The document discusses several medical devices that Baren-Boym Company has provided design services for, including a cervical disc holder, surgical spine instruments, an LVAD heart pump system, and a prone position table for breast cancer radiation therapy. The company's services included industrial design, mechanical engineering, concept generation, and finite element analysis to develop solutions for clients such as DePuy Spine, Thermo CardioSystems, and Orbital Therapy.

1. Cellect Graft Preparation Device SELECTIVE RETENTION™ Technology harnesses bone marrow, the osteogenic component of autograft, to populate a graft material with a 3-4 fold increase in osteoprogenitor cells through a minimally invasive approach. Minimally invasive aspiration of bone forming cells, unique needle designs reduces aspiration procedure time. Single-hole design aspirates highly cellular bone marrow. Three-hole design aspirates 3-times as much bone marrow without compromising marrow cellularity. Baren-Boym Company has performed Industrial Design and Mechanical Engineering Services. Client - DePuy Spine, J&J Company MEDICAL

2. Battery holder Designed to provide a power to the Left Ventricular Heart Assist Device the clips utilize a mechanism for quick snap and release of batteries. The housing is water tight, that protects the batteries from bad weather conditions. Baren-Boym Company provided Mechanical Design of the Plastic Battery Clips. Client - Thermo CardioSystems Inc MEDICAL

3. Blake Drain The BLAKE Drains are white, radiopaque silicone drains with four channels along the sides with a solid core center. Their other components consist of a silicone hub, silicone extension tubing and an adapter. Baren-Boym Company has provided the design for the multiple port adapters. Client - Ethicon Inc, J&J Company MEDICAL

4. SprayGel Kit The SprayGel Open Kit is designed for both abdominal and pelvic open surgical procedures. Baren-Boym Company has worked on the development of the technology to better atomize fluids with high viscosity. Client - Confluent Surgical Inc MEDICAL

5. MEDICAL

6. GUARDIAN Vaginal Retractor The unique design of the GUARDIAN Vaginal Retractor™ serves a long-standing need among physicians. It has been developed to effectively control the anatomy in order to give adequate visibility and access to the complete circumference of the vagina, the perineal tissue, and cervix during gynecologic procedures. Exceptionally well suited for episiotomy and vaginal laceration repair, the GUARDIAN Vaginal Retractor™ maximizes exposure in large episiotomies, 3rd and 4th degree lacerations, and lateral sulcas tears. Its design also appeals to physicians for gynecologic operative procedures. Baren-Boym Company provided Industrial Design and Mechanical Engineering Services. Client - Cooper Surgical Inc MEDICAL

7. Spine Rod Inserter A unique instrument serves the need to apply Expedium and the FRONTIER® Anterior Deformity System unites the clinical experience of MONARCH® 6.35 Ti Spine System, Kaneda Anterior Scoliosis System (KASS), MOSS® MIAMI Spine System, and ISOLA® Spine System with revolutionary technology developed specifically for thoracoscopic procedures to deliver unsurpassed versatility, simplicity and security. Baren-Boym Company provided complete mechanical engineering design and Finite Element Analysis. Client - DePuy Spine, J&J Company MEDICAL

8. Dermabond DERMABOND* Topical Skin Adhesive is a liquid skin adhesive used by doctors to close wounds. Baren-Boym Company has participated in the project and designed multiple tip applicators for dispensing the adhesive. Client - Ethicon Inc, J&J Company MEDICAL

9. Cervical disc holder While cervical discs are being delivered to the medical personnel, it is essential to keep them together. The design of the holder is an efficient way to deliver the cervical discs to the operational site. When the clip is opened, both discs maintain parallelism due to the special construction of the clip. Baren-Boym Company provided complete mechanical engineering design. Client - DePuy Spine, J&J Company MEDICAL

10. Surgical Spine Instrument Industrial Design Concepts of the spine reconstructive surgical tool. Baren-Boym Company generated 10 Concepts for the Johnson & Johnson, Depuy Spine Inc. Client - DePuy Spine, J&J Company MEDICAL

11. Vision Test Kit Conceptual work for the eye vision station. Baren-Boym Company performed visualization and industrial design services. Client – Confidential MEDICAL

12. Surgical Spine Instrument Industrial Design Concepts of the Surgical Instrument. Baren-Boym Company has presented 5 Concepts and provided industrial design and visualization services. Client - DePuy Spine, J&J Company MEDICAL

13. HeartMate LVAD The HeartMate Left Ventricular Assist System (LVAS). Baren-Boym Company has worked with Thermo CardioSystems to develop LVAD and associated systems: Controllers, Displays, Pnuematic Adapters. Client - Thermo CardioSystems Inc. (Thoratec Inc) MEDICAL

