Study and Comparison of Open Source and Licensed VLSI CAD Tools
using CMOS Design Methodology
Prachi Tiwari1
Anupama2
Ayoush Johari3
1, 2, 3
Department of Electronics and Communication Engineering
1, 2, 3
Lakshmi Narain College of technology and Science, Bhopal, India
Abstract—the design of VLSI circuits can be achieved at
many different refinement levels from the most detailed
layout to the most abstract architectures. VLSI design has
been the study of electronic design automation and related
semiconductor science, and many software tools have been
written to solve one or more problems associated with the
VLSI design flow. VLSI CAD tools have emerged as a boon
in assisting VLSI Design engineers to choose and optimize
various design models and technology. The importance of
CAD tool can be understood by seeing its complex
algorithms, data structures and modeling assumptions used
in each of the following steps namely logic synthesis, logic
verification, layout synthesis, timing verification and many
others. Thus a number of standard tools have emerged to
design and analyze VLSI chip from one step of the flow to
another. Computer-aided design (CAD) is the use
of computer systems to assist in the creation, modification,
analysis, or optimization of a design. Computer aids in VLSI
now offer advance capabilities so engineers can better
visualize their product designs. The VLSI CAD tools work
sideways together with chip designers to design and analyze
entire semiconductor chips. In this paper, a number of open-
source and licensed CAD tools will be studied and
compared. The tools have been used for various commercial
and academic purposes in various companies and
universities at different design abstraction levels. This paper
will help to comprehend many EDA tools and help to select
appropriate computer aid for chip design.
Key words: CAD tools, EDA, VLSI chip, Open source
CAD tools, Licensed CAD Tools, Design abstraction,
Design Methodologies.
I. INTRODUCTION
The use of integrated circuits in high performance
computing, telecommunications and consumer electronics
has been growing at a very rapid rate. The on-going
vanguard technologies by the time furnish to the ultimate
users an assertive amount of processing potential and
flexibility. VLSI chiefly comprises of Front End Design,
Back End design, verification and Testing. Generally front
end design includes analog, digital and mixed signal design
using HDL, schematic entry and spice level circuit modeling
and design verification through simulation and testing
techniques. It also includes design and testing through
various custom and Semi-custom methodologies.
The backend design comprises of CMOS layout,
cell and library design and its characterization using specific
process technology. CAD (computer - aided - design) tools
are essential for timely development of IC. Use of
sophisticated CAD tools and methodologies are also
essential for reducing the design time and for managing the
increasing complexity.
Fig. 1: Design and Analysis of IC Design
There are numerous number of EDA tools available
for IC Design at Custom and Semi-Custom level.
Comparative study of EDA Tools is carried out between the
following CAD tools such as:-alliance, electric CAD,
MAGIC, system C, my HDL, Cadence EDA, Mentor
graphics EDA, Synopsys EDA, Tanner EDA.
II. VLSI CAD TOOLS
In today’s market, there are lots of VLSI CAD tools are
available for IC Design. Some of them are free while others
are not. A proper tool that is suitable to the specific design
task can lead to high efficiency and less cost. CAD tools are
essential for timely development of IC. VLSI CAD TOOLS
based on the typical design work flow, an excellent CAD
technology for VLSI chip design can be categorized into
following areas: high level synthesis, logic synthesis, circuit
optimization, layout, simulation, design rules checking and
formal verification. Current systems are very complex. The
use of CAD tools and methodologies are essential for
reducing the design time and for managing the increasing
design complexity. To get the chip to the market fast CAD
tools are vary essential. CAD tools are inevitable. This paper
focuses on the study and comparison of open source CAD
tools and license based CAD tools.
OPEN SOURCE CAD TOOLSA.
The open-source license has allowed VLSI engineers with a
bent toward programming to implement clever ideas and
help magic stay abreast of fabrication technology. A key
benefit of using open-source applications is that the code
can be compiled on as system which is non-standard. some

