More details on the form manager, and advanced techniques. It was delivered at dojo.connect on 2/10/2010. Blog post: http://lazutkin.com/blog/2010/feb/10/rad-crud/

1. RAD CRUD
Rapid development of form-based applications.
1

2. Where did we stop?
• This presentation follows “CRUD with
Dojo: the bread and butter of IT.”
• http://lazutkin.com/blog/2009/dec/2/crud-with-dojo/
• But for those who missed it, or wants to
refresh their memory, I offer a small recap.
2

3. A short narrative of…
• …the previous episode.
• CRUD is a big hit in IT.
• If only we had a way to improve good
things and reduce bad things…
• Profit!
• If only we knew how…
3

4. Suddenly!
• The sound of heavy breathing fills airwaves.
• Scared audience can hear how cold air
rushes through myriad of small tubes
almost drowning the rhythmic clicking and
clacking of multiple valves.
• The deep voice seemingly from the guts of
the eternal void itself says:
4

5. Come to the Client Side,
Luke!
5

6. Sorry.
• That was my bronchitis acting up.
• So, Luke, we looked at what’s available in
browsers:
• A sorry mess of form elements with
different get/set value API and events.
• Good thing we have Dojo and Dijit!
6

7. Dijit and DojoX
• Dijit and DojoX form widgets are good for
CRUD:
• Unified API to get/set values.
• Unified events.
• Better visual representations for certain
values, e.g., sliders and spinners.
• Support validation.
7

8. Forms
• dijit.form.Form
• Makes sure that all widgets are validated
before submitting a form.
• Gets/sets form widgets using a dictionary.
• More can be found in dojox.form.manager
8

9. dojox.form.manager
The way to manage your forms.
9

10. Simple data model
• The form manager is used to annotate
complex form using simple Dojo markup.
• It views all controlled elements as a name-
based dictionary of objects.
• It can control: form widgets, form elements
(DOM nodes), arbitrary DOM nodes.
10

11. Simple value model
• The form manager can get/set a value to
any controlled element using the same API.
• It can get/set a group of values at the same
time.
11

12. Simple event model
• The form manager can observe value
changes of any controlled element using the
same API.
• When value has changed an observer can
be called.
• An observer is a method, which is called
with 4 parameters: new value, element
name, element, and an event object.
12

13. Observer
• An element can have any number of
observers.
• An observer can be attached to any
number of elements.
• Observers are used to implement all value-
change-driven functionality.
13

14. Architecture I
• The form manager is a collection of mixins
located in dojox/form/manager/.
• _Mixin.js provides all basic plumbing and
can work with form widgets and simple
DOM nodes.
• _FormMixin.js implements functionality
similar to dijit.form.Form.
14

15. Architecture II
• _NodeMixin.js adds 1st-class support to
form elements (DOM nodes).
• _ValueMixin.js adds helpers to get/set
values.
• _ClassMixin.js adds addClass()/
removeClass() helpers.
15

16. Architecture III
• _EnableMixin.js adds helpers to enable/
disable form fields.
• _DisplayMixin.js adds helpers to show/hide
DOM nodes.
16

17. Architecture IV
• Manager.js is an example widget, which
includes all mixins and searches
descendants to find controlled elements.
• When we talk about “the form manager”
we usually mean a functionality provided by
_Mixin.js, rather than actual Manager.js.
17

18. Architecture V
• Instead of using Manager.js (or a subset of
it), you can create a normal widget derived
from proper mixins, and place all form
elements in a normal template.
• This is a great way to share the same
form in several places.
• Observers would be simple methods of
your widget.
18

19. Practical examples
Let’s rock and roll.
19

20. Registering elements I
<form action=”/doForm” id=”myForm”
dojoType=”dojox.form.Manager”>
<!-- form widgets are registered
automatically by _Mixin.js -->
<input type=”text” name=”name” value=””
dojoType=”dijit.form.TextBox”><br>
<!-- form nodes are registered
automatically by _NodeMixin.js -->
<input type=”text” name=”email” value=””><br>
<!-- more to follow -->
</form>
20

21. Registering elements II
<form action=”/doForm” id=”myForm”
dojoType=”dojox.form.Manager”>
<!-- more follows -->
<!-- attach points are registered
automatically by _Mixin.js -->
<div dojoAttachPoint=”more”>
<span dojoAttachPoint=”notes”
class=”dojoFormValue”></span>
</div>
</form>
21

22. Registering elements III
• Explanations:
• All 3 types of controlled elements are
registered:
• “name” – a form widget.
• “email” – a form node (_NodeMixin.js
is needed).
• “more” and “notes” – DOM nodes.
22

23. Registering elements IV
• More on DOM nodes:
• By default DOM nodes cannot have
values, but we can:
• Show/hide them.
• Add/remove CSS classes.
• To indicate that a DOM node can have
value we use “dojoFormValue” class.
23

24. Registering elements V
• “more” is a <div> node.
• It will be used to show/hide its content.
• Its value is unchanged and unused.
• “notes” is a <span> node.
• It can have a value (“dojoFormValue”).
• It is inside of “more”.
24