14. SpotCure System SpotCure-P is specifically matched to Loctite® 4305 UV adhesive to provide tack-free curing in less than 5 seconds. Using an intense array of LED\'s at 400nm (UV-C) avoids problems with UV-A or UV-B devices. Baren-Boym Company provided Industrial Design and Mechanical Engineering Services for enclosure design and packaging. Client - Kinetic Instruments Inc MEDICAL

15. Blood vessel coagulation Baren-Boym Company designed internal mechanisms inside the handle and also provided Industrial Design for the handle. Client - Medsource Technologies Inc MEDICAL

16. System Monitor Designed to monitor the functions of Left Ventricular Heart Assist Device, providing information about the blood flow, heart rate and a stroke volume. Utilizes touch screen technology for patient programmable input information. It employs the unique mounting clamp for positioning the monitor horizontally on the bed rail or vertically on the IV pole. Baren-Boym Company provided Mechanical Design of the Display Monitor. Client - Thermo CardioSystems Inc MEDICAL

17. Full-Thickness Plicator The Endoscopic Full-Thickness Plicator has been designed to produce a lasting solution to GERD through a simple outpatient procedure. Baren-Boym Company provided Mechanical Engineering services for Plicator's design and Industrial Design services for the handle of the instrument. Client - NDO Surgical Inc MEDICAL

18. Express 3 & 4 The StatSpin Express 3 & 4, high speed horizontal centrifuges provide faster turnaround time and greater productivity for laboratory. Baren-Boym Company provided Industrial Design and Complete mechanical engineering services for both centrifuges housings and internal mechanisms. Client - StatSpin Technologies Inc MEDICAL

19. Hematocrit Reader The ideal, low-cost microhematocrit system for hospital, clinics, STAT labs and doctor offices. Digital Hematocrit Reader minimizes handling of tubes. Entire hematocrit rotor drops into reader. With one hand, rotate rotor to read each tube. The reader scale is backlit for easy viewing. Baren-Boym Company provided Industrial Design and Mechanical Engineering Services. Client - StatSpin Technologies Inc MEDICAL

20. Trek MEDICAL

21. Isometric Strength Testing Isometric Strength Testing Machine was developed for Massachusetts General Hospital Department of Neurology. This apparatus enables the doctor to measure and record strength of various muscle groups over the extended time periods. The machine utilizes only one load cell for value recording from various muscles measurement stations. MEDICAL

22. ClearVue(TM) prone position table Orbital Therapy’s carbon fiber ClearVue(TM) prone position table was designed by Baren-Boym Company to address current and future requirements to deliver this emerging therapy technique. ClearVue(TM) offers a number of advantages over other commercially available prone position tables. Prone position increases the separation of the target and critical organs and minimizes target motion caused by breathing. This results in the ability to deliver less dose to the surrounding organs such as lung and heart, and more precise dose to the intended target. The unique, patent-pending open design provides visual and treatment access to the breast allowing to plan and treat from multiple angles. The interchangeable mid-section allows you to quickly adjust the table configuration between closed “O” and open-sided “U”. The same inserts are used for right and left breast. Client - Orbital Therapy Inc MEDICAL

23. HTA System Insulated Sheath with Tenaculum Stabilizer Insulated continuous flow sheath is designed to help protect cervical canal from thermal effect. The Tenaculum Stabilizer feature is designed to help prevent accidental withdrawal of the sheath from the cervix while offering improved ease of use. Client - Boston Scientific MEDICAL

24. Luggage A number of Industrial Design concepts have been provided to the client. Baren-Boym Company provided industrial design and conceptual design services. Client – Confidential CONSUMER

25. Fire Alarm A combination Smoke/CO Alarm makes it easy to provide both types of protection throughout the home. A combination alarm can be installed on every level of the home and is an excellent way to ensure maximum protection for occupants, with a minimum of installation effort. Baren-Boym Company has provided industrial design and engineering design services. Client – Confidential CONSUMER

26. E-book Electronic hand held PDA system. Baren-Boym Company has provided mechanical engineering and industrial design services. Client – Confidential CONSUMER

27. Photo Camera A series of Industrial Design concepts were generated. Baren-Boym Company provided Industrial Design services. Client – Confidential CONSUMER

28. Gift Set A gift set was designed and engineered for the oil company. Baren-Boym Company provided Industrial Design and Mechanical Engineering services. Client – GazProm Inc CONSUMER

29. AC outlet plug Baren-Boym Company provided engineering and industrial design services for the development of the AC cable plugs. Client – Petoh Inc CONSUMER

30. Communication Tool A voice communicator is a part of hand held intercom system. Baren-Boym provided Industrial Design and Engineering service. Client – Confidential CONSUMER

