Shoaib Raheman is a piping designer with over 3 years of experience in piping design and modeling using software like PDMS, Navisworks, and AutoCAD. He has worked on projects in industries like oil and gas, water services. Some key responsibilities include piping modeling, preparing piping drawings, isometrics, material take-off, clash detection, and incorporating client comments. He holds a Bachelor's degree in Mechanical Engineering and is proficient in English, Hindi, Urdu and Telugu.

1. SHOAIB RAHEMAN
Yermaras Camp. Raichur. KARNATAKA
. +91-8095100093; : shoaibraheman786@gmail.com
OBJECTIVE
Targeting the Top Domestic/ International Organizations, Intending to build a challenging position in
the field of PIPING DESIGN that provides opportunity to excel both professionally and personally. Proficient
with Navisworks,PDMS, MS Office. Ability to make Equipment drawing, Plot plans, Piping, Piping Isometrics,
Detailed Drawings, Piping Layouts, Pipe Supports, and well conversant of material standard specification
codes.
PROFESSIONAL EXPERIENCE:
Company : Fox Plant Engineering Solutions
Designation : Piping Designer.
Duration : Since September 2015 to till date
PROJECTS HANDELED:
GSRP Plant Global Modelling, Taiwan:
• PDMS Modeling of Compressor Area of Project.
• Routing of Lines as per P&ID in PDMS.
• Scheduling of Initial MTO, Isometrics, and GA drawings as per assigned Schedule.
• Checking of Isometrics as per the client approved checklist.
• Clash Checking Of Piping system with other facilities in Navisworks
• Extraction of ISO using PDMS
• Preparing final Bill of material for entire project.
• Preparation of Nozzle Orientation Drawings for Vertical columns.
• Preparation of Intial, Intermediate,Final Stage MTO.
QAN ALAM Development Project Surface Facilities.
• Modeling of Equipments as per Equipment vendor drawing by using PDMS.
• Modeling of Piping as per P&ID’s by using PDMS.
• Extraction of Piping GAD`s & Support GAD`S from PDMS.
• Extraction of Piping Isometrics using PDMS.
• Clash-Resolution with Inter-Departments
• Checking Of Isometrics as per P&ID.
• Generation of GAD from 3D Design.
• Involved In internal review and updating of comments.
• Scheduling of outputs as per client schedule and preparing weekly progress report..

2. • Updating Client Comments after Review
PEDC-III-Veolia Water Services Singapore
Responsibilities:
• Designing of Equipment as per the Vendor Data, Vendor Package Drawing & SKID drawings in PDMS .
• Preparation of Equipment Layout. Of Separator, Water Injection Module in PDMS..
• Preparation of Escape Route Layout and Access way Layout.
• Preparation of Nozzle Orientation Drawings for Vertical columns.
• Scheduling of Isometrics and GA drawings as per assigned Schedule.
• Checking of Equipment Layout as per the vendor Information Available.
• Checking Of Isometrics as per P&ID.
• Updating of Site Queries and Generation of As-Build Drawings.
SOFTWARE KNOWLEDGE:
• PDMS 12.0.SP6.25.
• PDMS 12.0.SP4.10
• AutoCAD 2012
• Microsoft Office (Excel, Word)
EDUCATIONAL PROFILE:
Examination
Discipline/Specializ
ation
Board/University
Year of
passing
%
S.S.L.C S.S.L.C
Karnataka Secondary Education
Examination Board.
(KSEEB)Bangalore.
2008 67.52%
DIPLOMA
MECHANICAL
ENGINEERING
Department of Technical
Education. (DTE) Bangalore.
2012
(5 & 6 aggrt)
65.97%
B.E
(BACHELOR OF ENGINEERING)
MECHANICAL
ENGINEERING
Visvesvaraya Technological
University. (VTU) Belgaum.
2015
(5 to 8 aggrt)
60.11%
PERSONAL PROFILE:
Date of Birth:1st
june 1992
Language Proficiency: English, Hindi, urdu & telugu
