Deep Learning vs Multidimensional Classification in Human-Guided Text Mining

Deep Learning
2015/07/04
Marat Zhanikeev
maratishe@gmail.com
GI研＠天神イムズ
PDF: http://bit.do/150704
in Human-Guided
Text MiningvsMultidimensional Classification

.
Deep Learning vs MD Classifiers
• Deep Learning 08 10
◦ Feature-based: image → features → NN
◦ Raw/Pixels : image → raw pixels → NN
• Multi-Dimentional Classification 04 05
◦ assigning classes to items in multiple dimensions
• Human-Guided Text Mining 02
◦ Folksonomy + BigData
◦ learning from empty state with gradually diminishing human feedback
08 A.Nguyen+2 "Deep Neural Networks are Easily Fooled..." IEEE CVPR (2015)
10 G.Goos+2 "Neural Networks: Tricks of the Trade" Springer LNCS vol.7700, 2nd edition (2012)
04 X.Zhu+1 "Introduction to Semi-Supervised Learning" Morgan and Claypool Publishers (2009)
05 D.Koller+1 "Probabilistic Graphical Models: Principles and Techniques" MIT Press (2009)
02 myself+0 "Multidimensional Classification Automation with Human Interface based on Metromaps" 4th AAI (2015)
M.Zhanikeev -- maratishe@gmail.com -- Deep Learning vs Multidimensional Classification in Human-Guided Text Mining -- http://bit.do/150704 2/26
...
2/26

.
Deep Learning
...
3/26

.
Deep Learning (1) Feature-Based
• many feature extraction libraries, normally specific to environments/targets
• problem 1: wide range of errors, can be from 50% up to 96%
• problem 2: who decides on the features?
...
4/26

.
Deep Learning (2) Raw Pixels
• just feed the raw pixels to the Neural Network and let it sort it out for itself
...
5/26

.
Deep Learning (3) Google Faces
• a feature-based method, extremely specific, recently acquired by Google
...
6/26

.
Deep Learning (4) Google Cats
...
7/26

.
Deep Learning (5) Raw/Pixel Method
• a standard process for a pixel-based learning 12
• CSV files are traditional, one image becomes one line
0 1 1 … 0
1 …
0 …
… …
1 …
Handwriting
Black -n-white
Pixel map
Matrix in a CSV ﬁle
3
Deep
Learning
3
Training
Testing
12 "MNIST Dataset of Handwritten Digits" http://yann.lecun.com/exdb/mnist/ (2015)
...
8/26

.
Multi-Dimensional Classification
...
9/26

.
MDC : Binary Relevance (BR) Classes
• single dimension
• not practical today, when most things exists in multi-dimensional space 06
Training
Tuples
x1 x2 Y1 Y2 Y3
1 0.7 0.4 1 1 0
2 0.6 0.2 1 1 0
3 0.1 0.9 0 0 1
4 0.3 0.1 0 0 0
h1: X → Y1
h2: X → Y2
h3: X → Y3
06 J.Ortigosa-Hernandez+3 "A Semi-supervised Approach to Multi-dimensional Classification..." 6th TAMIDA (2010)
...
10/26

.
MDC : PairWise (PW) Sets
• define classes as pairs of base BR classes 06
• lower complexity, higher error rate
Training
Tuples
x1 x2 Y1 Y2 Y3
1 0.7 0.4 1 1 0
2 0.6 0.2 1 1 0
0.1 0.9 0 0 1
0.3 0.1 0 0 0
h1: X → Z1
h2: X → Z2
Z1 Z2
1 0
0 1
0 0
0 0
...
11/26

.
MDC : Label Combination (LC) Method
• a class for all combinations of base BR 06
• very high complexity, still high error rate
Training
Tuples
x1 x2 Y1 Y2 Y3
1 0.7 0.4 1 1 0
2 0.6 0.2 1 1 0
3 0.1 0.9 0 0 1
4 0.3 0.1 0 0 0
h: X → Z
Z
1
0
0
0
...
12/26