31. Thermometer Hand held thermometer has been designed by Baren-Boym Company. We have provided the industrial design and engineering services. Client – Confidential CONSUMER

32. Toolbox A series of toolbox designs have been generated. Baren-Boym Company provided Industrial Design services. Client – Confidential CONSUMER

33. Trash Can A series of trash can conceptual designs have been generated. Baren-Boym Company provided Industrial Design and complete mechanical engineering services. Client – Confidential CONSUMER

34. Zip New Balance New Balance hired Baren-Boym Company to help in design of the advanced running shoe. Baren-Boym Company provided design and analytical calculation on the sole of the shoe. Client – New Balance Inc CONSUMER

35. Measurement tool set Set of tools designed for the construction use. Baren-Boym provided complete Industrial Design and Mechanical Engineering Services. Client – Confidential CONSUMER

36. Water Filter Baren-Boym Company provided series of conceptual industrial design sketches for the water filtration machine. Client – Confidential CONSUMER

37. Manicure Station Portable Manicure Station was designed for the professional manicurist, to help her work faster, and more comfortably, with less strain to the neck and wrists. Client - RadaPro Inc CONSUMER

38. Palm Rest The Palm Rest is ergonomically designed to support your palms and keep your wrists in a neutral position. This helps to relieve the strain on your arms, wrists and hands and reduce the pain and discomfort you are experiencing while driving. In addition to providing comfort for the everyday driver, The Palm Rest is a great aid for people who suffer from carpal tunnel syndrome, tendinitis and arthriti. Baren-Boym Company provided both ID and ME Client - The Palm Rest Inc CONSUMER

39. Fridge In this project all elements have new places. The first new thing is an inclined triangle shelf for comfortable keeping the bottles there. In this way cellar can be created, or it can be just a place for juice. The next new thing is a movable shelf. Such system helps to solve some problems and use the fridge in a more comfortable manner. You can move the shelf and take what you want. One more interesting thing is a shelf with changing height. It is very simple to make the shelf higher or lower. CONSUMER

40. Table lamp with integrated function of ionizer CONSUMER

41. Machine for drilling the beds Machine is created for drilling beads of different size and form. There are different nozzles and a box in complication. The first nozzle is for drilling beads of spherical form. The second created for more complicated forms. The third will drill beads of very difficult forms. CONSUMER

42. Universal drying apparatus AIR CONSUMER

43. Kitchen knife CONSUMER

44. Audio Amplifier CONSUMER

45. Camera CONSUMER

46. Agros Toolset CONSUMER

47. Chair for Helicopter CONSUMER

48. SkyWater Machine Skywater® is the worlds first genuine alternative water source. Dependent only upon electricity, the Skywater® 300 unit can extract up to 300 gallons per day of fresh, pure water, directly from the humidity in the air. Baren-Boym Company provided Industrial Design Concepts. Client - Island Sky Inc. CONSUMER

49. Anti Mosquito Device The portable device. It is intended for scaring away of mosquitoes.It works on two accumulators AA. Uses replaceable cartridges. CONSUMER

50. Aluminum Wheel Casting Finite Element Analysis of aluminum wheel casting with ProCAST. This test allows prediction of porosity and shrinkage of the material. It also allows prediction of the residual stresses in the material. The FEA was successfully executed and no problems were detected. ANALYTICAL

51. Wheel Optimization Baren-Boym Company has developed an efficient virtual testing system for the automobile wheels analysis. Light alloy wheels optimization with FEA simulations of testing according ISO 7141, Client - Federal Motor Vehicle Agency ANALYTICAL

52. Bath Seat Analysis Baren-Boym Company has been contracted by First Years Inc to perform stability analysis and stress analysis in multiple components of the child bath seat. After the analysis we have found weak areas in some of the components and we have proposed their redesign to improve the stability and strength of the bath seat. Client – The First Years Inc ANALYTICAL

53. Spine Implants During the actual testing of the spine implants it was noticed that new molded peek implants were failing under torsion and compression loads. Depuy Spine Inc has asked Baren-Boym Company to look into the problem. We have performed the FEA analysis on the existing implant and have found that in fact the design could not withstand the exerted loads. Baren-Boym Company has provided seventy-two designs and FEA tests to find three possible configurations that would be adequate to sustain necessary loading conditions. Client – Depuy Spine Inc, J&J ANALYTICAL

54. Spinal Rod Inserter A unique instrument serves the need to apply Expedium and the FRONTIER® Anterior Deformity System unites the clinical experience of MONARCH® 6.35 Ti Spine System, Kaneda Anterior Scoliosis System (KASS), MOSS® MIAMI Spine System, and ISOLA® Spine System with revolutionary technology developed specifically for thoracoscopic procedures to deliver unsurpassed versatility, simplicity and security. Baren-Boym Company provided complete mechanical engineering design and Finite Element Analysis. Client - DePuy Spine, J&J Company ANALYTICAL