Study and Comparison of Open Source and Licensed VLSI CAD Tools using CMOS Design Methodology
(IJSRD/Vol. 1/Issue 9/2013/0079)
open source VLSI cad tools are selected for general
introduction and comparison.
Fig. 2: Simple VLSI CAD tool chain
Tools
Function and
Type
Platform
Latest
Version
Description
Alliance
Logic to Layout,
Mixed signal
Linux Version 5.0
Set of free
CAD tools
and
portable
libraries. It
supports
the
standard
VLSI
description
formats
like
SPICE,
EDIF,
VHDL,
CIF and
GDS2.
Magic
Circuit Layout,
Mixed signal
Linux Version 7.5
Easiest
tool to use
for circuit
layout,
contain an
incrementa
l design-
rule
checker
Electric
Logic to Layout,
Mixed signal
Linux,
Windo
ws and
Macint
osh
Version 9.04
It is a
sophisticat
ed
electrical
CAD
system
that can
handle
many
forms of
circuit
design.
My
HDL
Hardware
description
language,
Electronic
system level
Linux Version 0.8
MyHDL is
to use
Python
generators
to model
the
concurrenc
y required
in
hardware.
System
C
Library For
digital design,
Electronic
system level
Linux Version 2.2
System C
is C++
based
system
level
description
language.
Ngspice
Circuit
simulator,
Mixed signal
Linux Version 25
It
implement
s three
classes of
analysis
Nonlinear
DC
analyses,
Nonlinear
Transient
analyses
and Linear
AC
analyses.
Table. 1: Comparative study of various open sources VLSI
CAD tools[6,25,26,27]
LICENSED VLSI CAD TOOLSB.
Electronic Design Automation (EDA) products by various
vendors are sold on the basis of licensing models. EDA
licensing traditionally follows a perpetual model, in which
users buy a tool license that essentially lasts forever.
Along with that perpetual license, vendors typically
sell a maintenance deal on an annual basis.
Tools
Function
and Type
Platform
Latest
Version
Description
Cadence EDA
Comple
te CAD
flow,
Analog
and
mixed
signal
Unix and pc-
based
systems
version 16.6
Cadence
provides
contracted
methodology
and design
services. as well
as silicon design
IP.
Mentor graphics
EDA
Comple
te CAD
flow,
Analog
and
mixed
signal
Linux Genivi 3.0
The Mentor
Graphics tool is
Design
Manager, tool
that is
specifically
designed to
preserve and
manipulate the
objects.
Synopsys
EDA
Comple
te CAD
flow,
Analog
and
mixed
signal
Linux
Virtualizer
13.06
Synopsys is a
world leader in
software and IP
for
semiconductor
design,
verification.

