From 300k uncategorised images of watches to production models that recognise 58 classes with 90% precision, at scale. With more than 60 million new listings every month in our platform, it could be cumbersome to narrow down your options to the exact item you want and we don’t want to bother our users with extremely detailed forms to describe their listings. In fact, we want to extract those characteristics ourselves, automatically. That’s why we build an attribute extraction system that uses Deep Neural Networks for Image Classification and Object Localization to classify the many properties of watches, e.g. brand, type, style, color and materials of dials and straps, etc. This talk will focus on the approach we took to tackle the unique challenges of such problem, the techniques we used, how to evaluate them and how to scale them using Amazon SageMaker and TensorFlow Serving.

1. Structure unstructured data
From 300k uncategorised images of watches to production models that
recognise 58 classes with 90% precision, at scale
Carmine Paolino
OLX Group

2. Offline OLX

3. “Hey, we have thousands of
watches and I want to organise
them!

8. 1. Ask the right questions

9. Clarify business problem

10. Limit the problem space

11. Define an evaluation metric

12. Make models that extract at
least 50 attributes from images
of watches at 90% precision,
and prepare a labelled dataset.

13. 2. Data exploration and
Dataset creation

14. Use pretrained models for classification
Faster R-CNN
InceptionResNet v2
OpenImageDataset
Faster R-CNN
NASNet
COCO
OLX Stock image
detection
Clock
Clock
Stock ImageWatch
Wall clock
Alarm clock
Original Image
Digital clock
Pocket watch
Watch strap

15. Cluster embeddings of items
from pretrained models

18. (spoiler alert)
Fine-tune on your domain

19. N-gram frequency analysis

20. 1-gram:
“Omega”
2-gram:
“Omega Speedmaster”

29. A few other options:
Topic modelling
Sentiment analysis
Named entity recognition

32. 4. Train some models!

34. InceptionResNet v2
pretrained on ImageNet

39. Epochs
Accuracy
Brand classifier’s learning curve
training
softmax

41. Epochs
Accuracy
Brand classifier’s learning curve
training
softmax
+1 block

43. Epochs
Accuracy
Brand classifier’s learning curve
training
softmax
+1 block
+1 block

45. Epochs
Accuracy
Brand classifier’s learning curve
training
softmax
+1 block
+1 block
+1 block

47. Epochs
Accuracy
Brand classifier’s learning curve
training
softmax
+1 block
+1 block
+1 block
+1 block

48. Set the classification threshold of
every category in order to have
90% precision

49. Classifier Class Precision Recall Threshold
Brand Apple 0,90020 0,97720 0,17410
Brand Armani 0,90080 0,51010 0,54613
Brand Breitling 0,90030 0,63290 0,47542
Brand Casio 0,90100 0,25290 0,77514
Brand Diesel 0,90060 0,85480 0,27741

50. 5. Deploy and scale

51. Export your model to
TensorFlow SavedModel

52. def export_to_tf(model_path, classes_json, export_dir, top_k):
"""Converts the model to TensorFlow Serving."""
model = keras.models.load_model(model_path)
K.set_learning_phase(0)
# deal with serialized inputs
serialized_tf_example = tf.placeholder(tf.string, name='tf_example')
feature_configs = {
'image/encoded': tf.FixedLenFeature(shape=[], dtype=tf.string),
}
tf_example = tf.parse_example(serialized_tf_example, feature_configs)
jpegs = tf_example['image/encoded']
images = tf.map_fn(preprocess_image, jpegs, dtype=tf.float32)
# ...

53. def preprocess_image(image_buffer):
"""Emulates how Keras does preprocessing for its InceptionResnetV2
model. Check https://goo.gl/je7BCx"""
# Decode the string as an RGB JPEG
image = tf.image.decode_jpeg(image_buffer, channels=3)
# After this point, all image pixels reside in [0,1)
# until the very end, when they're rescaled to (-1, 1). The various
# adjust_* ops all require this range for dtype float.
image = tf.image.convert_image_dtype(image, dtype=tf.float32)
# Resize the image to the original height and width.
image = tf.expand_dims(image, 0)
image = tf.image.resize_bilinear(
image, [IMAGE_SIZE, IMAGE_SIZE], align_corners=False)
image = tf.squeeze(image, [0])
# Finally, rescale to [-1, 1] instead of [0, 1)
image = tf.subtract(image, 0.5)
image = tf.multiply(image, 2.0)
return image

54. # … continuing the function export_to_tf
# attach preprocessing to graph
output = model(images)
# output the top 3 predictions
prediction_scores, prediction_indexes = tf.nn.top_k(output, top_k)
# prediction classes
classes = json.loads(classes_json.read())
prediction_table = tf.contrib.lookup.index_to_string_table_from_tensor(
tf.constant(classes))
prediction_classes = prediction_table.lookup(
tf.to_int64(prediction_indexes))
# build the signature_def_map
classification_inputs = tf.saved_model.utils.build_tensor_info(
serialized_tf_example)
classification_outputs_classes = tf.saved_model.utils.build_tensor_info(
prediction_classes)
classification_outputs_scores = tf.saved_model.utils.build_tensor_info(
prediction_scores)

55. # … continuing the function export_to_tf
classification_signature = (
tf.saved_model.signature_def_utils.build_signature_def(
inputs={
signature_constants.CLASSIFY_INPUTS: classification_inputs
},
outputs={
signature_constants.CLASSIFY_OUTPUT_CLASSES:
classification_outputs_classes,
signature_constants.CLASSIFY_OUTPUT_SCORES:
classification_outputs_scores
},
method_name=signature_constants.CLASSIFY_METHOD_NAME))
builder = tf.saved_model.builder.SavedModelBuilder(export_dir)
with K.get_session() as sess:
builder.add_meta_graph_and_variables(
sess=sess,
tags=[tf.saved_model.tag_constants.SERVING],
clear_devices=True,
legacy_init_op=tf.tables_initializer(),
signature_def_map={
signature_constants.DEFAULT_SERVING_SIGNATURE_DEF_KEY:
classification_signature
})
builder.save()

56. Amazon
SageMaker

57. Save it as tar.gz to S3 and
deploy

58. import sagemaker
from sagemaker.tensorflow.model import TensorFlowModel, TensorFlowPredictor
def custom_tensorflow_predictor(endpoint_name, sagemaker_session):
def predictor():
return TensorFlowPredictor(endpoint_name, sagemaker_session)
return predictor
def deploy(model_path, entry_point_path, inference_instance_type, model_name):
sess = sagemaker.Session()
predictor = custom_tensorflow_predictor(model_name, sess)
model = TensorFlowModel(
model_data=model_path,
role=sagemaker.get_execution_role(),
entry_point=entry_point_path,
predictor_cls=predictor,
name=model_name)
model.deploy(
initial_instance_count=1, instance_type=inference_instance_type)

59. Set an autoscaling group and…

61. Thanks!
Questions?
Post, code, and more soon at
https://tech.olx.com/