25. Registering elements VI
• We can register/unregister elements
dynamically.
• _Mixin.js: (un)registerWidget(),
(un)registerWidgetDescendants().
• _NodeMixin.js: (un)registerNode(),
(un)registerNodeDescendants().
• (Un)registering attach points is trivial.
25

26. Populating values I
• Logically the form manager represent its
form as a dictionary:
var form = {
name: ...,
email: ...,
notes: ...
};
// our form has 3 value fields
26

27. Populating values II
• _ValueMixin.js provides all value helpers.
• setFormValues(dict) sets values:
var fm = dijit.byId(“myForm”);
// set just one value:
fm.setFormValues({name: “Bob”});
// set other values overriding “name”
fm.setFormValues({name: “Mike”, email: “mike@i.am”,
debug: “clearly fake email!”});
27

28. Populating values III
• gatherFormValues(names) gets values:
• A dictionary is returned as the result.
• If “names” is omitted, all values are read.
• If “names” is an array, only names from
the array are read.
• If “names” is a dictionary, its keys are
read, and values are ignored.
28

29. Populating values IV
• The last form of gatherFormValues()
compliments setFormValues():
// create our dictionary with a subset of values
var dict = {name: “Bob”};
// set values (actually just one name)
fm.setFormValues(dict);
…
// update values (the same subset)
dict = fm.gatherFormValues(dict);
29

30. Populating values V
• If you want to read/write just one value use
elementValue():
// set value
fm.elementValue(“name”, “Bob”);
…
// get value
var name = fm.elementValue(“name”);
30

31. Observing elements I
<form action=”/doForm” id=”myForm”
dojoType=”dojox.form.Manager”>
<input type=”text” name=”name” value=””
dojoType=”dijit.form.TextBox”
observer=”obReady”><br>
<input type=”text” name=”email” value=””
observer=”obReady”><br>
<input type=”submit” name=”submit”
disabled=”disabled”>
<!-- more to follow -->
</form>
31

32. Observing elements II
• Explanations:
• It is a slightly modified version of the
registration example.
• It has two fields and one disabled button.
• Both fields are observed by the same
observer “obReady”.
32

33. Observing elements III
• We can attach our observer declaratively
as a regular method:
<script type=”dojo/method” event=”obReady”
args=”value,name”>
// our observer is stupid:
// it enables the button, when value is not empty
this.enable({submit: value != “”});
// we will go over enable() later
</script>
33

34. Observing elements IV
• Slightly smarter observer:
<script type=”dojo/method” event=”obReady”
args=”value,name”>
// enable the button, when at least
// one value is not empty
var dict = this.gatherFormValues([“name”, “email”]);
this.enable({submit: dict.name || dict.email});
</script>
34

35. Observing elements V
• Notes:
• Observer is invoked when a value has
changed.
• Some text-based widgets do not fire
events on every key press. Force them:
intermediateChanges=”true”
35

36. Observing elements VI
• Notes:
• Attached DOM nodes cannot have
“change” events. And they cannot have
observers.
• Elements can have several observers
listed separated by comma.
36

37. _EnableMixin.js I
• This mixin is responsible for enabling/
disabling form elements.
• gatherEnableState() is modeled after
gatherFormValues() – the same
interpolation of input values are performed.
37

38. _EnableMixin.js II
• Three ways to collect the enabled status:
// read states of all elements as true/false values
en = fm.gatherEnableState();
// read states of two elements
en = fm.gatherEnableState([“name”, “email”]);
// read states of two elements
en = fm.gatherEnableState({“name”: 1, “email”: 0});
// only keys are processed, all values are ignored
38

39. _EnableMixin.js III
• Enable/disable unconditionally:
fm.enable(); // enable all
fm.enable(true); // the same as above
fm.enable(false); // disable all
var a = [“name”, “email”];
fm.enable(a); // enable two elements
fm.enable(a, true); // the same as above
fm.enable(a, false); // disable two elements
39

40. _EnableMixin.js IV
• Enable/disable using a dictionary:
var en = fm.gatherEnableState(); // get all states
…
// enable “name”, disable “email”
fm.enable({name: true, email: false});
…
fm.enable(en); // revert to old state
40

41. _EnableMixin.js V
• disable() compliments enable() and returns
the previous state:
var en = fm.disable(); // disable all
…
fm.disable([“name”, “email”]); // disable two elements
…
// now let’s revert to the old state
fm.enable(en); // == fm.disable(en)
41

42. _DisplayMixin.js
• This mixin is responsible for showing/hiding
controlled DOM nodes. It has the same
semantics as _EnableMixin.js:
• gatherDisplayState() behaves exactly like
gatherEnableState().
• show() is like enable().
• hide is like disable().
42

43. _ClassMixin.js I
• This mixin is responsible for adding/
removing CSS classes.
• Unlike other mixins, _ClassMixin.js is not
wired for reversing states.
• While it is possible to check for presence
of a CSS class, there is no helpers to use it.
It can be added in the future.
43

