Privileged Access Management (PAM)
- 1. Harnessing Privileged Access Management (PAM) to Defend Core Digital Assets Against a Breach By Dan Blum, Doug Moench and Doug Simmons October 16, 2015 1Copyright (c) 2015 Security Architects, LLC
- 2. Today’s Speakers Copyright (c) 2015 Security Architects, LLC 2 Expert in security, privacy, cloud computing and identity management Ex-Gartner Golden Quill award-winning VP and Distinguished Analyst Founding partner of Burton Group CISSP specializing in Security and Risk Management strategies and architectures, identity management solutions, and federation technologies. Over 30 years experience documenting current state environments and developing recommendations for improving infrastructure. Dan Blum Principal Consultant Doug Moench Senior IAM and Security Consultant Doug Simmons Principal Consultant Focuses on IT security, risk management and IAM. Has performed hundreds of engagements for large enterprise clients in multiple vertical industries including financial services, health care, higher education, federal and state government, manufacturing, aerospace, energy, utilities and critical infrastructure.
- 3. Why PAM? Copyright (c) 2015 Security Architects, LLC 3 Source: Information is Beautiful (Breach visualizations) Many of these could have been prevented or delayed
- 4. A Clear and Present Danger… Copyright (c) 2015 Security Architects, LLC 4 Common attack paths At least make the attackers work for it! Are too bloody easy
- 5. About Us • We are a consulting firm dedicated to helping organizations plan, specify and develop security programs, policies and technology solutions. Copyright (c) 2015 Security Architects, LLC 5 About Us Clients Enterprise Security Teams Cloud service providers (CSPs) Other Audiences Areas of Expertise Cloud Security Identity and Privacy Endpoint Security Cyber Security
- 6. Our Services Security Assessments Security Architectures Custom Consulting Security Workshops Consulting Services 6Copyright (c) 2015 Security Architects, LLC
- 7. What is PAM? • Privileged Account Management (PAM) Copyright (c) 2015 Security Architects, LLC 7 A set of technologies that allow organizations to identify, secure, and monitor accounts that have elevated privileges in order to minimize risks and ensure compliance. PAM is also sometimes referred to as: Privileged User Management Privileged Identity Management Privileged Access Management
- 8. Privileged Accounts are the Oil that Lubricates IT Copyright (c) 2015 Security Architects, LLC 8 Root and admin Network admin Domain admin DBA Other “superusers” Shared accounts Service accounts* What they’re for NOS devices DNS/DHCP servers Firewalls Routers, and switches Domain controllers Virtual machine admin IaaS Databases, applications What they do Love them or hate them you can’t run IT without them Operations: start/stop services, run jobs, or generate reports Configuration, updates, maintenance, patches, tuning, troubleshooting Develop applications, administer applications connect applications * For apps!
- 9. PAM Business Drivers • Reduce risk of breaches: • Compliance drivers – Maintain internal control • PAM specifically mentioned in PCI DSS, SOX, NERC/CIP, and some local/regional regulations – Simplify auditing and reporting – Detect/prevent Separation-Of-Duties (SOD) violations Copyright (c) 2015 Security Architects, LLC 9
- 10. Core Features Password vault Fine-grain privilege control Session manager Application credential management Copyright (c) 2015 Security Architects, LLC 10 Ancillary Services Discovery Services Role Management Policy Engine Logging and Auditing Platform flexibility Physical and virtual platforms Local or cloud-based Remote session protocols Holds PAM accounts, managed credentials, policies, logs Other considerations Availability and performance
- 11. PAM Architecture Pattern 11 Copyright (c) 2015 Security Architects, LLC
- 12. Password Vault • Contains accounts for privileged users • Contains policies for managed resources • Encrypts and stores passwords, SSH keys, policies and logs • Allows users to check-out/reserve a credential • Changes credentials on managed resources after use • Provides management console for centralized policy administration • Deployed as software on a physical server, virtual machine, or appliance Copyright (c) 2015 Security Architects, LLC 12 Privileged User and Admin Credentials Vault Admins Passwords/SSH Keys Must be hardened! Must maintain high availability!
