Testing Microservices with a Citrus twist
- 1. @citrus_test#Devoxx #CitrusTwist Testing Microservices with a Citrus Twist Christoph Deppisch ConSol* Software GmbH
- 2. @citrus_test#Devoxx #CitrusTwist Christoph Deppisch • Senior software developer • @ConSol* Munich, Germany • 10 years of experience in Java • Passionate about automated software testing • Founder of the Open Source framework Citrus • Happy to be here today! Twitter: @freaky_styley
- 3. @citrus_test#Devoxx #CitrusTwist What is Citrus? • Open Source integration test framework • Focus on messaging in distributed software systems • Automated interface tests • Ready-to-use endpoint components for message exchange • Works & integrates with well-known libraries • TestNG, JUnit • Apache Camel, Spring, Docker,Arquillian …
- 5. @citrus_test#Devoxx #CitrusTwist Every project needs integration tests!
- 6. @citrus_test#Devoxx #CitrusTwist Service A Service B Interface REST, JMS, File, SOAP
- 7. @citrus_test#Devoxx #CitrusTwist Service A Service B Interface REST, JMS, File, SOAP Mock? Simulator?
- 8. @citrus_test#Devoxx #CitrusTwist Service A Interface REST, JMS, File, SOAP
- 14. @citrus_test#Devoxx #CitrusTwist import com.consol.citrus.annotations.CitrusTest; import com.consol.citrus.dsl.testng.TestNGCitrusTestDesigner; import org.testng.annotations.Test; @Test public class SampleCitrusIT extends TestNGCitrusTestDesigner { @CitrusTest public void sayHello() { echo("Hello, Devoxx! This is my first Citrus test!"); } }
- 16. @citrus_test#Devoxx #CitrusTwist • Missing something? Adding custom actions is possible! Test actions Test action Description echo Log message to console send Sends a message receive Receives a message sleep Wait some time sql Execute SQL statements parallel Execute actions in parallel conditional Execute actions based on condition iterate Execute actions in iteration repeat-on-error Failsafe action execution …
- 17. @citrus_test#Devoxx #CitrusTwist @Test public class MessageExchangeIT extends TestNGCitrusTestDesigner { @Autowired private Endpoint orderEndpoint; @CitrusTest public void sendAndReceiveMessage() { send(orderEndpoint) .payload("..."); receive(orderEndpoint) .payload("..."); } }
- 18. @citrus_test#Devoxx #CitrusTwist @CitrusTest public void sendAndReceiveMessage() { variable("orderId", Functions.randomNumber(10L)); send(orderEndpoint) .payload("<order>" + "<id>${orderId}</id>" + "</order>") .header("operation", "placeOrder") .header("id", "${orderId}"); receive(orderEndpoint) .payload("<orderResponse>" + "<timestamp>@ignore@</timestamp>" + "<id>${orderId}</id>" + "<success>true</success>" + "</orderResponse>") .header("id", "${orderId}"); }
- 20. @citrus_test#Devoxx #CitrusTwist • Missing something? Adding custom components is easy! Endpoint components Component Description citrus-http Http REST client and server citrus-jms JMS queue or topic destination citrus-ws SOAP client and server citrus-mail SMTP mail client and server citrus-docker Docker container management citrus-camel Apache Camel endpoint citrus-ftp FTP client and server citrus-vertx Vert.x endpoint citrus-ssh SSH client and server …
- 21. @citrus_test#Devoxx #CitrusTwist <!-- JMS endpoints --> <citrus-jms:endpoint id="orderEndpoint" destination-name="factory.order.inbound"/> <citrus-jms:sync-endpoint id="errorEndpoint" destination-name="base.error.service" timeout="${global.receive.timeout}"/> <!-- JMS connection factory and message broker --> <bean id="connectionFactory" class="org.apache.activemq.ActiveMQConnectionFactory"> <property name="brokerURL" value="tcp://localhost:61616" /> </bean> Endpoints: citrus-jms
- 22. @citrus_test#Devoxx #CitrusTwist <!-- REST Http client --> <citrus-http:client id="reportingClient" request-method="GET" timeout="5000" request-url="http://localhost:8080/services/report"/> <!-- REST Http server --> <citrus-http:server id="reportingServer" port="8080" auto-start="true"/> Endpoints: citrus-http
- 24. @citrus_test#Devoxx #CitrusTwist Cookie factory sample worker worker worker webapp reporting 2x 4x 1x
- 25. @citrus_test#Devoxx #CitrusTwist Docker infrastructure brokerwebapp report worker worker worker
- 28. @citrus_test#Devoxx #CitrusTwist Demo tools • docker-maven-plugin • docker:build, docker:start, docker:stop • https://github.com/rhuss/docker-maven-plugin • Apache Camel • Content-based routing, REST endpoints, standalone worker • http://camel.apache.org/ • Demo Code • https://github.com/christophd/citrus-demo-devoxx
- 34. @citrus_test#Devoxx #CitrusTwist What else!? • Docker integration • build, start, stop, inspect, … • Manage Docker containers at test runtime • Arquillian extension • Use Citrus in Arquillian test • @CitrusFramework, @CitrusEndpoint, @CitrusResource • Apache Camel integration • Create, start, stop routes at test runtime
- 35. @citrus_test#Devoxx #CitrusTwist Information • Homepage • http://citrusframework.org • Blog • http://labs.consol.de/tags/citrus/ • User Guide • http://citrusframework.org/reference/html/index.html • Mailing List • user@citrusframework.org
