Dear Readers,
Address
TELE-satellite Magazine Analog TV channels are being turned off and replaced by digital channels all over the
world. In some countries, this task has already been completed; in others the process is
PO Box 1234 underway while at the same time some countries are planning to make the transition but
85766 Munich-Ufg have not yet started. In the end it doesn’t really matter, sooner or later there won’t be any
GERMANY/EUROPA UNION analog TV channels anymore.

The advantage of digital technology is simply that fewer transmission channels are needed.
Editor-in-Chief
One frequency can be used multiple times.
Alexander Wiese This effectively means that fewer transmission
alex@TELE-satellite.com channels are needed or, to put it another way,
after the transition to digital technology, there
Published in 22 Languages by will be quite a few transmission channels that
are no longer being used.
TELE-satellite Medien GmbH
Aschheimer Weg 19 So what’s going to happen with these newly
85774 Unterfoehring available transmission channels? Other services
GERMANY/EUROPA UNION will be using these open channels - in particular
mobile telephone operators. But they won’t
be using these wide band frequencies just for
Design telephone conversations, but rather primarily
Németi Barna Attila for data services. When you say data services
today, this means Internet. And when we
Advertising start talking about Internet with high-speed
transmission rates, IPTV immediately comes to
www.TELE-satellite.com/ads/ mind! The term IPTV, that is TV via the Internet,
was up until recently just associated with cable
Printer or a very fast VDSL connection but also linked
�� to cable. But if IPTV could be made wireless, it
would open up a whole new world.
08850 Gavà
SPAIN/EUROPA UNION IPTV offers an entirely new quality in the world
of TV. Up until now, a TV operator always
Copyright had to get permission from someone. It was
© 2010 by TELE-satellite either a cable company that owned the cable
infrastructure or it was a satellite operator that controls who transmits on its satellites.
��
ISSN 1435-7003 available to its customers. And with terrestrial TV, it’s the local authorities that give out
the necessary licenses.

Why should it be any different with IPTV? It’s different because with IPTV anyone can
surface as a broadcaster. The enormously large number of radio channels in the Internet
is the prelude to what we can expect to see in the IPTV age. Anyone can create their own
TV channel. Sending and receiving in top-notch quality is no longer a problem. Or is it? If
it’s that easy, everyone would be doing it by now. Could it be that it’s really not that easy
to produce your own video stream?

Now seems to be the right time to point this out: take a close look at the advertisements
in this issue of TELE-satellite. Two of them are especially interesting. In one ad there’s
a company that offers the precise generator that you need. Except for a fast Internet
connection, the generator is all you need to produce IPTV. And there you have it: your
own TV station. No uplink satellite dish for which you would need authorization and no
expensive cable infrastructure needed to reach viewers. You can become a TV broadcaster
for just a small investment. And regarding IPTV, for sure soon there will be IPTV receivers
with antenna connections for terrestrially transmitted mobile stations - see above.

The second ad you might notice is not directly connected to IPTV but instead has to do with
a related subject: this company offers Internet-via-satellite and links this with telephone
��
future. A technology that up until now hasn’t had that much attention and was for the most
part overlooked by TELE-satellite is now gaining recognition.

Naturally, we plan to bring detailed test reports regarding these new and exciting
TELE-satellite was established
possibilities to you in upcoming issues of TELE-satellite.
in 1981 and today is the oldest,
largest and most-read digital
tv trade magazine in the
world. TELE-satellite is seen by
more than 350,000 digital tv
professionals around the world Alexander Wiese
and is available both in printed Editor-in-Chief TELE-satellite
form and online. TELE-satellite
is published worldwide in 22
language editions. P.S.: And along these lines, my favorite radio station of the month: “Munich Radio”
with so-called lounge music around the clock presented commercial free and without
