1. The document provides guidelines for modeling systems of systems and internet of things using Capella and ARCADIA. 2. It discusses modeling constituent systems as separate Capella projects due to different stakeholders. 3. The "system to subsystem transition" feature in Capella allows creating sub-projects to represent constituent systems. 4. Capella library projects can be used to reuse components or systems across projects.

1. Copyright
Obeo
@2022

2. Introduction
Please note your
microphone is muted
Click the Q&A icon and ask
your questions 10+ min
at the end of the presentation
Laurent Delaigue
laurent.delaigue@obeosoft.com
www.obeosoft.com
Copyright
Obeo
@2022

3. Our Speaker
Tony KOMAR
Siemens
-
tony.komar@siemens.com
Copyright
Obeo
@2022

4. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 4
Introduced to Capella.
Shortly after the introduction I built my first very detailed model.
Siemens and OBEO announcing partnership and product based on Capella
Launched an internal user group at Siemens to promote SMW/Capella
Mentored middle school students on Capella and they won
Won a state (PA) 4-H State Competition!
University Michigan began pilot course with Capella
Lunch with Larry Master Class Series
Presented Capella Ventilator at two international events
University Michigan began pilot course with Capella
Launched YouTube Channel Innovating with Capella
University of Michigan presents Keynote at INCOSE IW
My personal history with Capella
Solar Charger
2017
2018
2019
2020
2021
2022

5. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 5
Capella can support the modeling System of Systems
Multi-Level Mission and Drone
Definition:
• A System of Systems (SoS) is a collection of independent
systems, integrated into a larger system that delivers unique
capabilities.
• The independent constituent systems collaborate to
produce global behavior that they cannot produce alone.
INCOSE Systems of System Primer INCOSE-TP-2018-003.01.0

6. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 6
Capella meets the unique challenges of System of Systems
Constituent Systems
Multi-Level Mission and Drone
• Unique Issues/Attributes of Constituent Systems
• Constituent systems may make decisions or upgrades
without considering the rest of the SoS.
• Constituent systems may withdraw (possibly without
warning) from the SoS if their own goals conflict with SoS
goals
• Separate constituent systems are often drawn from
different engineering disciplines, and the SoS itself is
commonly large-scale and usually highly complex.
• Testing and verifying upgrades to an SoS is difficult and
expensive (sometimes prohibitively) due to scale,
complexity and constant evolution
INCOSE Systems of System Primer INCOSE-TP-2018-003.01.0

7. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 7
Systems of Systems models and Internet of Things models
have things in common
Battery Powered Hand drill and IOT Charger Multi-Level Mission and Drone
System of Systems Strong
Weak
INCOSE Systems of System Primer INCOSE-TP-2018-003.01.0

8. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 8
Guidelines for System of Systems modeling using Capella
and ARCADIA Method
1. A Project has only one system, it becomes the “system” of a SoS.
2. A Project should focus on the stakeholders for the “system” of a SoS.
3. A system may be composed of
• constituent systems, and/or
• components.
4. The Functional Chains deliver the needs of stakeholders across the Constituent
Systems and/or Components.
5. System of Systems will result in a set of Capella Projects, due to different
stakeholders of CS and Components.
6. Capella projects can use “System to Subsystem transitions” to create sub-projects
that represents constituent systems or components of primary project.
7. Capella projects can use a Capella Library Projects to reuse components or
constituent systems.

9. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 9
Guideline for SoS model:
A project has only one system, it becomes the “System” of a SoS
Roques, Pascal. “MBSE with the ARCADIA Method and the Capella Tool.” (2016).
https://api.semanticscholar.org/CorpusID:9283412

10. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 10
Guideline for SoS model:
A Project should focus on the stakeholders for the “system” of
SoS
Roques, Pascal. “MBSE with the ARCADIA Method and the Capella Tool.” (2016).
https://api.semanticscholar.org/CorpusID:9283412

11. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 11
Guideline for SoS model:
A system may be composed of constituent systems, and/or
components.
Roques, Pascal. “MBSE with the ARCADIA Method and the Capella Tool.” (2016).
https://api.semanticscholar.org/CorpusID:9283412

12. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 12
Guideline for SoS model:
The Functional Chains deliver the needs of stakeholders across
the Constituent Systems and Components.
Bonnet, Stephane; Voirin, Jean-Luc, Navas. Jaun: “Arcadia and Capella: Augmenting requirement with models to improve the articulation
between systems engineering levels and optimize V&V practices.
Component = SoS Constituent System
SoS Capability

13. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 13
Example: SoS Model
Level Model – Disaster Recovery System

14. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 14
SoS Example – Disaster Recovery System

15. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 15
SoS Example –– Disaster Recovery System

16. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 16
SoS Example – Disaster Recovery System

17. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 17
SoS Example – Disaster Recovery System

18. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 18
SoS Example – Disaster Recovery System

19. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 19
SoS Example – Disaster Recovery System

20. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 20
Guideline for SoS model:
System of Systems will result in a set of Capella Projects,
due to different stakeholders for CSs and Components.
Reasons:
• Constituent systems stakeholders may be
different than the System.
• Constituent systems lifecycles may be different
than System.
• Many cases they will pre-exist the “System”
• System may have intellectual property they
do not want to expose to Prime Contractor,
Partner or Supplier.
• Constituent Systems may be developed by
Prime Contractor, Partner or Supplier
• Constituent Systems may have Intellectual
Property they do not want to place in higher
level model.

21. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 21
Stakeholders' priorities drive the need for a network of
models.
INCOSE Systems of System Primer INCOSE-TP-2018-003.01.0

22. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 22
Guideline for SoS model:
Capella projects can use “System to Subsystem transitions” to create
sub-projects
Faisandier, A. 2012. Systems Architecture and Design. Belberaud, France: Sinergy'Com.
Guide to the Systems Engineering Body of Knowledge (SEBoK),version 2.5, Page 252
Capella rich meta-model support this recursive
process.
• System to Subsystem Transition
• Addon for Capella
• Built into Siemens System Modeling
Workbench
• Components, Functions, and Functional Chains
are transitioned
• Siemens latest SMW 6 release is leveraging this
capability to carve out a portion of a model for
transition to SysML V2
https://www.youtube.com/watch?v=njW_zdE_FzI
Daly, Jim: Arcadia/Capella for a
large complex mechanical
system, Apr 2019.

23. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 23
Demo - System to System Transition
System to Subsystem Transition
(Recursion) allow
• Creation of a Constituent System From
Parent
• Selectively transfer content from Parent
Model to Constituent System Model

24. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 24
Guideline for SoS model:
Capella projects can use a Capella Library Project to reuse
components or constituent systems.
Systems can be composed of pre-
existing content.
Capella supports reuse with Libraries and
REC/RPL concept.
• A library can define the Reusable
Element.
• A library and be referenced by a
model and Replicas can be created
from the library’s Reusable Element.

25. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 25
Demo - Inclusion of FLIR into a model from Siemens
Xcelerator

26. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 26
Guidelines for System of Systems and Internet of Things
modeling using Capella and ARCADIA Method
1. A Project has only one System, it becomes the “system” of a SoS.
2. A Project should focus on the stakeholders for the “system” of a SoS.
3. A system may be composed of
• constituent systems (CS), and/or
• components.
4. The Functional Chains deliver the needs of stakeholders across the Constituent
Systems and/or Components.
5. System of Systems will result in a set of Capella Projects, due to different
stakeholders CSs and Components
6. Capella projects can use “System to Subsystem transitions” to create sub-Projects
that represents constituent systems or components of primary project.
7. Capella projects can use a Capella Library Project to reuse components or
constituent systems.

27. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 27
Internet of Things are on the weaker side of the SoS
spectrum, but same guidelines apply.
Battery Powered Hand drill and IOT Charger Multi-Level Mission and Drone
System of Systems
Strong
Weak
Reasons
• Stakeholders may be shared.
• Constituent System lifecycle may
align to “system” or other
constituents' systems.
• Intellectual Property may still
persist.
• Suppliers may still be engaged.
• IoT infrastructure is a
• Constituent System

28. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 28
Guideline for IOT model:
A project has only one System.
Roques, Pascal. “MBSE with the ARCADIA Method and the Capella Tool.” (2016).
https://api.semanticscholar.org/CorpusID:9283412

29. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 29
Guideline for IOT model:
A Project should focus on the stakeholders for that system.
Roques, Pascal. “MBSE with the ARCADIA Method and the Capella Tool.” (2016).
https://api.semanticscholar.org/CorpusID:9283412

30. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 30
Guideline for IOT model:
A system may be composed of constituent systems, and/or components.
Roques, Pascal. “MBSE with the ARCADIA Method and the Capella Tool.” (2016).
https://api.semanticscholar.org/CorpusID:9283412

31. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 31
Guideline for IOT model:
The Functional Chains deliver the needs of stakeholders across
the Constituent Systems and Components.
Bonnet, Stephane; Voirin, Jean-Luc, Navas. Jaun: “Arcadian and Capella: Augmenting requirement with models to improve the articulation
between systems engineering levels and optimize V&V practices.

32. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 32
IOT Example - Intelligent Connected
Battery Charger

33. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 33
IOT Example - Intelligent Connected Battery Charger

34. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 34
IOT Example - Intelligent Connected Battery Charger

35. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 35
IOT Example - Intelligent Connected Battery Charger

36. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 36
IOT Example - Intelligent Connected Battery Charger

37. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 37
IOT Example - Intelligent Connected
Battery Charger

38. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 38
Guideline for IOT model:
System of System will result in a set of Capella Projects, due
to different stakeholders.
Assume it is not going to be all
done in one project.
Reasons:
• Constituent systems
Stakeholders may be different
than the System.
• Constituent systems lifecycles
may not be the same.
INCOSE Systems of System Primer INCOSE-TP-2018-003.01.0

39. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 39
Guideline for IOT model:
Capella projects can use “System to Subsystem” transitions
to create sub-projects that represents systems of primary
project.
System to Subsystem Transition
(Recursion) is used
• Complexity of lower level
• Expectation that subsystem
does not exist and component.

40. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 40
Guideline for IOT model:
Capella project can use a Capella Library Project that contain
reusable components to build a system.

41. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 41
Summary: Guidelines for System of Systems modeling using
Capella and ARCADIA Method.
1. A Project has only one System, it becomes the “System” of a SoS
2. A Project should focus on the stakeholders for that “System” of and SoS
3. A system may be composed of
• constituent systems, and/or
• components.
4. The Functional Chains deliver the needs of stakeholders across the Constituent
Systems and Components.
5. System of Systems will result in a set of Capella Projects, due to different
stakeholders for the CSs and Components.
6. Capella projects can use “System to Subsystem transitions” to create sub-Projects
that represents systems of primary project.
7. Capella projects can use a Capella Library Project that contain reusable
components to build a system.

42. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 42
Stay tuned to “Innovating with Capella” for LORAWAN
Helium Based Solution
Battery Powered Hand drill and IOT Charger Multi-Level Mission and Drone
System of Systems
Strong
Weak
LORAWAN “Helium” Network Solution

43. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 43
Stay tuned to “Innovating with Capella” for LORAWAN
Helium Based Solution

44. Unrestricted | © Siemens 2022 | 2022-02-17 | Tony Komar| Enterprise Architect | Siemens Digital Industries Software | Where today meets tomorrow.
Page 44
Thank you to Capella Community
Thales
Stephane Bonnet
Juan Navas
Jean-Luc Voirin
OBEO
Etienne Juliot
Stephane LaCrampe
Pascal Rogues
Jim Daly

45. Q & A
Thanks for listening!
Do you have any questions?
Copyright
Obeo
@2022

46. Stay tuned!
▪ Capella Annual Message
by Juan Navas (Thales)
Don’t miss an opportunity to learn from Capella experts :
▪ March 21-28, 2022 | 2:00 pm - 5:30 pm UTC+1
An online training program in English, through 6 courses of 3.5 hours
each, from Monday to the following Monday.
March 15th, 2022
Contact sales@obeosoft.ca
