1. <?PHP Performance ?>
w/APC + Memcached
for Windows
@FordAntiTrust
thaicyberpoint.com
thaithinkpad.com
thaihi5.com

2. Cache Theory ?

3. Cache Theory ?
Req
1 Check
2 Miss
Compute
Store 3 Cache
4 Hit
Output
Miss - [Store] - Hit

4. Type ?
Fast Slow
http://ralphlosey.files.wordpress.com/2007/06/ram.jpg
http://www.pctechguide.com/images/31HardDrive.jpg

5. APC ?
Alternative PHP Cache

6. Opcode Cache and Variables Cache
Automatic update w/code changes
Code not changes request and Simply Installation

7. Free & Open Source

8. PHP Flow
Req
• Scanning and Lexing
(Plain Text to Tokens)
• Parsing • Scanning
• Lexing
(Tokens to Expressions) • Parsing
• Compilation
• Compilation
(Translated Expressions to Opcode)
• Execution Execution
(Opcode stacks are processed)
Output

9. Normal PHP vs APC

10. Normal PHP vs APC
Req
• Scanning
• Lexing
• Parsing
• Compilation
Execution
Output

11. Normal PHP vs APC
Req
APC hook
• Scanning
• Lexing
• Parsing Miss
• Compilation
APC hook Store Opcode
cache
Execution
Hit
Output

12. Why ?

13. Why ?
http://ralphschindler.com/

14. Why ?
http://ralphschindler.com/

15. Installation
• Windows (http://downloads.php.net/pierre/)
– extension=php_apc.dll

16. Installation
• Windows (http://downloads.php.net/pierre/)
– extension=php_apc.dll
• Basic PECL
(http://pecl.php.net)
– pecl install apc

17. Installation
• Windows (http://downloads.php.net/pierre/)
– extension=php_apc.dll
Conf
• Basic PECL
(http://pecl.php.net)
– pecl install apc

19. Benchmark
PHP Native PHP w/APC
Concurrency Level 10
Time taken for tests 60 seconds
Complete requests 298 914
Total transferred 643,149 bytes 1,962,675 bytes
HTML transferred 516,971 bytes 1,582,035 bytes
Requests per second 4.91 [#/sec] (mean) 15.21 [#/sec] (mean)
Time per request 2035.405 [ms] (mean) 657.623 [ms] (mean)
Time per request 203.541 [ms] 65.762 [ms]
(mean, across all concurrent requests)
Transfer rate 10.35 [KB/s] received 31.88 [KB/s] received

20. Memcached

21. History
“Developed by Danga Interactive for
LiveJournal.com”

22. Memcached ?
• a distributed memory object caching system
with hash table

23. Memcached ?
• a distributed memory object caching system
with hash table

24. Memcached ?
• a distributed memory object caching system
with hash table
• a generic two stage hashing system (clients
and servers). Clients are written for specific
application languages. Server is written in C

25. Memcached ?
• a distributed memory object caching system
with hash table
• a generic two stage hashing system (clients
and servers). Clients are written for specific
application languages. Server is written in C

26. Memcached ?
• a distributed memory object caching system
with hash table
• a generic two stage hashing system (clients
and servers). Clients are written for specific
application languages. Server is written in C
• 85% of top 20 sites use memcached; 50%+ of
top 5k sites uses Memcached

27. Memcached ?
• a distributed memory object caching system
with hash table
• a generic two stage hashing system (clients
and servers). Clients are written for specific
application languages. Server is written in C
• 85% of top 20 sites use memcached; 50%+ of
top 5k sites uses Memcached

28. Limits (c/Hash Table)
• Key : max 250 chars.
• Values: max 1MB

29. Why Memcached ?
• Scale-out
– Machine
– Process (Use different ports)
• Memory faster than Disk
• Allows for efficient use of your database
• Can utilize existing network
– Uses non-blocking network I/O (TCP/IP)
• Very flexible
• Client libraries in all major languages

31. “We use more than 800 servers supplying over
28 terabytes of memory to our users.”
“total throughput achieved is 300,000 UDP req/s”
by Paul Saab Saturday, December 13, 2008 at 2:43am
• 8-core machines
• 20-30% CPU usage.
• scale memcached to 8 threads on an 8-core system
• moved to UDP for get operations to reduce network traffic
http://www.facebook.com/note.php?note_id=39391378919

32. Architecture practical ?
http://barry.files.wordpress.com/2007/04/new-servers-back-04-2007.jpg

33. Cache
Memcached
APC Memcached
Instance Reverse
Memcached
Instance
Memcached
Instance Proxy
Instance
I
n
t
e
PHP Web App
Web Server r
n
e
Session Files
t
Memcached Memcached
Memcached
Instance Memcached
Instance
Master Slave Memcached
Instance Memcached
Instance
Memcached
Instance Instance
CDN/DFS
Instance
DB

34. Installation & Used
memcached binary packages
• http://labs.northscale.com/memcached-packages/
1. Unzip into a directory of choice
2. Open the shell of your choice (i.e. cmd.exe); cd into the directory
3. Run memcached.exe passing standard arguments.
Sample
C:memcachedmemcached.exe -m 128 -p 11211 -l 127.0.0.1 -d

35. PHP Session w/Memcached
session.save_handler = files
session.save_path = “C:/Windows/temp”
TO
session.save_handler = memcache
session.save_path = “tcp://server:port “
OR
ini_set('session.save_handler', 'memcache');
ini_set('session.save_path', 'tcp://server:port,tcp://server:port');

36. Coding ? (in PHP)
/* OO API */
$memcacheObj = new Memcache;
$memcacheObj->connect('memcache_host', 11211);
/* set */
$memcacheObj->set('key', 'data', MEMCACHE_COMPRESSED, 50);
/ * get w/single key */
$var = $memcacheObj->get('key');
/ * get w/multiple key */
$var = $memcacheObj->get(array('key1', 'key2'));
$memcacheObj->close();

37. CMS ?
• Drupal has Memcache API and Integration
http://drupal.org/project/memcache
• Wordpress has object cache
http://mohanjith.net/blog/2008/10/using-memcached-with-
wordpress-object-cache.html

38. Tips

39. Two Level Caching with Zend_Cache
• Tagging System in Files Cache
• Memcached Key used Tagging System

40. Two Level Caching - Workflow
Req
Compute Files Cache
Memcached
Output
1. Check 3. Store
2. Miss 4. Hit

41. Implement with Zend_Cache

42. Used Two Level with Zend_Cache

43. Ref.
• Improving PHP Application Performance with APC
http://www.slideshare.net/vortexau/improving-php-application-
performance-with-apc-presentation
• PHP Accelerators : APC vs Zend vs XCache with Zend
Framework
http://blog.digitalstruct.com/2007/12/23/php-accelerators-apc-vs-zend-vs-
xcache-with-zend-framework/
• Scaling with memcached
http://www.slideshare.net/acme/scaling-with-memcached
• Gear6 and Scaling Website Performance: Caching Session and
Profile Data with Memcached
http://www.slideshare.net/gear6memcached/gear6-and-scaling-website-
performance-caching-session-and-profile-data-with-memcached

44. Ref. (2)
• PHP: Memcache - Manual
http://th.php.net/manual/en/book.memcache.php
• http://danga.com/memcached/
• http://pecl.php.net/package/memcache
• http://www.socialtext.net/memcached/

45. Discussion
Q&A
