This flow chart outlines a basic calculator program that allows a user to choose between addition, subtraction, multiplication, or division and then performs the calculation on input values a and b before printing the result. The user can also choose to exit the program. The flow chart starts and stops the program, displays a menu, gets input for an operation and values, performs the selected calculation, and either prints the result or exits if the user chose to.

1. Flow Chart
Start
Stop
Menu
+: Addition
-: Subtraction
*: Multiplication
/: Division
E: Exit
Input Choice
If o/p=‘E’
Switch
(o/p)
C=a+b
Print Sum
C=a-b C=a*b C=a/b
Print Diff Print Multi Print Div
Input a,b
Yes
No