Tanner EDA
Comple
te CAD
flow,
Analog
and
mixed
signal
Windows,
Linux.
V16
Tanner EDA is a
suite of tools for
the design of
integrated
circuits. Tanner
EDA is mainly
used to analyze
circuits at switch
level & gate
level.
Table 2: Comparative study of licensed VLSI EDA tools
[ 34,21,20]
Designer’s aim is to Transfer Design description in one
domain into a fully equivalent design descriptions in
respective other.
DESIGN METHODOLOGYC.
Systematic design methods or the design methodologies are
necessary for successfully designing complex digital
hardware. Our design methods usually differ by the number
of abstraction levels and the complexities involved.
Fig. 4: Limitation and challenges to overcome at various
abstraction levels in VLSI Design and CAD
Fig. 5: Abstraction Hierarchy 1 [1]
The design cycle may be short or can be long depends on
the requirement of the requirement. Assuring integrity of the
design and success requirement are the different parts in
characterizing the design. Various methodologies look in to
the design with multiple views and the representation will be
different with each set of characterization. The complexity
can rise further due to insufficient documentation.
Fig. 6: Abstraction Hierarchy 2 [1]
III. VLSI EDA CLASSIFICATION
A kind of activity which uses a computer to assist on the
creation, modification and analysis of design. CAD tools
generally consist of the following components, input handler
(input from mouse or keyboard), data structure and
algorithms (in memory), output handler (output to display).
CAD environment generally consists of a simulator, design
space exploration and design sign off.
Following is the brief classification of CAD
1) High Level synthesis CHDL
2) Logic Synthesis Tools
3) Circuit optimization Tools
i) Transistor sizing Tools
ii) Process variation Tools
iii) Statistical Design Tools
4) Layout Tools
i) Floor planning Tools
ii) Place and Route
iii) Module Generation
iv) Automatic Call and placement routing
5) Layout Extraction Tools
6) Simulation (SPICE for circuit level simulation)
7) Layout schematic verification Tools
Fig. 7: Co-evolution of CAD Tools and methodologies [19]
The role of the CAD tool in VLSI design is
1) Accurately generated and easily modifiable graphical
representation of the product. The user can nearly view
the actual product on screen, make any modifications
to it, and present his/her ideas on screen without any
prototype, especially during the early stages of the
design process.
2) Perform complex design analysis in short time and
Implementing Finite Elements.
3) The user can perform the following analysis methods:
i) Static, Dynamic and Natural Frequency analysis,
Heat transfer analysis, Plastic analysis, Fluid
flow analysis, Motion analysis, Tolerance
analysis, Design optimization.
4) Record and recall information with consistency and
speed.
IV. VLSI EDA COMPLEXITIES [1,11]
Problem Domain ComplexityA.
The functionality of the integrated chip should be taken into
account with respect to the 3p’s [9] i.e. price, power and
performance. The problem may be competing or posseing

contradictory requirements in terms of speed power and
other design metrics. The problem can also arise due to the
mismatch between the users and designers. Application area
specialization and knowledge with ever changing and
evolving specifications. The cost of design and development
also depends on the extent to which the specification issues
have been captured.
Design/ Development Process ComplexityB.
VLSI is a fast growing industry, if automobile industry
would have developed at the same rate cars would have
been far more affordable. The rapid change in technology is
basically due to advancements in various fabrication
procedures and simultaneously in design methodologies.
The modularity and hierarchical let the large task into
smaller modules, the large tasks requiring multidisciplinary
