP.NET Web API