44. _ClassMixin.js II
• Three ways to collect the class status:
// read presence of a CSS class from all
cs = fm.gatherClassState(cls);
// read states of two elements
cs = fm.gatherClassState(cls, [“name”, “email”]);
// read states of two elements
cs = fm.gatherClassState(cls, {“name”: 1, “email”: 0});
// only keys are processed, all values are ignored
44

45. _ClassMixin.js III
• Three ways to add class:
// add a CSS class to all elements
fm.addClass(cls);
// add a class to two elements
fm.addClass(cls, [“name”, “email”]);
// add a class to two elements
fm.addClass(cls, {“name”: 1, “email”: 0});
// only keys are processed, all values are ignored
45

46. _ClassMixin.js IV
• Three ways to remove class:
// remove a CSS class from all elements
fm.removeClass(cls);
// remove a class from two elements
fm.removeClass(cls, [“name”, “email”]);
// remove a class from two elements
fm.removeClass(cls, {“name”: 1, “email”: 0});
// only keys are processed, all values are ignored
46

47. Hints and tips
And advanced techniques.
47

48. Do you need it? I
• You have a multipart complex form.
• It is unwise to show a huge form to end
users. It is better to structure it so only a
part is shown at any given time.
• A part should have well defined logically
entry and exit points with an
intermediate validation.
48

49. Do you need it? II
• A possible way to structure a form (the
shopping basket style):
• Split in logically independent blocks.
• Organize blocks as a chain of screens
validating each screen independently.
• At the end of a chain – a summary
screen, which allows to re-start edits.
49

50. Do you need it? III
• Field values interact with each other.
• You have complex validation rules
involving several form fields.
• Variant: you can auto-suggest a value of
one field using values of other fields.
• Variant: a value of one field restrict
possible values of other fields.
50

51. Do you need it? IV
• Working with form involves I/O, which
depends on already entered values.
• When chaining screens, screen
boundaries can be used to do an
intermediate I/O.
• Variant: asynchronous server-side
validation.
51

52. Do you need it? V
• Working with form involves I/O, which
depends on already entered values.
• When chaining screens, screen
boundaries can be used to do an
intermediate I/O.
• Variant: asynchronous server-side
validation.
52

53. Do you need it? VI
• Try to simplify as much as possible:
• Use validating widgets whenever possible.
• Carefully weigh in if you need to use
_DisplayMixin.js or just proper layout
widgets.
53

54. Resetting values I
• Frequently end user realizes that the
changes were not good and want go back.
• Simple and well-known technique is to
“reset a form” reverting to previous values.
• Use gatherFormValues() to make a
snapshot before editing.
54

55. Resetting values II
• Restore the snapshot with setFormValues()
when user wants to “reset”.
• This technique works well for a part of
form – just use a proper subset when
taking a snapshot.
55

56. Suspending a form I
• Typical way to submit a form is:
• Collect all necessary data fields.
• In some cases you pre-process them.
• In some cases you produce new
synthetic fields.
• Submit it using XHR to a server.
56

57. Suspending a form II
• Analyze a return value from the server.
• If errors were encountered:
• Notify user about them.
• Allow to re-edit a form so it can be
resubmitted again.
• Redirect, or reset, if success.
57

58. Suspending a form III
• While you are busy doing I/O and waiting
for a server, it makes sense to “suspend a
form”, so no editing can be done.
• Use disable() to disable all visible fields
while waiting.
• Save a snapshot returned by disabled() –
it can be used later to recreate the
previous state.
58

59. Suspending a form IV
• Obviously it helps that you inform an end
user what is going on using a proper
message.
• Less elegant way to do the same is to use a
modal message visible until you get results
from a server.
59

60. Suspending a form V
• Soft version of “suspending a form”
happens when you want to update some
elements dynamically by loading values
from a server.
• In this case you should disable only affected
elements, show a proper message next to
them while waiting.
• After the update was done, enable them.
60

61. Suspending a form VI
• In the same category of “soft suspension” is
a server-side validation.
• Disable involved fields.
• Tell user what is going on.
• Wait for a response.
• Update messages and enable fields back.
61

62. Field interactions I
• First you need to define what is an ultimate
result of validation looks like.
• Example: city, state, and zip should match,
otherwise we cannot advance to the next
screen.
• In this example we have 3 input fields and
one output: enabled/disabled “Next”
button.
62

63. Field interactions II
• The example can be solved by one
observer attached to all three fields.
• Every time it is called, it reads 3 values,
does its magic, sets a proper enabled/
disabled flag on the button, and updates
error messages.
• The same way we can solve most validation
problems.
63

64. Field interactions III
• One form of field interaction is to show
unobtrusive error/warning messages
depending on input values.
• Usually such messages go to DOM nodes,
and effectively are pseudo-fields.
64

65. Pseudo-fields
• Pseudo-fields:
• They are not originated in a database.
• Frequently they are not transmitted at all.
• They are purely for UI convenience.
• Pseudo-fields are a powerful tool, but
cannot be generalized.
65

66. That’s all folks!
Questions? Suggestions?
66

67. About me
• I am an independent software developer.
• My web site:
• http://lazutkin.com
• Follow me on Tweeter:
• http://twitter.com/uhop
67