team, separated by geographical regions.
The design cycle may be short or can be long
depends on the requirement of the requirement. Assuring
integrity of the design and success requirement are the
different parts in characterizing the design. Various
methodologies look in to the design with multiple views and
the representation will be different with each set of
characterization. The complexity can rise further due to
insufficient documentation.
Complexity of choicesC.
As the time goes on, advancement in the design
methodologies have been done with respect to speed area
and power dissipation. Many technologies and
implementation choices such as NMOS, PMOS. Many
methodologies (FPGA, Semi-custom, CPLD, Full custom,
ASIC etc.). Many different styles of implementation in static
(ratioed, general transistor logic, pass transistor logic,
transmission gate logic etc.). Many logic styles in dynamic 2
phase,4 phase) Cascaded logic (Domino, NPMOS, Zipper
etc.). Many possible partitions at each level increase the
complexity of choices.[4,9]
Fig. 8: Design representation levels and formats associated
[1]
Complexities of design tasksD.
These complexities include various clocking and timing
issues, testing related issues, packaging related issues and
concurrency related operations. The design tasks exist in the
front end as well as in the back end.
V. LIMITATIONS AND CHALLENGES TO BE
OVERCOMEIN CAD TOOLS [1, 11]
In this section, various established and emerging design
quality metrics and the main challenges of CAD tools to
effectively predict, analyze their interactions, and optimize
them in the CMOS technology were discussed. In the last
few years, the research developers have witnessed
increasing levels of interactions between physical, logical,
and functional realms in the synthesis of VLSI circuit and
systems. Various approaches with varying levels of
interactions between the synthesis and layout phases have
been proposed. These techniques are classified into several
classes:
Gain-Based SynthesisA.
It is based on logical effort theory, which performs the gate
sizing based on logical effort, electrical effort and timing
constraints. The succeeding layout phase is then performed
with additional timing and capacitance constraints to meet
the initial gate sizing decision. Appropriate circuit libraries
are must.
Layout-Friendly SynthesisB.
Here, Synthesis of layout implications is given more
importance. The wire planning is a best example for this
type of synthesis. The research developers use the placement
of I/O pins to achieve a layout-friendly logic factorization.
Layout-Driven SynthesisC.
In this synthesis depends on companion, layout/placement
of various parts of the logic. After synthesis nodes may get
created or deleted, and the companion layout may need to be
updated to reflect these changes. The benefit of having a
companion layout view is access to a more realistic estimate
about inter-connects parasitic. This would allow the
synthesis phase to make better decisions, while optimizing
the logic.
Integrated Synthesis and LayoutD.
The ultimate integration of the synthesis and layout phases
was carried out by this class.
Synthesis-Driven LayoutE.
This category consists of those techniques which perform
layout optimization moves either within the synthesis phase
or in a post-layout phase where synthesis and layout
optimizations are applied to improve the design or meet the
performance constraints.
Synthesis-Friendly LayoutF.
This type of synthesis consists of layout synthesis
algorithms and environments which is capable of
withstanding functional and logic changes, with minimal
disruption to the layout.
VI. CONCLUSION
With design technology, it would be possible to implement,
verify and test the complex integrated circuits. It is through
design technology that the ideas and objectives of design,
circuit and fabrication engineers are transformed into reality

