Printers
Dr. Kinjal Patel
Assistant Professor,
Department of Physics,
UTU, Bardoli
Classification of Printers
Printers used in computers are classified in the following three broad categories.
 1. Impact and Non-impact Printers
Impact printers form characters on a paper by striking the paper with a print
head and squeezing an inked ribbon between the print head and the paper.
Non-impact printers form characters without engaging the print mechanism
with the print surface, e.g. by heating sensitised paper or by spraying ink
from a jet.
 2. Fully Formed Character and Dot Matrix Printer
Fully formed characters are like those made by a standard typewriter—all
parts of characters are embossed in the reverse on the type bars of the
typewriter. When printed, all type elements appear connected or fully
formed. Dot matrix characters are shaped by combinations of dots that form
a group representing a letter or number when viewed together.
 3. Character at a Time and Line at a Time Printer
Character at a time printers (character printers or serial printers), print
each character serially, and virtually instantaneously
Ref. Electronic Instrumentation by H S Kalsi
Printer Character Set
 Most printers used with mini or micro computers use ASCII codes. Printers
are specified as using the 48 character set, the 64 character set, the 96
character set or the 128 character set.
 The 48 and 64 character sets include commonly used special symbols,
numbers, a space, and upper case (capital) English alphabets.
 The 96 ASCII character set includes the lower case English alphabet and
several additional special symbols. Of the 96 characters, ‘space’ and
‘delete’ do not print, leaving only 94 printable characters.
 The entire 128 character ASCII set contains 32 characters normally used
for communication and control. These characters usually do not print, but
correspond to expandable functions, such as communication and control.
Ref. Electronic Instrumentation by H S Kalsi
Drum Wheel
Ref. Electronic Instrumentation by H S Kalsi
Ref. Electronic Instrumentation by H S Kalsi
Drum Wheel
 The typewriter is the classic example of this printer, with
characters fully formed-because they are embossed on each type
bar.
 The print mechanism is a vertical cylinder. Characters are
embossed in several rows and columns around the cylinder, as
shown in Fig.
 The ASCII character code sent to the printer, is translated into
motion that rotates the cylinder, so that the column containing
the desired character faces the paper. The cylinder is then raised
or lowered (depending on the ASCII code) to present the column
containing the desired character to be printed directly to the
paper. A hanuner mechanism propels (hits) the cylinder towards
the paper, Where only the positioned character strikes the ribbon,
creating the printed impression of the character on the paper.
Ref. Electronic Instrumentation by H S Kalsi
Daisy Wheel
 It has characters mounted on the periphery of a spinning print
head, known as a daisy wheel printer. and is shown in Fig.
 A daisy wheel print head is mounted on a rotating disk with
flexible flower like petals similar to a daisy flower. Each
petal contains the embossed character in reverse. As the
daisy wheel spins, a hammer strikes the desired flexible petal
containing the character, in turn impacting the paper with the
embossed character through an inked ribbon.
 To print a letter, the wheel is rotated until the desired letter is
in position over the paper. A solenoid driven hammer then
hits the petal against the ribbon to print the letter.
Ref. Electronic Instrumentation by H S Kalsi
Daisy Wheel
Line Printers
 In line printers, characters or spaces constituting printable
lines are printed simultaneously across the entire line. Paper is
spaced up and the next line is printed.
 An embossed type font is positioned across a line for‘printing
by using embossed type, either on a carrier consisting of a
chain, train or band moving horizontally across the paper and
print line, or a drum rotating in front of the paper with
characters embossed. Typically, there are 132 columns on the
drum.
 As the drum rotates, the column of characters pan vertically
across the paper and the print line as shown in figure. In both
methods, hammers (one for each. Of 132 print positions)
strikes when the correct character is positioned, imprinting the
character on the paper with an inked ribbon.
Ref. Electronic Instrumentation by H S Kalsi
Ref. Electronic Instrumentation by H S Kalsi
Line Printers
 Print characters are embossed on the band. The band revolves
between two capstans, passing in front of the paper. An inked
ribbon is positioned between the moving band and the paper. As
the print characters on the band move by 132 horizontal print
positions, the 132 corresponding print hammers behind the paper
strike the band at the appropriate time, causing the line of
characters to print each desired character in I32 print positions.
 In band printers, a metallic or plastic band has a fully formed
etched character on it. The band rotates at high speed. There is
one hammer for one print position, because several hammers can
strike simultaneously for many print positions. These printers
are faster than dot matrix printers.
Ref. Electronic Instrumentation by H S Kalsi
Line Printers
Ref. Electronic Instrumentation by H S Kalsi
Drum Printer
Drum Printer
 Figure illustrates a drum printer. Each of the 64 or 96 characters
used is embossed in 132 columns around the drum, corresponding to
the print poslttons. The drum rotates in front of the paper and
ribbon. Print. hammers strike the paper, imprinting characters from
the drum through the ribbon and formmg an impression on the
paper.
 The drum printer uses a cylindrical drum which contains characters
embossed around it. There is one complete character set for each
print position. To print characters, magnetically driven hammers in
each character position strike the paper and ribbon against the
spinning drum. An entire line of characters can be printed during
each rotation of the drum. The drawbacks of drum printers are that
the fonts are not easily changeable, and the print lines may be
wavy.
Ref. Electronic Instrumentation by H S Kalsi
Ref. Electronic Instrumentation by H S Kalsi
Dot-Matrix Printers
Dot-Matrix Printers
 Dot matrix characters are formed by printing a group of dots to form
a letter, number or other symbol. This method is widely used with
mini and micro computers.
 Dots are formed both by impact and non impact print methods and
are both character at a time and line at a time printers.
 Figure shows the letter ‘A’ formed by a dot-matrix, five dots wide
and seven dots. high (5 X 7) and in a 9 x 7 matrix. A 5 x 7 dot-
matrix is frequently used when all letters are acceptable, in upper
case.
 Dot-matrix printers can print any combination of dots with all
available print positions in the matrix. The character is printed
when one of 128 ASCII codes is signalled and controlled by the
ROM (read only memory) chip, which in turn controls the patterns
of the dots. By changing the ROM chip a character set for any
language or graphic character set can be used by the printer.
Ref. Electronic Instrumentation by H S Kalsi
Non Impact Dot-Matrix Printers
 Non-impact dot-matrix printers cause a mark without directly
touching the paper. They are therefore quiet compared to
impact printers.
 They cannot make carbon copies, however, as there is no force
to impress the character through multiple carbon copies.
NIDM printers are useful for printing single copies of
computer output, for recording the output of printing
calculators and video displays, and for logging industrial data.
 There are four types of NIDM printers thermal,
electrosensitive, electrostatic, and ink jet.
Ref. Electronic Instrumentation by H S Kalsi