- 13. Session Manager • Session management mechanisms to control access to resources • Enables monitoring, logging, and recording of administrative activities • Role management and policy enforcement capabilities, SOD rules • Generate alerts for policy exceptions • Emergency access mechanisms to bypass normal operations when needed. Copyright (c) 2015 Security Architects, LLC 13 • Roles • Policies • SOD Rules • Filters • ACLs Logging and Recording Roles Policies SOD Rules Filters ACLs SOC Monitoring Session Management RDP, SSH, VNC, PCoIP, NX Privileged Users Admins Target Resources (Network, Systems)
- 14. Fined-Grained Privilege Control • Establish more granular filters to limit administrative activities. • Often includes agents installed within clients or target servers (similar to desktop management or AD Bridge tools). Copyright (c) 2015 Security Architects, LLC 14 Target Infrastructure Resources (Network, Systems) Server agent to enforce Fine-grained privileges Privileged Users Admins Client agent for some apps (i.e. Active Directory)
- 15. Application Credential Manager • Identify, store, and rotate application credentials and SSH keys in the password vault • Eliminate the need to hard-code authentication information – Use a simple API call instead • May support caching to minimize performance impacts • Commonly supported interfaces and protocols include: – HTTP and HTTPS – SOAP/XML – Java – VBScript – C/C++ – PowerShell Copyright (c) 2015 Security Architects, LLC 15 Applications UserID/ Password SSH Keys Other credential Target Resources (Network, Systems) API Password Vault Local Cache Local Cache Local Cache Secure Key Exchange PW/Key Rotation API Call
- 16. PAM Market Landscape • Relatively small niche, but growing rapidly ~$500 million annually, 32% rate • Market leaders (in share + core features) • More market players around the world • Differentiators High availability, platform + multi-tenancy support, workflow integration and SoD features, credential management, SIEM integration, session recording features Copyright (c) 2015 Security Architects, LLC 16 Beyond Trust CA CyberArk Dell Lieberman Software Exceedium
- 17. The PAM Map Copyright (c) 2015 Security Architects, LLC 17 Hitachi ID Systems BeyondTrust CA, Centrify Dell, Enforcize, IBM, Lieberman, ManageEngine, Micro Focus, Observe IT, Oracle, SecureLink, Thypotics, Xceedium CyberArk Raz-Lee Security Pitbull Software Wallix Osirium Balait MasterSAM Applecross SSH Communications Security NRI Secure * Some names shortened, or omitted for space * Source: Gartner list of 2015 PAM vendors Arcon
- 18. Deploying PAM: Key Issues • Getting and keeping stakeholder buy-in • Creating high availability, disaster recovery and “break glass” procedures that work • Integrating with identity, workflow and monitoring infrastructures • Phasing in functionality on your schedule rather than the vendors • Locking in favorable professional services and product support Copyright (c) 2015 Security Architects, LLC 18
- 19. Getting and Keeping Stakeholder Buy-in “Nobody implements our product because they want to. They do it because someone is telling them they have to.” – Philip Lieberman, in an informal conversation with us, about 4 years ago Recommendations – Follow ALL recommendations in coming slides to make PAM as transparent as possible for IT and the business – Involve IT and business stakeholders and representatives from all affected teams in project phasing and process development – Develop a communications and support package for all privileged users and administrators that will be affected Copyright (c) 2015 Security Architects, LLC 19
- 20. Maintain High Availability • Eliminate single points of failure • Deploy high-availability password vault – Active-active or active-passive failover, stretch cluster or PAM- replication across sites – Create and test DR plans • Estimate and measure usage, size appropriately, utilize with load balancers for all PAM components • Have “break glass” processes to keep IT running in the event any part of PAM fails • Prevent or detect any abuse of “back doors” Copyright (c) 2015 Security Architects, LLC 20
- 21. Other Critical Recommendations • Thoroughly plan and design integration with identity, workflow and monitoring infrastructures • Phase in functionality on your schedule, not the vendor’s sales quotas – Calibrate phasing to your infrastructure maturity level • Lock in favorable professional services and product support terms Copyright (c) 2015 Security Architects, LLC 21
- 22. Conclusion • PAM deployments can range from basic password vaults to advanced application hardening, session monitoring and analytics • Although the market is relatively mature, few enterprises have deployed the technology outside niches to their full IT environment • Don’t over-reach or you’ll get thrown on the defensive with internal constituencies • The good news: An effective PAM deployment is likely to resolve some of your audit and compliance issues – as well as prevent many breach scenarios Copyright (c) 2015 Security Architects, LLC 22
- 23. Open Q&A Security Architects, LLC http://security-architects.com info@security-architects.com +1 (301) 585-4717 Copyright (c) 2015 Security Architects, LLC 23