55. Heart Cannula CFD During the design of the heart blood pump it is essential to design a perfect outflow cannula because the blood must flow freely inside the tube. There must not be any areas in the cannula where the blood can slow down or even stop. Baren-Boym Company has been contracted by Levitronix Inc to perform the analysis of the blood cannula. We have found areas in the cannula that may present problems. They have been redesigned and final CFD analysis confirmed a superior cannula design. Client – Levitronix Inc ANALYTICAL

56. ZIP New Balance Shoe While developing new and advanced running shoe New Balance Inc contracted Baren-Boym Company to optimize the sole performance. The redesign and followed analysis showed tremendous improvements in sole performance and durability under various loading and temperature conditions. Client – New Balance Inc ANALYTICAL

57. Wirefeeder The Portafeed VS 212 is a purpose built, portable, solid sate controlled voltage sensing wire feeder. Its rugged injection molded, fiberglass reinforced, flame retardant, polypropylene case represents the latest in high strength, super tough, light weight materials. A recessed control panel protects the controls which include a power switch, inch and purge switch, gun trigger hold and the digital display for monitoring wire speed, amps, volts, arc time and meter hold function. A lifting eye, gun holder, removable voltage sensing lead and recessed carrying handle are just some of the refined external features of the Portafeed® VS 212. Baren-Boym Company provided complete Mechanical Engineering and Industrial Design services Client - Thermal Dynamics Inc INDUSTRIAL

58. Welding Plasma Torch Baren-Boym Company designed numerous products for Thermadyne. This is one of the hand held plasma torches that combines ergonomic torch handle and exceptional functionality. With an innovative, easy-to-use torch trigger release, encapsulated protected torch head and precisely engineered grip, the 1Torch RPT torch is both easy and comfortable to use. Client - Thermal Dynamics Inc INDUSTRIAL

59. Fiber Distribution Terminals Baren-Boym Company designed and developed fiber optic hardware and equipment. Among them are Fiber Distribution Hubs, RC(TM) Terminals and RC Drops. Fiber Distribution Hubs are used to provide connections between fiber optic cables from the central officehub electronics locations and passive optical splitters in the outside plant (OSP) environment, all installed for underground applications. The RC Terminals are used to interface between distribution cables and drop cables required in aerial and underground applications. Client - Fons Inc INDUSTRIAL

60. System Monitor Baren-Boym Company provided complete Industrial Design and Mechanical Engineering for the hand held TV over IP Monitoring system. All components with complex surfaces were designed in SolidWorks using advanced techniques. INDUSTRIAL

61. Gas Leak Detector The new VS Series Leak Detectors from Varian, Inc. combine the simplicity of two-button operation with advanced system intelligence to give you easy access to powerful testing capability. Baren-Boym provided industrial design and mechanical engineering services for the housing design and packaging the internal components. Client - Varian Technology Inc INDUSTRIAL

62. Saw INDUSTRIAL

63. INDUSTRIAL Autoscanner Data acquisition system.The scanner is designed to collect the data from the car engine. Baren-Boym provided Industrial design and mechanical design of the plastic housing and other plastic components.

64. Electric Meter Baren-Boym Company provided industrail design and complete mechanical engineering services for the design of the electric meter. The housings have EMI/RFI shielding on the inside surface. INDUSTRIAL

65. Electric Heater Table top electric heater was designed and developed by Baren-Boym Company. We provided industrial design and complete mechanical engineering services including the thermal analysis for a complete system. INDUSTRIAL

66. ADSL Modem ADSL modem was designed by Baren-Boym Company. We provided industrial design services and mechanical engineering design of the housings including the pachaging of the internal components providing the final assembly to the client . INDUSTRIAL

67. Fire Alarm System Baren-Boym Company provided Industrial Design and Mechanical Engineering services for the fire alarm system including housing designs for the wall mounted system base and hand held controllers. INDUSTRIAL

68. Custom Rover Tuning Baren-Boym Company provided numerous designs in the field of custom car tuning and styling for the aftermarket companies. Current example shows the Range Rover styling. INDUSTRIAL

69. Tractor Restyling Baren-Boym Company was hired to do complete restyling of the tractor older model. We provided restyling of the tractor front end, including head optical components. INDUSTRIAL

70. Bus Concepts This example shows the line of conceptual designs generated by Baren-Boym Company for a transportation company. INDUSTRIAL

71. Steering Column Module Multifunctional Controller provides driver interface control. Levers are able to rotate in multiple planes. The design overcomes challenges in space limitation and safety regulations. INDUSTRIAL