.
MDC : The CC Method
• CC: Classifier Chains method 07 -- literally, a chain of BR classes
• controlled complexity, much better error rate, but the main problem is which order?
Training
Tuples
x1 x2 Y1 Y2 Y3
1 0.7 0.4 1 1 0
2 0.6 0.2 1 1 0
3 0.1 0.9 0 0 1
4 0.3 0.1 0 0 0
h1: X → Y1
h2: Y1 → Y2
h3: Y2 → Y3
h2h1 h3
07 J.Read+3 "Classifier chains for multi-label classification" Machine Learning, Springer (2011)
...
13/26

.
The MetroMap Classifier (MMC)
...
14/26

.
The Metromap Concept
• like a map of a train network 01
• main advantage: e2e paths in (ontology) graphs
01 myself+0 "On Context Management Using Metro Maps" 7th SOCA (2014)
...
15/26

.
MMC : A Practical Setting
Human
judgment
Auto
judgement
Folksonomy
...
16/26

.
MMC : Processing Logic
• processing based on human-defined metromap, the function is similar to
chaining BR classes, but with higher performance
Metromap
Classiﬁer
Human
Check
Metromap
Fuzzy?
Cold?
Hot?
Robot (Automatic Classiﬁcation)
Bad
Input
No
Yes
No
No
...
17/26

.
MDC (MMC) vs DL(pixels)
...
18/26

.
DL : graphics vs Text
• graphics
◦ pixels are already numeric
◦ images can be resized to provide same-size input -- DL needs fixed-size input
• text requires complex processing
1. tokenize text (words)
2. frequency distribution -- variable size
3. sample distribution -- finally, the same/fixed size!
...
19/26

.
Experimental Setup (1) Humans
• 2 main cases: hot + cold = picked but not used, hot - cold = picked and used
(blackswans) 03
03 myself+0 "Black Swan Disaster Scenarios" IEICE PRMU研 (2014)
...
20/26

.
Experimental Setup (2) Process
• the text is not numeric by nature, has to be converted into sampled
frequency distribution
• calculations in R, used h2o package 11 for deep learning
0 1 1 … 0
1 …
0 …
… …
1 …
Text
Matrix in a CSV ﬁle
Deep
Learning
Tokenize
Frequency
Distribution
Sample
Bayes
Many
(Chains, Metromap , etc.)
Path 1
Path 2
11 "H2O: R Package for Learning Algorithms" http://cran.r-project.org/web/packages/h2o (2015)
...
21/26

.
Results (1) MMC vs BR
0 20 40 60 80 100 120
Time sequence
0
10
20
30
40
50
60
70
80
90
Goodcount
Dumb Classifier
Metromap Classifier
Hits on a timeline
title
0
10
20
30
40
50
60
70
80
Goodcount
title:keywords
0
10
20
30
40
50
60
70
80
90
Goodcount
title:keywords:abstract
0 20 40 60 80 100 120
Time sequence
0 20 40 60 80 100 120
Time sequence
02 myself+0 "Multidimensional Classification Automation with Human Interface based on Metromaps" 4th AAI (2015)
...
22/26

.
Results (2) DL Results
0 20 40 60 80 100
Time sequence
0
20
40
60
80
100
Deeplearninghits
Diagonal/humanDeep learning
keys(title)
rule(cold#yes hot#yes)
0 20 40 60 80 100
Time sequence
0
20
40
60
80
100
Deeplearninghits
keys(title:keywords:abstract)
0 20 40 60 80 100
Time sequence
0
20
40
60
80
100
Deeplearninghits
rule(cold#no hot#yes)
0 20 40 60 80 100
Time sequence
0
20
40
60
80
100
Deeplearninghits
• compared to x = y
case
• DL performs very
badly
• best performs
when abstract is
used, even then about
25% hits
• same performance for
hot + cold and hot
- cold cases
...
23/26

.
That’s all, thank you ...
...
24/26

.
MDC and Social Robotics Go Together
...
25/26

.
Social Robotics in Text Mining Context
Rebot
(careless)
Input
Human
Human
{structure}
(pinpoint)
Select
Browse
(or use otherwise)
Some
Knowledge
(folksonomies,
knowledge bases,
databases, indexes,
ontologies, etc.)
(metromaps )
...
26/26
