Power Flow Solution

•Download as PPT, PDF•

0 likes•33 views

Power systems engineers must ensure that electricity is delivered reliably and efficiently from generators to consumers. To do so, they use power flow analysis to model how power will flow through transmission lines, transformers, and other equipment under different conditions. This allows identification of potential overloads or violations of system security before they occur.

Power System is an integrated network that interconnects the installations for generation, transmission and distribution of electricity. In Bangladesh electricity is generated at 50 Hertz frequency and at a nominal voltage of 11 KV (Kilo Volts) or 15 KV to be stepped up through transformers to 132 kV or 230 kV for feeding to the grid i.e. a high voltage transmission network that transmits the power to grid substation transformers to be stepped down at 33 kV. 11 kV and 0.4 kV for delivery to the consumers of various categories.