and the quality of the design tools and associated
methodologies determine the design time, performance, cost
and the correctness of the final product chip. The
development in the design tools, collaborative design
methods, the role of human factors and integration factors in
the design technology marks the outline of various design
methodologies. This paper explains design quality metrics
from a CAD tool perspective. Various shortcomings of the
current CAD tools and methodologies to tackle the VLSI
design challenges were discussed and several promising
remedies and their implications on design and
methodologies are explored.
Below table will summarize a comparative study of
open source and licensed CAD Tools.
Key Features
Open Source
EDA Tool
Licensed EDA
Tool
Design time More Less
Performance Good Excellent
Correctness Good Excellent
Reliability Good Good
Compatibility with
Operating System
Compatible with
Linux, windows
and others.
Compatible with
mostly Linux and
similar Unix
flavors.
Design Quality Depends on flow Good
Standardization
For academic
purposes.
For academic and
commercial
purposes.
Table. 3: Comparative study of Open source CAD tools and
Licensed VLSI EDA tools
REFERENCES
[1] Randal E. Bryant, Kwang-TingCheng , Andrew B
Kahang, Kurt Kreutzer, Wojciech Maly, Richard
Newton, Lawerance Pileggi, Jan M Rabaey, Alberto
Saniovanni- Vincentelli, “Limitations and Challenges
of CAD technology for CMOS VLSI”
[2] Catherine H. Gebotys, Mohamed I. Elmasry, “Vlsi
Design Synthesis and Testability”
[3] A.H. Farrahi, D.J. Hathaway, M.Wang and
M.Sarrafzadeh, “Quality OF EDA CAD Tools:
Definitions, Metrics and Directions”
[4] K.A. Sumithra Devi, “Algorithms for CAD tools VLSI
design”
[5] Neil Weste and David Harris, CMOS VLSI Design, the
Third Edition, Pearson Education, 2004.
[6] Static Free Software. November 2009
http://www.staticfreesoft.com.
[7] Alliance. November 2009. http://www
asim.lip6.fr/recherche/alliance.
[8] Magic VLSI Resource. November 2009.
http://www.opencircuitdesign.com/magic.
[9] Cadence OrCAD Solutions. February 2010.
http://www.cadence.com/products/orcad.
[10] Yohn K. Ousterhout, Gordon T. Hamachi, Robert N.
Mayo, Walter S. Scott, and George S. Taylor, “Magic:
A VLSI Layout System”, Design Automation, 1984.
21st Conference on, 25-27 June 1984.
[11] Ayoush Johari, VVS Lavanya, Rakeshwari Pal, “Study
of VLSI Design Methodologies and Limitations using
CAD tools for CMOS Technology” IJEECT, Vol.10,
Issue9 ,August 2013, INFLUENCE 2013, Bhopal
(ISSN-2229-3207).
[12] Scott, W. S. and Ousterhout, J. K. “Plowing:
Interactive Stretching and Compaction in Magic”,
Design Automation, 1984.
[13] Alain Greiner and Francois Pecheux, “ALLIANCE: A
complete Set of CAD Tools for teaching VLSI
Design”, Technical Report: Laboratoire MASI/CAO-
VLSI, Institute de Programmation, University Pierre et
Marie, 1992.
[14] Amara Amara, Alain Greiner, Luis Lucas, Frederic
Petrot, Franck Wajsburt, Laurent Winckel, “The
Portable Cell Libraries of the Freeware Alliance CAD
system”.
[15] IRSIM, February 2010.
http://opencircuitdesign.com/irsim.
[16] J. B. MacQueen, "Some Methods for classification and
Analysis of Multivariate Observations”, Proceedings of
5-th Berkeley Symposium on Mathematical Statistics
and Probability, Berkeley, University of California
Press, 1967, pp. 281-297.
[17] http://nptel.iitm.ac.in/courses/IIT-
MADRAS/CAD_for_VLSI_Design_I/index.php
[18] Topped – Open Source Layout Editor, February 2010.
http://www.toped.org.uk.
[19] Computer Aids for VLSI Design Second Edition
Steven M. Rubin
[20] Synopsys, “Design Compiler FPGA,” 2004.
[21] Mentor Graphics, “Leanardo Spectrum,” 2001.
[22] V. Betz, J. Rose, and A. Marquardt, Architecture and
CAD for Deep-Submicron FPGAs.Kluwer Academic
Publishers, 1999.
[23] Bar, M., Fogel, K., Open Source Development with
CVS, 3rd Edition, Para glyph Press, 2003. Chromatic,
Myths Open Source Developers Tell Ourselves,
O’Reilly On Lamp,
[24] Fellor J, Fitzgerald B., Raymond, E., Understanding
Open Source Software Development, Addison-
Wesley,2001, ISBN 0201734966
[25] Alliance. http://www.asim.lip6.fr/recheche/alliance
[26] Magic VLSI Resource.
http://www.opencircuitdesign.com/magic
[27] http://www.vlsiacademy.org/open-source-cad-
tools.html
[28] Custom IC Design,
http://www.cadence.com/products/cic
[29] D. Lidsky, J. M. Rabaey, “Early Power Exploration--a
World Wide Web Application”, Design Automation
Conference, June 1996.
[30] M. Nemani and F. Najm. “High-Level Area and Power
Estimation for VLSI, Circuits”. IEEE Transactions on
Computer Aided Design, 18(6):697–713, June 1999.
[31] C. S. Shung et al., “An integrated CAD system for
algorithmspecificIC design,” IEEE Trans. CAD Integ.
Circ. and Syst., Apr.1999
[32] Alain Greiner and Francois Pecheux, “ALLIANCE: A
complete Set of CAD Tools for teaching VLSI
Design”, Technical Report: Laboratoire MASI/CAO-

VLSI, Institut de Programmation, Universite Pierre et
Marie, 1992.
[33] Amara Amara, Alain Greiner, Luis Lucas, Frederic
Petrot, Franck Wajsburt, Laurent Winckel, “The
Portable Cell Libraries of the Freeware Alliance CAD
system”.
[34] Cadence OrCAD Solutions. February 2010.
http://www.cadence.com/products/orcad.
[35] Magic VLSI Resource. November 2009.
http://www.opencircuitdesign.com/magic.

Study and Comparison of Open Source and Licensed VLSI CAD Tools using CMOS Design Methodology

More Related Content

What's hot

Similar to Study and Comparison of Open Source and Licensed VLSI CAD Tools using CMOS Design Methodology

More from ijsrd.com

Recently uploaded

Study and Comparison of Open Source and Licensed VLSI CAD Tools using CMOS Design Methodology
